Electron Plus ASA101A User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
ASA101A User Manual
software version: 24.001
manual version: 13 June 2024
Check for latest version of this manual here:
http://electron.plus/pages/manuals

Advertisement

loading
Need help?

Need help?

Do you have a question about the ASA101A and is the answer not in the manual?

Questions and answers

Related Manuals for Electron Plus ASA101A

Summary of Contents for Electron Plus ASA101A

  • Page 1 ASA101A User Manual software version: 24.001 manual version: 13 June 2024 Check for latest version of this manual here: http://electron.plus/pages/manuals...

  • Page 2: Table Of Contents

    ASA101A User Manual support@electron.plus Table of contents 1 Notices ..1.1 Copyright ....................4 ..1.2 Part number .................... 4 ..1.3 Issue ....................... 4 ..1.4 Location ....................4 ..1.5 Published by .................... 4 ..1.6 Notes ...................... 4 ..1.7 Trademark acknowledgement ..............5 ..1.8 Purpose of manual ...................
  • Page 3 ASA101A User Manual support@electron.plus 5.5.3.1 Mode > Advanced/Compact Mode ..........37 .5.5.4 Test ....................37 5.5.4.1 Test > Signature Overwrite ............38 5.5.4.2 Test > Open Circuit Detect Threshold ........39 5.5.4.3 Test > Stable Signature Detect Threshold ........40 5.5.4.4 Test >...

  • Page 4: Notices

    This manual (or part thereof) may not be reproduced by any means (electronic or photographic, including translation into a foreign language) without prior written consent and agreement from Electron Plus as set-out in United Kingdom and international copyright laws. Electron Plus is a trading style of BFRAD Limited.

  • Page 5: Trademark Acknowledgement

    Copying or reproducing this document or any part of this document without written  permission of Electron Plus is strictly prohibited. ..1.7 Trademark acknowledgement Electron Plus fully recognises and acknowledges any trademark(s) of the respective trademark holder, these include (but not limited to): Windows is a trademark of Microsoft Corporation.

  • Page 6: Specifications

    ASA101A User Manual support@electron.plus 2 Specifications ..2.1 Absolute Maximum Ratings Exceeding these specifications, even briefly, may cause permanent damage to the device. Parameter Rating Input Voltage -12V to +12V (via connector 'spike') Input Voltage -0.6V to +5.5V (via connector 'USB')

  • Page 7: General Specifications

    ASA101A User Manual support@electron.plus ..2.3 General Specifications ..2.4 PC Requirements 24.001 / 13 June 2024 7 / 109...

  • Page 8: System Requirements

    We recommend at least Windows 7 operating system - although most customers are using Windows 10 or Windows 11. ASA is available in both 32 bit and 64 bit from the Electron Plus website. Minimum requirement for connection to ASA device: 1x USB 2.0 type A (common) for connection to the instrument, at 0.5A.

  • Page 9: Getting Help

    ASA101A User Manual support@electron.plus ..3.2 Getting help Help is available by email: support@electron.plus If you are experiencing an issue with EPIC, please email a copy of the following files (see below) found in the EPIC installation folder along with a description of the problem.

  • Page 10: Introduction

    ASA101A User Manual support@electron.plus 4 Introduction ..4.1 Welcome Congratulations and thank you for purchasing an Electron Plus product. Please take a few minutes to read the ‘Before you start’ section of this manual, especially as misusing this product can result in damage to it, your device-under-test or potentially place you in-danger.

  • Page 11: Before You Start

    ..4.2 Before you start The supplied metal spike is SHARP. When you have finished using the ASA101A, unscrew the spike, turn it round and screw it lightly back into the ASA101A. Ensure that all DUT* capacitors and energy storage devices are fully discharged before using the ASA101A.

  • Page 12: New In Software

    ASA101A User Manual support@electron.plus ..4.3 New in software ASA covers most Electron Plus instruments and not all instruments are updated between versions: V24.001 Change to Daily Update Check function Split Views out of Display menu Bug fixes Various small tweaks V22.001...

