- Page 1 P/N: U00301 HDMI 130M HDBT Extender with HDMI Loop out UT-130FHD-TR User Manual VER 1.0 Stock Code 873117 en.rgble.com 400-1661-021...
-
Page 2: Table Of Contents
P/N: U00301 Thank you for purchasing RGBLE product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc. -
Page 3: Introduction
HDMI 130M HDBT Extender with Loop out 1. Introduction The RGBLE UT-130FHD-TR HDMI HDBT Extender with HDMI Loop out can extend HDMI signal over 427 feet/130 meters to an HDMI compatible display via single Cat5e/6 cable. It also supports bi-directional Infrared control signal and RS-232 transmission together with HDMI signal, it can allow you to easily control your DVD player at TV side or control your TV at the DVD player side when using this extender. -
Page 4: Operation Controls And Functions
Flashing: The Transmitter and Receiver are in poor connections status. Lamp Dark: The Transmitter and Receiver are not connected. Data Signal Illuminate: HDMI signal with HDCP. ➓ Indicator Flashing: HDMI signal without HDCP. Lamp Dark: No HDMI signal. 3 / 9 Stock Code 873117 en.rgble.com 400-1661-021... - Page 5 Flashing: The Transmitter and Receiver are in poor connections Lamp status. Dark: The Transmitter and Receiver are not connected. Illuminate: HDMI signal with HDCP. Data Signal ➒ Flashing: HDMI signal without HDCP. Indicator Lamp Dark: No HDMI signal. 4 / 9 Stock Code 873117 en.rgble.com 400-1661-021...
-
Page 6: Connection Diagram
P/N: U00301 4.2 Connection diagram Description 1：POC (Power over Cable) Application Example Description 2：Bidirectional Infrared control Application Example Description 3：Bidirectional RS-232 control Application Example 5 / 9 Stock Code 873117 en.rgble.com 400-1661-021... -
Page 7: Specifications
P/N: U00301 5. Specifications Brand Name RGBLE Model Number UT-130FHD-TR Technical HDMI Compliance HDMI 1.4 HDCP Compliance HDCP 1.4 Video Bandwidth 165MHz Video Resolutions Up to1080P @60Hz YUV4:4:4 RGB4:4:4 Color Space RGB, YUV4:4:4, YUV 4:2:2 Color Depth 8-bit HDMI Audio Formats LPCM 2/5.1/7.1CH, Dolby Digital, DTS 5.1, Dolby Digital+, Dolby... -
Page 8: Connection Diagram
P/N: U00301 6. Connection Diagram 7 / 9 Stock Code 873117 en.rgble.com 400-1661-021... -
Page 9: Safety Instructions
Attention: In order to avoid electric shock. Please do not open the lid. Please contact with the professional staff. Information instructions It is list some contents about operation and setting unsuccessful, and some correlation notice information. 8 / 9 Stock Code 873117 en.rgble.com 400-1661-021... -
Page 10: Notice
➢ The electrolytic capacitor on the circuit board burn lead to explode. ➢ Please classified collection and disposal. Do not get to household garbage. ➢ Please classified disposal or according to the environmental regulations to disposal. 9 / 9 Stock Code 873117 en.rgble.com 400-1661-021...
