Wireless AC/DC Current Clamp
Introduction
The Fluke a283 FC Wireless AC/DC Current Clamp (the
Product or Clamp) is a wireless True-RMS current clamp
with a thin jaw to fit into tight spaces.
The Clamp measures up to 60 A. You can wirelessly connect
to a 283 FC Meter and view the Clamp measurements on the
Meter display.
Contact Fluke
Fluke Corporation operates worldwide. For local contact
information, go to our website: www.fluke.com.
To register your product, or to view, print, or download the
latest manual or manual supplement, go to our website:
www.fluke.com/productinfo.
Fluke Corporation
6920 Seaway Blvd
Everett WA 98203
U.S.A.
+1-425-446-5500
PN 5593600 (English) 7/2024 Rev. 1, 8/24
©2024 Fluke Corporation. All rights reserved. Specifications are
subject to change without notice. All Product names are
trademarks of their respective companies.
Fluke Europe B.V.
P.O. Box 1186
5602 BD Eindhoven
The Netherlands
fluke-info@fluke.com
a283 FC
Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the a283 FC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Fluke a283 FC

  • Page 1 Wireless AC/DC Current Clamp Instructions Introduction The Fluke a283 FC Wireless AC/DC Current Clamp (the Product or Clamp) is a wireless True-RMS current clamp with a thin jaw to fit into tight spaces. The Clamp measures up to 60 A. You can wirelessly connect to a 283 FC Meter and view the Clamp measurements on the Meter display.
  • Page 2: Safety Information

    Safety Information A Warning identifies hazardous conditions and procedures that are dangerous to the user. A Caution identifies conditions and procedures that can cause damage to the Product or the equipment under test. Warning To prevent possible electrical shock, fire, or personal injury: Read all safety information before you use the ...
  • Page 3 Do not use a current measurement as an  indication that a circuit is safe to touch. A voltage measurement is necessary to know if a circuit is hazardous. Do not use the Product around explosive gas,  vapor, or in damp or wet environments. Use only specified replacement parts.
  • Page 4 Do not dispose of this product as unsorted municipal waste. For information about take-back and recycling programs available in your country, see the Fluke website. Batteries To install or replace the batteries: 1. Turn off the Product. 2. Use a Phillips head screwdriver to remove the screw in the battery door.
  • Page 5 Pair Clamp with 283 FC Meter For information about how to wirelessly pair the Clamp to the Meter, see the 283 FC True-RMS 1500 V Multimeter Users Manual at www.fluke.com. How to Use The maximum distance for operation between the Meter and Clamp is 10 m (33 ft).
  • Page 6 4. When the test is done, push and release The green power light turns off. Note When Auto Power Off is disabled, the Clamp continues to operate until the battery voltage level is <1.2 V. DC Current Zero Adjustment The output zero offset current of the Clamp may change due to residual magnetism and other environmental conditions.
  • Page 7 When Auto Power Off is enabled, the Clamp: Goes to the Sleep Mode if paired with a Meter and then  disconnected from that Meter for >20 minutes, The blue LED is continuously on and the green LED is off. Note When connection with the meter is re-established, the clamp is reactivated.
  • Page 8: Maintenance

    Maintenance Periodically wipe the case with a damp cloth and mild detergent. Do not use abrasives or solvents to clean the Product. Product Disposal Dispose of the Product in a professional and environmentally sound manner: Delete personal data on the Product before disposal. ...
  • Page 9 Temperature Coefficients .......Add 0.1 x specified accuracy for each °C >28 °C or <18 °C AC Current Range........60.00 A Resolution ......0.01 A Accuracy ........1.5 % +15 digits (45 Hz to 500 Hz) <1 % range, unspecified Crest Factor (50 Hz/60 Hz)......3 @ 60.00 A DC Current Range........60.00 A Resolution ......0.01 A...
  • Page 10 THIS WARRANTY IS YOUR ONLY REMEDY. NO OTHER WARRANTIES, SUCH AS FITNESS FOR A PARTICULAR PURPOSE, ARE EXPRESSED OR IMPLIED. FLUKE IS NOT LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES OR LOSSES, ARISING FROM ANY CAUSE OR THEORY.
