VA249QG/VA279QG/
VA279HG series
LCD Monitor
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VA249QG Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Asus VA249QG Series

Summary of Contents for Asus VA249QG Series

  • Page 1 VA249QG/VA279QG/ VA279HG series LCD Monitor User Guide...
  • Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification or alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.

  • Page 3: Table Of Contents

    Contents Contents ...................... iii Notices ......................iv Safety information ..................vi Care & Cleaning ..................vii Takeback Services ..................viii Product information for EU energy label ..........viii Chapter 1: Product introduction Welcome! ..................1-1 Package contents ................. 1-1 Monitor introduction ..............1-2 1.3.1 Front view ...............

  • Page 4: Notices

    All ASUS products with the ENERGY STAR logo comply with the ENERGY STAR standard, and the power management feature is enabled by default. The monitor and computer are automatically set to sleep after 10 and 30 minutes of user inactivity.
  • Page 5 NOTE: Energy Star is NOT supported on FreeDOS and Linux-based operating system. Canadian Department of Communications Statement This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.

  • Page 6: Safety Information

    Safety information • Before setting up the monitor, carefully read all the documentation that came with the package. • To prevent fire or shock hazard, never expose the monitor to rain or moisture. • Never try to open the monitor cabinet. The dangerous high voltages inside the monitor may result in serious physical injury.

  • Page 7: Care & Cleaning

    This symbol of the crossed out wheeled bin indicates that the product (electrical, electronic equipment, and mercury-containing button cell battery) should not be placed in municipal waste. Please check local regulations for disposal of electronic products. AEEE yönetmeliğine uygundur Care & Cleaning •...

  • Page 8: Takeback Services

    About Flicker https://www.asus.com/Microsite/display/eye_care_technology/ Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for our customers to be able to responsibly recycle our products, batteries and other components as well as the packaging materials.
  • Page 9 A third-party certification according to ISO 14024 Toward sustainable IT products Say hello to a more sustainable product IT products are associated with a wide range of sustainability risks throughout their life cycle. Human rights violations are common in the factories.

  • Page 11: Welcome

    Thank you for purchasing the ASUS LCD monitor! The latest widescreen LCD monitor from ASUS provides a broader, brighter and crystal-clear display, plus a host of features that enhance your viewing experience. With these features, you can enjoy the convenience and delightful visual...

  • Page 12: Monitor Introduction

    Monitor introduction 1.3.1 Front view Brightness Exit Power Energy Saving Brightness Exit Power Energy Saving Power indicator • The color definition of the power indicator is as the below table. Status Description White Amber Standby mode Central button: • Press this button to turn the monitor on during standby mode.
  • Page 13 • The size of the phone holder is 12.7 x 185.2 mm. Make sure your device fits into the groove. • You can paste the phone holder stickers on the inside of the front side of the groove to protect your device. ASUS VA249QG/VA279QG/VA279HG series LCD Monitor...

  • Page 14: Back View

    1.3.2 Back view VA279HG VA279QG / VA249QG DisplayPort. This port is for connection for a DisplayPort compatible device. HDMI port. This port is for connection with an HDMI compatible device. VGA port. This 15-pin port is for PC VGA connection. Earphone jack.

  • Page 15: Assembling The Monitor Arm/Base

    Attach the base into the arm, making sure the tab on the base fits into the groove on the arm. We recommend that you cover the table surface with soft cloth to prevent damage to the monitor. ASUS VA249QG/VA279QG/VA279HG series LCD Monitor...

  • Page 16: Detaching The Arm/Base (For Vesa Wall Mount)

    Detaching the arm/base (for VESA wall mount) The detachable arm/base of this monitor is specially designed for VESA wall mount. To detach the arm/base: Have the front of the monitor face down on a table. Press the release button and detach the stand (arm and base) from the monitor.

  • Page 17: Adjusting The Monitor

    • Hold the stand to prevent the monitor from falling when you change its angle. • The recommended adjusting angle is +23˚ to -5˚ (for tilt). -5°~+23° (Tilt) ASUS VA249QG/VA279QG/VA279HG series LCD Monitor...

  • Page 18: Connecting The Cables

    Input item in the OSD menu. If you need to replace the power cord or the connection cable(s), please contact ASUS customer service. Turning on the monitor Press the central or right button. See page 1-2 for the location of these buttons.

  • Page 19: Osd (On-Screen Display) Menu

    To exit and save the OSD meun, press the Left key repeatedly until the OSD menu disappears. To adjust other functions, repeat steps 1-5. • ASUS DisplayWidget Center: Displays a QR code for you to access the information about ASUS DisplayWidget Center. ASUS VA249QG/VA279QG/VA279HG series LCD Monitor...

