- Page 1 Setup Guide Mobibooth EDGE Version Date Author Comments 10-3-24 Initial release...
-
Page 2: Table Of Contents
Table of Contents Supported Devices ..................4 Introduction ..................... 5 Assembly Instructions ..................6 1. Attach tower baseplate ................6 2. Install the top tower tube ................. 6 3. Install top tube ..................7 4. Install portable speaker (optional) ............7 4. - Page 3 3. Select your event ..................21 4. Select accessories ................. 21 5. Select your Mobibooth controller ............21 6. Device type selection (not required) ............. 22 7. Editing animations ................. 22 Connecting the Camera to Snappic ............. 23 1. Open Snappic app .................. 23 2.
-
Page 4: Supported Devices
Supported Devices iPad Models iPad Air 13 (2024) iPad Pro 13 (2024 Surface Pro Models Surface Pro 8 Surface Pro 9 Surface Pro 10 Surface Pro 11 DSLR Camera Models Canon M50 Canon M50 Mark II Canon R50 Canon R100 (Recommended) Canon Rebel Series *Other cameras may be housed in the unit. -
Page 5: Introduction
Introduction Congratulations on your purchase of the new Mobibooth Edge. The Mobibooth EDGE turnkey photo booth system is a cutting-edge system leveraging iPad + DSLR/mirrorless or Surface Pro + DSLR/mirrorless camera technology to provide the best photographic results. Version 1... -
Page 6: Assembly Instructions
Assembly Instructions 1. Attach tower baseplate Flip bottom tower tube upside down and place baseplate on top. Install and tighten 4 bolts firmly (do not over- tighten) using T-handle tool. 2. Install the top tower tube Flip bottom tower tube with the attached baseplate over and place the top tower tube... -
Page 7: Install Top Tube
4. Install portable speaker (optional) Place portable Bluetooth speaker on shelf inside of top tower tube. This is an optional step and only required if you have purchased the EDGE Audio Kit. Version 1 Last modified October 3, 2024 Page... -
Page 8: Attach Head Assembly
4. Attach head assembly Attached the head assembly by placing the brackets located at the bottom of the head inside of the top tube. Install and tighten four bolts to secure the head. Version 1 Last modified October 3, 2024 Page... -
Page 9: Attach Printer Stand Baseplate
5. Attach printer stand baseplate Flip printer stand tower tube upside down and place baseplate on top. Install and tighten 4 bolts firmly (do not over- tighten) using T-handle tool. 6. Attach printer stand shelf Flip bottom printer stand tube with the attached baseplate over and attach printer stand shelf to tube using 4... -
Page 10: Connect Usb Printer Cable
7. Connect USB printer cable Connect USB printer cables between printer stand and main tower. Version 1 Last modified October 3, 2024 Page... -
Page 11: Electronics Installation
Electronics Installation 1. Rear door iPad installation Remove door blank from the rear door housing slot. Slide in the iPad with the USB-C connection side up into the rear door housing slot. Version 1 Last modified October 3, 2024 Page... - Page 12 Connect USB-C cable labeled IPAD DOOR to iPad. Version 1 Last modified October 3, 2024 Page...
-
Page 13: Front Ipad Installation
2. Front iPad installation Insert the front iPad with its camera on top and USB connection on left into the housing through the inside of the rear door. Connect USB-C cable labeled IPAD OR SURFACE to iPad. 3. Front iPad bracket installation Insert the 2 metal brackets with bumpers facing... -
Page 14: Camera Installation
4. Camera installation Rotate the mounting bracket up to the portrait orientation (up and down). Insert 2 washers onto the thumbscrew. Version 1 Last modified October 3, 2024 Page... - Page 15 Insert thumbscrew with 2 washers through the bracket slot. Add the included spacer/riser through the thumbscrew above the bracket slot (if needed) for smaller mirrorless cameras. Position the camera and screw the thumbscrew into the camera's tripod mount. Tighten as needed.
-
Page 16: Insert Dummy Battery
5. Insert dummy battery Rotate the camera down to the landscape position. Open the camera battery door and insert the included dummy battery with cable into the camera’s battery compartment. Close the camera battery door, ensuring the connecting cable is clear. -
Page 17: Connect Camera Usb-C Cable
6. Connect camera USB-C cable Plug the USB-C cable labeled CAMERA R100 into the camera. 7. Connect PC sync & hot shoe adapter Connect the included adapter to the PC sync cable. Version 1 Last modified October 3, 2024 Page... -
Page 18: Connect Power & Usb Printing Cable
Slide the PC sync and hot shoe adapter into the top camera hot shoe mount and tighten with the locknut. 8. Connect power & USB printing cable Pull out the power cable from the tower interior and plug it into the head power adapter. -
Page 19: Close And Secure Door
Pull out the USB-A printer cable from the tower interior and plug it into the head USB-A adapter cable. Close and secure door. Version 1 Last modified October 3, 2024 Page... -
Page 20: Bluetooth App Connectivity
Bluetooth App Connectivity As an owner of a Mobibooth photo kiosk, you have access to 10% off on any new Snappic subscription. To take advantage of Mobibooth exclusive savings go to https://mobibooth.co/getsnappic. In this section, we will demonstrate how to connect the Mobibooth RGBW Bluetooth®... -
Page 21: Select Your Event
This will bring up a list of all available Bluetooth devices. Your Mobibooth will start with MOBIBLE_. 5. Select your Mobibooth controller In the pop-up locate the Mobibooth Ring Light section. Pair with your Mobibooth tap the device listed there. -
Page 22: Device Type Selection (Not Required)
6. Device type selection (not required) It is no longer required that you specify a device type as the firmware in the hardware knows this. 7. Editing animations Once connected to the Bluetooth controller the app is able to customize several app states. -
Page 23: Connecting The Camera To Snappic
If you do not already have an account with Snappic you will need to create one at www.mobibooth.co/getsnappic and save doing so as a Mobibooth customer. 1. Open Snappic app Open the Snappic by tapping the app icon on the iPad’s screen. -
Page 24: Configure Camera
4. Configure camera Tap the Configure Camera button on the event details view. 5. Select camera Select the camera and iPad camera to use from the list presented in the dialog box. Note: Canon M50 was used in demonstration. If using another camera Snappic will show that camera. -
Page 25: Start Event
6. Start event Tap the start event button to begin using the app. For detailed software instructions refer to Snappic’s documentation at https://help.getsnappic.com. Recommended settings from Snappic can be found at https://help.snappic.com/en/articles/7177566-basic-camera-settings-for-a- canon-dslr-setup-with-snappic. Version 1 Last modified October 3, 2024 Page... -
Page 26: Troubleshooting
Trouble Shooting If you have connectivity issues try the following steps. 1. Power down the camera. 2. Unplug the USB cable from the camera. 3. Close the Snappic app on the iPad completely. 4. Reseat the USB-C cable to the iPad in the head. 5.
