INSTRUCTION MANUAL - TERMOFOL TF-H5 HEATING THERMOSTAT
CHARACTERISTICS
Termofol H5 thermostat is an advanced device designed for optimal management of electric heating
systems. Thanks to modern technology, an intuitive interface and many functions, the Termofol H5 ther-
mostat ensures maximum convenience and energy efficiency. Below is a drawing of the thermoregulator
display and its basic technical parameters.
SPECIFICATION
Power: 90-240 Vac 50/60HZ
Sensor: NTC(10k)1%
Current: 3A (WW) 16A (WE)
Set temperature range: 1~70°C
DISPLAY ICON
Program mode
Manual mode
Temporary manual mode
Holiday mode
Heating on
Room temperature
SET
Set the temperature
OPERATION KEY
Short press to turn on/off thermostat.
Long press to Lock/Unlock key.
Power on state short press to choose
manual or auto mode.
Long press to program/set time/set
holiday mode and so on.
Power off state short press to display
EXT sensor temperature,long press to
set advance options
SETTING TIME
Turn on thermostat, long press to enter setting interface, rotate the knob to choose
press to set time, next press to choose hour, minute and week, rotate the knob to change the
value.
HOLIDAY MODE
Turn on thermostat, long press to enter setting interface, rotate the knob to choose
press to enter, short press to choose days and temperature, rotate the knob to change the value.
PROGRAMMABLE
There are six programming working modes for users to choose:
5+2 (default), 6+1, 7 day (same as every day).
Select the programming working mode from Advanced option A. Turn on thermostat, long press
enter setting interface, rotate the knob to choose
choose hour, minute and temperature, rotate the knob to change the value. After finished, wait 10 se-
conds to exist.
P1 P2 P3
Wake up Out door Back home
6:00 20 °C 8:00 15 °C 11:30
Default set temperature range: 5~35°C
Accuracy: ±0.5 °C
Size: 82 x 82 mm (frame)
Degree of protection: IP20
Child lock
Clock icon
Antifreeze
Blinking, activate window function
EXT
External sensor temperature
Cooling mode,this icon is always
displayed when switching to cooling
mode and flashes when the cooling
load is output
Power off state ,long press
+
to enter advanced option
Rotate left-minus
Rotate right -plus
On program mode, rotate the
knob into temporary manual
mode
P
,then short press to program, short press
P4 P5
Out door Back home
15 °C 13:30 15 °C 17:00 15 °C
ADVANCE OPTION
Turn off thermostat, long press
knob to change the value. After setting, the parameters will be automatically saved, press
seconds to exit the menu.
No.
Measure Temperature
1
Calibration
Temperature return
2
difference
External sensor control
3
return difference
4 Choose sensor
5 Child lock
High temperature
6
protection
Low temperature
7
protection
The lowest setting
8
temperature
The highest setting
9
temperature
A Descaling function
Power with memory
B
C Programmable
D Standby display
E
Window function
F
triggers temperature
Window function
H
running time
+
P
L Heating/Cooling mode
ADVANCE OPTION P
Power off state, long press
change the value. After setting, the parameters will be automatically saved and exited after holding the
interface for 10 seconds.
No.
Power consumption
P1
of previous day
P2 Total power consumption
Rate power
P3
of heating device
RETURN DIFFERENCE - Limit valve of external sensor is 28°C for factory default (6), value of external
,then short
sensor control return difference (3) is 2. when temperature rise to 28 °C,then relay stop working and will
remind high temperature protection alarm
and alarm will be relieved. (it can be operated, only when indoor temperature is lower than setting tem-
perature).
SENSOR FAULT DISPLAY - Please choose correct working way of built-in and external sensor, if choose
wrongly or sensor fault (breakdown), "E1" or "E2" will be displayed on the screen. Thermostat will stop
,then short
heating until the fault is eliminated
WIRING AND INSTALLATION INSTRUCTIONS
to
to
WIRING
WE
P6
Sleep
22:00 15 °C
WE - electrical heating
to enter advance option. Short press
Items Parameter
0.5-2.5 °C
N1 : internal sensor
(high temperature protection closed)
N2: external sensor
(high temperature protection closed)
N3: internal sensor for temperature controlling,
external sensor for high temperature protection
0: half lock
1: 20°C - 70°C
2: less than 20°C, display【--】
mean closed this function
1: 1°C-10°C
2: more than 10°C display【--】
mean closed this function
0: closed
0:Power with memory function
1:Off state after connecting with power
function
2:On state after connecting with power
0: 5+2 ; 1: 6+1 ;
0: display nothing
1:Standby brightness is weak-bright
2: Standby brightness is semi-bright
Reset Long press
10-20°C,setting temperature is 10°C,
decrease it,will display【--】
then canceled this function
10-20 min
0: heating
1: cooling
+ for 3-5 seconds to access advanced option
Items Parameter
XXXX Kwh, long press
XXXX Kwh, long press
XXXX W, Setting range: 100-3500W
. If temperature decline to 5 °C relay continue to work
WW
WW - water heating
to choose item, rotate the
or wait 10
Default
-9-+9 °C -1
1 °C
1~9 °C 2
N3
1: full lock 0
28
5
1-10 °C 5
20-70 °C 35
0
1: open
0
2: 7 0
2
until whole display Ao
--
10
0
P
. Rotate the knob to
Default
to clear the data
to clear the data
2000W
LD
LD - boiler heating
and water heating