  • Page 20: Osd Function Introduction

    Standard Mode DisplayPort Standard Mode Splendid sRGB Mode Scenery Mode Eye Care Theater Mode Game Mode Color ASUS DisplayWidget Center Night View Mode Learn More Reading Mode Image Darkroom Mode Input Back/Exit Enter • Standard Mode: Best choice for document editing with Splendid Video Enhancement.
  • Page 21 High energy blue light may lead to eye strain and AMD (Age-Related Macular Degeneration). Blue light filter reduces 70% (max.) of harmful blue light to avoid CVS (Computer Vision Syndrome) when the user adjusts blue light filter bar to maximum level. ASUS VA249QG/VA279QG/VA279HG series LCD Monitor...
  • Page 22 Color Augmentation: The adjusting range of color enhancement is from 0 to 100. This function is not available when sRGB Mode is selected in the Splendid menu. Color Set a desired color setting from this menu. ASUS VA249QG Splendid Input Brightness 1920x1080 120Hz Standard Mode...
  • Page 23 • Aspect Control: Adjusts the aspect ratio to Full or 1:1 Ratio. • ASCR: Turns on/off the ASCR (ASUS Smart Contrast Ratio) function. • Motion Sync: Offers a more clear mode while displaying motion pictures. Please note this function only works when the refresh rate is 100Hz or 120Hz.
  • Page 24 This function is not available when Motion Sync is enabled. Input In this function, you can select your desired input source or decide if you want the monitor to automatically search for input sources. ASUS VA249QG Splendid Input Brightness 1920x1080 120Hz...
  • Page 25 Alignment: This facilitates designers and users to organize content and layout on one page and achieve a consistent look and feel. Alignment 1 Alignment 2 Alignment Grid 1 Alignment Grid 2 ASUS VA249QG/VA279QG/VA279HG series LCD Monitor...
  • Page 26 Paper size: You can view the documents in real size on the screen. Letter Letter A4 (VA279HG/VA279QG only) Photo: The various real photo sizes displayed allow photographers and other users to accurately view and edit their photos in real size on the screen. 4x6,3x5,2x2 8x10,5x7 8x10...
  • Page 27 When a certain function is selected or activated, your shortcut key may not support. Available function choices for shortcut: Blue Light Filter, Splendid, Brightness, Contrast, Input, Color Temp., Volume, QuickFit, GamePlus, Rest Reminder, Color Augmentation, Energy Saving. ASUS VA249QG/VA279QG/VA279HG series LCD Monitor...

  • Page 28: Specifications Summary

    3.2 Specifications summary VA249QG/VA279QG Panel Type TFT LCD Panel size VA249QG: 23.8” (16:9, 60.45 cm) wide screen VA279QG: 27” (16:9, 68.5 cm) wide screen Max. Resolution 1920 x 1080 Pixel pitch VA249QG: 0.2745 mm VA279QG: 0.311 mm Brightness (Typ.) 300 cd/m Contrast Ratio (Typ.) 3000:1 Contrast Ratio (Max.)
  • Page 29 9, RoHs, CEC, TÜV Flicker free, TÜV Low Blue Light, SIOC, Windows 10 & 11 WHQL, PSB, Vietnam Energy, CECP, Vietnam Energy, FSC MIX *Specifications are subject to change without notice. **Measuring a screen brightness of 300 nits without audio/USB/Card reader connection. ASUS VA249QG/VA279QG/VA279HG series LCD Monitor 3-11...
  • Page 30 VA279HG Panel Type TFT LCD Panel size 27” (16:9, 68.5 cm) wide screen Max. Resolution 1920 x 1080 Pixel pitch 0.311 mm Brightness (Typ.) 300 cd/m Contrast Ratio (Typ.) 3000:1 Contrast Ratio (Max.) 100,000,000:1 (with ASCR on) Viewing angle (H/V) CR>10 178˚/178˚...
  • Page 31 9, RoHs, CEC, TÜV Flicker free, TÜV Low Blue Light, SIOC, Windows 10 & 11 WHQL, PSB, Vietnam Energy, CECP, Vietnam Energy, FSC MIX *Specifications are subject to change without notice. **Measuring a screen brightness of 300 nits without audio/USB/Card reader connection. ASUS VA249QG/VA279QG/VA279HG series LCD Monitor 3-13...

  • Page 32: Outline Dimensions

    Outline dimensions VA249QG 3-14 Chapter 3: OSD (On-Screen Display) menu...
  • Page 33 VA279QG 101,5 [4.0] 16,5 [0.7] 336,3 [13.2]-Active area 194,2 [7.6] 362,1 [14.3] 447,1 [17.6] 144,9 [5.7] 85,0 [3.3] 100,0 [3.9] ASUS VA249QG/VA279QG/VA279HG series LCD Monitor 3-15...
  • Page 34 VA279HG 101,5 [4.0] 16,5 [0.7] 336,3 [13.2]-Active area 194,2 [7.6] 362,1 [14.3] 447,1 [17.6] 144,9 [5.7] 85,0 [3.3] 100,0 [3.9] 3-16 Chapter 3: OSD (On-Screen Display) menu...

  • Page 35: Troubleshooting (Faq)

    • Ensure that the signal cable is properly connected to the monitor and the computer. • Adjust the volume settings of both your monitor and signal source. • Ensure that the computer sound card driver is properly installed and activated. ASUS VA249QG/VA279QG/VA279HG series LCD Monitor 3-17...

  • Page 36: Supported Operating Modes

    Supported operating modes Timing Resolution Input Source Horizontal Vertical Dot Clock Frequency Frequency Hz Frequency 640 x 480 HDMI/DP/VGA 31.47(N) 59.94(N) 25.18 640 x 480 HDMI/DP/VGA 37.5(N) 75.00(N) 31.5 800 x 600 HDMI/DP/VGA 37.88(P) 60.32(P) 800 x 600 HDMI/DP/VGA 46.86(P) 75.00(P) 49.5 1024 x 768...