  • Page 13: Installation Sequence

    ASA101A User Manual support@electron.plus ..4.4 Installation sequence Please install the ASA software and the associated USB driver software BEFORE connecting your device to a computer. You do not need to remove a previous copy of ASA, the new copy will overwrite the necessary existing file(s).

  • Page 14: Installing The Software

    ASA101A User Manual support@electron.plus ..4.5 Installing the Software Electron Plus products require a USB connection to a PC running ASA (our proprietary software) in order to function. ASA now comes in two compiled versions (since version 21.010): ASA64 - for 64 bit Windows installations & PC's (we recommend this).

  • Page 15: Installing The Usb Driver

    ASA101A User Manual support@electron.plus ..4.6 Installing the USB driver The product covered in this document communicates with the host PC via USB using an FTDI FT230X bridge IC. A copy of the official FTDI device driver is available from the SOFTWARE section of our website (www.electron.plus/pages/software), device drivers can also be downloaded directly...

  • Page 16: Operation

    ASA101A User Manual support@electron.plus 5 Operation ..5.1 Selecting Instrument When ASA is first installed it will initially start in ASA100 mode. To change this: INSTRUMENT > CHANGE INSTRUMENT and select the actual instrument you wish to use, you will then have to close and reopen ASA for this to take effect.

  • Page 17: Connecting Instrument

    ASA101A User Manual support@electron.plus ..5.2 Connecting Instrument To connect to the instrument you can use the options in the MENU or the button on the Control Ribbon. INSTRUMENT > CONNECT to connect, or DISCONNECT to disconnect. Fig. 2 Fig. 3...

  • Page 18: Check For Updates

    ASA101A User Manual support@electron.plus ..5.3 Check for updates Once per day ASA will check if there is a newer version available. This feature maybe disabled or re-enabled here: UTILITIES > DAILY UPDATE CHECK Tick will enable ASA to perform the daily update check, unticking will prevent ASA from performing the daily update check.

  • Page 19: Control Ribbon

    ASA101A User Manual support@electron.plus ..5.4 Control Ribbon The Control Ribbon has most of the functions necessary for the operation of the instrument. Fig. 5 The following sections are descriptions of Instrument Status, Signature Generator, Test Controls Edit Controls and their functions.

  • Page 20: Instrument Status

    ASA101A User Manual support@electron.plus .5.4.1 Instrument Status Reconnect/Connected button shows the status of the connection between the instrument and ASA: Fig. 6 Pressing this button will connect or disconnect the instrument to ASA. Should the instrument be disconnected, the status of this button will automatically change.

  • Page 21: Signature Generator

    Buttons A and B (as shown below) can be used to quickly access a favourite or much used function. Fig. 11 The two push-buttons on the ASA101A (also labelled A and B) map directly to these two on- screen buttons, and when pressed the on-screen buttons will go yellow. 24.001 / 13 June 2024...
  • Page 22 ASA101A User Manual support@electron.plus Two drop down lists below enable the user to select the function associated with each button (list shown below, with button A assigned to cycle frequency): Fig. 12 The cycle function (i.e. Cycle Frequency) will go up relevant function and 'roll-over' to the minimum setting (e.g.

  • Page 23: Test Controls - Advanced Mode

    ASA101A User Manual support@electron.plus .5.4.3 Test Controls - Advanced Mode The Pin/record selected is incremented/decremented manually (using the buttons below) or advanced automatically (when in Auto Test, Auto Capture or Single Capture). Fig. 13 These buttons (above) will increment/decrement through the individual Pin/records - using the controls below will increment/decrement through entire components at a time.
  • Page 24 ASA101A User Manual support@electron.plus During a test, the percentage of pins that test GOOD and BAD is calculated and displayed (see image below). Fig. 18 GOOD and BAD buttons (above) will mark each record as either GOOD or BAD - typically this is used when overriding automatically tested signature results.

