User Guide
Machine Types: 20LD, 20LE, 20LF, and 20LG

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 20LE and is the answer not in the manual?

Questions and answers

Related Manuals for Lenovo 20LE

Summary of Contents for Lenovo 20LE

  • Page 1 User Guide Machine Types: 20LD, 20LE, 20LF, and 20LG...
  • Page 2 • Safety and Warranty Guide • Setup Guide • “Important safety information” on page v The latest Safety and Warranty Guide, Setup Guide, and the Regulatory Notice are available on the Lenovo Support Web site at: http://www.lenovo.com/support First Edition (January 2018) ©...

  • Page 3: Table Of Contents

    Operating environment ... . Passwords introduction ..Lenovo programs ....Setting, changing, or removing a password . .
  • Page 4 Lenovo Support Web site ..102 Diagnosing problems with Lenovo Companion. . . Calling Lenovo ... . . 102 Troubleshooting ....
  • Page 5 Appendix G. Trademarks ..125 and Canada ....116 Recycling information for China ..116 © Copyright Lenovo 2018...
  • Page 6 User Guide...

  • Page 7: Important Safety Information

    • Avoid keeping your hands, your lap, or any other part of your body in contact with a hot section of the computer for any extended time. • Periodically take hands from using the keyboard by lifting your hands from the palm rest. © Copyright Lenovo 2018...
  • Page 8 Protect yourself from the heat generated by the ac power adapter. When the ac power adapter is connected to an electrical outlet and your computer, it generates heat. Extended contact with your body, even through clothing, may cause a skin burn.

  • Page 9: Conditions That Require Immediate Action

    In the unlikely event that you notice any of the following conditions, or if you have any safety concerns with your product, stop using the product and unplug it from the power source and telecommunication lines until you can speak to the Customer Support Center for further guidance. © Copyright Lenovo 2018...

  • Page 10: Service And Upgrades

    Replacement parts approved for customer installation are referred to as Customer Replaceable Units, or CRUs. Lenovo provides documentation with instructions when it is appropriate for customers to install options or replace CRUs. You must closely follow all instructions when installing or replacing parts.

  • Page 11: Power Cords And Power Adapters

    Never overload these devices. If power strips are used, the load should not exceed the power strip input rating. Consult an electrician for more information if you have questions about power loads, power requirements, and input ratings. © Copyright Lenovo 2018...

  • Page 12: Plugs And Outlets

    Plugs and outlets DANGER If a receptacle (power outlet) that you intend to use with your computer equipment appears to be damaged or corroded, do not use the outlet until it is replaced by a qualified electrician. Do not bend or modify the plug. If the plug is damaged, contact the manufacturer to obtain a replacement.

  • Page 13: External Devices

    Batteries supplied by Lenovo for use with your product have been tested for compatibility and should only be replaced with approved parts. A battery other than the one specified by Lenovo, or a disassembled or modified battery is not covered by the warranty.

  • Page 14: Notice For Non-Rechargeable Coin-Cell Battery

    Notice for non-rechargeable coin-cell battery DANGER If the coin-cell battery is incorrectly replaced, there is danger of an explosion. The battery contains a small amount of harmful substance. Do not heat to more than 100°C (212°F). The following statement applies to users in the state of California, U.S.A. California Perchlorate Information: Products containing manganese dioxide lithium coin-cell batteries may contain perchlorate.

  • Page 15: Heat And Product Ventilation

    • Do not restrict or block any ventilation openings. • Do not operate your computer inside furniture, as this might increase the risk of overheating. • Airflow temperatures into the computer should not exceed 35°C (95°F). xiii © Copyright Lenovo 2018...

  • Page 16: Electrical Current Safety Information

    Electrical current safety information DANGER Electric current from power, telephone, and communication cables is hazardous. To avoid a shock hazard: • Do not use your computer during a lightning storm. • Do not connect or disconnect any cables or perform installation, maintenance, or reconfiguration of this product during an electrical storm.

  • Page 17: Liquid Crystal Display (Lcd) Notice

    2 can be dangerous due to excessive sound pressure levels. If your Lenovo computer came with headphones or earphones in the package, as a set, the combination of the headphones or earphones and the computer already complies with the specifications of EN 50332-1. If different headphones or earphones are used, ensure that they comply with EN 50332-1 (Clause 6.5...

