- Page 1 AFA4000/E Airflow Controller Gas Sensor Operation Manual Rev01 For AFA4000/E controllers with firmware versions 5.96 or higher. May 2024...
-
Page 2: Table Of Contents
1. Index. General Operator Keypad Filter Selection Configuration Calibration Calibration Tips Control Settings Alarm and Display Settings Operation Alarms / Events Connection Diagrams Installation Warranty... -
Page 3: General
Manuals” on the TEL UK website: https://tel-uk.com/downloads/ The AFA4000/E airflow controller can be configured to monitor carbon filter saturation using an additional organic vapour type “gas” sensor. For recirculating fume cupboards, hoods and cabinets, the controller can be used to manually adjust the fan speed or can be set to control the fan speed to maintain a face velocity set point for Hepa Filter compensation. -
Page 4: Operator Keypad
3. Operator Keypad. Filter Status Bar graph Hours Counter Indicator Airflow Display Alarm Status Pushbutton Icons Pushbuttons Mute / Menu Pushbuttons... -
Page 5: Filter Selection
4. Filter Selection. The filter type is selected in the controller menus, then displayed on power up and in the diagnostics menus, selectable types: GP+, ACI+, ACR, ACM, AMM, FOR, EDU, MULTI, HEPA, GP/HEP Containment Suitability Filter Name ACIDS Acetic, Acetic anhydride, Acrylic, Butyric, Caprylic, Carbolic, Formic, Lactic, Osmium tetroxide, Palmitic, Phenol, Proprionic, Valeric (General Purpose) ALCOHOLS Ethyl, Amyl, Buryl, Cyclohexanol, Isopropyl, Methyl (methanol), Propyl... -
Page 6: Configuration
5. Configuration. Start Up: When the controller is first powered up, the following sequence of event occur: a. If the controller has been calibrated, the controller will run and enter normal operating mode. b. If the controller has not been calibrated, the unit will display “Requires Setup”, Press Mute to continue. - Page 7 Note – Steps 13, Power Up Memory, the controller stores the pushbutton on/off current status and when enabled, will restore the pushbutton to the previous state before powering down, e.g. if the fan was before power down on the controller will power back on with the fan on. Note –...
-
Page 8: Calibration
6.1 Calibration. 1. Ensure the Fan is switched on. 2. From the RUN screen, Press and Hold the Mute button until the Main Menu appears. 3. Use the Up / Down arrows to select Set Up Monitor and press Mute. 4. -
Page 9: Calibration Tips
6.2 Calibration Tips. 1. Allow at least 15 to 20 seconds wait for the airflow to settle before capturing the airflow samples, this will minimize the chance of an error caused by turbulence or fluctuations. 2. Avoid moving in front of the cabinet whilst calibrating the controller. 3.The low and high samples should be at least 0.2m/sec apart to calibrate the controller to ensure the controller is calibrated over a sensible working range. -
Page 10: Alarm And Display Settings
8. Alarm and Display settings. The Cal Config Menu contains all of the alarm, sensor and display functions and settings. Parameter Function Suggested Settings Display units Sets the velocity display units (m/sec or fpm) m/sec Low air alarm Sets the low air alarm value (typically 80% of design velocity) 0.32m/sec (64fpm) Reduced low air alarm Sets the low air alarm for Low set point (occupancy control) -
Page 11: Operation
9. AFA4000 Operation. • Switch the power on. • Press Fan On – Pushbutton 1. • The Filter saturation alarm will be inhibited for 60 seconds. • The Airflow alarms will be inhibited for the fan start up timer period. •... -
Page 12: Connection Diagrams
11. Connection Diagrams. 1. Using on board low voltage relay outputs, Max 24VAC/DC 1A. AFA4000/E AIRFLOW CONTROLLER REFER TO www.tel-uk.com GAS SENOR INSTALLATION INSTRUCTIONS INTERFACE BEFORE AIRFLOW SENSOR RJ45 0-10VDC 0-1 0V SPEED CONTROL RJ12 TO EC FAN RJ12 SENSOR CABLE (2M / 6’) - Page 13 2. Using high voltage relay outputs, Max 240VAC 10A AC1 from optional Relay Interface Unit. AFA4000/E AIRFLOW CONTROLLER REFER TO GAS SENOR INSTALLATION www.tel-uk.com INSTRUCTIONS INTERFACE BEFORE AIRFLOW SENSOR RJ45 0-10VDC 0-1 0V SPEED CONTROL RJ12 TO EC FAN RJ12 SENSOR CABLE (2M / 6’)
- Page 14 Typical Fan Wiring Diagrams. EC Fan: The 0-10V output can connect directly to the EC fan controller, the fan will automatically switch off at 0V input. Mains power fan with AC motor speed controller: The 10V signal can be wired in series with R1 so when the fan is off the 10V signal will be off and the fan will stop, and the minimum fan speed is set in the AFA4000 menus.
- Page 15 Typical Lights wiring diagrams. LED lights: The 24VDC power can be switched through the AFA4000 on board relay (R2). 230VAC lights / Fluorescent lights: The relay interface is required for 230V circuits. Lights Power Supply...
-
Page 16: Installation
Fit the airflow sensor to the side of the cabinet, ensure that the sensor is open to the room. • Connect the airflow and gas sensors. Note – full fitting instructions for the AFA4000 and SM7 airflow sensor are found in the standard AFA4000/E operation manual. Typical Installation. - Page 17 *The sensitivity and response speed of the gas sensor will depend on the sensor location in the plenum. Pre-tested cabinets: for cabinets that have been previously used or have been tested with the gas sensor fitted, ensure the sensor is mounted in the correct location. Un-tested cabinets: for cabinets that have never had a gas sensor fitted, the system will require testing to ensure the sensor detects the filter saturation correctly.
-
Page 18: Warranty
WARRANTY AND LIABILITY may not be amended or modified nor may any of its terms be waived except by a writing signed by an authorized representative of the Seller. Temperature Electronics Ltd. Unit 2 Wren Nest Road Glossop SK13 8HB United Kingdom T: +44 (0) 1457 865 635 www.tel-uk.com E: sales@tel-uk.com...
