M O B I U S M 2 1 0 M I L L

QUICKSTART

GUIDE (1/3)

Position your Mobius M210 in your work area and lock

the castors.

While the perforated screens can be installed in any

orientation, the rasp screens are directional. Forward

motion of the rotor is clockwise so we want to install

the rasp screen with the openings facing to the right.

Once the milling screen is in place, close and lock the

door. Now we're ready to start milling!

Video instructions are available

online for your reference.

Now you can plug in the unit.

Ensure that the back edge of the screen slots into the

groove on the back panel of the chamber which will

then align it with the groove on the door.

Check the e-stop and, if it's engaged, release it.

1-866-874-6244 |

INFO@MOBIUSTRIMMER.COM | MOBIUSTRIMMER.COM

Need help?

Do you have a question about the M210 MILL and is the answer not in the manual?

Page 1 QUICKSTART Video instructions are available GUIDE (1/3) online for your reference. Position your Mobius M210 in your work area and lock Now you can plug in the unit. the castors. While the perforated screens can be installed in any Ensure that the back edge of the screen slots into the orientation, the rasp screens are directional.
Page 2 M O B I U S M 2 1 0 M I L L QUICKSTART Video instructions are available GUIDE (2/3) online for your reference. To start the machine, press the start. Then press the forward buttons. And crank up the speed to 11! Most of your milling activity will be performed at max speed.
Page 3 M O B I U S M 2 1 0 M I L L QUICKSTART Video instructions are available GUIDE (3/3) online for your reference. The M210 will mill 35 – 200 lbs per hour (15 – 90 kg per To work through the last half pound, adjust the rotor hour), but the last half pound can take up to 5 minutes speed down to 1 or 2 and run for 5 –...