  • Page 18: Glass Parts Notice

    Glass parts notice CAUTION: Some parts of your product may be made of glass. This glass could break if the product is dropped on a hard surface or receives a substantial impact. If glass breaks, do not touch or attempt to remove it. Stop using your product until the glass is replaced by trained service personnel.

  • Page 19: Chapter 1. Product Overview

    This chapter provides basic information to help you get familiar with your computer. Computer controls, connectors, and indicators This section introduces hardware features of the computer. Front view Ambient light sensor Infrared camera (available on some models) Conventional camera (available on models with the Microphones infrared camera) © Copyright Lenovo 2018...
  • Page 20 TrackPoint pointing stick TrackPoint buttons Trackpad ® Your computer is equipped with the Lenovo-unique ThinkPad pointing device. For more information, see “Using the ThinkPad pointing device” on page 22. Fingerprint reader Fingerprint authentication provides simple and secure user access by associating your fingerprint with a password.

  • Page 21: Left-Side View

    The two USB-C connectors both work as the power connector. Use the shipped USB-C power adapter and power cord to connect the computer to ac power through the USB-C connector. Lenovo provides various USB-C accessories to help you expand your computer functionality. For more information, go to: http://www3.lenovo.com/us/en/accessories-and-upgrades/c/ACCESSORY?menu-id=Accessories_Upgrades...
  • Page 22 ThinkPad Pen Pro The ThinkPad Pen Pro is similar in size and shape to an actual ink pen, so touch actions and on-screen writing feel comfortable. Its high-level pressure sensitivity provides precise content creation. Click and eraser buttons are built into the pen and provide additional functionality to interact with data. For more information, see “ThinkPad Pen Pro”...

  • Page 23: Rear View

    Lenovo makes no comments, judgments, or warranties about the function, quality, or performance of the locking device and security feature. Cable locks for your product are available from Lenovo at https:// www.lenovoquickpick.com/...

  • Page 24: Bottom View

    5. Remove the card and store it safely for future use. Note: If you do not remove the card from your computer after you eject the card from the Windows operating system, the card can no longer be accessed. To access the card, you must remove it first, and then insert it again.
  • Page 25 Note: Depending on the model, your computer might look different from the following illustrations. Camera status indicator When this indicator is on, the camera is in use. Fn Lock indicator This indicator shows the status of Fn Lock function. For more information, see “Using the special keys” on page 20.

  • Page 26: Important Product Information

    • FCC ID and IC Certification information • Windows operating systems information Machine type and model information When you contact Lenovo for help, the machine type and model information helps the technicians to identify your computer and provide faster service. User Guide...

  • Page 27: Fcc Id And Ic Certification Number

    The following illustration shows where to find the machine type and model information of your computer. FCC ID and IC Certification number You can find the FCC and IC Certification information through one of the following methods: • Through an electronic-label screen (E-label screen) preinstalled on your computer. To view the E-label screen, see “Regulatory labels”...

  • Page 28: Computer Features

    installed, the installation program checks the computer firmware for a valid, matching Product ID to complete the activation. In some cases, an earlier Windows version might be preinstalled under the terms of the Windows 10 Pro license downgrade rights. Computer features The computer features introduced in this topic cover various models.

  • Page 29: Computer Specifications

    Security features • Conventional camera with camera shutter (available on some models) • Face authentication (available on models with the infrared camera) • Fingerprint reader • Password • Security-lock slot Wireless features • Bluetooth • NFC • Wireless local area network (WLAN) •...

  • Page 30: Lenovo Programs

    2. If you do not find the program in the program list, search for the program in the search box. An introduction to Lenovo programs This topic provides a brief introduction to Lenovo programs. Depending on your computer model, some of the programs might not be available.
  • Page 31 • Configure hardware settings. • Create and manage your Lenovo ID. This app is filled with exclusive Lenovo content to help you learn more about what you can do with your Lenovo computer. Chapter 1...
  • Page 32 User Guide...

  • Page 33: Chapter 2. Using Your Computer

    This chapter provides information to help you use the various features provided by your computer. Registering your computer When you register your computer, information is entered into a database, which enables Lenovo to contact you if there is a recall or other severe problem. In addition, some locations offer extended privileges and services to registered users.

