MiTAC 8060B Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SERVICE MANUAL FOR
SERVICE MANUAL FOR
SERVICE MANUAL FOR
Repair Technology Research Department /EDVD
Repair Technology Research Department /EDVD
8060B
8060B
8060B
8060B
8060B
8060B
8060B
8060B
8060B
8060B
8060B
8060B
BY:
Sissel Diao
Sissel Diao
Jun. 2003

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8060B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MiTAC 8060B

Summary of Contents for MiTAC 8060B

  • Page 1 SERVICE MANUAL FOR SERVICE MANUAL FOR SERVICE MANUAL FOR 8060B 8060B 8060B 8060B 8060B 8060B 8060B 8060B 8060B 8060B 8060B 8060B Sissel Diao Sissel Diao Repair Technology Research Department /EDVD Repair Technology Research Department /EDVD Jun. 2003...

  • Page 2: Table Of Contents

    8060 B N/B Maintenance 8060 B N/B Maintenance Contents 1. Hardware Engineering Specification ………………………………………………………………… 1.1 Introduction …………………………………………………………………………………………………………. 1.2 System Architecture ………………………………………………………………………………………………… 1.3 Electrical Characteristic …………………………………………………………………………………………… 2. System View and Disassembly ………………………………………………………………………... 2.1 System View ………………………………………………………………………………………………………… 2.2 System Disassembly ………………………………………………………………………………………………… 3. Definition & Location of Connectors / Switches …………………………………………………….. 3.1 Mother Board ………………………………………………………………………………………………………..
  • Page 3 8060 B N/B Maintenance 8060 B N/B Maintenance Contents 6. System Block Diagram ……………………………………………………………………………….. 7. Maintenance Diagnostics ……………………………………………………………………………… 7.1 Introduction ………………………………………………………………………………………………………… 7.2 Error Codes …………………………………………………………………………………………………………. 7.3 Maintenance Diagnostics …………………………………………………………………………………………… 8. Trouble Shooting ……………………………………………………………………………………… 8.1 No Power …………………………………………………………………………………………………………….. 8.2 No Display …………………………………………………………………………………………………………… 8.3 VGA Controller Failure LCD No Display …………………………………………………………………………...
  • Page 4 8060 B N/B Maintenance 8060 B N/B Maintenance Contents 9. Spare Parts List ……………………………………………………………………………………….. 10. System Exploded Views ……………………………………………………………………………… 11. Circuit Diagram ……………………………………………………………………………………… 12. Reference Material …………………………………………………………………………………...

  • Page 5: Hardware Engineering Specification

    1.1 Introduction 1.1.1 General Description This document describes the system hardware engineer specification for 8060B portable notebook computer system.The 8060B notebook computer is a new mainstream high performance thin and light notebook in the MiTAC notebook family. 1.1.2 System Overview - Mobile Intel Banias, 1.3-1.7GHz or above...
  • Page 6 8060 B N/B Maintenance 8060 B N/B Maintenance Continued to previous page Audio - Built-in AC97 V2.2 Codec - Sound Blaster Pro compatible - 3D stereo enhancement - Built-in mono microphone - Built-in 22W / 3ohm stereo speakers Audio DJ - 4 player buttons: Play/Pause, Next Track, Previous Track, Stop/Eject (support System Power-off play) - 1 push button and 1 LED for Audio DJ function On/Off (Push 1 second for turn-on, toggle for turn-off) - Automatically turn-off for CD player idle more than 5 minutes...

  • Page 7: System Architecture

    8060 B N/B Maintenance 8060 B N/B Maintenance 1. .2 System Architecture 1.2.2 Function Description 1.2.2.1 CPU Mobile Intel Banias processor with 400MT/s BPSB (100MHz) Capable of 478-pin, Micro-FCPGA processor package On-die 32KB instruction cache and 32KB write-back data cache On-die 1MB L2 cache Assisted Gunning Transceiver Logic (AGTL+) bus driver technology 1.2.2.2 Core Logic...
  • Page 8 8060 B N/B Maintenance 8060 B N/B Maintenance - AC’97 2.2 Interface - USB 1.1 and USB 2.0 Host Controllers 1.2.2.3 Memory Support 200/266MHZ SO-DIMMs DDR Memory expandable to 1024MB (2 SO-DIMM DDR slot). Slot1 Slot2 Total 64MB 64MB 64MB 64MB 128MB 64MB...
  • Page 9 8060 B N/B Maintenance 8060 B N/B Maintenance 1.2.2.4 I/O Ports CRT Port - Standard VGA compatible port - DDC1 and DDC2B compliant Signal Description Red analog video output GREEN Green analog video output BLUE Blue analog video output Monitor Sense Monitor Sense Ground Ground...
  • Page 10 8060 B N/B Maintenance 8060 B N/B Maintenance 7 Pins S-Video port for TV-Out - Support up 1024*768 resolution - Support PAL and NTSC system - Support Composite Output by a transfer cable System Input(Active) Resolution Active TV Lines Over/Under Scan NTSC 320 x 320 480 ~ 400...
  • Page 11 8060 B N/B Maintenance 8060 B N/B Maintenance IEEE 1394 Port - Supports serial bus data rates of 100, 200, and 400Mbits/second - The Asynchronous and Isochronous data transfers are supported - One IEEE1394 port supported Signal Name Description TPB- TPB+ TPA- TPA+...
  • Page 12 8060 B N/B Maintenance 8060 B N/B Maintenance RJ-11 - Connection to Modem Daughter Board Connector - Support 56Kbps/V.90 Signal Name Direction Description No Connect LINE + Phone Line Positive LINE – Phone Line Negative No Connect Table 6. Modem Port Figure 3.
  • Page 13 8060 B N/B Maintenance 8060 B N/B Maintenance Infrared interface supporting IRDA format - FIR IrDA 1.1 compliant. - HP-SIR supported. USB Ports - Three industry standard USB 2.0 ports - Support MAX. Power Current 500mA each port Signal Name Direction Description USB Device Power (+5VDC)
  • Page 14 8060 B N/B Maintenance 8060 B N/B Maintenance Signal Name Direction Description STROBE# Data Strobe PP Data bit 0 PP Data bit 1 PP Data bit 2 PP Data bit 3 PP Data bit 4 PP Data bit 5 PP Data bit 6 PP Data bit 7 -ACK Printer Acknowledge...

  • Page 15: Pc Card Slot

    8060 B N/B Maintenance 8060 B N/B Maintenance 1.2.2.5 PC Card Slot One Type II/I slot supporting the 1997 PC Card standard,and including full R2 (16-bit) and 32-bit Cardbus data transfer TI PCI4510 (PCMCIA Controller) & TI TPS2211A (Power Switch) 1.2.2.6 Graphical Subsystem nVIDIA NV34M graphical controller AGP4X including power management pins...

  • Page 16: Ide Interface

    8060 B N/B Maintenance 8060 B N/B Maintenance 1.2.2.8 IDE Interface Support Dual Independent IDE Channels, One is Hard Disk. The other one is Optical Device Supports PIO mode 0,1,2,3,4 and Ultra DMA 33/66/100 1.2.2.9 Read Only Memory (BIOS Flash) Fully compatible with industry standard software including Windows 2000 &...

  • Page 17: Keyboard Controller

    8060 B N/B Maintenance 8060 B N/B Maintenance Thermal management Fully US EPA Energy Start compliant 1.2.2.11 Keyboard Controller Hitachi H8-3437S 1.2.2.12 Super I/O NS PC87393F LPC interface Ultra I/O 1.2.2.13 LEDs Indicator HDD & CDROM & NUM & CAP & SCROLL & Wireless LAN & Audio DJ POWER 1.2.2.14 Buttons One Power Button 7 Audio Control Buttons...

  • Page 18: Touch Pad Module

    8060 B N/B Maintenance 8060 B N/B Maintenance 1.2.2.15 Touch Pad Module Synaptics TM41P-350 with two Buttons 1.2.2.16 Audio DJ Seven Audio Control Buttons - PLAY_PAUSE - NEXT_TRK/SCAN_FW - PREV_TRK/SCAN_RW - STOP_EJECT - Volume up (Digital Volume Control) - Volume Down (Digital Volume Control) - Power on / off Audio DJ Allowing CD play while the notebook is OFF Low power consumption...
  • Page 19 8060 B N/B Maintenance 8060 B N/B Maintenance 1.2.2.17 MODEM (MDC) - Option Signal Name Signal Name MONO_OUT MODEM_SPK Pull Up to +3V ACSYNC ACSDOUT MSDIN -ACRST MSDIN ACBITCLK Table 10. Modem Daughter Board Connector 1.2.2.18 Mini PCI MiniPCI Specification V1.0 802.11b wireless LAN (optional) with built-in Antenna...

