leisurecraft Pure cube Neptune Assembly Instructions Manual

Hide thumbs

Advertisement

Table of Contents

Neptune
11/2024
Outdoor Pure Cube
Assembly Instructions
Requirements:
2 People (recommended)
Staple Gun
Rubber Mallet
Hammer
Carpenters Level
Step Ladder
Tape Measure
Utility Knife
Cordless Drill
Chisel
Phillips & Robertson Drill Bits
4mm Hex Bit
2" hole Saw
Jig Saw & Circular Saw
It is highly recommended to view the assembly video prior to starting assembly!
Click here to View the assembly process or scan the QR code.
Manufactured by:
tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pure cube Neptune and is the answer not in the manual?

Questions and answers

Related Manuals for leisurecraft Pure cube Neptune

Summary of Contents for leisurecraft Pure cube Neptune

  • Page 1 2” hole Saw Jig Saw & Circular Saw It is highly recommended to view the assembly video prior to starting assembly! Click here to View the assembly process or scan the QR code. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 2 Assembly Instructions Please read this entire manual before proceeding with the assembly. Congratulations on the purchase of your Leisurecraft Pure Cube sauna. Leisurecraft Pure Cube saunas are available with various options. This manual is designed for these options, and every attempt has been made to make the installation information as clear as possible.
  • Page 3 Front Window Installation Roof Assembly Metal Siding & Trim Installation Wood Siding & Trim Installation Bench Assembly Side Wall Bench Assembly (Electric Heater Only) Inside Trim Installation Vent Kit Installation Care &Maintenance Warranty Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 4 A solid base for your sauna is recommended and can be made from the following. Concrete Pad Wood Deck Crushed Stone Patio Stone/Paver Blocks It is recommended to build a base larger than required to provide a sitting area for cooling off during your sauna session Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...

  • Page 5: Base Assembly

    Roughly center the 4 middle joists between the outside joists. Secure the outside joists to the front and back joists using 2 – 1 ½” (38mm) screws per corner. Repeat on all 4 corners. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 6 These will be the center floor joists and will be 2 joists back to back. Ensure the insulation supports are facing inwards to each side and secure with 2 – 1 ½” screws in the pre- drilled holes. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 7 (38mm) screws in the pre-drilled holes ensuring they are the same spacing as the front joist. Place the blocks of foam insulation in between the joists. You may need to trim off the end for a proper fit. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 8 For extra support, Secure every third floorboard to the inside floor joists with staples or finishing nails as well. When you get to the middle of the floor, remove the temporary floorboard that was placed earlier. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 9 You may use a rubber mallet to tap it into place. Once the last floorboard is in the proper placement, secure each of the unscrewed floorboards with a 1 ½” (38mm) screw into each joist. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...

  • Page 10: Wall Assembly

    Ensure it is flush to the back edge of the floor and secure with 2 – 3 ½” (89mm) screws into the back floor joist and 4 – 2 ½” (64mm) screws into the other wall panel. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 11 2 – 3 ½” (89mm) screws into the outer floor joist and 4 – 2 ½” (64mm) screws into the previous wall panel. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 12 Secure with 4 – 2 ½” (64mm) screws through the previous wall panel into the door panel. Install the last narrow next to the door and secure to the door panel with 4 – 2 ½” (64mm) screws. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 13 The lip of the panel rigger should be tight to the bottom side of the panel. Slide the dowel through the hole in the rigger so it is even on both sides. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 14 Insert the front window panel and ensure it is flush to the front of the floor and the side wall panels. Use a rubber mallet to finesse widow until it is flush by tapping on the wood of the panel. (if needed) Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 15 Repeat on the opposite side. Once the front window is installed, secure the narrow panel on either side of the glass panel with 2 - 3 ½” (89mm) screws to the outside floor joists. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 16 Neptune Outdoor Pure Cube Assembly Instructions Front Window Installation secure the front glass panel with 4 - 2 ½” (64mm) screws to the front floor joist. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...