  • Page 34: Operating Modes

    • Follow the “General tips for preventing problems” on page 71. • Diagnose problems yourself by using the preinstalled diagnostic software. See “Diagnosing problems with Lenovo Companion” on page 71. • Check for recovery solutions in Chapter 8 “Recovery information” on page 87.
  • Page 35 Attention: Do not rotate the computer display with too much force, otherwise the computer display or hinges might get damaged. Do not apply too much force to the upper-right or upper-left corner of the computer display. By rotating the display to different angle, your computer features the following four operating modes (also called YOGA Modes).

  • Page 36: Using The Multi-Touch Screen

    Notebook mode Stand mode Tent mode Tablet mode Using the multi-touch screen This topic provides instructions on how to use the multi-touch screen that is available on some models. Notes: • Your computer screen might look different from the following illustrations. •...
  • Page 37 Touch gesture (touch models Description only) Touch: Tap. Mouse action: Click. Function: Open an app or perform an action on an open app, such as Copy, Save, and Delete, depending on the app. Touch: Tap and hold. Mouse action: Right-click. Function: Open a menu with multiple options.

  • Page 38: Using The Special Keys

    Touch gesture (touch models Description only) Touch: Swipe in from the left edge. Mouse action: Click the task-view icon on the taskbar. Function: View all your open windows in task view. • Short swipe for full-screened app or when your computer is in the tablet mode Touch: Swipe downwards shortly from the top edge.
  • Page 39 1. Go to Control Panel, and then change the view of Control Panel from Category to Large icons or Small icons. 2. Click Lenovo - Keyboard Manager and the Keyboard Manager window is displayed. 3. Select the options of your preference.

  • Page 40: Using The Thinkpad Pointing Device

    • Fn+Spacebar: If your computer supports keyboard backlight, press Fn+Spacebar to switch between the different keyboard backlight status (off, low, or high). Note: If your computer is installed with Lenovo Companion 4.0 or later version, there are four modes for the keyboard backlight: Off, Low, High, and Auto.

  • Page 41: Using The Trackpoint Pointing Device

    By default, both the TrackPoint pointing device and the trackpad are active with the touch gestures enabled. To change the settings, see “Customizing the ThinkPad pointing device” on page 25. Using the TrackPoint pointing device The TrackPoint pointing device enables you to perform all the functions of a traditional mouse, such as pointing, clicking, and scrolling.

  • Page 42: Using The Trackpad

    Using the trackpad The entire trackpad surface is sensitive to finger touch and movement. You can use the trackpad to perform all the pointing, clicking, and scrolling functions of a traditional mouse. The trackpad can be divided into two zones: Left-click zone (primary-click zone) Right-click zone (secondary-click zone) To use the trackpad, see the following instructions:...

  • Page 43: Using The Trackpad Touch Gestures

    Using the trackpad touch gestures The entire trackpad surface is sensitive to finger touch and movement. You can use the trackpad to perform the same point and click actions as you would use a traditional mouse. You also can use the trackpad to perform various touch gestures.

  • Page 44: Replacing The Cap On The Pointing Stick

    Replacing the cap on the pointing stick The cap on the end of the pointing stick is removable. After you use the cap for a period of time, you might consider replacing the cap with a new one. Notes: • Ensure that you use a cap with grooves as shown in the following illustration.

  • Page 45: Using The Battery

    Using the battery When you use your computer away from electrical outlets, you depend on battery power to keep your computer running. Different computer components consume power at different rates. The more you use the power-intensive components, the faster you consume battery power. Spend more time unplugged with ThinkPad batteries.

  • Page 46: Managing The Battery Power

    • Recharge the battery completely before using it. You can see whether the battery is fully charged from the battery-status icon in the Windows notification area. • Always use power management features such as power-saving modes. Managing the battery power To achieve the best balance between performance and power saving, adjust your power plan settings.

  • Page 47: Cabled Ethernet Connections

    To attach an Ethernet cable to your computer, you need an Ethernet extension adapter. The Ethernet extension adapter is available as an option and shipped with some computer models. You can purchase an Ethernet extension adapter from Lenovo at http://www.lenovo.com/essentials DANGER To avoid the risk of electrical shock, do not connect the telephone cable to the Ethernet connector.

  • Page 48: Using The Wireless-Wan Connection

    Using the wireless-WAN connection Wireless wide area network (WAN), which uses cellular networks for data transmission, enables you to establish wireless connections over remote public or private networks. These connections can be maintained over a large geographical area by use of multiple antenna sites or satellite systems maintained by wireless service providers.