  • Page 25: Edit Controls - Advanced Mode

    ASA101A User Manual support@electron.plus .5.4.4 Edit Controls - Advanced Mode The default condition is Manual Test (Edit/Capture signature unticked). Fig. 23 To enter Capture signature mode, tick the box (see below). Fig. 24 Pressing the Edit/Add Records button (see above) will open a new window (see Edit/Add Records &...

  • Page 26: Freeze Controls - Compact Mode

    ASA101A User Manual support@electron.plus .5.4.5 Freeze Controls - Compact Mode Compact Mode is designed so that you can quickly perform: 1. classic analog signature analysis display 2. fast comparison between two circuits To switch between Compact and Advanced modes click here.
  • Page 27 ASA101A User Manual support@electron.plus The basic controls (signature generator) are the same as Advanced mode. Three extra controls (bottom left) have the following functions: Freeze Golden button/function Pressing this button will freeze the current signature and keep it displayed in a golden colour until it is either unfrozen (pressing the button again), or by enabling Auto Freeze.
  • Page 28 ASA101A User Manual support@electron.plus Fig. 27 Auto Freeze button/function Auto Freeze allows for rapid comparison between two signatures without having to remember the previous signature and having to interact with the controls. When enabled, Auto Freeze will: 1. apply test probes across known good test points, then 2.
  • Page 29 ASA101A User Manual support@electron.plus Fig. 28 Switching off Auto Freeze will preserve the screen until a new signature is displayed. 24.001 / 13 June 2024 29 / 109...

  • Page 30: Menu Bar

    ASA101A User Manual support@electron.plus ..5.5 Menu Bar Across the top of the screen is the Menu Bar. Controls for file management, instrument connection, overall mode, test settings, scope settings, visualisation, utilities and help are here: Fig. 29 A detailed description of each drop down menu follows on the next few pages.

  • Page 31: File

    ASA101A User Manual support@electron.plus 5.5.1.1 File > New This topic is also covered here. To create a new, empty .EPT test file: Fig. 30 Will bring up the Save file selector: Fig. 31 Files can be saved to any location on your computer or network, however consider the speed of access to the file if storing across a network (especially lower cost NAS devices).

  • Page 32: File > Open

    ASA101A User Manual support@electron.plus 5.5.1.2 File > Open To open a .EPT test file: Fig. 32 Select the .EPT file to open: Fig. 33 24.001 / 13 June 2024 32 / 109...

  • Page 33: File > Save

    ASA101A User Manual support@electron.plus 5.5.1.3 File > Save To save a .EPT file: Fig. 34 Enter either a new name OR just click SAVE on the file selector: Fig. 35 24.001 / 13 June 2024 33 / 109...

  • Page 34: File > Open Recent

    ASA101A User Manual support@electron.plus 5.5.1.4 File > Open Recent To open a recently saved .EPT file: Fig. 36 Select a file to open by selecting one of the eight most recent .EPT files: Fig. 37 24.001 / 13 June 2024...

  • Page 35: Instrument

    ASA101A User Manual support@electron.plus 5.5.2.1 Instrument > Connect/Disconnect To connect to the instrument you can use the options in the MENU or the button on the Control Ribbon. INSTRUMENT > CONNECT to connect, or DISCONNECT to disconnect. Fig. 38 Fig. 39...

  • Page 36: Instrument > Change Instrument

    ASA101A User Manual support@electron.plus 5.5.2.2 Instrument > Change Instrument When ASA is first installed it will initially start in ASA100 mode. To change this: INSTRUMENT > CHANGE INSTRUMENT and select the actual instrument you wish to use, you will then have to close and reopen ASA for this to take effect.

  • Page 37: Mode > Advanced/Compact Mode

    ASA101A User Manual support@electron.plus 5.5.3.1 Mode > Advanced/Compact Mode To change between Compact and Advanced modes: Fig. 41 The operational mode is immediately changed. A description of Compact Mode function can be found here. 24.001 / 13 June 2024 37 / 109...

  • Page 38: Test > Signature Overwrite

    ASA101A User Manual support@electron.plus 5.5.4.1 Test > Signature Overwrite This function determines whether or not to overwrite an already captured golden signature. Fig. 42 If disabled (no tick) the AUTO CAPTURE will move to the next available pin that has not been sampled (i.e.

