Operating and Installation Instructions
Household Use
Ceramic Hob
Model No. : KY-R64ARLJPQ
Operating and Installation Instructions
............................................................................
2 - 26
Thank you for purchasing this Panasonic product.
• This appliance is intended for household use only.
• Please read these instructions carefully before attempting to install, operate or service this product.
• For optimum performance and safety, please read these instructions carefully and follow safety precautions
when using this product.
• Before using this product please pay extra attention to "Safety Precautions" (Page 3 - 5).
Keep these Operating and Installation Instructions for future use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KY-R64ARLJPQ and is the answer not in the manual?

Questions and answers

Summary of Contents for Panasonic KY-R64ARLJPQ

  • Page 1 Operating and Installation Instructions ................2 - 26 Thank you for purchasing this Panasonic product. • This appliance is intended for household use only. • Please read these instructions carefully before attempting to install, operate or service this product. • For optimum performance and safety, please read these instructions carefully and follow safety precautions when using this product.
  • Page 2: Table Of Contents

    Table of Contents Safety Precautions ..........................3 - 5 Parts Identication ..........................6 - 7 • Parts Identication ..........................6 • Control Panel ............................6 • Accessories ............................7 Using the Ceramic Hob ........................8 - 15 • Operating the Ceramic Hob ....................... 8 - 9 •...
  • Page 3: Safety Precautions

    • The body is de rmed or abnormally hot. manufacturer, its service agent or • The Glass Panel is cracked. similarly qualified pe ons in order Contact a Panasonic Authorised oid a hazard. Service Centre immediate Be sure to disconnect the maintenance / repair.
  • Page 4 Safety Precautions Make sure to foll these instructions WARNING Clean the wer Plug regularly Unattended cooking on a hob with with dry oth, otherwise, it may fat or oil can be dangerous and may cause insufficient insulation due to result in a fire. moisture and may cause fire.
  • Page 5 Safety Precautions Make sure to foll these instructions CAUTION When stir frying with Ceramic Hob, Spray eaner is not to be used observe the foll ing points: cleaning. • Do not le e this Ceramic Hob unattended. A steam eaner is not to be used It •...
  • Page 6: Parts IdentiCation

    Parts Identifi cation Parts Identifi cation Max.1200 W zone Max.1800 W zone Glass plate Max.1800 W zone Max.1200 W zone ON/OFF Control Panel Cont l ro Pa Heating zone Timer regulating Heating zone selection controls controls selection controls Power/Timer regulating controls Key lock ON/OFF control...
  • Page 7: Accessories

    Parts Identifi cation Accessories Warranty Ca Operating and Installation Instructions Shape of the bottom • The bottom is flat and has uni form contact with the Glass Panel. • Do not use if : a. The cookware has a round-bottom. b.
  • Page 8: Using The Ceramic Hob

    Using the Ceramic Hob Operating the Ceramic Hob Before use • Read this guide, taking special note of the ‘Safety Precautions’ section. • Remove any protective fi lm that may still be on the Ceramic Hob. Using the Touch Controls •...
  • Page 9: Finish Cooking

    4. Select a heat setting by touching the “-” or “+” control. • If you don’t choose a heat setting within 1 minute, the ceramic hob will automatically switch o��. You will need to start again at step 1. • You can modify the heat setting at any time during cooking. •...
  • Page 19: Failure Display And Inspection

    Failure Display and Inspection The hob is equipped with a self diagnostic function. With this test the technician is able to check the function of several components without disassembling or dismounting the hob from the working surface. Failure code occur during customer usage & Solution for it; No Auto-Recovery Failure code Problem...
  • Page 20: Specifications

    Specifi cations 220 - 240 V Electrical Rating Voltage 380 - 415 V 3N Wattage 5500 - 6600 W Frequency 50Hz or 60Hz × × × ×...
  • Page 21: Installation Instructions

    Installation Instructions For Installer Safety precautions for installation Please read these precautions fully WARNING Failure to foll these instructions may cause a risk of personal injury or death. Foll these instructions when The ground should be installed by installing the Ceramic Hob. a qualified electrician.
  • Page 22 Installation Instructions For Installer CAUTION Failure to foll these instructions may cause a risk of personal injury or death. Use heat resistant materials for the Do not step on or drop any ha rd work surface. arti e down on the Glass nel.
  • Page 23: Installation Requirements

    Installation Instructions For Installer Installation Requirements Cut out th work surface according to the sizes shown in the drawing. For the purpose of installation and use, a minimum of 50 mm space shall be preserved around the hole. Be sure the thic kn ss of the work surface is at least 30 mm.
  • Page 24 Installation Instructions For Installer Under any circumstance ma ke sure the Ceramic Hob is well ve ntilated and the air inlet and outlet are not blo d. Ensure the Ceramic Hob is in a good wo rking stat as sh below.
  • Page 25 Installation Instructions For Installer Before the Ceramic Hob is installed make sure that: • The work surface is square and level, and no st ctural pa rts interfere with space requirements. • The work surface is made of a heat-resistant mate al. •...
  • Page 26 Installation Instructions For Installer CAUTION The Ceramic Hob must be installed qualified pe rsonnel or technicians. Never conduct the operation yourself. The Ceramic Hob must not be installed direct e a dishwasher fridge freezer, washing machine or clothes drye as the humidity may damage the Ceramic Hob electronics.
  • Page 27: Electrical Connection

    Installation Instructions For Installer Electrical Connection WARNING This Ceramic Hob must be connected to the main power supp ly by a suitab qualified person. Before connecting the Ceramic Hob to the main power supply, check that: • The domestic wiring system is suitable for the power drawn the Ceramic Ho •...
  • Page 28 Website: http://www.panasonic.com 16166000A06458 Printed in China G0318-0...