  • Page 49: Using The Nfc Devices

    Using the NFC devices Depending on the model, your computer might come with the near field communication (NFC) feature. NFC is a high-frequency and short-range wireless communication technology. By using NFC, you can establish radio communications between your computer and another NFC-enabled device over a few centimeters or inches.

  • Page 50: Using Audio Features

    If you want to configure the camera settings, open the Start menu and then click Lenovo Companion ➙ Hardware Settings ➙ Display, Camera & Audio/Media. Locate the Camera section and then follow the instructions on the screen to configure the camera settings.

  • Page 51: Using An External Display

    Infrared light-emitting diode (LED) The infrared LED emits infrared light. Normally the infrared light is invisible to the naked eyes. Infrared camera lens The infrared camera lens is used for creating the facial image of a user. Camera indicator When the camera indicator is on, the infrared camera is in the recognition mode. To set the infrared camera for face authentication, do the following: 1.
  • Page 52 • Up to 4096 x 2160 pixels / 60 Hz, with an external display connected to the USB-C (Thunderbolt 3 compatible) connector • Up to 4096 x 2160 pixels / 24 Hz, with an external display connected to the HDMI connector For more information about the external display, see the manuals that come with it.

  • Page 53: Traveling With Your Computer

    If you are traveling to another country or region, you might want to consider an appropriate ac power adapter for the country or region to which you are traveling. To purchase travel accessories, go to: http://www.lenovo.com/accessories Chapter 2 Using your computer...
  • Page 54 User Guide...

  • Page 55: Chapter 3. Enhancing Your Computer

    This chapter provides instructions on how to use hardware devices to expand your computer capabilities. Finding ThinkPad options If you want to expand the capabilities of your computer, Lenovo has a number of hardware accessories and upgrades to meet your needs. Options include memory modules, storage devices, network cards, port replicators or docking stations, batteries, power adapters, keyboards, mice, and more.
  • Page 56 Using the ThinkPad Pen Pro The following illustration shows the ThinkPad Pen Pro. Eraser button Click button You can perform the following operations with the ThinkPad Pen Pro: • To click or make a selection, tap the display once with the pen. •...
  • Page 57 15 seconds and 100% charged in about five minutes. Note: Ensure that your computer is on or in sleep mode. Otherwise, the pen will not be charged. The ThinkPad Pen Pro is also available as an option from Lenovo. To purchase the ThinkPad Pen Pro, go to: http://www.lenovo.com/accessories...
  • Page 58 User Guide...

  • Page 59: Chapter 4. Accessibility, Ergonomic, And Maintenance Information

    This chapter provides information about accessibility, ergonomic, and cleaning and maintenance. Accessibility information Lenovo is committed to providing users who have hearing, vision, and mobility limitations with greater access to information and technology. This section provides information about the ways these users can get the most out of their computer experience.
  • Page 60 If you prefer to type or enter data into your computer using a mouse, joystick, or other pointing device instead of a physical keyboard, you can use On-Screen Keyboard. On-Screen Keyboard displays a visual keyboard with all the standard keys. You can select keys using the mouse or another pointing device, or you can tap to select the keys if your computer supports multi-touch screen.

  • Page 61: Ergonomic Information

    Your computer provides industry-standard connectors that enable you to connect assistive devices. Documentation in accessible formats Lenovo provides electronic documentation in accessible formats, such as properly tagged PDF files or HyperText Markup Language (HTML) files. Lenovo electronic documentation is developed to ensure that visually impaired users can read the documentation through a screen reader.

  • Page 62: Cleaning And Maintenance

    Many ThinkPad product solutions are available to help you modify and expand your computer to best suit your needs. You can find some of these options at http://www.lenovo.com/ . Explore your options for docking solutions and external products that provide the adjustability and essentials features that you want.
  • Page 63 • Before moving your computer, be sure to remove any media, turn off attached devices, and disconnect cords and cables. • When picking up your open computer, hold it by the bottom. Do not pick up or hold your computer by the display.
  • Page 64 User Guide...

  • Page 65: Chapter 5. Security

    The following two types of hard disk passwords can help protect the information stored on the storage drive: • User hard disk password © Copyright Lenovo 2018...

  • Page 66: Setting, Changing, Or Removing A Password

    Lenovo cannot reset your passwords or recover data from the storage drive. You must take your computer to a Lenovo reseller or a marketing representative to have the storage drive replaced. Proof of purchase is required, and a fee will be charged for parts and service.