  • Page 20: Electrical Characteristic

    8060 B N/B Maintenance 8060 B N/B Maintenance 1.3 Electrical Characteristic 1.3.1 Power On Sequence Plug in AC Adapter or Main Battery (11) H_PWRGD (Banias) PWR_ON VDMAIN -H8_RESET -5VA (13) -HCPURST DC/DC PWN IMP811 Controller -3VA (MAX1999) Press Power Button (12)-PCIRST MCH-M (Odem)
  • Page 21 8060 B N/B Maintenance 8060 B N/B Maintenance 1.3.2 Power On Suspend Sequence (1) -STPCLK ICH4M (Banias) (3) -CPUSLP (82801DBM) 1. Press LID Process Stop Grant Cycle 1. –STPCLK (High -> Low) 2. Select Windows Standby 2. After CPU Stop Grant Cycle, the ICH4M will 3.
  • Page 22 8060 B N/B Maintenance 8060 B N/B Maintenance 1.3.4 Suspend To RAM Sequence 1. Press LID Button 2. Select Windows Standby Function 3. Press Internal Keyboard Fn+F12 (1) -STPCLK (Banias) Process Stop Grant Cycle ICH4M Graphics (2) -CPUSLP (82801DBM) (NVIDIA NV18-PRO) 1.
  • Page 23 8060 B N/B Maintenance 8060 B N/B Maintenance 1.3.5 Resume from Suspend To RAM Sequence (4) -STPCLK (Banias) Process Stop Grant Cycle 1. Press LID Button 2. Select Windows Standby Function Graphics (4) -CPUSLP 3. Press Internal Keyboard Fn+F12 (NVIDIA NV18-PRO) Turn On DC/DC Circuitry ICH4M...
  • Page 24 8060 B N/B Maintenance 8060 B N/B Maintenance 1.3.6 Suspend to Disk Sequence (Banias) Produce Stop Grant Cycle (2) -CPUSLP (1) -STPCLK ICH4M Graphics (82801DBM) (4) -PCIRST (3) SUS_STAT (NVIDIA NV18-PRO) 1. STPCLK (High -> Low) Turn Off 2. Produce –CPUSLP 3.
  • Page 25 8060 B N/B Maintenance 8060 B N/B Maintenance 1.3.7 ICH4-M (82801DBM) GPI/O Pin Define Pin Name Signal Name Power Plane Type Original During Immediately S4/S5 Description Plane Type PCIRST# after PCIRST# GPIO0/REQA# -PCI_REQA +3.3VS Driven GPIO1/REQB#/REQ5# -PCI_REQB +3.3VS Driven GPIO2/PIRQE# -PCI_INTE +3.3VS High - 2...
  • Page 26 8060 B N/B Maintenance 8060 B N/B Maintenance Continued to the previous table Pin Name Signal Name Power Type Original During Immediately S4/S5 Description Plane Plan Type PCIRST# after PCIRST# GPIO23 SSMUXSEL/TP +3.3VS GPIO24 PCLKRUN +3.3VS High GPIO25 -1394PWR +3.3V_ICH High High High...
  • Page 27 8060 B N/B Maintenance 8060 B N/B Maintenance 1.3.8 Keyboard Controller Pin Define Port Signal Name Type Connect To Description 79~72 P10~P17 KO[0:7] Internal Keyboard Keyboard Matrix 67~60 P20~P27 KO[8:15] Internal Keyboard Keyboard Matrix 82~89 P30~P37 SD[0:7] Super I/O ISA Data Bus -CONN_RW OZ165 Audio DJ Scan RW...
  • Page 28 8060 B N/B Maintenance 8060 B N/B Maintenance Continued to the previous table Port Signal Name Type Connect To Description -ADEN D/D Connector Adaptor in -CONN_PLAYPAUSE OZ165 Audio DJ Play and Pause -BATT_EDAD Power Circuitry Indicated the battery capacity is not enough to power on system LAN/CARD BUS If system on suspend mode, then received this signal &...
  • Page 29 8060 B N/B Maintenance 8060 B N/B Maintenance Continued to the previous table Port Signal Name Type Connect To Description -H8_MCCS Super I/O Port 60h/64h chip select -IOW Super I/O Input/Output Write -IOR Super I/O Input/Output Red -H8_KBCS Super I/O Port 62h/66h chip select H8_A20GATE ICH3M...

  • Page 30: System View And Disassembly

    8060 B N/B Maintenance 8060 B N/B Maintenance 2. System View and Disassembly 2.1 System View 2.1.1 Front View Turn Down Button Turn Up Button Stop/Eject Button Play/Pause Button Button Button CD/DVD-ROM Power Button External Microphone Jack Line Out Phone Jack Line Out Phone Jack Top Cover Latch Hard Disk Drive...

  • Page 31: Right-Side View

    8060 B N/B Maintenance 8060 B N/B Maintenance 2.1.3 Right-side View PCMCIA Card Socket IR Sensor 2.1.4 Rear View Power Connector USB Ports 1394 Jack RJ-45 Connector Parallel Port VGA Port System Fan S-Video Output Connector Kensington Lock RJ-11 Connector Ventilation Openings...

  • Page 32: Bottom View

    8060 B N/B Maintenance 8060 B N/B Maintenance 2.1.5 Bottom View Wireless Card Battery Pack Extend SO-DIMM Hard Disk Drive 2.1.6 Top-open View Battery Charge Indicator Battery Power Indicator AC Power Indicator Microphone Keyboard Touch Pad LCD Screen Device Indicators Power Button...

  • Page 33: System Disassembly

    8060 B N/B Maintenance 8060 B N/B Maintenance 2.2 System Disassembly The section discusses at length each major component for disassembly/reassembly and show corresponding illustrations. Use the chart below to determine the disassembly sequence for removing components from the notebook. NOTE: 1.
  • Page 34 8060 B N/B Maintenance 8060 B N/B Maintenance 2.2.1 Battery Pack 2.2.2 Keyboard 2.2.3 HDD Module Modular Components 2.2.4 CD-ROM Drive 2.2.5 Wireless Card 2.2.6 LCD Assembly NOTEBOOK LCD Assembly Components 2.2.7 Inverter Board 2.2.8 LCD Panel 2.2.9 CPU 2.2.10 SO-DIMM 2.2.11 Modem Card 2.2.12 D/D Board Base Unit Components...

  • Page 35: Battery Pack

    8060 B N/B Maintenance 8060 B N/B Maintenance 2.2.1 Battery Pack Disassembly 1. Carefully put the notebook upside down. 2. Slide the release lever to the “unlock” ( ) position ( ), while take the battery pack out of the compartment ( ). (Figure 2-1) Figure 2-1 Remove the battery pack Reassembly...
  • Page 36 8060 B N/B Maintenance 8060 B N/B Maintenance 2.2.2 Keyboard Disassembly 1. Remove the battery pack. (See section 2.2.1 Disassembly) 2. Open the top cover. 3. Loosen the four latches locking the keyboard. (Figure 2-2) Figure 2-2 Loosen the four latches Figure 2-3 Disconnect the cable 4.

  • Page 37: Hdd Module

    8060 B N/B Maintenance 8060 B N/B Maintenance 2.2.3 HDD Module Disassembly 1. Carefully put the notebook upside down. 2. Remove the battery pack. (See section 2.2.1 Disassembly) 3. Remove one screw and slide out the HDD compartment cover. (Figure 2-4) 4.

  • Page 38: Cd/Dvd-Rom Drive

    8060 B N/B Maintenance 8060 B N/B Maintenance 2.2.4 CD/DVD-ROM Drive Disassembly Disassembly 1. Carefully put the notebook upside down. Remove the battery pack. (See section 2.2.1 Disassembly) 2. Remove the HDD module. (See section 2.2.3 Disassembly) 3. Remove one screw fastening the CD/DVD-ROM drive. (Figure 2-6) 4.

  • Page 39: Wireless Card

    8060 B N/B Maintenance 8060 B N/B Maintenance 2.2.5 Wireless Card Disassembly Complete the steps in Section 2.2 to prepare the system for disassembly. 1. Remove the battery pack. (See section 2.2.1 Disassembly) 2. Remove two screws fastening the mini PCI cover. (Figure 2-8) 3.
  • Page 40 8060 B N/B Maintenance 8060 B N/B Maintenance Reassembly 1. To install the wireless card, match the wireless card’s notched part with the socket’s projected part and firmly insert the card into the socket. Then push down until the retaining clips lock the card into the socket. 2.
  • Page 41 8060 B N/B Maintenance 8060 B N/B Maintenance 2.2.6 LCD ASSY Disassembly 1. Remove the battery pack and keyboard. (See sections 2.2.1 and 2.2.2 Disassembly) 2. Carefully upside down the notebook, then remove two screws on the bottom of the notebook. (Figure 2-10) 3.
  • Page 42 8060 B N/B Maintenance 8060 B N/B Maintenance 5. To remove the hinge cover, unscrew three screws. (Figure 2-12) 6. Disconnect the LCD cables from the mother board ( ) and Pull out the antenna from the KB cable’s compartment ( ).

  • Page 43: Inverter Board

    8060 B N/B Maintenance 8060 B N/B Maintenance 2.2.7 Inverter Board Disassembly 1. Remove the battery pack, keyboard and LCD assembly. (See sections 2.2.1, 2.2.2 and 2.2.6 Disassembly) 2. Remove six rubber pads and six screws fastening the LCD cover. (Figure 2-14) 3.

