OIL FILLED RADIATOR
OPERATING INSTRUCTIONS
IMPORTANT SAFEGUARDS
PLEASE READ THIS GUIDE CAREFULLY AND SAVE THESE IMPORTANT SAFETY INSTRUCTIONS
1: When using electrical appliances, basic precautions should always be followed to reduce the risk
of fi re, electric shock, and injury to persons, including the following:
2. Before using, ensure that mains cord is fully extended and is not touching the surface of the heater.
3. Before connecting the heater, check that the voltage indicated on the rating plate corresponds.
4. Avoid the use of an extension cord because it may lead to overheating.
5. The radiator should be placed on fl at ground. You must not place it on an uneven or angled surface.
6. DO NOT use the radiator in a room containing combustible or explosive gas.
7. DO NOT use aerosols, infl ammable substances or materials sensitive to heat in the fl ow of hot air.
8. DO NOT use this heater in the immediate area surrounding a bath, shower or swimming pool.
9. The heater must not be placed immediately below a socket outlet.
10. To ensure your safety do not put anything in between the fi ns of the radiator.
11. When in use, there should be safety buffer around the heater of at least 8 inches. There must also
be a 3-foot clearance above the unit to allow for ventilation.
12. Warning:In order to avoid overheating, do not cover the heater.
13. Prevent overheating of the heater by keeping the air inlet and outlet free of obstructions.
14. Before cleaning the radiator, turn off power and remove plug from outlet.
15. Only touch the heater with dry hands.
16. Please always unplug the unit from the socket when not in use.
H03613 9 Fin Oil Rad.indd 1
MODEL NO.: H03613
It is important that you read these instructions before
using your new oil fi lled radiator and we strongly
recommend that you keep them in a safe place for
future reference.
BRIEF PRODUCT DESCRIPTION
This oil fi lled heater uses a tubular element as a heat
source, with long-lasting heat conduction oil sealed
inside. Heat spreads via the radiation fi ns, increasing the
room temperature by air circulation.
FEATURES
1: 3 heat settings: 1000/1500/2500W
2: Tip over switch
3: Lower noise level
4: Over heating protection
5: Smooth rolling casters for easy movement
1
10/04/2015 09:26
Advertisement
Table of Contents
Related Manuals for RHINO H03613
Summary of Contents for RHINO H03613
- Page 1 14. Before cleaning the radiator, turn off power and remove plug from outlet. 15. Only touch the heater with dry hands. 16. Please always unplug the unit from the socket when not in use. H03613 9 Fin Oil Rad.indd 1 10/04/2015 09:26...
-
Page 2: Connecting To Power
This unit is designed to operate on 220-240V ~ 50Hz only. Connecting it to other power sources may damage the unit. The wires in this mains lead are colored in accordance with the following code: BLUE = NEUTRAL BROWN = LIVE GREEN+YELLOW=EARTH H03613 9 Fin Oil Rad.indd 2 10/04/2015 09:26... -
Page 3: Names Of Components
Caster board Cord wrap Caster Power switch (at the bottom of cord wrap) Control panel POWER TEMP MODE Remote control Temperature Digital display Timer Celsius Child-lock TIMER Power Display panel ECO I H03613 9 Fin Oil Rad.indd 3 10/04/2015 09:26... -
Page 4: Caster Installation
Slide thumb or finger on control panel, fig 1 fig 2. fig 1 fig 2 CASTER INSTALLATION Parts Identification: figure 1 figure 2 figure 3 DESCRIPTION DRAWING QUANTITY Straight Foot bracket and Casters Butterfly nuts H03613 9 Fin Oil Rad.indd 4 10/04/2015 09:26... -
Page 5: Installation
The first time the heater is used there may be an odor that will disappear after the first 30 minutes of operation. The odor is due to a lubricant used during the manufacturing of the heater. Overheating protection safety device. H03613 9 Fin Oil Rad.indd 5 10/04/2015 09:26... -
Page 6: Troubleshooting
Number of fins: 11 fins This product is for home/office use only. WASTE ELECTRICAL PRODUCTS SHOULD NOT BE DISPOSED OF WITH HOUSEHOLD WASTE. PLEASE RECYCLE WHERE FACILITIES EXIST. CHECK WITH YOUR LOCAL AUTHORITY FOR RECYCLING ADVICE H03613 9 Fin Oil Rad.indd 6 10/04/2015 09:26... - Page 7 NOTES H03613 9 Fin Oil Rad.indd 7 10/04/2015 09:26...
- Page 8 BIRCHWOOD PRICE TOOLS BIRCH PARK PARK LODGE ROAD GILTBROOK NOTTINGHAM NG16 2AR Tel: +44 ( 0 ) 115 9389000 Fax: +44 ( 0 ) 115 9389010 H03613 9 Fin Oil Rad.indd 8 10/04/2015 09:26...