  • Page 67: Hard Disk Security

    Hard disk security To protect the computer from unauthorized security attacks, refer to the following tips to enhance security: • Set a power-on password as well as a hard disk password. For security, a longer password is recommended. • The hard disk drive built into your computer can be protected by UEFI BIOS. To provide reliable security, use the security chip and a security program with the Trusted Platform Module (TPM) management feature.

  • Page 68: Using The Fingerprint Reader

    1. Restart the computer. When the logo screen is displayed, press F1 to start the ThinkPad Setup program. 2. Select Security ➙ Security Chip by using the directional keys. 3. Press Enter. The Security Chip submenu opens. 4. Move to an item you want to set by using the directional keys. When the item is highlighted, press Enter. 5.
  • Page 69 Lenovo-authorized servicer or a marketing representative to have the password canceled. If you forget your hard disk password, Lenovo cannot reset your password or recover data from the storage drive. You must take your computer to a Lenovo-authorized servicer or a marketing representative to have the storage drive replaced.

  • Page 70: Deleting Data From Your Storage Drive

    • Move the data to the Recycle Bin, and then empty the Recycle Bin. • Format your storage drive, using the software to initialize it. • Use the recovery program provided by Lenovo to bring the storage drive back to the factory default settings.

  • Page 71: Using Firewalls

    Protecting data against viruses Lenovo provides a full version of antivirus software on your computer with a free 30-day subscription. After 30 days, you must renew the license to continue receiving the antivirus software updates. For more information about your antivirus software, see the help system of your antivirus software.
  • Page 72 User Guide...

  • Page 73: Chapter 6. Advanced Configuration

    8. After installing the device drivers, apply Windows Update to get the latest modules, for example the security patches. 9. Depending on your preference, install Lenovo programs. For information about Lenovo programs, see “Lenovo programs” on page 12. Note: After installing the operating system, do not change the initial UEFI/Legacy Boot setting in the ThinkPad Setup program.

  • Page 74: Installing Device Drivers

    Lenovo Companion is preinstalled on your computer and is ready to run. The only prerequisite is an active Internet connection. You can start the program manually, or you can use the schedule feature to enable the program to search for updates automatically at specified intervals.

  • Page 75: Configuring Thinkpad Setup

    Configuring ThinkPad Setup The ThinkPad Setup program menu lists various items about system configuration. Attention: The default configurations are already optimized for you. Improper change of the configurations might cause unexpected results. To configure ThinkPad Setup, do the following: 1. Restart the computer. When the logo screen is displayed, press F1. The ThinkPad Setup program starts. Note: If you are required to enter the supervisor password, enter the correct password.

  • Page 76: Updating The Uefi Bios

    • The computer must be engaged in the Preboot eXecution Environment (PXE). • A network-management program must be installed on the computer of the network administrator. For instructions on how to update the UEFI BIOS, go to http://www.lenovo.com/support BIOS menu This topic introduces the following BIOS menus of your computer: •...

  • Page 77: Config Menu

    • Preinstalled operating system license • UEFI Secure Boot • OA3 ID • OA2 Config menu Note: The BIOS menu items might change without notice. Depending on the model, the default value might vary. Network • Wake On LAN Values: Disabled, AC only, AC and Battery Description: The network administrator can turn on a computer from a management console by using the Wake on LAN feature.
  • Page 78 Description: Enable or disable the Wireless Auto Disconnection feature when the Ethernet cable is attached. If you select Enabled, the Wireless LAN function is automatically turned off when the Ethernet cable is attached. Note: The Wireless Auto Disconnection feature is not supported for the Ethernet connection through a USB port.
  • Page 79 Values: Disabled, Enabled Description: If you select Enabled, pressing the function keys directly inputs F1–F12. If you select Disabled, pressing the function keys directly initiates the special function printed as an icon on each key. To temporarily switch the above two functions, press Fn+Esc. Display •...
  • Page 80 – Maximize Performance: Reduce CPU throttling. • CPU Power Management Values: Disabled, Enabled Description: Enable or disable the power-saving feature that stops the microprocessor clock automatically when there are no system activities. Normally, it is not necessary to change the setting. •...