  • Page 44: Lcd Panel

    8060 B N/B Maintenance 8060 B N/B Maintenance 2.2.8 LCD Panel Disassembly 1. Remove the battery pack, keyboard, and LCD assembly. (See sections 2.2.1 to 2.2.2 and 2.2.6 Disassembly) 2. Remove the LCD cover. (See the step 1 to 3 of section 2.2.7 Disassembly) 3.
  • Page 45 8060 B N/B Maintenance 8060 B N/B Maintenance 2.2.9 CPU Disassembly 1. Remove the battery pack, keyboard, HDD module, CD/DVD-ROM drive and LCD assembly. (See sections 2.2.1 to 2.2.6 Disassembly) 2. Turn the four hex nuts to left to unscrew it completely. (Figure 2-17) 3.
  • Page 46 8060 B N/B Maintenance 8060 B N/B Maintenance 4. Remove three screws fastening the mother board ASSY. (Figure 2-19) 5. Disconnect the two speaker cables ( ); MDC wire ( ); cover switch cable ( ); MIC wire ( ); Audio cable ( ). (Figure 2-20) Figure 2-19 Remove the three screws Figure 2-20 Disconnect all the cables and wires...
  • Page 47 8060 B N/B Maintenance 8060 B N/B Maintenance 7. Disconnect the TP & MB cable. Now you can separate the system board ASSY. (Figure 2-21) 8. To remove the heatsink ASSY, remove four spring screws fastening the heatsink ASSY and disconnect the fan’s power cord.
  • Page 48 8060 B N/B Maintenance 8060 B N/B Maintenance 7. Using a flat screwdriver, rotate the lock of the CPU socket until the arrow points to the “O” position for removing the CPU. (Figure 2-23) Figure 2-23 Remove the CPU Reassembly 1.
  • Page 49 8060 B N/B Maintenance 8060 B N/B Maintenance 6. Reconnect the two speaker cables ( ); MDC wire ( ); cover switch cable ( ); MIC wire ( ); Audio cable ( ). 7. Fasten the mother board by three screws. 8.
  • Page 50 8060 B N/B Maintenance 8060 B N/B Maintenance 2.2.10 SO-DIMM 2.2.10.1 Extend SO-DIMM Disassembly 1. Remove the battery pack. (See section 2.2.1 Disassembly) 2. Remove two screws locking the extend SO-DIMM compartment cover. (Figure 2-24) 3. Full the retaining clips outwards ( ) and remove the SO-DIMM ( ). (Figure 2-24) Figure 2-24 Remove the extend SO-DIMM cover Figure 2-24 Remove the extend SO-DIMM Reassembly...
  • Page 51 8060 B N/B Maintenance 8060 B N/B Maintenance 2.2.10 SO-DIMM 2.2.10.2 Extend SO-DIMM Disassembly 1. Remove the mother board ASSY. (See the step 1 to 7of section 2.2.1 Disassembly) 2. Full the retaining clips outwards ( ) and remove the SO-DIMM ( ). (Figure 2-25) Figure 2-25 Remove the SO-DIMM Figure 2-25 Remove the SO-DIMM Reassembly...

  • Page 52: Modem Card

    8060 B N/B Maintenance 8060 B N/B Maintenance 2.2.11 Modem Card Disassembly 1. Remove the battery pack, keyboard, HDD module, CD/DVD-ROM drive and LCD assembly. (See sections 2.2.1 to 2.2.6 Disassembly) 2. Remove the mother board ASSY. (See the step 1 to 7of section 2.2.1 Disassembly) 3.
  • Page 53 8060 B N/B Maintenance 8060 B N/B Maintenance 2.2.12 D/D Board Disassembly 1. Remove the battery pack, keyboard, HDD module, CD/DVD-ROM drive and LCD assembly. (See sections 2.2.1 to 2.2.6 Disassembly) 2. Remove the mother board ASSY. (See the step 1 to 7of section 2.2.1 Disassembly) 3.

  • Page 54: Mother Board

    8060 B N/B Maintenance 8060 B N/B Maintenance 2.2.13 Mother Board Disassembly 1. Remove the battery pack, keyboard, HDD module, CD/DVD-ROM drive and LCD assembly. (See sections 2.2.1 to 2.2.6 Disassembly) 2. Remove the heatsink, CPU, SO-DIMM, modem card, D/D board. (See section 2.2.9 to 2.2.12 Disassembly) 3.

  • Page 55: Audio Board

    8060 B N/B Maintenance 8060 B N/B Maintenance 2.2.14 Audio Board Disassembly 1. Remove the battery pack, keyboard, HDD module, CD/DVD-ROM drive and LCD assembly. (See sections 2.2.1 to 2.2.6 Disassembly) 2. Remove the mother board ASSY. (See the step 1 to 7of section 2.2.1 Disassembly) 3.

  • Page 56: Touch Pad Board

    8060 B N/B Maintenance 8060 B N/B Maintenance 2.2.15 Touch Pad Board Disassembly 1. Remove the battery pack, keyboard, HDD module, CD/DVD-ROM drive and LCD assembly. (See sections 2.2.1 to 2.2.6 Disassembly) 2. Remove the mother board ASSY. (See the step 1 to 7of section 2.2.1 Disassembly) 3.
  • Page 57 8060 B N/B Maintenance 8060 B N/B Maintenance 2.2.16 Touch Pad Module Disassembly 1. Remove the battery pack, keyboard, HDD module, CD/DVD-ROM drive and LCD assembly. (See sections 2.2.1 to 2.2.6 Disassembly) 2. Remove the mother board ASSY. (See the step 1 to 7of section 2.2.1 Disassembly) 3.

  • Page 58: Definition & Location Of Connectors / Switches

    8060 B N/B Maintenance 8060 B N/B Maintenance 3. Definition & Location of Connectors / Switches 3.1 Main Board (Side A) – 1 J1 : FAN Connector J2 : RJ11 Connector J3 : Secondary EIDE Connector J4 : LCD Connector J5 : S-Video Connector J6 : USB Port Connector J7 : Primary EIDE Connector...
  • Page 59 8060 B N/B Maintenance 8060 B N/B Maintenance 3. Definition & Location of Connectors/ Switches 3.1 Main Board (Side A) – 2 ------ Continued to previous page ------ J14 : RTC Battery Connector J15 : Internal Keyboard Connector J16 : PCMCIA Card Bus Socket J18 : LAN (RJ45) Connector J19 : IEEE1394 Connector J20 : USB Port Connector...

  • Page 60: Main Board (Side B)

    8060 B N/B Maintenance 8060 B N/B Maintenance 3. Definition & Location of Connectors/ Switches 3.1 Main Board (Side B) J501 : MDC Jump Wire Connector J502 : Left Internal Speaker Connector J501 J502 J504 : DDR SO-DIMM Module Socket J505 : Internal Microphone Connector J509 J504...

  • Page 61: Audio Dj Board

    8060 B N/B Maintenance 8060 B N/B Maintenance 3. Definition & Location of Connectors / Switches 3.2 Audio DJ Board SW501 : Volume Up Switch SW502 : STOP/EJECT Switch Side A SW503 : PLAY/PAUSE Switch J502 SW504 : FF Switch SW507 SW501 SW502...

  • Page 62: Dc To Dc Board

    8060 B N/B Maintenance 8060 B N/B Maintenance 3. Definition & Location of Connectors / Switches 3.3 DC to DC Board Side A J501 : DC to DC Board Connector PU504 : LTC3707 (DDR_2.5V) DC to DC Converter J501 PU504 Side B J1 : Inverter Board Connector SW1 : Power Switch...

  • Page 63: Definition & Location Of Major Components

    8060 B N/B Maintenance 8060 B N/B Maintenance 4. Definition & Location of Major Components 4.1 Main Board (Side A) U1 : Intel Pentium M Processor U3 : Intel 82855GM Memory Controller Hub (Odem) U8 : NVIDIA NV18M VGA Controller U9 : RTL8101L LAN Controller U12 : Flash ROM (BIOS) U17 : ALC202 Audio CODEC...
  • Page 64 8060 B N/B Maintenance 8060 B N/B Maintenance 4. Definition & Location of Major Components 4.1 Main Board (Side B) U505 : OZ165 Audio DJ Controller U506 : ICS950810 Clock Generator U515 U507 : Intel 82801DBM I/O Controller Hub 4 Mobile (ICH4-M) U515 : PC87393 Super I/O Controller U506...

  • Page 65: Pin Description Of Major Component

    8060 B N/B Maintenance 8060 B N/B Maintenance 5. Pin Descriptions of Major Components 5.1 Intel Pentium M Processor Signal Name Type Description Signal Name Type Description A[31:3]# A[31:3]# (Address) define a 2 32 -byte physical memory address space. BPRI# BPRI# (Bus Priority Request) is used to arbitrate for ownership of the In sub-phase 1 of the address phase, these pins transmit the address of a processor system bus.
  • Page 66 8060 B N/B Maintenance 8060 B N/B Maintenance 5.1 Intel Pentium M Processor Signal Name Type Description Signal Name Type Description DBSY# DBSY# (Data Bus Busy) is asserted by the agent responsible for driving DPWR# DPWR# is a control signal from the Intel 855PM and Intel 855GM data on the processor system bus to indicate that the data bus is in use.
  • Page 67 8060 B N/B Maintenance 8060 B N/B Maintenance 5.1 Intel Pentium M Processor Signal Name Type Description Signal Name Type Description INIT# INIT# (Initialization), when asserted, resets integer registers inside the PWRGOOD PWRGOOD (Power Good) is a processor input. The processor requires processor without affecting its internal caches or floating-point registers.
  • Page 68 8060 B N/B Maintenance 8060 B N/B Maintenance 5.1 Intel Pentium M Processor Signal Name Type Description Signal Name Type Description Processor core power supply. SMI# SMI# (System Management Interrupt) is asserted asynchronously by VCCA provides isolated power for the internal processor core PLL’s. VCCA[3:0] system logic.

