Sealey TP9312.V2 Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Wear eye
instructions protection
1. SAFETY
Maintain the pump in good condition (use an authorised service agent).
9
Replace or repair damaged parts. Use recommended parts only. Non authorised parts may be dangerous and will invalidate the warranty.
9
Keep the pump clean for best and safest performance.
9
Familiarize yourself with the applications, limitations and potential hazards of the Transfer Pump.
9
Ensure the power supply (vehicle battery) corresponds with the requirements of the pump.
9
Ensure that there is more liquid in the delivery tank than will be needed.
9
Ensure that the capacity of the receiving tank is sufficient to hold the dispensed fuel.
9
Wear safety goggles and gloves, and protective clothing when working around fuel. A full range of personal safety equipment is
9
available from your local Sealey Stockist.
Keep area clean and tidy and free from unrelated materials, and ensure there is adequate lighting.
9
Maintain correct balance and footing. Ensure the floor is not slippery and wear non slip shoes.
9
Use the pump in an appropriate working area for its function. Keep area clean and tidy and free from unrelated materials.
9
Keep children and unauthorised persons away from the working area.
9
DO NOT run the pump dry. This will damage the pump's internal components and will invalidate your warranty.
8
DO NOT operate the pump continuously for more than 30 minutes. The duty cycle of the unit is 30 minutes, after which the motor must be
8
left to cool down for 30 minutes.
DO NOT run the unit for more than 2-3 minutes with the delivery nozzle closed.
8
DO NOT start or stop the pump by connecting or disconnecting the battery clamps.
8
DO NOT operate the pump with wet hands.
8
DO NOT use the pump where explosive or flammable vapours may be present.
8
DO NOT tamper with the pump connections.
8
DO NOT pull or carry the unit by its cables and do not pull the negative and positive clamps from the battery terminals.
8
WARNING! DO NOT use the unit to pump the following fluids: Petrol, flammable liquids with flash point <38°C, water, foodstuffs,
‰
corrosive chemicals and solvents.
DO NOT smoke or allow a spark, or flame in the vicinity of the battery or pump.
8
WARNING! DO NOT use the unit to pump the following fluids:
‰
Petrol, flammable liquids with PM <55°C, water, alimentary liquids with viscosity >20 cSt., corrosive chemicals and solvents.
WARNING! The warnings, cautions and instructions referred to in this manual cannot cover all possible conditions and situations that
‰
may occur. It must be understood that common sense and caution are factors which cannot be built into this product, but must be
applied by the operator.
2. INTRODUCTION
Robust and compact portable pump ideal for extracting engine oil or diesel. Powered from a 12V battery. Supplied with a 1.2m suction
hose, 2m discharge hose and a 1.7m battery cable with clips. Not suitable for use with Petrol.
3. SPECIFICATION
MODEL NO: TP9312.V2
Current: 7A
Duty Cycle: 30min on/30min off
Flow Rate: 1.92L/min
Nett Weight: 0.86kg
Power: 84W
Voltage: 12V
© Jack Sealey Limited
12V OIL TRANSFER PUMP
TP9312.V2
MODEL NO:
Wear protective Warning
gloves
Original Language Version
FIG.1
TP9312.V2
Illustration
purposes only
Issue 1 16/05/24
