Tuscany 673-7169 Installation Manual

Krieger commercial style pull-down kitchen faucet
Hide thumbs

Advertisement

Table of Contents

Tools
- Adjustable Wrenches
- Slip Joint Pliers
- Silicone
Maintenance
Tuscany
faucets are crafted with skill and quality to last a
®
lifetime. By following the instructions in this booklet, you will
enjoy this quality item for years to come. To clean, wipe gently
with a soft damp cloth, then wipe dry. Tuscany
very durable. However, to assure a long lasting luster, harsh
abrasives or polishes should be avoided.
Safety Tips
Turn off the water before loosening any connections or
disassembling the faucet. When working underneath a sink,
protect your eyes from any dust or dirt by wearing safety
glasses.
Important Points
Most problems can be fixed by tightening a nut or connection,
or replacing a washer. Check supply line connections for any
leaks and tighten if necessary. Don't overtighten any supply
line connections.
For Models:
673-7169, 673-7170
Krieger
Commercial Style
Pull-Down Kitchen Faucet
finishes are
®
1.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 673-7169 and is the answer not in the manual?

Questions and answers

Related Manuals for Tuscany 673-7169

Summary of Contents for Tuscany 673-7169

  • Page 1 ® lifetime. By following the instructions in this booklet, you will enjoy this quality item for years to come. To clean, wipe gently with a soft damp cloth, then wipe dry. Tuscany finishes are ® very durable. However, to assure a long lasting luster, harsh abrasives or polishes should be avoided.

  • Page 2: Package And Hardware Contents

    Package and Hardware Contents Product Specifications Maximum Flow Rate: 1.8 GPM (6.8 LPM) @ 60 PSI ASME A112.18.1/CSA B125 NSF/ANSI/CAN 61: Q ≤ 1 Ceramic cartridge Manufactured to include no more than 0.25% weighted average lead content on wetted surfaces PART DESCRIPTION QUANTITY...

  • Page 3: Installation Instructions

    Installation Instructions Shut off the water at the supply valves under the sink or at the main water supply. Disconnect the supply lines. Remove the existing faucet from the sink. Clean and dry the surface area where the new faucet will be mounted. To install with the optional deckplate for a 3-hole sink, skip to Step 4.

  • Page 4: Care And Cleaning

    Installation Instructions (Continued) From underneath the sink, secure the faucet body (A) to the sink using the rubber gasket (F), washer (E) and quick-install mounting nut (D). Push the quick-install mounting nut (D) upwards over the faucet shank (5.1) until it is pressed firmly against the underside of the sink and turn to tighten.

  • Page 5: Troubleshooting

    Troubleshooting If a faucet installation doesn’t deliver water properly or leaks, finding the cause and fixing it can be easy. PROBLEM POSSIBLE CAUSE SOLUTION Faucet leaks underneath Cartridge retaining nut has come 1. Move the handle to the OFF position. Unscrew the handle screw and handle.

  • Page 6: Replacement Parts

    Replacement Parts For replacement parts, call our customer service department at (877) 319-3757, 7:30 a.m. - 4:30 p.m., CST, Monday - Friday. PART # PART DESCRIPTION 673-7169 673-7170 Spray head RP 00025SS RP 00025MB Handle assembly RP 00026SS RP 00026MB...

  • Page 7: Limited Lifetime Warranty

    Rough-In Limited Lifetime Warranty The distributor warrants to the original consumer purchaser this product to be free from defects in material and workmanship under normal use in residential applications. At its option, the Company will provide repair parts or replace defective product when the product is used in accordance with the manufacturer’s specifications.

This manual is also suitable for:

673-7170