  • Page 69: Intel 82855Gm Memory Controller Hub (Odem)

    8060 B N/B Maintenance 8060 B N/B Maintenance 5.2 Intel 82855GM Memory Controller Hub (Odem) Host Interface Signals Host Interface Signals Continue Signal Name Type Description Signal Name Type Description Address Strobe: The system bus owner asserts ADS# to indicate ADS# DINV[3:0]# Dynamic Bus Inversion: Driven along with the HD[63:0]# signals.
  • Page 70 8060 B N/B Maintenance 8060 B N/B Maintenance 5.2 Intel 82855GM Memory Controller Hub (Odem) Host Interface Signals (Continued) DDR SDRAM Interface Signals Continune Signal Name Type Description Signal Name Type Description SWE# Write Enable: Used with SCAS# and SRAS# (along with SCS#) to HREQ[4:0]# Host Request Command: Defines the attributes of the request.
  • Page 71 8060 B N/B Maintenance 8060 B N/B Maintenance 5.2 Intel 82855GM Memory Controller Hub (Odem) Hub Interface Signals Clock Signals Continue Signal Name Type Description Signal Name Type Description Packet Data: Data signals used for HI read and write operations. HI_[10:0] DVOCC.LK Differential DVO Clock Output: These pins provide a differential...
  • Page 72 8060 B N/B Maintenance 8060 B N/B Maintenance 5.2 Intel 82855GM Memory Controller Hub (Odem) Dedicated LVDS LCD Flat Panel Interface Signals (Continued) Digital Video Output C (DVOC) Port Signals Signal Name Type Description Signal Name Type Voltage Description DVOC Data: This data bus is used to drive 12-bit RGB data on ICLKBP 1.25 V±...
  • Page 73 8060 B N/B Maintenance 8060 B N/B Maintenance 5.2 Intel 82855GM Memory Controller Hub (Odem) Analog CRT Display Signals GPIO Signals Continue Signal Name Type Description GPIO I/F Total Type Comments VSYNC CRT Vertical Synchronization: This signal is used as the vertical LCLKCTLA SSC Chip Clock Control: Can be used to control an external clock CMOS...
  • Page 74 8060 B N/B Maintenance 8060 B N/B Maintenance 5.2 Intel 82855GM Memory Controller Hub (Odem) Voltage Reference, PLL Power Signals Voltage Reference, PLL Power Signals Continue Signal Name Type Description Signal Name Type Description Host Processor Hub Interface HXRCOMP Analog Host RCOMP: Used to calibrate the Host AGTL+ I/O buffers.

  • Page 75: Intel 82801Dbm I/O Controller Hub 4 Mobile (Ich4-M)

    8060 B N/B Maintenance 8060 B N/B Maintenance 5.3 Intel 82801DBM I/O Controller Hub 4 Mobile (ICH4-M) Hub Interface Signals Firmware Hub Interface Signals Signal Name Type Description Signal Name Type Description HI[11:0] Hub Interface Signals FWH[3:0]/ Firmware Hub Signals. Muxed with LPC address signals. LAD[3:0] HI_STB/HI_STBS Hub Interface Strobe/ Hub Interface Strobe Second: One of two...
  • Page 76 8060 B N/B Maintenance 8060 B N/B Maintenance 5.3 Intel 82801DBM I/O Controller Hub 4 Mobile (ICH4-M) PCI Interface Signals (Continued) PCI Interface Signals (Continued) Signal Name Type Description Signal Name Type Description FRAME# Cycle Frame: The current Initiator drives FRAME# to indicate the STOP# Stop: STOP# indicates that the ICH4, as a Target, is requesting the beginning and duration of a PCI transaction.
  • Page 77 8060 B N/B Maintenance 8060 B N/B Maintenance 5.3 Intel 82801DBM I/O Controller Hub 4 Mobile (ICH4-M) PCI Interface Signals (Continued) IDE Interface Signals Continue Signal Name Type Description Signal Name Type Description I/OD PCI Power Management Event: PCI peripherals drive PME# to PME# Primary and Secondary IDE Device Data: These signals directly PDD[15:0],...
  • Page 78 8060 B N/B Maintenance 8060 B N/B Maintenance 5.3 Intel 82801DBM I/O Controller Hub 4 Mobile (ICH4-M) IDE Interface Signals (Continued) LPC Interface Signals Signal Name Type Description Signal Name Type Description PIORDY#/ Primary and Secondary I/O Channel Ready (PIO): This signal LAD[3:0]/ LPC Multiplexed Command, Address, Data: For the LAD[3:0] (PDRSTB/PWDMA...
  • Page 79 8060 B N/B Maintenance 8060 B N/B Maintenance 5.3 Intel 82801DBM I/O Controller Hub 4 Mobile (ICH4-M) Power Management Interface Signals Power Management Interface Signals Continue Signal Name Type Description Signal Name Type Description THRM# Thermal Alarm: This is an active low signal generated by external LAN_RST# LAN Reset: This signal must be asserted at least 10 ms after the hardware to start the hardware clock throttling mode.
  • Page 80 8060 B N/B Maintenance 8060 B N/B Maintenance 5.3 Intel 82801DBM I/O Controller Hub 4 Mobile (ICH4-M) Power Management Interface Signals (Continued) Processor Interface Signals Continue Signal Name Type Description Signal Name Type Description Deeper Sleep - Voltage Regulator: This signal is used to lower the DPRSLPVR IGNNE# Ignore Numeric Error: This signal is connected to the ignore error...
  • Page 81 8060 B N/B Maintenance 8060 B N/B Maintenance 5.3 Intel 82801DBM I/O Controller Hub 4 Mobile (ICH4-M) Processor Interface Signals (Continued) Real Time Clock Interface Signals Signal Name Type Description Signal Name Type Description CPU Power Good: This signal should be connected to the Special Crystal Input 1: This signal is connected to the 32.768 kHz crystal.
  • Page 82 8060 B N/B Maintenance 8060 B N/B Maintenance 5.3 Intel 82801DBM I/O Controller Hub 4 Mobile (ICH4-M) AC’97 Link Signals Power and Ground Signals Signal Name Type Description Signal Name Description AC_RST# AC ’97 Reset: This signal is a master hardware reset to external VCC3_3 3.3 V supply for core well I/O buffers.

  • Page 83: System Block Diagram

    8060 B N/B Maintenance 8060 B N/B Maintenance 6. System Block Diagram U501 Thermal Sensor Intel Pentium M Processor ADM1032 Micro-FCPGA CRT D-SUB 15 AGP Bus 4X NVIDIA TV S-Video NV18M Odem 200 pin DDR SO-DIMM Socket * 2 LCD Panel J507 North Bridge MINI PCI...

  • Page 84: Maintenance Diagnostics

    8060 B N/B Maintenance 8060 B N/B Maintenance Maintenance Diagnostics 7.1 Introduction Each time the computer is turned on, the system bios runs a series of internal checks on the hardware. This power-on self test (post) allows the computer to detect problems as early as the power-on stage. Error messages of post can alert you to the problems of your computer.

  • Page 85: Error Codes

    8060 B N/B Maintenance 8060 B N/B Maintenance 7.2 Error Codes Following is a list of error codes in sequent display on the PIO debug board. Code POST Routine Description Code POST Routine Description Boot started Initialize the Chipset Disable A20 through A20 Search For ISA Bus VGA Adapter Initialize chipset Reset Counter/Timer 1...
  • Page 86 8060 B N/B Maintenance 8060 B N/B Maintenance 7.2 Error Codes Following is a list of error codes in sequent display on the PIO debug board. Code POST Routine Description Code POST Routine Description Test Battery Fail & CMOS X-SUM Test Keyboard Command Byte Test DMA Controller TEST, Blank and Count All RAM...
  • Page 87 8060 B N/B Maintenance 8060 B N/B Maintenance 7.2 Error Codes Following is a list of error codes in sequent display on the PIO debug board. Code POST Routine Description Initialize option ROMs OEM’s init of power management Update NumLock Status Test For Coprocessor Installed OEM Function Before Boot Dispatch To Op.Sys.Boot...

  • Page 88: Maintenance Diagnostics

    8060 B N/B Maintenance 8060 B N/B Maintenance Maintenance Diagnostics 7.3.1 Diagnostic Tool for PIO Port : P/N:411904800001 Description: PWA; PWA-378 Port Debug BD Note: Order it from MIC/TSSC 7.3.2 Diagnostic Tool for Mini PCI Slot : P/N:411906900001 Description: PWA; PWA-378 Port Debug BD Note: Order it from MIC/TSSC...

  • Page 89: Trouble Shooting

    8060 B N/B Maintenance 8060 B N/B Maintenance 8. Trouble Shooting 8.1 No Power 8.2 No Display 8.3 VGA Controller Failure LCD No Display 8.4 External Monitor No Display 8.5 Memory Test Error 8.6 Keyboard (K/B) Touch-Pad (T/P) Test Error 8.7 Hard Driver Test Error 8.8 CD-ROM Driver Test Error 8.9 PIO Port Test Error...

  • Page 90: No Power

    8060 B N/B Maintenance 8060 B N/B Maintenance 8.1 No Power When the power button is pressed, nothing happens, no fan activity is heard and power indicator is not light up. No power Is the notebook connected Connect AC adaptor to power (either AC adaptor Check following parts and signals: or battery.
  • Page 91 8060 B N/B Maintenance 8060 B N/B Maintenance 8.1 No Power When the power button is pressed, nothing happens, no fan activity is heard and power indicator is not light up. PQ5,JL502 PR14,PU505 PU9,PU503,PL30,PU10 ADINP_1 +1.3VS Main Voltage Map Charge PQ5,PR36,JL501 PU11,PU504,PL18,PL13 Q9,L530...
  • Page 92 8060 B N/B Maintenance 8060 B N/B Maintenance 8.1 No Power When the power button is pressed, nothing happens, no fan activity is heard and power indicator is not light up. ALWAYS PD506 Mother Board BAV70LT1 ADINP JL502 PL29 ADINP_1 120Z/100M PD507 PR36...
  • Page 93 8060 B N/B Maintenance 8060 B N/B Maintenance 8.1 No Power When the power button is pressed, nothing happens, no fan activity is heard and power indicator is not light up. ADINP PR52 +1.5V +3VS +2.8VS EC31QS04 DCIN PR21 PU502 AME8801LEEV +1.5V +3VS...
  • Page 94 8060 B N/B Maintenance 8060 B N/B Maintenance 8.1 No Power When the power button is pressed, nothing happens, no fan activity is heard and power indicator is not light up. PU24 +5VA +5VAS TPC8107 SI2301DS DBATT DVMAIN PR47 PD10 100K BAV70LT1 PR45...