  • Page 17: Roof Assembly

    Repeat for the side wall panels ensuring the roof panel is flush to the side walls. Repeat the above steps for the 2 roof panel. Ensure the insulation blocks are already installed in the roof panels Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 18 Repeat for the second sheet of plywood. Repeat for the last smaller sheet of plywood. You may need to trim off the end of the small sheet if it is not flush to the roof panel. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 19 Ensure it is flush at the front and 1” above the bottom of the top wall panel stud. Secure the nosing to the roof panels with 9 – 2 ½” (64mm) screws. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 20 *If metal siding option is selected, continue to next page, If wooden siding option is chosen, please skip to page 26 Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 21 Place a side metal trim piece over the side nosing and secure with 6 black screws on the top and 3 centered on the bottom of the metal trim. Repeat on opposite side. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 22 Cut out the fold over on the top of the metal trim on both ends. This will leave the side and bottom to be able to slide into the side trim of the sauna. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 23 Slide the trim assembly in until you have a ½” (13mm) gap between the assembly and the membrane on the back of the sauna. Secure the brackets to the side trim with 2 of the provided black roofing screws on each end. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 24 (3 on each side of the metal trim) Repeat on opposite side, Repeat the process for the trim at the back of the sauna only securing with screws on the outside edges of trim at this point. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 25 Place the first piece of metal siding by sliding it into the “J” side piece and then securing with 3 of the provided screws, 1 at the top, middle and bottom. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 26 On the door side of the sauna, Place a top “J” piece between the trim piece and the door and secure with 3 of the provided black screws. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 27 Install the bottom trim piece ensuring it is snug between the side “J” trim pieces securing with 3 of the provided screws. Follow the same process as the back wall for installing the metal siding pieces up to the door. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 28 Repeat for the opposite side wall of the sauna. Ensure the 2 last full piece of metal siding has the vent hole cut out towards the top. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 29 Place a wood trim piece on one side of the sauna front wall ensuring it is flush with the nosing. Secure with 7 – 2 ½” (64mm) screws. Repeat on opposite side. Repeat on the back of the sauna. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 30 Locate the small finisher piece. Ensure the groove is tight into the tongue of the previous panel and secure with 1 ¼” staples or finishing nails. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 31 Only put in the middle screw for the 3 and 4 board as they will be coming back off in the upcoming steps. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 32 Ensure it is level and trace the base of the vent cover. Remove the 3 & 4 boards. To make it easier for cutting, transfer the measurements from the front of the boards to the back side. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 33 Place the vent cover in the opening and trace out the top of the cover. Use a saw and a chisel to cut out the ribbed part of the board so it allows the vent cover to sit flush. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 34 (38mm) screws into the top, middle and bottom wall studs. Drill a 2” (51mm) hole in the center of the cut out. Only drill have way to prevent splintering on the inside of the sauna. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 35 Install the last full size siding board for this side of the sauna. Locate the small finisher piece. Ensure the tongue is tight into the groove of the previous panel and secure with 1 ¼” staples or finishing nails. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 36 Drill a 2” (51mm) hole in the center of the vent cut out. Only drill have way to prevent splintering on the inside of the sauna. Finish drilling the hole from the inside for a cleaner look. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 37 1 ½” (38mm) screws into the top trim and the middle and bottom wall studs. To make the last boards easier to install, you can remove the corner trim. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 38 Secure the brackets to the roof trim with 2 – ¼” hex bolts. Repeat on the other end. Center the bottom vent support under the top hole, ensure it is level and secure it with 3 – 1 ½” (38mm) screws Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 39 Use the hex key to snug up, do not tighten all the way. Ensure the outer handle lines up with the magnetic catch on the door frame and then tighten the lag bolts completely. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...

  • Page 40: Bench Assembly

    Repeat with the lower bench ensuring the curved front of the bench is facing upwards. Secure the support to the bench with 2 – 2 ½” (64mm) screws per support ensuring the support is square to the bench. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 41 Place the upper bench enclosure in place and secure with 2 - 1 ½” (38mm) screws into each support. Repeat for bottom enclosure. Screw between the slats of the support to make the screws less visible. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 42 Ensure the bench is tight to the side wall then secure with 2 - 2 ½” (64mm) screws in the back support and 2 - 2 ½” (64mm) screws in the floor support on each bracket. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 43 Place the side wall backrest 10” (25cm) to the bottom of the 2 slat above the bench and secure with 2 ½” (64mm) screws into each support. Screw between the slats of the support to hide the screws. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 44 Use a full piece of the corner trim for the side wall. Measure the distance remaining and cut accordingly. Repeat on opposite side wall. Repeat the above steps for the corners on the front wall. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 45 Cut accordingly and secure with staples or finishing nails. Install the crown molding over the seam between the 2 roof panels. Measure the remaining gap and cut a piece to fit. Secure it with staples or finishing nails. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...

  • Page 46: Vent Installation

    Only drill have way to prevent splintering on the inside of the sauna. Finish drilling the hole from the inside for a cleaner look. Install the vent and secure with the provided screws. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 47 Secure with 3 – 1 ½” (38mm) screws. Repeat the process for removing the insulation and installing the vent for the lower vent hole. Repeat the process to install the cedar slide cover. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
  • Page 48 Under normal conditions, a slight wash of the floor and benches with warm soapy water several times a year will maintain its cleanliness. Leisurecraft offers a sauna room cleaner that can be used pure or diluted at a 4-1 ratio. Simply spray and wipe! You can use a sheet of fine grit sandpaper or a low-pressure wash to remove more stubborn stains or for a deeper cleaning of the interior of your sauna.
  • Page 49 This natural weathering will not harm the wood or impair the sauna’s performance. If you wish to retain the natural color of your Leisurecraft Sauna, Leisurectaft offers cedar sauna stains in 4 amazing colors, Espresso, Limestone Trail, Onyx Gem and Pickled White in convenient 1-gallon pails.

  • Page 50: Warranty

    WARRANTY LeisureCraft warrants our saunas against defects in materials and workmanship under normal/residential use for a period of five (5) years, as applicable, from the date of receipt of the product by the original end-user consumer. This warranty does not apply to normal wear and tear and/or natural weather conditions.