  • Page 81: Date/Time Menu

    Description: Enable or disable the Thunderbolt BIOS Assist mode. If you select Enabled, Thunderbolt ports are controlled by the BIOS instead of the operating system, power consumption is increased, and wake from Modern Standby mode is disabled. You can only set to Enabled on the Linux and the Windows 10 (earlier than version 1709) operating systems.
  • Page 82 Values: Disabled, Enabled Descriptions: Enable this option to prevent unauthorized users from changing any settings in ThinkPad Setup. To use this function, a supervisor password is required. • Password at Unattended Boot Values: Disabled, Enabled Descriptions: When this option is enabled, a password prompt is displayed when the computer is turned on or resumed from hibernation mode by an unattended event such as a Wake on LAN attempt.
  • Page 83 Descriptions: If the fingerprint is not authenticated, you can enter a password instead. If you have selected Normal, enter either the power-on password or the supervisor password; if you have selected High, supervisor password must be entered. • Password Authentication Values: Disabled, Enabled Descriptions: Enable this option to use password authentication when fingerprints are not available.
  • Page 84 Note: This item is set as Disabled by default when the OS Optimized Defaults on the Restart menu is set as Disabled. This item is set as Enabled by default when the OS Optimized Defaults is set as Enabled. • Windows UEFI Firmware Update Values: Enabled, Disabled Descriptions: Enable or disable the Windows UEFI Firmware Update feature.
  • Page 85 • Internal Storage Tamper Detection Values: Disabled, Enabled Descriptions: When this option is enabled, removing any internal storage device when your computer is in sleep mode will be detected. If you remove the internal storage device while the computer is in sleep mode, the computer will shut down when you wake it up, and any unsaved data will be lost.

  • Page 86: Startup Menu

    Descriptions: Change Owner EPOCH to a random value. Use this option to clear SGX user data. Device Guard • Device Guard Values: Disabled, Enabled Descriptions: This option is used to support Microsoft Device Guard. When this option is enabled, Intel Virtualization Technology, Intel VT-d Feature, Secure Boot, and OS Optimized Defaults are automatically enabled.

  • Page 87: Restart Menu

    Values: Disabled, Enabled Descriptions: Enable this option to lock the boot device priority order. Restart menu Note: The BIOS menu items might change without notice. Depending on the model, the default value might vary. • Exit Saving Changes Descriptions: Save the changes and restart the computer. •...
  • Page 88 Wake on LAN The network administrator can turn on a computer from a management console by using the Wake on LAN feature. When the Wake on LAN feature is enabled, many operations, such as data transfer, software updates, and flash updates of the UEFI BIOS, can be done remotely without remote attendance. The updating process can perform after normal working hours and on weekends, so that the users are not interrupted during work, and the LAN traffic is kept to a minimum.

  • Page 89: Chapter 7. Troubleshooting Computer Problems

    Note: If you are unable to isolate and repair the problem yourself after running Lenovo Companion, save and print the log files created by the program. You need the log files when you speak to a Lenovo technical support representative.

  • Page 90: Troubleshooting

    Lenovo Companion supports the hardware scan function. It combines diagnostic tests, system information collection, security status, and support information, along with hints and tips for optimal system performance. To run Lenovo Companion, see “Accessing Lenovo programs” on page 12. The troubleshooting information or the diagnostic programs might tell you that you need additional or updated device drivers or other software.

  • Page 91: Error Messages

    Error messages • Message: 0177: Bad SVP data, stop POST task. Solution: Checksum of the supervisor password in the EEPROM is not correct. The system board should be replaced. Have the computer serviced. • Message: 0183: Bad CRC of Security Settings in EFI Variable. Enter ThinkPad Setup. Solution: Checksum of the Security settings in the EFI Variable is not correct.

  • Page 92: Beep Errors

    Firmware Interface Specification. If the user selects “No”, all data will be kept, but the operating system or programs will not be able to create, modify, or delete data in the storage. If this error happens at a service center, Lenovo authorized service personnel will clean up the non-volatile system UEFI variable storage using the preceding solution.

  • Page 93: Memory Module Problems

    The following section describes some beep errors and the corresponding solutions. Note: Do not attempt to service a product yourself unless instructed to do so by the Customer Support Center or product documentation. Only use a Lenovo-authorized service provider to repair your product. Error codes...

  • Page 94: Ethernet Problems

    3. Run diagnostic programs. See “Diagnosing problems with Lenovo Companion” on page 71. Ethernet problems • Problem: My computer cannot connect to the network. Solution: Ensure that: – The cable is installed correctly. The network cable must be securely connected both to the Ethernet connector of your computer and to the RJ45 connector of the hub.

