Kinhank SUPER CONSOLE CUBE X3 User Manual
  1. Manuals
  2. Brands
  3. Kinhank Manuals
  4. Game Console
  5. SUPER CONSOLE CUBE X3
  6. User manual

Kinhank SUPER CONSOLE CUBE X3 User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
SUPER CONSOLE CUBE X3
User Manual
Model:
Super Console Cube X3
Dual System: Game & TV
CPU:Amlogic S905X3
RAM:4GB DDR3
GPU:Mail-G31 MP2
ROM:32GB eMMC
DC Power:5V/3A
Bluetooth: BT4.0
WiFi:2.4G/5G
Language:Multi-languages
1. Product Information
Product size: 12.5cm*10.7cm*4cm
Product weight: 200g
Support HDMI-compatible
Support 2.4G/5G WiFi. 10/1000M LAN
Support Multi-language
Three Systems: EmuELEC4.5 & Android 9.0 & CoreELEC

Advertisement

loading
Need help?

Need help?

Do you have a question about the SUPER CONSOLE CUBE X3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kinhank SUPER CONSOLE CUBE X3

Summary of Contents for Kinhank SUPER CONSOLE CUBE X3

  • Page 1 SUPER CONSOLE CUBE X3 User Manual Model: Super Console Cube X3 Dual System: Game & TV CPU:Amlogic S905X3 RAM:4GB DDR3 GPU:Mail-G31 MP2 ROM:32GB eMMC DC Power:5V/3A Bluetooth: BT4.0 WiFi:2.4G/5G Language:Multi-languages 1. Product Information Product size: 12.5cm*10.7cm*4cm Product weight: 200g Support HDMI-compatible Support 2.4G/5G WiFi.

  • Page 2: Product Features

    2. Product Features * Mini size, retro design, palm size, can be put in the pocket, it’s the best choice for family, travel, party, corporate entertainment. * Equipped with upgraded S905X3 chip, Amlogic Quad Core ARM Cortex-A55 CPU, 4-core processor, main frequency 1.91GHz. Powerful GPU:Mail-G31 MP2. *Built-in up to 100000+ retro games.
  • Page 3 EmuELEC 4.5 Android 9.0 CoreELEC 5. Three Systems: Game Console & TV & CoreELEC TV system to game system: When the card is not inserted, it is Android system, it supports watching TV, Youtube, Googleplay.TV system turn into game system: Follow the steps below to use the remote control My Application>>LiberELEC>>OK>>Allow Game System to TV system：...

  • Page 4: System Startup And Shutdown

    7. System Startup and Shutdown (1) System Startup: Press the power button to start the system. (2) Shut Down: Press SELECT---->>SHUTDOWN SYSTEM (software shutdown protection system), and then cut off the power. 8. Common hotkey settings Left/right cross keys and joystick Switch emulator platform B key (right side function key) Enter or confirm...
  • Page 7 （2）Controller Button Mapping After the USB interface is connected to the handle, press the handle B (OK) button to enter the handle button setting.
  • Page 9 (2) WIFI Connection START---->>NETWORK SETTINGS---->>ENABLE WIFI, then select the wifi network as required and fill in the password;...
  • Page 11 (3) Game/TV Dual System TV system to game system: When the card is not inserted, it is Android system, it supports watching TV, Youtube, Googleplay.TV system turn into game system: Follow the steps below to use the remote control My Application>>LiberELEC>>OK>>Allow Game System to TV system：...
  • Page 12 10. Adding Game Methods There are many ways to copy games: The First Type: (compatible with multiple win systems) Insert the game console memory card into the computer and use DiskGenius software: (1) Open DiskGenius, make sure DiskGenius has recognized the memory card ; (2) Find the rom folder and put the game in the corresponding folder ;...
  • Page 13 In the example below, the IP address is: 10.10.10.117 In the computer resource manager, enter \\10.10.10.117 and press Enter.
  • Page 14 If prompted to enter a user name and password, the default user name: root, password: emuelec. (2) Open the Storage/Roms Folder: You can see many sub folders, each of which corresponds to a simulator game, and the corresponding game needs to be placed in the corresponding folder to be correctly identified (3) Example of the folder list corresponding to the simulator: Arcade-FBA format roms\arcade\fba...
  • Page 15 Note: The system distinguishes games by folder name, do not modify any directory structure, just copy the game files to the folder of the corresponding simulator. 11. Change Game Emulators: There may be multiple emulator files. If individual games cannot be opened or you want to try the effects of other simulators, please use the following methods to change the simulator: Select the game you want to change the emulator--->>Long press the B key--->>Game...

  • Page 16: Fcc Warning

    12. More Tutorial Videos: For more usage methods, please refer to: URL 1: https://www.youtube.com/channel/UC9pHw2msnsd8i1QZVY180eQ?view_as=subscriber FCC WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