  • Page 39: Test > Open Circuit Detect Threshold

    ASA101A User Manual support@electron.plus 5.5.4.2 Test > Open Circuit Detect Threshold Selects the percentage variation from true 'open circuit' that ASA uses to determine the 'open circuit' condition. Fig. 43 Typically leave this at 0.5% (default) unless it is causing false OC triggers (reduce to 0.25%) or there is noise in the test setup (raise to 1%).

  • Page 40: Test > Stable Signature Detect Threshold

    ASA101A User Manual support@electron.plus 5.5.4.3 Test > Stable Signature Detect Threshold Selects the percentage variation allowable between consecutive signature samples before the ASA considers the signature meets the basic stable status. Fig. 45 Typically leave this at 1% (default) unless noise in the DUT (rare but possible) is causing false stable signature triggers (increase to 2%) or there is requirement for tighter performance between good and bad signatures (reduce to 0.5%).

  • Page 41: Test > Stable Signature Delay

    ASA101A User Manual support@electron.plus 5.5.4.4 Test > Stable Signature Delay Controls the number of consecutive cycles that meet the 'stable signature' condition to be considered a stable signature (the point at which a signature is automatically captured). Fig. 47 To aid tuning, text at the bottom right of the graph displays Count when stable conditions are met: Fig.

  • Page 42: Test > Golden/Live Signature Difference Threshold

    ASA101A User Manual support@electron.plus 5.5.4.5 Test > Golden/Live Signature Difference Threshold Selects the percentage variation between a previously captured Golden Signature and the live signature before the ASA considers them a match. Fig. 49 Smaller percentages will typically increase the time it takes to match signatures and also result in fewer matches (due to noise and other minor differences between the Golden and DUT units.

  • Page 43: Test > Collapse Test Tree

    ASA101A User Manual support@electron.plus 5.5.4.6 Test > Collapse Test Tree Collapsing the Test Tree will quickly close all the expanded test points and is there to save time manually collapsing each test point (useful on larger boards). Fig. 50 An example of a partially expanded Test Tree: Fig.

  • Page 44: Scope

    ASA101A User Manual support@electron.plus The same Test Tree after the 'Collapse Test Tree' function is triggered: Fig. 52 NOTE - The currently selected pin/component is deliberately not collapsed. 24.001 / 13 June 2024 44 / 109...

  • Page 45: Scope > Graticule

    ASA101A User Manual support@electron.plus 5.5.5.1 Scope > Graticule To enable/disable the Graticule: Fig. 53 An example with the Graticule ON: Fig. 54 24.001 / 13 June 2024 45 / 109...
  • Page 46 ASA101A User Manual support@electron.plus An example with Graticule OFF: Fig. 55 24.001 / 13 June 2024 46 / 109...

  • Page 47: Scope > Crosshairs

    ASA101A User Manual support@electron.plus 5.5.5.2 Scope > Crosshairs The Crosshairs have three settings: Fig. 56 Example shown here Crosshairs ON (graticule OFF for clarity): Fig. 57 Example shown here Crosshairs Classic (graticule OFF for clarity): 24.001 / 13 June 2024...
  • Page 48 ASA101A User Manual support@electron.plus Fig. 58 24.001 / 13 June 2024 48 / 109...
  • Page 49 ASA101A User Manual support@electron.plus Example shown here Crosshairs Off (graticule OFF for clarity): Fig. 59 24.001 / 13 June 2024 49 / 109...

  • Page 50: Scope > Crosshairs (Mini-Scopes)

    ASA101A User Manual support@electron.plus 5.5.5.3 Scope > Crosshairs (mini-scopes) To enable/disable the Crosshairs in the mini-scopes: Fig. 60 An example of mini-scopes with the Crosshairs OFF (default): Fig. 61 An example of mini-scopes with the Crosshairs ON: 24.001 / 13 June 2024...

