NOTICE: When fasteners are removed, always reinstall them at the same location from which they were removed. If a
fastener needs to be replaced, use the correct part number fastener for that application. If the correct part number
fastener is not available, a fastener of equal size and strength (or stronger) may be used. Fasteners that are not reused,
and those requiring thread locking compound will be called out. The correct torque value must be used when
installing fasteners that require it. If the above conditions are not followed, parts or system damage could result.
SUBJECT
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7D-1
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7D-1
ldentification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7D-2
Diagnosis of Transfer Case . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7D-2
On-Vehicle Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7D-3
Fluid Change . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7D-3
Vent Hose Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7D-3
Extension Housing Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7D-5
Transfer Case Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7D-7
Transfer Case Unit Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7D-8
Disassembly of the Transfer Case . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7D-8
External Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7D-8
Internal Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7D-8
Bearings and Seals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7D-8
Cleaning and lnspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7D-11
Assembly of the Transfer Case.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7D-12
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7D-16
Special Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7D-17
The BORG WARNER-4472 transfer case is a two-piece
aluminum case, chain driven, viscous clutch type transfer
case. This produces a system in which all wheel drive is
engaged all the time. Torque is transmitted through a plan-
etary gear set which distributes torque at a ratio of 1/3 front
2/3 rear. All wheel drive is automatic and has no external
controls.
The viscous clutch used in the BW-4472 is a torque distri-
bution device and is nonserviceable. The internal construc-
tion of the viscous clutch consists of alternating plates that
are connected to the front and rear outputs of the transfer
case. The viscous clutch is filled with a high viscosity fluid
which flows through slots in the plates. The resistance to
sheer causes the plates to transmit torque.
SECTION 7D
TRANSFER CASE
SYCLONE AND TYPHOON
CONTENTS
DESCRlPTlON
OPERATION
Torque is transmitted through the input shaft to the
planet carrier assembly. The viscous clutch provides the
connection between the gear ring and the sun gear shaft.
Torque flow continues through the gear ring to the rear
output shaft. -Torque also flows from the planet carrier
assembly to the sun gear shaft which is splined to the drive
gear. The drive gear is connected to the driven sprocket by
the drive chain. Torque continues through the driven
sprocket to the front output shaft flange (figure 1).
7D-1
