- Page 1 Setup Guide Aura V2 Photo Kiosk Version Date Author Comments 6/22/22 Initial release 11/30/22 Updated tools & accessories 3/16/23 Removed Cloud, added Snappic Removed Mobibooth Cloud™ reference 5/25/23...
- Page 2 V e r s i o n 4 L a s t m o d i f i e d M a y 2 5 , 2 0 2 3 P a g e...
-
Page 3: Table Of Contents
6. Device type selection (not required) ........16 7. Editing animations ..............17 How to Pack Your Mobibooth Aura™ ..........18 V e r s i o n 4 L a s t m o d i f i e d M a y 2 5 , 2 0 2 3... - Page 4 V e r s i o n 4 L a s t m o d i f i e d M a y 2 5 , 2 0 2 3 P a g e...
-
Page 5: Supported Devices
Supported Devices iPad Models iPad Pro 11-inch (2018) iPad Pro 11-inch (2020) iPad Pro 11-inch (2021) iPad Pro 11-inch (2022) iPad Pro 12.9-inch (2018) iPad Pro 12.9-inch (2020) iPad Pro 12.9-inch (2021) iPad Pro 12.9-inch (2022) iPad Air (2022) V e r s i o n 4 L a s t m o d i f i e d M a y 2 5 , 2 0 2 3 P a g e... -
Page 6: Setup Video & Tools
Setup Video & Tools Setup video available at: https://mobibooth.co/aura/assemble In this video we cover: • What parts are included with your photo booth. • How to attach the baseplate. • How to stack and secure vertical tubes. • How to connect power cords. -
Page 7: Tools & Accessories
Tools & Accessories WHITE UNITS Tools and accessories stored in the black velvet hardware bag include: 1 - T-handle tool. 14 - hex head bolts (8 white, 6 all silver). 1 - Allen wrench (hex keys) used for repairs only. BLACK UNITS Tools and accessories stored in the black velvet hardware bag include: 1 - T-handle tool. -
Page 8: Assembly Instructions
Assembly Instructions 1. Unpack parts Unpack the top tube, bottom tube and baseplate carefully placing parts on the floor. Flip bottom tube upside down and place baseplate on top. 2. Attach baseplate Install and tighten 4 bolts snugly (do not over tighten) using T-handle tool. -
Page 9: Flip Lower Assembly
3. Flip lower assembly Pull the power cord from the bottom of the tube. Flip the assembly over so that the baseplate is now on the ground. 4. Connect power cables between tubes Ensure that all power cords and blocks are securely installed in the power strips within the lower... -
Page 10: Install The Top Tube
Connect the ring light power cord to the power block in the top tube. Plug the iPad USB power cord into the white power block. 5. Install the top tube Place the top tube onto the bottom tube with aligning green dots. -
Page 11: Install Four Tube Bolts
6. Install four tube bolts Install and tighten four bolts to secure the top tube to the bottom tube. Tighten bolts snug being careful to not over tighten them. 7. Attach head assembly Feed the wiring pigtail through the oval opening in the top of the pivoter. -
Page 12: Fasten Head Assembly
Attach the head assembly using the two front guide pins to line up the bolt holes. 8. Fasten head assembly Install and tighten two bolts at the rear of the head assembly base to secure it to the pivoter. V e r s i o n 4 L a s t m o d i f i e d M a y 2 5 , 2 0 2 3 P a g e... -
Page 13: Connect Power Cords
9. Connect power cords Push the head assembly forward to maximum forward angle to access the head pigtail and pivoter pigtail. Connect power cords for light (barrel connector) and iPad (USB-C). 10. Power unit Plug the extension cord into a standard 120 VAC outlet. -
Page 14: Bluetooth App Connectivity
Bluetooth App Connectivity As an owner of a Mobibooth photo kiosk, you have access to 10% off on any new Snappic subscription. To take advantage of Mobibooth exclusive savings go to https://mobibooth.co/getsnappic. In this section, we will demonstrate how to connect the Mobibooth RGBW Bluetooth®... -
Page 15: Select Your Event
This will bring up a list of all available Bluetooth devices. Your Mobibooth will start with MOBIBLE_. V e r s i o n 4 L a s t m o d i f i e d M a y 2 5 , 2 0 2 3... -
Page 16: Select Your Mobibooth Controller
5. Select your Mobibooth controller In the pop-up locate the Mobibooth Ring Light section. Pair with your Mobibooth tap the device listed there. 6. Device type selection (not required) It is no longer required that you specify a device type as the firmware in the hardware knows this. -
Page 17: Editing Animations
7. Editing animations Once connected to the Bluetooth controller the app is able to customize several app states. To edit an app mode, tap the Edit button. Tapping Preview will trigger the current LED settings to execute. V e r s i o n 4 L a s t m o d i f i e d M a y 2 5 , 2 0 2 3 P a g e... -
Page 18: How To Pack Your Mobibooth Aura
How to Pack Your Mobibooth Aura™ 1. Make sure 2. Place head case is on assembly a level in bottom surface. of case. surface. 3. Place 4. Place square baseplate foam pad in next. on top of diffuser. 5. Place 6.
