Summary of Contents for leisurecraft Southern Fantasy Tiki Bar
- Page 1 Southern Fantasy Tiki Bar 08/2023 Assembly Instructions Requirements: 2 People (recommended) Carpenter’s Hammer Cordless Drill Tape Measure Rubber Mallet View the assembly process Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
-
Page 2: Parts List
805903 Short Side Bar Wall - Right 805904 Assembled Bar Top with 2 Holes CT3672HARDWARE Southern Fantasy Hardware Package CT3672MANUAL Southern Fantasy Tiki Bar Owners Manual Options BCT3672C 3 Door Cabinet 805913 Front Cabinet Panel with 3 Pre-hung Doors 805914 11"x47-1/4"... - Page 3 Southern Fantasy Tiki Bar Assembly Instructions Index Parts List Base Assembly 3 Door Cabinet Assembly (Optional) Roof Assembly (Optional) Palm Thatch Installation (Optional) Synthetic Thatch Installation (Optional) Care &Maintenance Warranty Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 4 Slide the long front bar wall into place. Holding the walls flush together, secure them together using the provided 2 ½” (64mm) screws from the inside of the long front wall into the short side walls. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
-
Page 5: Base Assembly
Screw the bar top to the side walls using a 2 ½” (64mm) screw by screwing on an angle through the post holes into the wall. Repeat on opposite side. This completes the assembly of your Southern Fantasy Tiki Bar Base. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com... - Page 6 2 ½” (64mm) screws. The pre drilled holes in the top shelf should be facing away from the cabinet and on the bottom. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 7 Carefully stand the tiki bar back up. Secure the top shelf to the front wall using 2 ½” (64mm) screws in the pre-drilled holes. This completes the assembly of your Southern Fantasy Tiki Bar 3 door Cabinet! Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
-
Page 8: Roof Assembly
Insert the other log roof bottom side plate onto the other ends of the roof supports. Tap tight with a rubber mallet if necessary. Make sure the roof supports are straight and secure each joint with a 2 ½” (64mm) screw. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com... - Page 9 You may need to tap the boards with a rubber mallet to ensure they are tight together before screwing. Make sure the roof supports are straight and secure each joint with a 2 ½” (64mm) screw. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 10 You may need to tap the boards with a rubber mallet to ensure they are tight together before screwing. Install the roof bottom boards (straight edge on bottom) on each side. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 11 Using a hammer, fasten the palm thatch to the roof using the provided staple clips. These should be placed approximately every 8” and at least three rows per side. Repeat on other side of roof. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 12 Secure the assembled bar to the T posts from the inside using a 2 ½” (64mm) screw. Repeat on other end of bar. This completes the assembly of your Southern Fantasy Tiki Bar Palm Thatch Roof! Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
-
Page 13: Care And Maintenance
Southern Fantasy Tiki Bar! Care & Maintenance * The Southern Fantasy Tiki Bar is coated with a water based outdoor clear coat. To maintain this look, it may be required to re-apply a finish depending on the weathering. The natural palm thatch roofing material should be removed and stored indoors in the winter or when not in use for an extended period of time. -
Page 14: Warranty
This warranty is a parts only warranty and any service or labor costs would not be considered as part of the 3 year warranty. Purchaser Name: ________________________ Date: _______________ Purchased From: ________________________ Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