  • Page 95: No Display

    8060 B N/B Maintenance 8060 B N/B Maintenance 8.2 No Display There is no display on both LCD and VGA monitor after power on although the LCD and monitor is known-good. No Display Monitor Replace monitor or LCD module Board-level or LCD.
  • Page 96 8060 B N/B Maintenance 8060 B N/B Maintenance 8.2 No Display ****** System Clock Check ****** +3VS FS2 FS1 FS0 CPUCLK 100MHZ R126 133MHZ PR506 HCLK_CPU R610 PU501 -CLK_ENABLE VTT_PWRGD# R613 -HCLK_CPU MAX1907 Banias R510 R511 R612 49.9 1% 49.9 1% R128 +3VCLKPCI +3VCLK66...
  • Page 97 8060 B N/B Maintenance 8060 B N/B Maintenance 8.2 No Display ****** Power Good & Reset Circuit Check ****** -HCPURST MCH-M +3VS +VCCP -PCIRST Odem R502 PR505 PR502 PU501 100K VR_PWRGD HPWRGD Banias MAX1907 -PCIRST R624 PR44 -RSMSRT PU22 R184 D/D Board C748 R623...

  • Page 98: Vga Controller Failure Lcd No Display

    8060 B N/B Maintenance 8060 B N/B Maintenance 8.3 VGA Controller Failure LCD No Display There is no display or picture abnormal on LCD although power-on-self-test is passed. VGA Controller Failure LCD No Display 1. Confirm LCD panel or monitor is good Check if and check the cable are connected Re-soldering.
  • Page 99 8060 B N/B Maintenance 8060 B N/B Maintenance 8.3 VGA Controller Failure LCD No Display There is no display or picture abnormal on LCD although power-on-self-test is passed. Q501 +3VS SI4800DY L503 120Z/100M LCDVCC C590 C563 C570 C561 C572 +12VS 0.1µ...

  • Page 100: External Monitor No Display

    8060 B N/B Maintenance 8060 B N/B Maintenance 8.4 External Monitor No Display There is no display or picture abnormal on CRT monitor, but it is OK for LCD. External Monitor No Display 1. Confirm monitor is good and check Check if the cable are connected properly.
  • Page 101 8060 B N/B Maintenance 8060 B N/B Maintenance 8.4 External Monitor No Display There is no display or picture abnormal on CRT monitor, but it is OK for LCD. +5VS +3VS D501 EC11FS2 +5VS DDC2B F503 C723 FA501 mircoSMDC110 10µ +5VS R583 R581...

  • Page 102: Memory Test Error

    8060 B N/B Maintenance 8060 B N/B Maintenance 8.5 Memory Test Error Extend DDRAM is failure or system hangs up. Memory Test Error 1.If your system installed with expansion SO-DIMM module then check them for One of the following components or signals on the motherboard proper installation.
  • Page 103 8060 B N/B Maintenance 8060 B N/B Maintenance 8.5 Memory Test Error Extend DDRAM is failure or system hangs up. DDR_2.5V RP508~RP521 56*8 J504 CKE [0:3], -CS [0:3] CKE [0,1], -CS[0,1] MDQS[0:8] MDQSA [0:8] MD [0:63] MDD [0:63] MEM_BS [0,1] MEMA_BS [0,1] MA [0:12], MCB [0:7] MAA [0:12], MCBA [0:7]...

  • Page 104: Keyboard (K/B) Touch-Pad (T/P) Test Error

    8060 B N/B Maintenance 8060 B N/B Maintenance 8.6 Keyboard (K/B) Touch-Pad (T/P) Test Error Error message of keyboard or touch-pad failure is shown or any key does not work. Keyboard or Touch-Pad Test Error Check U18, J17, J10 Re-soldering for cold solder? Is K/B or T/P cable connected to...
  • Page 105 8060 B N/B Maintenance 8060 B N/B Maintenance 8.6 Keyboard (K/B) Touch-Pad (T/P) Test Error Error message of keyboard or touch-pad failure is shown or any key does not work. +3VS +5VA H8_VDD5 120Z/100M R290 C862 C866 C255 C867 C262 C259 C256 C249...

  • Page 106: Hard Driver Test Error

    8060 B N/B Maintenance 8060 B N/B Maintenance 8.7 Hard Drive Test Error Either an error message is shown, or the drive motor spins non-stop, while reading data from or writing data to hard disk. Hard Driver Test Error Board-level 1.
  • Page 107 8060 B N/B Maintenance 8060 B N/B Maintenance 8.7 Hard Drive Test Error Either an error message is shown, or the drive motor spins non-stop, while reading data from or writing data to hard disk. +5VS 41, 42 +3VS 0.1µ 0.1µ...

  • Page 108: Cd-Rom Drive Test Error

    8060 B N/B Maintenance 8060 B N/B Maintenance 8.8 CD-ROM Drive Test Error An error message is shown when reading data from CD-ROM drive. CD-ROM Driver Test Error Board-level 1. Try another known good compact disk. Troubleshooting 2. Check install for correctly. One of the following parts or signals on the motherboard may be defective, use an oscilloscope to check the signals or replace the parts one at a time and test after each replacement.
  • Page 109 8060 B N/B Maintenance 8060 B N/B Maintenance 8.8 CD-ROM Drive Test Error An error message is shown when reading data from CD-ROM drive. +5V_CD +5V_CD L522 Mode PAV_EN ISCDROM PCSYSTEM_OFF ISCDROM 120Z/100M +5V_CD 9,58,44 CDPlayer(System off) VCC[0:2] R137 Direct(system on) +3VS R129 JS501...

  • Page 110: Usb Test Error

    8060 B N/B Maintenance 8060 B N/B Maintenance 8.9 USB Test Error An error occurs when a USB I/O device is installed. USB Test Error Check if the USB device is installed properly. (Including charge board.) Check the following parts for cold solder or one of the following Board-level parts on the mother-board may be defective, use an oscilloscope Troubleshooting...
  • Page 111 8060 B N/B Maintenance 8060 B N/B Maintenance 8.9 USB Test Error An error occurs when a USB I/O device is installed. U511 L538 120Z/100M VOUT0 VIN[0,1] VOUT0 C293 C285 R684 VOUT1 1µ 470P 220µ -USBOC0 C846 R683 1000P L535 90Z/100M USBP0- USBP0+...

  • Page 112: Pio Port Test Error

    8060 B N/B Maintenance 8060 B N/B Maintenance 8.10 PIO Port Test Error When a print command is issued, printer prints nothing or garbage. PIO Port Test Error 1. Check if PIO device is installed properly. (J13) Board-level 2. Check CMOS LPT port setting properly. Troubleshooting One of the following parts or signals on the motherboard may be defective, use an oscilloscope to check the signals or replace...
  • Page 113 8060 B N/B Maintenance 8060 B N/B Maintenance 8.10 PIO Port Test Error When a print command is issued, printer prints nothing or garbage. D504 BAS32L +5VS R644 RP525 RP523 RP507 RP505 2.2K 2.2K*4 2.2K*4 2.2K*4 2.2K*4 RP504 33＊4 -P_STB STB# -P_AFD AFD#...

  • Page 114: Audio Failure

    8060 B N/B Maintenance 8060 B N/B Maintenance 8.11 Audio Failure No sound from speaker after audio driver is installed. Audio Failure 1. Check if speaker cables are connected properly. 2. Make sure all the drivers are installed Board-level Check the following parts for cold solder or one of the following parts on the properly.
  • Page 115 8060 B N/B Maintenance 8060 B N/B Maintenance 8.11 Audio Failure – Audio IN No sound from speaker after audio driver is installed. AVDDAD +5V_CD +3VS R210 R200 R199 J505 +12VS +12VS Internal R211 +12VS C207 C197 10µ ADP3301AR 120Z/100M 0.1µ...
  • Page 116 8060 B N/B Maintenance 8060 B N/B Maintenance 8.11 Audio Failure – Audio OUT No sound from speaker after audio driver is installed. +5V_CD +5V_AMP +3VS +3VS_SPD Q501 Audio DJ Board SPKROUT+ R508 SI2301DS J509 EC10QS04 SPKROUT- 18,3,8 Internal Speaker Connector PVDD[0,1] SPKLOUT+ 600Z/100M...

  • Page 117: Lan Test Error

    8060 B N/B Maintenance 8060 B N/B Maintenance 8.12 LAN Test Error An error occurs when a LAN device is installed. LAN Test Error 1.Check if the driver is installed properly. Check the following parts for cold solder or one of the following 2.Check if the notebook connect with the parts on the mother-board may be defective, use an oscilloscope LAN properly.
  • Page 118 8060 B N/B Maintenance 8060 B N/B Maintenance 8.12 LAN Test Error An error occurs when a LAN device is installed. +3V_LAN AVDD_LAN +3V_LAN +3V_LAN R652 5.6K +3V_LAN AVDD_LAN VDD[0:5] L526 AVDD_LAN 120Z/100M 120Z/100M U508 C805 120Z/100M 0.1µ 59,70,75 9346A AVDD[0:2] R640 PCICLK_LAN...

  • Page 119: Pc Card Socket Failure

    8060 B N/B Maintenance 8060 B N/B Maintenance 8.13 PC Card Socket and IEEE1394 Failure An error occurs when a PC card device or 1394 device is installed. PC Card Socket and IEEE1394 Failure 1. Check if the PC CARD or 1394 device Check the following parts for cold solder or one of the following is installed properly.
  • Page 120 8060 B N/B Maintenance 8060 B N/B Maintenance 8.13 PC Card Socket and IEEE1394 Failure An error occurs when a PC card device or 1394 device is installed. +12V 3.3VA,B -VCCEN1 PCICLK_CARD VCCA VPPA VCCD1 From U506 Clock Generator 5VA,B -VCCEN0 VCCD0 11-13...