  • Page 95: Wireless-Lan Problem

    Wireless-LAN problem Problem: I cannot connect to the network using the built-in wireless network card. Solution: Ensure that: • The Airplane mode is off. • Your wireless-LAN driver is the latest version. • Your computer is within the range of a wireless access point. •...

  • Page 96: Keyboard Problems

    Note: If the Fn and function keys tab is not displayed, connect your computer to the Internet. Then download and install the ThinkPad Hotkey Features program from the Lenovo Support Web site. For more information, see “Installing device drivers” on page 56.
  • Page 97 – The ac power adapter is connected to the computer and the power cord is plugged into a working electrical outlet. – The computer is turned on. (Press the power button again for confirmation.) – The brightness level of the screen is appropriately set. If a power-on password is set, press any key to display the prompt for the power-on password and then type the correct password and press Enter.

  • Page 98: External Monitor Problems

    5. If more than two monitor types are displayed, select Generic PnP Monitor or Generic Non-PnP Monitor. 6. Click Properties. If you are prompted for an administrator password or confirmation, type the password or provide confirmation. 7. Click the Driver tab. 8.

  • Page 99: Audio Problems

    1. Connect the external monitor to the monitor connector, and then connect the monitor to an electrical outlet. 2. Turn on the external monitor and the computer. 3. Right-click on the desktop, and then click Display settings ➙ Display. Note: If your computer cannot detect the external monitor, click Detect in the Display window. 4.
  • Page 100 1. Go to Control Panel, and ensure that you view Control Panel by Category. 2. Click Hardware and Sound. 3. Click Sound. 4. Click the Recording tab in the Sound window. 5. Select Internal Microphone, and click Properties. 6. Click the Levels tab, and move the Microphone Boost slider upwards. 7.

  • Page 101: Fingerprint Reader Problems

    8. Play any sound through a music program. Ensure that sound comes from the headset attached directly to the computer. Fingerprint reader problems • Problem: The surface of the reader is dirty, stained, or wet. Solution: Gently clean the surface of the reader with a dry, soft, lint-free cloth. •...

  • Page 102: Power Problems

    • Problem: I receive an error message while the operating system is loading the desktop configuration after the POST is completed. Solution: Find solutions by searching for the error message at the following Web sites: – http://www.lenovo.com/support – https://support.microsoft.com/ Sleep and hibernation problems •...

  • Page 103: Solid-State Drive Problem

    Solution: If the microprocessor overheats, the computer automatically enters sleep mode to allow the computer to cool and to protect the microprocessor and other internal components. Check the settings for sleep mode. • Problem: The computer enters sleep mode immediately after the power-on self-test. Solution: Ensure that: –...

  • Page 104: Thinkpad Pen Pro Problem

    Control Panel by Category, and click Hardware and Sound ➙ Device Manager. If you are prompted for an administrator password or confirmation, type the password or provide confirmation. Refer to “Diagnosing problems with Lenovo Companion” on page 71 and run a diagnostic test of the USB connector.

  • Page 105: Chapter 8. Recovery Information

    After two consecutive failed boot attempts, the Windows recovery environment starts automatically. Then you can choose repair and recovery options by following the on-screen instructions. Note: Ensure that your computer is connected to ac power during the recovery process. © Copyright Lenovo 2018...

  • Page 106: Creating And Using A Recovery Usb Drive

    It is recommended that you create a recovery USB drive as early as possible. If you did not create a recovery USB drive as a precautionary measure, you can contact Lenovo Customer Support Center and purchase one from Lenovo. For a list of the Lenovo Support phone numbers for your country or region, go to: http://www.lenovo.com/support/phone Creating a recovery USB drive To create a recovery USB drive, you need a USB drive with at least 16 GB of storage capacity.

  • Page 107: Chapter 9. Replacing Devices

    If you intend on installing the CRU, Lenovo will ship the CRU to you. CRU information and replacement instructions are shipped with your product and are available from Lenovo at any time upon request. You might be required to return the defective part that is replaced by the CRU.

  • Page 108: Disabling The Built-In Battery

    Customer Replaceable Unit (CRU), do not open the static-protective package until the instructions direct you to install the part. When you handle options or CRUs, or perform any work inside the computer, take the following precautions to avoid static-electricity damage: •...

  • Page 109: Replacing The Base Cover Assembly

    1. Open the nano-SIM-card door 2. Gently push the nano-SIM card to eject it , and then slide it out of the slot 3. Insert a new nano-SIM card . Note the orientation of the new card and ensure that it is snapped into place.