  • Page 51: Display

    ASA101A User Manual support@electron.plus Fig. 62 24.001 / 13 June 2024 51 / 109...

  • Page 52: Display > Pcb Crosshairs

    ASA101A User Manual support@electron.plus 5.5.6.1 Display > PCB Crosshairs The PCB view Crosshairs can be 1 pixel wide (white) or 3 pixels wide (white centre line, flanked by black lines), this can be changed here: Fig. 63 An example of 1 line crosshairs (most commonly used): Fig.
  • Page 53 ASA101A User Manual support@electron.plus An example of 3 line crosshairs (useful if you have a light/white coloured PCB image): Fig. 65 24.001 / 13 June 2024 53 / 109...

  • Page 54: Display > Display Colours

    ASA101A User Manual support@electron.plus 5.5.6.2 Display > Display Colours Display Colours can be changed: Fig. 66 When this option is selected a separate window is brought up: Fig. 67 Clicking a button (e.g. "Scope Background") will bring up a colour palette, select a new colour and click OK to make the change: 24.001 / 13 June 2024...
  • Page 55 ASA101A User Manual support@electron.plus Fig. 68 Each coloured item option (e.g. "Scope Background") can be reset to default by pressing the "< set to default" button. All coloured item options can be set to default simultaneously by pressing the "Set colours: dark mode (default)"...

  • Page 56: Views

    ASA101A User Manual support@electron.plus .5.5.7 Views There are multiple 'view' configurations that can be selected. Users will often prefer one style (commonly this is: 2 mini-scopes + PCB + TestTree+ BadTree), however we encourage testing alternate 'views' as they may be better suited to your testing.
  • Page 57 ASA101A User Manual support@electron.plus RED - bad signature YELLOW - untested (no DUT signature captured) PINK - no Golden signature recorded yet. 24.001 / 13 June 2024 57 / 109...

  • Page 58: Views > 9 Mini-Scopes

    ASA101A User Manual support@electron.plus 5.5.7.1 Views > 9 mini-scopes Fig. 71 The centre mini-scope of the 9 is the current Pin/record (same image as the main scope). Clicking on any of the mini-scopes will select that Pin/record as the main scope image.

  • Page 59: Views > 6 Mini-Scopes + Testtree

    ASA101A User Manual support@electron.plus 5.5.7.2 Views > 6 mini-scopes + TestTree Fig. 72 The centre-right mini-scope of the 6 is the current Pin/record (same image as the main scope). Clicking on any of the mini-scopes or TestTree points will select that Pin/record as the main scope image.

  • Page 60: Views > 3 Mini-Scopes + Testtree

    ASA101A User Manual support@electron.plus 5.5.7.3 Views > 3 mini-scopes + TestTree Fig. 73 The centre mini-scope of the 3 is the current Pin/record (same image as the main scope). Clicking on any of the mini-scopes or TestTree points will select that Pin/record as the main scope image.

  • Page 61: Views > 3 Mini-Scopes + Testtree + Badtree

    ASA101A User Manual support@electron.plus 5.5.7.4 Views > 3 mini-scopes + TestTree + BadTree Fig. 74 The centre mini-scope of the 3 is the current Pin/record (same image as the main scope). Clicking on any of the mini-scopes, TestTree or BadTree points will select that Pin/record as the main scope image.

  • Page 62: Views > 3 Mini-Scopes + Pcb

    ASA101A User Manual support@electron.plus 5.5.7.5 Views > 3 mini-scopes + PCB Fig. 75 The middle mini-scope of the 3 is the current Pin/record (same image as the main scope). Clicking on any of the mini-scopes or test points (on the PCB image) will select that Pin/record as the main scope image.

  • Page 63: Views > 3 Mini-Scopes + Pcb + Testtree

    ASA101A User Manual support@electron.plus 5.5.7.6 Views > 3 mini-scopes + PCB + TestTree Fig. 76 The middle mini-scope of the 3 is the current Pin/record (same image as the main scope). Clicking on any of the mini-scopes, TestTree points or test points (on the PCB image) will select that Pin/record as the main scope image.