  • Page 121: Spare Parts List

    B N/B Maintenance 8060 B N/B Maintenance 9. Spare Parts List - 1 Part Number Description Location(S) Part Number Description Location(S) 441999900211 AC ADPT ASSY OPT ION;8060B 272075103403 CAP;.01U ,50V,10%,0603,X7R,SMT C3,C16 442672600031 AC ADPT ASSY;19V,3.16A,DELT A,706 272075103403 CAP;.01U ,50V,10%,0603,X7R,SMT C20,C21,C22 361400003030 ADHESIVE;ABS+PC PACK,G485,CEMIDA...
  • Page 122 8060 B N/B Maintenance 8060 B N/B Maintenance 9. Spare Parts List - 2 Part Number Description Location(S) Part Number Description Location(S) 627207510241 CAP;1000P,50V ,10%,0603,X7R,SMT 272003105701 CAP;1U ,CR,25V ,+80%-20%,0805, PC519 272030102405 CAP;1000P,CR,3KV,10%,1808,X7R,TU C11,C196,C5 272071105403 CAP;1U ,10V ,10%,0603,X5R,SMT 272075102402 CAP;1000P,CR,50V,10%,0603,X7R,IN C635,PC19 272001225401 CAP;2.2U ,CR,10V ,10%,0805,X7R,S 272075101701...
  • Page 123 CARD BOARD;TOP/BTM,PALLET,8060 291000150411 CON;FPC/FFC,4P,1MM,R/A,SMT,85202 221600020128 CARTON;380MM*320MM*320MM,BC FLUT 291000150411 CON;FPC/FFC,4P,1MM,R/A,SMT,85202 221503220001 CARTON;BATTERY,GRAMPUS 291000012411 CON;HDR,12P*1,1.25,ACES,SMT 221673120003 CARTON;N-B,8060 291000013022 CON;HDR,FM,15*2,2.54mm,3A,SMT J501 431676300001 CASE KIT;8060B 291000013021 CON;HDR,FM,15P*2,0.8MM,ST,H=5.2, 335152000044 CFM-BAT;FUSE THERMAL 98'C 331040044017 CON;HDR,FM,22P*2,2MM,H=5.4,R/A,D 342665500008 CFM-SUYIN;S-STANDOFF,#4-40H4.8,N 331040050016 CON;HDR,FM,25P*2,0.8MM,H=2,R/A,D 324180786564 CFM-TCL;IC,CPU,PENTIUM-M,1.3G,uF 291000021101 CON;HDR,MA,11P*1,1.25,R/A,DF13-1 412676300001 CFM-TCL;INTEL Clexico 802.11b;PR 291000013023 CON;HDR,MA,15*2,2.54mm,3A,SMT...
  • Page 124 342673100023 CONTACT PLATE;W5L80T0.13 ,1/5T,4 288100084002 DIODE;BZX84C5V6,5.2~6V,350mA,SOT ZD1,ZD2 342503400002 CONTACT PLATE;W5L9T0.13,7170LI,P 288101004024 DIODE;EC10QS04,RECT,40V,1A,CHIP, D28,PD508 313000150109 CORE;110OHM/100MH,15.0*14.0*23.0 288101004024 DIODE;EC10QS04,RECT,40V,1A,CHIP, PD501 340676300001 COVER ASSY;8060B 288100112003 DIODE;EC11FS2-TE12L,SCHOTTKY,200 D501,PD8 340673100021 COVER ASSY;DDR,8060 288103104001 DIODE;EC31QS04-TE12L,40V,3A,SMT PD1,PD4,PD6,PD7,PD9 340673100002 COVER ASSY;HINGE,8060 288104148001 DIODE;RLS4148,200MA,500MW,MELF,S 340673100007 COVER ASSY;LCD,8060 288100024003 DIODE;RLZ24B,ZENER,22.61~23.77,S...
  • Page 125 EC;820U ,4V,+-20%,10X10.5,FPCAP PC1,PC5,PC6 295000010044 FUSE;1.1A/6V,POLY SWITCH,1210,SM F501,F502 227673100001 END CAP;L/R,8060 295000010057 FUSE;228R,139C',5A/250V,SMT,PRC 227672300004 EPE PAD;K/B,MANGUSTA 295000010126 FUSE;FAST,2A,63VDC,1206,SMT,PRC 481676300002 F/W ASSY;KBD CTRL,8060B 335152000062 FUSE;LR4-730,POLY SWITCH,PRC 481676300001 F/W ASSY;SYS/VGA BIOS,8060B 295000010016 FUSE;NORMAL,6.5A/32VDC,3216,SMT PF1,PF501,PF502 273000610025 FERRITE ARRAY;120OHM/100MHZ,ONLY FA501 345673100027 GASKET;AUDIO,PCB,8060 273000610025 FERRITE ARRAY;120OHM/100MHZ,ONLY 345673100024 GASKET;PCMCIA,MB,8060...
  • Page 126 8060 B N/B Maintenance 8060 B N/B Maintenance 9. Spare Parts List - 6 Part Number Description Location(S) Part Number Description Location(S) 282574164002 IC;74VHC164,SIPO REGISTER,TSSOP, U501 281307085001 IC;NC7SZ08P5,2-INPUT & GATE,SC70 U10,U513,U514 284501032001 IC;ADM1032,TEMPERATURE MTR,SO8 U501,U6 284500034002 IC;NV34M GPU,VGA CTRL,BGA701 286303301001 IC;ADP3301AR-5,.8%,REG.,SO,8P 284500593001 IC;ODEM MCH-M mFCBGA 593p;PWR...
  • Page 127 LABEL;LOT NUMBER,RACE 346673100083 INSULATOR-1;TVOUT,8060 242674600010 LABEL;NVIDIA;CAIMAN 531067310013 KBD ASSY;UI,8060 242600000001 LABEL;PAL,20*5MM,COMMON 531017240063 KBD;87,UI,3000160130,ZIPPY,8060 242600000315 LABEL;RED ARROW HEAD,PRC 451676300031 LABEL KIT;TCL W/NAMEPLATE,8060B 242600000315 LABEL;RED ARROW HEAD,PRC 242600000145 LABEL;10*10,BLANK,COMMON 441673100031 LCD ASSY;AU,WXGA,15.2",8060 242600000145 LABEL;10*10,BLANK,COMMON 451673100051 LCD ME KIT;WXGA,15.2",8060 242600000434 LABEL;25*6MM,COMMON 413000020345 LCD;B152EW01,TFT,15.2",LVDS,WXGA 242600000385 LABEL;27*10,LAN ID BAR CODE...
  • Page 128 LED;BLUE,H1.1,SF0805-B65140-38,S 316676300001 PCB;PWA-8060-B/MOTHER BD 294011200069 LED;GREEN,19-21VGC/TR8,LED_CL190 LED1,2,3,4 222670820003 PE BAG;L560*W345,7521N 294011200070 LED;RED/GREEN,19-22SRVGC/TR8,LED LED5,6 222503220001 PE BUBBLE BAG;BATTERY,GRAMPUS 416267630901 LT PF OPTION;WXGA,15.2",8060B 340676300002 PLATE ASSY;CPU,8060B 416267630001 LT PF;AU,WXGA,15.2",8060B 411673100004 PWA;PWA-8060,T/P BD,SMT 526267630015 LTXNX;8060B/W5AX/XXC/7UIX/L2D3A/ 411673100011 PWA;PWA-8060,T/P BD,T/U 346673100084 MYLAR;LCD,8060 411504100003 PWA;PWA-8060/BATT GAUGE BD,LI 242676300002 NAMEPLATE;TCL,8060-B...
  • Page 129 8060 B N/B Maintenance 8060 B N/B Maintenance 9. Spare Parts List - 9 Part Number Description Location(S) Part Number Description Location(S) 271071000002 RES;0 ,1/16W,5% ,0603,SMT PR1,R502 271071121211 RES;12.1K,1/16W,1% ,0603,SMT PR38,PR39 271071000002 RES;0 ,1/16W,5% ,0603,SMT R508 271071131101 RES;130 ,1/16W,1% ,0603,SMT R582 271071010301 RES;1 ,1/16W,5% ,0603,SMT...
  • Page 130 8060 B N/B Maintenance 8060 B N/B Maintenance 9. Spare Parts List - 10 Part Number Description Location(S) Part Number Description Location(S) 271034278301 RES;2.7 ,1/2W ,5% ,2010,SMT R695 271071334301 RES;330K ,1/16W,5% ,0603,SMT R216 271071272101 RES;2.7K ,1/16W,1% ,0603,SMT 271071334102 RES;330K,1/16W,1%,0603,SMT 271071272301 RES;2.7K ,1/16W,5% ,0603,SMT R221,R295,R296 271071333301...
  • Page 131 8060 B N/B Maintenance 8060 B N/B Maintenance 9. Spare Parts List - 11 Part Number Description Location(S) Part Number Description Location(S) 271071475311 RES;475K ,1/16W,1% ,0603,SMT PR11,PR32,PR557,PR558 271071683101 RES;68K ,1/16W,1% ,0603,SMT 271071473101 RES;47K ,1/16W,1% ,0603,SMT PR509,PR53,PR57,PR60 271071683301 RES;68K ,1/16W,5% ,0603,SMT R219 271071473301 RES;47K ,1/16W,5% ,0603,SMT...
  • Page 132 9. Spare Parts List - 12 Part Number Description Location(S) Part Number Description Location(S) 345673100006 RUBBER;LCD UP,8060 370102010404 SPC-SCREW;M2L4,K-HD,NIB 345671200002 RUBBER;MIDDLE,LCD,8170 370102010405 SPC-SCREW;M2L4,NIW,K-HD(+),NYLOK 565167630001 S/W;CD ROM,SYSTEM DRIVER,8060B 370103010405 SPC-SCREW;M3L4,NIW,K-HD,T0.3 565180626001 S/W;CD*1,DVD,WIN-DVD,INTERVIDEO 340676300006 SPEAKER ASSY;L,2W,8060B 371102030303 SCREW;M2L3,K-HEAD(+),NIW/NLK 340676300005 SPEAKER ASSY;R,2W,8060B 340673100031 SHIELDIND ASSY-1;HDD,8060 346676300006 SPONGE;DDB,SWITCH,8060B...
  • Page 133 288200144003 TRANS;DTC144TKA,N-MOSFET,SOT-23 Q502 270140000003 VARISTOR;280V,5.6X3.8MM,TVB280-0 288203904010 TRANS;MMBT3904L,NPN,Tr35NS,TO236 421666200009 WIRE ASSY;BATTERY BIOS,NV 288203906002 TRANS;MMBT3906L,40V,200mA,SOT23, 422673100004 WIRE ASSY;INVERTOR,LCD,8060 288203906018 TRANS;MMBT3906L,PNP,Tr35NS,TO236 422676300001 WIRE ASSY;MDC,8060B 288202301001 TRANS;SI2301DS,P-MOSFET,SOT-23 PQ2,Q1 422673100007 WIRE ASSY;MIC,8060 288202301001 TRANS;SI2301DS,P-MOSFET,SOT-23 Q501 422673100001 WIRE LCD ASSY;LCD,8060 288202303001 TRANS;SI2303DS,P-MOSFET,SOT-23 PQ502,Q9 332110020111 WIRE;#20,UL1007,120MM,RED,YIYI;P 288202304001 TRANS;SI2304DS,N-MOSFET,SOT-23...