  • Page 110: Replacing The Wireless-Wan Card

    The following information is only for models that support user-installable modules. Ensure that you use only a Lenovo-authorized wireless module specifically tested for this computer model. Otherwise, the computer will generate an error-code beep sequence when you turn on the computer.
  • Page 111 Attention: Do not touch the contact edge of the wireless-WAN card. Otherwise the wireless-WAN card might get damaged. To replace the wireless-WAN card, do the following: 1. Disable the built-in battery. See “Disabling the built-in battery” on page 90. 2. Ensure that the computer is turned off and disconnected from ac power and all cables. 3.

  • Page 112: Replacing The M.2 Solid-State Drive

    6. Install a new wireless-WAN card by doing the following: a. Align the contact edge of the new wireless-WAN card with the key in the slot. Then carefully insert the card into the slot at an angle of about 20 degrees .
  • Page 113 1. Disable the built-in battery. See “Disabling the built-in battery” on page 90. 2. Ensure that the computer is turned off and disconnected from ac power and all cables. 3. Close the computer display and turn the computer over. 4. Remove the base cover assembly. See “Replacing the base cover assembly” on page 91. 5.

  • Page 114: Replacing The Coin-Cell Battery

    If the coin-cell battery is incorrectly replaced, there is danger of an explosion. The coin-cell battery contains a small amount of harmful substance. To avoid possible injury: • Replace only with a battery of the type recommended by Lenovo. • Keep the battery away from fire.

  • Page 115: Replacing The Speaker Assembly

    5. Open the film and detach the connector. Then remove the coin-cell battery. 6. Install the new coin-cell battery and attach the connector. Then cover the battery with the film. 7. Reinstall the base cover assembly. 8. Turn the computer over. Connect the ac power adapter and all cables to the computer. Note: After you replace the coin-cell battery, reset the system date and time in the ThinkPad Setup program.
  • Page 116 4. Remove the base cover assembly. See “Replacing the base cover assembly” on page 91. 5. Open the film that covers the speaker connector and detach the connector from the system board. Then, remove the screws that secure the speaker assembly. 6.

  • Page 117: Replacing The Pen Charger

    7. Install the new speaker assembly in place. Correctly route and secure the cable. 8. Install the screws to secure the speaker assembly and attach the connector of the speaker assembly. Then cover the connector with the film. 9. Reinstall the base cover assembly. 10.
  • Page 118 5. Detach the connector from the system board and remove the screw that secure the pen charger. Then, remove the pen charger. 6. Note the orientation and place the pen charger to the correct location. Install the screw to secure the pen charger.

  • Page 119: Chapter 10. Getting Support

    • What is the serial number? Getting help and service If you need help, service, technical assistance, or more information about Lenovo products, you will find a wide variety of sources available from Lenovo to assist you. Information about your computer and preinstalled software, if any, is available in the documentation that comes with your computer or on the Lenovo Support Web site at http://www.lenovo.com/support...

  • Page 120: Lenovo Support Web Site

    • Lenovo hardware repair - If the problem is determined to be caused by Lenovo hardware under warranty, trained service personnel are available to provide the applicable level of service.

  • Page 121: Purchasing Additional Services

    Telephone numbers For a list of the Lenovo Support phone numbers for your country or region, go to http://www.lenovo.com/ support/phone or refer to the Safety and Warranty Guide that comes with your computer. Note: Phone numbers are subject to change without notice. The latest phone numbers are available at .
  • Page 122 User Guide...

  • Page 123: Appendix A. Supplemental Information About The Ubuntu Operating System

    The LLW also is preinstalled on the computer. To access the LLW, go to the following directory: /usr/share/doc/lenovo-doc If you cannot view the LLW either from the Web site or from your computer, contact your local Lenovo office or reseller to obtain a printed version of the LLW.
  • Page 124 User Guide...

  • Page 125: Appendix B. Regulatory Information

    Appendix B. Regulatory information This chapter provides regulatory and compliance information about Lenovo products. Certification-related information Product name: ThinkPad X1 Yoga Compliance ID: TP00076D Machine types: 20LD, 20LE, 20LF, and 20LG The latest compliance information is available at: http://www.lenovo.com/compliance Regulatory labels...

This manual is also suitable for:

20ldThinkpad x1 yoga20lf20lg

Table of Contents