  • Page 64: Views > 2 Mini-Scopes + Pcb + Testtree + Badtree

    ASA101A User Manual support@electron.plus 5.5.7.7 Views > 2 mini-scopes + PCB + TestTree + BadTree Fig. 77 The left mini-scope displays the previous Pin/record and the right mini-scope displays the next Pin/record. Clicking on any of the mini-scopes, TestTree points, BadTree points or test points (on the PCB image) will select that Pin/record as the main scope image.

  • Page 65: Views > 2 Mini-Scopes + Pcb + Testtree

    ASA101A User Manual support@electron.plus 5.5.7.8 Views > 2 mini-scopes + PCB + TestTree Fig. 78 The left mini-scope displays the previous Pin/record and the right mini-scope displays the next Pin/record. Clicking on any of the mini-scopes, TestTree points or test points (on the PCB image) will select that Pin/record as the main scope image.

  • Page 66: Views > 1 Mini-Scope + Testtree + Badtree

    ASA101A User Manual support@electron.plus 5.5.7.9 Views > 1 mini-scope + TestTree + BadTree Fig. 79 The mini-scope displays the previous Pin/record. Clicking on the mini-scope, TestTree points, BadTree points or test points (on the PCB image) will select that Pin/record as the main scope image.

  • Page 67: Views > Pcb

    ASA101A User Manual support@electron.plus 5.5.7.10 Views > PCB Fig. 80 Clicking on the test points (on the PCB image) will select that Pin/record as the main scope image. Clicking on any area of the PCB image (but not on a test point) will...

  • Page 68: Calibrate

    ASA101A User Manual support@electron.plus 5.5.8.1 Calibrate To calibrate the ASA (unlikely you will need to): Fig. 81 This will bring up the calibration window, to calibrate you will follow the steps (1 to 12): Fig. 82 Do not use the controls below the yellow "Factory/Debug only" bar. These are for Electron 24.001 / 13 June 2024...
  • Page 69 ASA101A User Manual support@electron.plus Plus factory use only. 24.001 / 13 June 2024 69 / 109...

  • Page 70: Daily Update Check

    ASA101A User Manual support@electron.plus 5.5.8.2 Daily Update Check To change the Daily Update Check mode: Fig. 83 For a more detailed description of this function, click here. 24.001 / 13 June 2024 70 / 109...

  • Page 71: About

    ASA101A User Manual support@electron.plus 5.5.9.1 About Displays "About" information: Fig. 84 Click "OK" or the close "X" to close this window. 24.001 / 13 June 2024 71 / 109...

  • Page 72: Support

    ASA101A User Manual support@electron.plus 5.5.9.2 Support Displays "Support" information: Fig. 85 Click "OK" or the close "X" to close this window. 24.001 / 13 June 2024 72 / 109...

  • Page 73: Setting Up A Test File

    ASA101A User Manual support@electron.plus ..5.6 Setting up a test file Over the next few pages we will show an example of: 1. Setting up a new test file 2. Adding an image to the test file 3. Defining and naming some test points (resistors, capacitors, IC's etc..) .5.6.1 Creating new test file...
  • Page 74 ASA101A User Manual support@electron.plus The screen will look something like Fig below (depending on View selected, click here to see View options and how to change them): Fig. 87 At this point you can either start capturing signatures add an image of the your PCB.

  • Page 75: Adding An Image

    ASA101A User Manual support@electron.plus .5.6.2 Adding an image One or more images can be added to the test file. Images can be located anywhere on your computer or network, however we advise that you keep them in the same folder as the .ept test file or a related sub-folder.
  • Page 76 ASA101A User Manual support@electron.plus Pressing "Select Image" button will bring up a file selector: Fig. 90 Once an image is chosen the screen will look something like this: Fig. 91 24.001 / 13 June 2024 76 / 109...
  • Page 77 ASA101A User Manual support@electron.plus Remember to perform a "Quick Save" at this point by pressing the "Quick Save" button. Next we will add some test points. 24.001 / 13 June 2024 77 / 109...