  • Page 134: System Exploded Views

    PDF created with FinePrint pdfFactory trial version http://www.fineprint.com...

  • Page 135: Circuit Diagram

    MODEL : 8060B Revision R01 IDSEL IDSEL CHIP AD11 Contexts AD17 MINIPCI AD18 LAN RTL8101L AD19 PCMCIA/IEEE1394 Title Page AD21 Cover Sheet PCBA PCIINT System Block Diagram PCIINT CHIP INTA NV18M-PRO Power Block Diagram INTB MINIPCI INTC PCI4510 Banias INTD...
  • Page 136 8060B System Block Diagram Banais C.P.U. Clock ADM1032 Generator Micro-FCPGA 478 pin ICS950810 Thermal Sensor TPS2211 IC CARD Power Switch Socket SSOP 16 VSYNC NVIDIA HSYNC 200 Pin DDR SO-DIMM Socket*2 NV34M D-SUB 15 Odem PCI 4510 AGP BUS 4X MD[0..63]...
  • Page 137 DDR_2.5V +1.8VS SWITCH BLOCK DIAGRAM OF THE 8060B SI4800 +1.5VS DDR DC to DC Converter Requlator MAX1858 SI4800+SC431 SWITCH AGP_MEM2.5 SI4800 LP2996 PWR_ON REF_1.25V +3VS +3VA MAX1999 SUSB# Shut Down MOSFET 3.3V DC to DC Convertor +5VS +5VA Self- D/VMAIN...
  • Page 138 CPU_CORE : PROCESSOR CORE POWER SUPPLY.(1.468~0.748V) (1.05V) Banias 2.5A VCCA : ISOLATE POWER FOR INTERNAL PLL.(1.8/1.5 VS) +VCCP CPU_CORE VCCP : PROCESSOR I/O POWER SUPPLY.(1.05V) AB19 VCCP_0 VSS_146 VSS_0 VSS_73 VCCQ : QUIET POWER SUPPLY FOR ON DIE COMP CKT.(1.05V) HCLK_CPU AB21 VCCP_1...
  • Page 139 Odem -HA[3..31] -HD[0..63] -HA[3..31] -HD[0..63] -HA3 -HD0 +1.5VS +VCCP HA3# HD0# -HA4 -HD1 HA4# HD1# -HA5 -HD2 HA5# HD2# -HA6 -HD3 +VCCP +VCCP AG29 AJ23 HA6# HD3# VCC1_5_0 VTT_0 -HA7 -HD4 AC29 AG23 HA7# HD4# VCC1_5_1 VTT_1 -HA8 -HD5 C603 C616 C617 AJ21...
  • Page 140 Odem AGP_AD[0..31] AGP_AD[0..31] MA[0..12] MA[0..12] (8) AGP_AD0 G_AD0 SMA0 AGP_AD1 G_AD1 SMA1 AGP_AD2 G_AD2 SMA2 AGP_AD3 G_AD3 SMA3 AGP_AD4 G_AD4 SMA4 AGP_AD5 G_AD5 SMA5 AGP_AD6 G_AD6 SMA6 AGP_AD7 G_AD7 SMA7 AGP_AD8 G_AD8 SMA8 VSS_0 VSS_71 AGP_AD9 G_AD9 SMA9 VSS_1 VSS_72 AGP_AD10 MA10 G_AD10...
  • Page 141 CLOCK GENERATOR +3VS +3VCLKCPU L523 CPUCLK 120Z/100M 2012 C731 C733 C732 C728 100MHZ 0.1U 0.1U 0.1U 2.2U 0603 0603 0603 0805 14.318MHZ +80-20% 133MHZ C119 C118 JP_NET20 0603 0603 USBCLK_ICH USBCLK_ICH (15) 14M_ICH R124 0603 14M_ICH (14) SIO_14.318MHZ +3VS R125 0603 SIO_14.318MHZ (21) U506...
  • Page 142 DDR SO-DIMM Module DDR SO-DIMM SERIAL RESISTOR DIMM 0 DIMM 1 DDR_2.5V DDR_2.5V DDR_2.5V DDR_2.5V PARALLEL RESISTOR MDD2 REF_1.25V MDD7 MDD6 10*4 MDD2 J504 MDQS0 MDQSA0 1206 MDD7 RP508 MDQS0 REF_DIM REF_DIM MDD1 MDD6 56*8 VREF1 VREF2 MDD0 MDQSA0 RPX8 VSS1 VSS17 MDD5...
  • Page 143 NV18M/NV31 Place under the GPU AGP_AD[0..31] AGP_AD[0..31] AGP_AD0 AJ28 AD11 PCIAD0 AGPVDDQ_0 +1.5VS AGP_AD1 AK28 AD14 2.5V (3A) PCIAD1 AGPVDDQ_1 AGP_AD2 AH27 AD17 PCIAD2 AGPVDDQ_2 AGP_AD3 AK27 AD20 PCIAD3 AGPVDDQ_3 AGP_AD4 VGA_MEM2.5 AJ27 AD23 C645 C663 C669 C678 C688 C647 PCIAD4 AGPVDDQ_4 MEMB_MD[63..0]...
  • Page 144 Addr:98h NV18M/NV31 Layout Note: +3VS (平 行 且 等 長 ） HSYNC TP27 VIPPCLK (13) HSYNC DACA_HSYNC BUFRST_ ROMCS_ VIPPCLK as short as possible ROMA14 VSYNC 0603 R111 0603 (13) VSYNC DACA_VSYNC ROMA14 ROMA15 LCD_ID2 10 mil trace LCD_ID2 (13) THERMDA ROMA15 VIPHAD0...
  • Page 145 NV18M/NV31 MEMA_CLK0 MEMA_CLK1 R544 0603 0603 -MEMA_CLK0 -MEMA_CLK1 MEMA_MA0 MEMA_MD32 MEMA_MA1 MEMA_MD33 U503 MEMA_MA[11..0] MEMA_MD[63..0] MEMA_MA0 MEMA_MD0 MEMA_MA2 MEMA_MD34 MEMA_MA1 MEMA_MD1 MEMA_MA3 MEMA_MD35 MEMA_MA2 MEMA_MD2 MEMA_MA4 MEMA_MD36 MEMA_MA3 MEMA_MD3 MEMA_MA5 MEMA_MD37 MEMA_MA4 MEMA_MD4 MEMA_MA6 MEMA_MD38 MEMA_MA5 MEMA_MD5 MEMA_MA7 MEMA_MD39 MEMA_QS[7..0] (9) MEMA_MA6 MEMA_MD6 MEMA_MA8...
  • Page 146 NV18M/NV31 MEMB_CLK1 MEMB_CLK0 R566 R560 0603 0603 -MEMB_CLK1 -MEMB_CLK0 U504 MEMB_MA[11..0] MEMB_MD[63..0] (9) MEMB_MA0 MEMB_MD32 MEMB_MA1 MEMB_MD33 MEMB_MA0 MEMB_MD0 MEMB_MA2 MEMB_MD34 MEMB_MA1 MEMB_MD1 MEMB_MA3 MEMB_MD35 MEMB_MA2 MEMB_MD2 MEMB_MA4 MEMB_MD36 MEMB_MA3 MEMB_MD3 MEMB_MA5 MEMB_MD37 MEMB_MA4 MEMB_MD4 MEMB_MA6 MEMB_MD38 MEMB_MA5 MEMB_MD5 MEMB_MA7 MEMB_MD39 MEMB_QS[7..0] (9) MEMB_MA6...
  • Page 147 LCD & CRT INTERFACE TXOUT0+1+2+3+/0-1-2-3- Layout Note: 四組各自平行走線等長 S/W/W/S=12/5/5/12 mils +3VS as short as possible LCD_VCC Q501 SI4800DY +3VS L503 LCD ID Select Table LCDVCC LCDVCC 10K*4 TXOUT1+ TXOUT0- Display LCD_ID3 LCD_ID2 LCD_ID1 LCD_ID0 (10) TXOUT1+ TXOUT0- (10) 1206 TXOUT1- TXOUT0+ 120Z/100M CLOSE TO NDS 9410...
  • Page 148 +3VS U507A VCC3_3 AC23 VCC3_3 AC18 VCC3_3 AC14 VCC3_3 AC10 VCC3_3 VCC3_3 VCC3_3 AB20 U507D VCC3_3 U507B AD[0..31] -AGP_BUSY VCC3_3 R192 AA22 AD[0..31] (17,18,20) APICCLK AGPBUSY#/GPIO 6 -AGP_BUSY (9) VCC3_3 -PCI_INTA AD31 R189 GPIO7 AA16 (9,16) -PCI_INTA PIRQA# AD31 APICD_0 GPIO 7 TP527 VCC3_3...
  • Page 149 I/O CONTROLLER HUB U507E HUB_HI[0..10] HUB_HI[0..10] USBP0+ HUB_HI0 (23) USBP0+ USBP_0 HI 0 USBP0- HUB_HI1 (23) USBP0- USBP_0# HI 1 HUB_HI2 TP32 USBP_1 HI 2 HUB_HI3 Route signals with 5/10 trace/space TP35 USBP_1# HI 3 USBP2+ HUB_HI4 (23) USBP2+ USBP_2 HI 4 routing.Signals must match +/- 0.1"...
