- Page 1 Installation Manual WP60XT...
-
Page 2: Table Of Contents
Welcome Thank you for purchasing a WPX speaker from Dayton Audio. This rugged, all-purpose speaker is designed to deliver reliable, high-quality audio in commercial and residential applications while withstanding outdoor environments. The WPX series features an IP66 weather-resistant ABS construction, 2-way coaxial speaker design and passive bass radiators. -
Page 3: What's In The Box
What’s In The Box WP60XT DAYTONAUDIO... -
Page 4: 70V Connection
70V Connection In large commercial installations such as restaurants, warehouses, theme parks, or schools WPX speakers can be installed with a matching 70V amplifier to provide full coverage without risking amplifier overload or loss in signal quality. Connect the speakers in parallel with a single cable coming from the amplifier. -
Page 5: Connection
8Ω Connection WPX speakers can also be used in standard stereo installations. Set the transformer tap on the rear of the speaker to 8Ω and connect one speaker to each of the outputs on a stereo amplifier. Do not use any 70V tap settings in this situation as the amplifier could become overloaded, resulting in poor sound quality. -
Page 6: Pendant Installation
Make sure the speaker is properly secured to the ceiling or support structure. Use appropriate fasteners and connectors to the type of structure. Failure to do so may cause the speaker to become unsecured, resulting in potential damage or injury. WP60XT DAYTONAUDIO... -
Page 7: Landscape Installation
Landscape Installation 1. Assemble the landscape as shown in figure to the right. 2. Bury the entire assembly for increased stability. WP60XT DAYTONAUDIO... -
Page 8: Surface Mount Installation
Surface Mount Installation Use appropriate hardware for securing the wall mount bracket to any wall of surface. The bracket can be adjusted to point the speaker in the desired direction. WP60XT DAYTONAUDIO... -
Page 9: Troubleshooting
The amplifier is Some commercial amplifiers have built in high using a high pass filters to deliver more power in a 70V pass filter system. Check the setting and specifications of the amplifier WP60XT DAYTONAUDIO... -
Page 10: Specifications
Specifi cations All specifi cations are accurate at the time of printing. Dayton Audio reserves the right to make improvements without notice. 5-Year Limited Warranty See daytonaudio.com for details daytonaudio.com 705 Pleasant Valley Dr. tel + 937.743.8248 Springboro, OH 45066 info@daytonaudio.com...