  • Page 78: Adding A Component

    ASA101A User Manual support@electron.plus .5.6.3 Adding a component We will now add a small group of components. Pressing the "Select Zoom Window" button: Fig. 92 Text at the top of the PCB screen will show "Click on top-left corner of Component", click the mouse pointer at the top-left of the area of interest: Fig.
  • Page 79 ASA101A User Manual support@electron.plus Fig. 94 24.001 / 13 June 2024 79 / 109...
  • Page 80 ASA101A User Manual support@electron.plus After both corners have been selected, the PCB image will zoom in to the area of interest: Fig. 95 Note image co-ordinates and zoom factor are displayed in the line of boxes at the bottom of the image.
  • Page 81 ASA101A User Manual support@electron.plus Fig. 96 24.001 / 13 June 2024 81 / 109...
  • Page 82 ASA101A User Manual support@electron.plus We will now add a component (small electrolytic capacitor - C653), first we create the name of the part and then select the component type - component name will be automatically assigned if you don't input a name (it can be renamed later): Fig.
  • Page 83 ASA101A User Manual support@electron.plus Now we click "Create New Component", as soon as this is done the text at the top of the image screen will show "Click on Pin 1": Fig. 98 24.001 / 13 June 2024 83 / 109...
  • Page 84 ASA101A User Manual support@electron.plus Now we click the mouse pointer on Pin 1 of the capacitor - a PINK square (PINK=test point without signature assigned, square indicates it is Pin 1) as well as crosshairs will now be displayed: Fig. 99 Note that the text boxes at the bottom of the screen will be updated.
  • Page 85 ASA101A User Manual support@electron.plus Fig. 100 Note that as the component ID has been automatically incremented (as the tick-box "Auto Increment Component Number" is selected). 24.001 / 13 June 2024 85 / 109...
  • Page 86 ASA101A User Manual support@electron.plus Next we will click the "Create New Component" button and then use the mouse pointer to define more pins of a few more passive components: Fig. 101 Now we've added these extra 5 components (extra 10 pins), we will adjust their names to suit.
  • Page 87 ASA101A User Manual support@electron.plus Fig. 102 24.001 / 13 June 2024 87 / 109...
  • Page 88 ASA101A User Manual support@electron.plus 3. Pressing the "^Update^" button (to complete the Component name change). Both pin records for that component (formerly C654) have now been changed to C407: Fig. 103 Be sure to hit "Quick Save" regularly. 24.001 / 13 June 2024...

  • Page 89: Adding An Ic

    ASA101A User Manual support@electron.plus .5.6.4 Adding an IC Adding an IC is very similar to adding a simple 2 pin component. 1. First we find the last component record by pressing "Last"** : Fig. 104 2. Next we locate the IC we want to setup (using "ZOOM ALL" to show the whole PCB and the "SELECT ZOOM WINDOW"...
  • Page 90 ASA101A User Manual support@electron.plus Fig. 105 24.001 / 13 June 2024 90 / 109...
  • Page 91 ASA101A User Manual support@electron.plus With that done, now click the "Create New Component" button, and the screen looks like this: Fig. 106 Click the mouse pointer onto Pin 1 of the IC and a PINK square will be created. Instead of automatically going to Pin 2, the software will ask you to click on the last pin on that side (e.g.
  • Page 92 ASA101A User Manual support@electron.plus Fig. 107 24.001 / 13 June 2024 92 / 109...
  • Page 93 ASA101A User Manual support@electron.plus Once Pin 4 has been added, the software will automatically create Pins 2 and 3, then will ask for Pin 5: Fig. 108 Once Pin 5 has been added, the software will ask for Pin 8: 24.001 / 13 June 2024...
  • Page 94 ASA101A User Manual support@electron.plus Fig. 109 24.001 / 13 June 2024 94 / 109...
  • Page 95 ASA101A User Manual support@electron.plus When Pin 8 has been added, the software will automatically create Pins 6 & 7: Fig. 110 This process also works with square package components (like QFP's) as well as multi-row connectors. An example of a QFP (64 pins), this was done by defining only 8 locations (Pins 1,16,17,32,33,48,49 and 64): 24.001 / 13 June 2024...
  • Page 96 ASA101A User Manual support@electron.plus Fig. 111 Be sure to hit "Quick Save" regularly. **Components do not have to be inserted at end of the sequence - the software will automatically insert the new component after the currently selected component record.