  • Page 150 ST[1] has an internal pull-up straps on BPSB for 100Mhz AGP BUS PULL UP/DOWN ENHANCED IDE +1.5VS R564 R568 1K/NA 8.2K/NA 0603 0603 0603 PDD[8..15] PDD[8..15] (15) AGP_ST2 PDD[0..7] (6,9) AGP_ST2 (15) PDD[0..7] AGP_ST1 (6,9) AGP_ST1 AGP_ST0 PDD8 PDD7 (6,9) AGP_ST0 PDD6 PDD9...
  • Page 151 R272 0603 VDPLL 0/NA R286 0603 C266 0.1U R229 R279 0603 0603 0603 C257 Place close to PCI4510 -CBLOCK CSTSCHG -CSERR CAUDIO -CPERR CARD_CLK CCLK R299 0603 -CSTOP CPAR 0603 -CINT -CREQ 24.576MHZ VCCA C263 -CGNT R2_D14 -CDEVSEL R2_A18 -CTRDY R2_D2 -CIRDY R243...
  • Page 152 LAN CONTROLLER AD[0..31] -CBE[0..3] +3V_LAN (14,17,20) AD[0..31] -CBE[0..3] (14,17,20) R203 0805 120Z/100M 1608 +3VS C145 C187 C186 C175 C146 R204 0805 L20 120Z/100M/NA 1608 2.2U 2.2U 0.1U 0.1U 0.1U LAN_WAKE 1206 1206 0603 0603 0603 LAN_WAKE (22) L_GND -PME -PME (14,17,20) L_GND L527 0603...
  • Page 153 +5V_CD AUDIO CODEC R199 R227 0603 LINE_IN_L LINE_IN_L (20) R200 SI2303DS +12VS +3VS +12VS R224 0603 LINE_IN_R LINE_IN_R (20) 0603 C203 0603 C216 C213 +12VS R230 R222 100P 100P 0603 0603 100K 100K 120Z/100M L530 0.01U 1608 0603 0603 AVDDAD 120Z/100M SI2304DS 0603...
  • Page 154 +5V_CD R617 R618 2.2K 2.2K U505 0603 0603 SCLK SDATA 0603 (14,16) -PCI_INTG INT# (28) -WIRE_LED +3VS OZ165 R611 0_DFS CSDD[0..15] CSDD[0..15] (16) (15) SDD[0..15] SDD15 CSDD15 HDD[15] CDD[15] SDD14 CSDD14 HDD[14] CDD[14] SDD13 CSDD13 Q515 C289 C849 C850 C847 C287 C852 C290...
  • Page 155 0.1U -ROMCS (22) XA18/GPIO16/JOYBBTN0/DSR2# XCS0#/DR1#/XDRY/GPIO25 TP537 SA19 282574373004 XA19/DCD2#/JOYABTN0/GPIO17 R284 0603D 0603 PC87393 284587393002 PQFP100_0.5MM MITAC INTERNATIONAL CORP. Title BIOS,SUPER-IO,TOUCHPAD Size Document Number Custom 411676300001 01/1.0 Date: Thursday, June 12, 2003 Sheet PDF created with FinePrint pdfFactory trial version http://www.fineprint.com...
  • Page 156 H8 Mode Select Table MODE Description R660 Install keyboard AC 80V Remove keyboard AC 98V MODE1 Expended mode with On-Chip ROM disable 20M/NA 0603 MODE2 Expended mode with On-Chip ROM enable Q506 I_LIMIT +5VS I_LIMIT (28) 500~750 uA MODE3 Single-Chip mode U509 1M/NA R659...
  • Page 157 Place two fuses on same location, +5VS +3VS only use one fuse. 120Z/100M D504 2012 BAS32L GND_TV GND_TV GND_TV C583 33P 0603 GND_IO2 BAV99/NA BAV99/NA BAV99/NA L505 120Z/100M 1608 place as close as paraller port connect TV_COMP S-VIDEO TV_COMP (10) C573 33P 0603 L504...
  • Page 158 PD506 ALWAYS ADINP BAV70LT1 JL502 ADINP_1 SHORT-SMT1 JL501 ADINP_2 SHORT-SMT1 PR36 DVMAIN DVMAIN PR37 EC31QS04 PR558 475K TPC8107 0603 PC548 PR545 PR546 PC540 PC542 PR557 4.7K 4.7K 0.1U EC31QS04 0.1U 1000P PD507 0603 0805 0805 0603 0603 PR565 LEARNING 475K EC31QS04_NA (22) LEARNING...
  • Page 159 SYSTEM POWER (5V 3V 12V) PL508 BEAD PL23 BEAD DVMAIN DVMAIN ALWAYS PR551 PC59 PC560 PC556 PC57 0805 0.1U 0.1U 1812 1210 0603 0603 PR547 +3VA PR33 PC78 PGND 0.1U +5VA PR27 PU15 PC551 PC73 SI4800DY 1206 1206 PR44 (22,28) PWR_ON N.C.
  • Page 160 PL502 BEAD 0805C DVMAIN PL501 PW10 BEAD 0805C PC510 PC507 PC504 PC505 PC506 PC508 PC509 0.01U 0.01U 0.1U 0.1U 7243 7243 7243 0603 0603 0603 0603 PR503 (14,15) DPRSLPVR +5VS +3VS PR501 PGND 0603 0.1U 0603 1206 PR505 0603 0603 PR504 SI7888DP SI7888DP...
  • Page 161 DVMAIN PW13 120Z/100M 2012 PC26 PC25 0.1U 0603 1210 PGND PC13 0805 0805 PR527 PW14 PW15 +5VS +1.2VS PC15 120Z/100M PC19 0.047U 4.7UH 2012 SPC-10039P 1000P PR529 PC518 PR522 PC17 2.2K 0603 0.1U 10%,X7R 0603 5.1K 1206 0603 0603 PC20 SI4816DY 220U PC21...
  • Page 162 ADINP ADINP ADINP_2 ADINP_2 ADINP_1 ADINP_1 (22) I_LIMIT PR31 PC80 PR21 0603 1206 PC81 PR22 PR38 0.1U 12.1k 0603 0603 EC31QS04 EC31QS03L_NA PR52 0603 PR55 100K PC69 PC68 PL26 PL27 0603 BEAD BEAD_NA 0805C 0805C 0805 0805 PW23 +5VA PR550 PR46 PC58 PC60...
  • Page 163 J501 LED INDICATOR -WIRE_LED BLADJ PWR_ON +5VS +5VS LED_DATA DVMAIN LED_CLK DVMAIN -H8_RESET DVMAIN -CDROMACTP CDROM HDD NUM CAP SCROLL 0603 0603 0603 0603 -HDDACTP +5V_CD ENPBLT1 -POWERSW +12VS +5VAS +1.8VS -SCROLL CL-190G DDR_2.5V DDR_2.5V -NUM CL-190G DDB-11 VGA_MEM2.5 VGA_MEM2.5 REF_1.25V +1.5VS -CAP...
  • Page 164 AUDIO DJ BOARD +5V_CD JO17 JO16 JO15 LINE_OUT_L/R Trace width/Space/Isolate must 15/15/15 R501 4.7K 0603 J503 -DEVICE_DECT 600Z/100M 1608 600Z/100M 1608 +5V_CD LINE_OUT_L LINE_OUT_R BAV99/NA +5V_CD R502 4.7K_NA -DECT_HP/OPT 600Z/100M 1608 0603 R506 4.7K 600Z/100M 1608 C500 1U_NA +5VS 0603 Drive SPDIFOUT 0603...

  • Page 165: Reference Material

    Reference Material Intel Mobile Pentium M Processor Intel, INC Intel 82855 Memory Controller Hub (Odem) Intel, INC Intel 82801DBM I/O Controller Hub 4 Mobile (ICH4-M) Intel, INC 8060B Hardware Engineering Specification Technology Corp./MiTAC...
  • Page 166 SERVICE MANUAL FOR 8060B SERVICE MANUAL FOR SERVICE MANUAL FOR 8060B Sponsoring Editor : Jesse Jan Author : Sissel Diao Assistant Editor : Janne Liu Publisher : MiTAC International Corp. Address : 1, R&D Road 2, Hsinchu Science-Based Industrial, Hsinchu, Taiwan, R.O.C.

Table of Contents
