- Page 1 P/N: O00501 4 Fibers DVI/HDMI Signal Single/Multi Mode Fiber Extender User Manal V1.0 Stock Code 873117 en.rgble.com 400-1661-021 1 / 7...
- Page 2 P/N: O00501 Dear users: Thank you for using RGBLE product. We provide a detailed user manual for you to better experience the visual effect of this product. Please read the manual carefully before you start to use the product. You can get the knowledge from product introduction, how to use it and so on, so that you can use the device correctly.
- Page 3 Low power consumption, working steadily without distortion 24 hours a day 7 days a week. First grade Laser to ensure eyes safety Comply with 3C/CE/FC/RoHS Does not support transmission of DVI&HDMI signals with HDCP (High-bandwidth Digital Content Protection). Stock Code 873117 en.rgble.com 400-1661-021 3 / 7...
- Page 4 LINK of port 4 is normal. If both the port 3 and 4 are connected, the red half and blue half would be all on, the LED color displays orange. 1/2/3/4: Single/multi-mode 4 LC fiber input interface Stock Code 873117 en.rgble.com 400-1661-021 4 / 7...
-
Page 5: Installation Instructions
EDID is recovered. Note: When the display device (monitor, projector, etc.) or the receiving device is HDMI interface, DVI female to HDMI male adapter is needed, repeat the above steps for EDID manual learning. Stock Code 873117 en.rgble.com 400-1661-021 5 / 7... -
Page 6: Technical Specifications
P/N: O00501 Technical Specifications Device OT-4DS-T-V2MM OT-4DS-R-V2MM I/O Interface 1×DVI-D (18+1) Transportation 4 female LC connectors ports Support Up to 1920*1200@60Hz, HDTV 1080p@60Hz Resolution DDC protocol EDID manual Learning Front Panel 3×Indicator 1×EDID button 5× Indicator 1500M (Single mode G.652D fiber) - Page 7 ➢ The electrolytic capacitor on the circuit board burn lead to explode. ➢ Please classified collection and disposal. Do not get to household garbage. ➢ Please classified disposal or according to the environmental regulations to disposal. Stock Code 873117 en.rgble.com 400-1661-021 7 / 7...