  • Page 97: Moving A Pin

    ASA101A User Manual support@electron.plus .5.6.5 Moving a pin If a pin is placed in the wrong place, then it can be moved using the "Move Pin" button/function: 1. Select the Pin to move: Fig. 112 2. Press the "Move Pin" button, text will appear at the top of the PCB image ("Move Pin: Click on new location for Pin 1"), click the mouse pointer on the new location for the Pin:...
  • Page 98 ASA101A User Manual support@electron.plus Fig. 113 The Pin has been relocated to the new position: 24.001 / 13 June 2024 98 / 109...
  • Page 99 ASA101A User Manual support@electron.plus Fig. 114 Be sure to hit "Quick Save" regularly. 24.001 / 13 June 2024 99 / 109...

  • Page 100: Deleting Components/Pins

    ASA101A User Manual support@electron.plus .5.6.6 Deleting components/pins To delete a whole component, select any pin record that contains that component, then press the "Delete Whole Component" button: Fig. 115 The component record (in this example R448) that contained Pins 1 & 2 has been deleted.
  • Page 101 ASA101A User Manual support@electron.plus To delete a single pin record, select the pin and press the "Delete Single Pin Record", in this case 'C399, Pin 1' has been deleted: Fig. 116 Be sure to hit "Quick Save" regularly. 24.001 / 13 June 2024...

  • Page 102: Common/Grounding Importance

    ASA101A User Manual support@electron.plus ..5.7 Common/Grounding importance Analog signature analysis relies on examining the voltage vs current signature between two points in a circuit. In most circuitry this is between a supply rail (typically 0V) and the point-of-interest, however it doesn't have to be so.

  • Page 103: Capturing Golden Signatures

    ASA101A User Manual support@electron.plus ..5.8 Capturing Golden signatures Capturing 'golden' signatures should happen AFTER the test file has been setup and the test points have been chosen. Capturing signatures can be done either singly ("Single Capture") or automatically ("Auto Capture").
  • Page 104 ASA101A User Manual support@electron.plus Fig. 119 At anytime you can go back and recapture/overwrite a signature by selecting the test point on the photograph or in the TestTree. In the example below, the signature for "C1, Pin 2" has been improved by changing the frequency to 500Hz: Fig.
  • Page 105 ASA101A User Manual support@electron.plus harm in saving them as you go along. 24.001 / 13 June 2024 105 / 109...

  • Page 106: Auto Capture

    ASA101A User Manual support@electron.plus .5.8.2 Auto Capture Auto capture is very similar to single capture mode and is entered into in a similar way, by pressing the AUTO CAPTURE button. Once auto capture is enabled, you can probe the test point shown by the white crosshairs and the software will: 1.

  • Page 107: Performing A Test

    ASA101A User Manual support@electron.plus ..5.9 Performing a test Tests can be performed in either a manual test mode or an automatic test mode: .5.9.1 Manual Test Assuming that you have prepared a test plan and loaded it, connected an ASA, etc.
  • Page 108 ASA101A User Manual support@electron.plus Each time a test point is selected, the test parameters (voltage, frequency, resistance) associated with test point will load automatically. To stop this, deselect the V/R/Hz checkbox on the Test Controls area. When you have finished a test, you can save the file. This will save the results of your test and is useful for review at a later date or as part of quality control etc.

  • Page 109: Auto Test

    ASA101A User Manual support@electron.plus .5.9.2 Auto Test Similar to performing a manual test, you will have prepared a test plan and loaded it, connected an ASA, etc. Go to the first test point, either by pressing the "First" button in the Test Controls area or selecting the test point using the TestTree or clicking the test point on the board image.
