Page 1 Thermal Optical Bi-spectrum Network Camera User Manual...
Page 2: About This Manual
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKMICRO BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT...
Page 3 Thermal Optical Bi-spectrum Network Camera User Manual WITHOUT LIMITATION, RIGHTS OF PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS. YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN RIGHTS ABUSES.
Page 4: Symbol Conventions
Thermal Optical Bi-spectrum Network Camera User Manual Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Indicates a hazardous situation which, if not avoided, will or Danger could result in death or serious injury. Indicates a potentially hazardous situation which, if not avoided, Caution could result in equipment damage, data loss, performance...
Page 5: Safety Instruction
Thermal Optical Bi-spectrum Network Camera User Manual Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. Laws and Regulations In the use of the product, you must be in strict compliance with the electrical safety ●...
Page 6: Installation
Thermal Optical Bi-spectrum Network Camera User Manual Please purchase the charger by yourself. Input voltage should meet the Limited Power ● Source (12 VDC, 24 VAC, or PoE(802.3af)) according to the IEC62368 standard. Please refer to technical specifications for detailed information. Make sure the plug is properly connected to the power socket.
Page 7 Thermal Optical Bi-spectrum Network Camera User Manual Never place the equipment in an unstable location. The equipment may fall, causing ● serious personal injury or death. This equipment is for use only with corresponding brackets. Use with other (carts, ● stands, or carriers) may result in instability causing injury.
Page 8 Thermal Optical Bi-spectrum Network Camera User Manual The equipment shall not be exposed to dripping or splashing and that no objects filled ● with liquids, such as vases, shall be placed on the equipment. No naked flame sources, such as lighted candles, should be placed on the equipment. ●...
Page 9: Table Of Contents
Thermal Optical Bi-spectrum Network Camera User Manual Contents Chapter 1 Overview ........................1 1.1 Brief Description ......................1 1.2 Function .......................... 1 Chapter 2 Device Activation and Accessing ................2 2.1 Activate Device ......................2 2.1.1 Activate the Device via Browser ................2 2.1.2 Activate the Device via SADP ................
Page 10 Thermal Optical Bi-spectrum Network Camera User Manual 3.13 Set SRTP ........................14 3.14 Set Modbus ........................ 14 3.15 Operate via Mobile Client ..................15 3.15.1 Enable Hik-Connect Service on Camera ............15 3.15.2 Set Up Hik-Connect ................... 16 3.15.3 Add Camera to Hik-Connect ................16 Chapter 4 Live View .........................
Page 11 Thermal Optical Bi-spectrum Network Camera User Manual 5.1.6 Frame Rate ......................23 5.1.7 Video Encoding ....................23 5.1.8 Smoothing ......................25 5.1.9 Display VCA Info ....................25 5.1.10 Audio Settings ....................25 5.1.11 Two-way Audio ....................26 5.1.12 Set ROI ....................... 26 5.1.13 Metadata ......................
Page 12 Thermal Optical Bi-spectrum Network Camera User Manual 5.2.20 Scene Mode ...................... 35 5.2.21 Local Output ...................... 35 5.3 OSD ..........................35 5.4 VCA Rule Display Settings ..................35 5.5 Set Privacy Mask ......................36 5.6 Overlay Picture ......................36 5.7 Set Manual DPC (Defective Pixel Correction) ............36 5.8 Set Picture in Picture ....................
Page 13 Thermal Optical Bi-spectrum Network Camera User Manual 7.2 Fire and Smoke Detection ................... 56 7.2.1 Recommended Scene ..................56 7.2.2 Set Fire and Smoke Detection ................56 7.2.3 Set Dynamic Fire Source Detection ..............59 7.2.4 Set Detection Shield Region ................60 7.3 Perimeter Protection ....................
Page 14 Thermal Optical Bi-spectrum Network Camera User Manual 9.2.4 Notify Surveillance Center .................. 77 9.2.5 Trigger Recording ....................77 9.2.6 Set Audible Alarm Output ................... 78 9.2.7 Set Flashing Alarm Light Output ................ 78 Chapter 10 System and Security .................... 80 10.1 View Device Information ...................
Page 15 Thermal Optical Bi-spectrum Network Camera User Manual 10.14.7 Set SSH ......................89 10.14.8 Set HTTPS ....................... 90 10.14.9 Set QoS ......................90 10.14.10 Set IEEE 802.1X .................... 91 10.15 User and Account ....................91 10.15.1 Set User Account and Permission ..............91 10.15.2 Online Users ....................
Page 16: Chapter 1 Overview
Thermal Optical Bi-spectrum Network Camera User Manual Chapter 1 Overview 1.1 Brief Description Thermal & Optical Bi-spectrum network camera equipped with built-in GPU which supports intelligent perimeter protection algorithm, can realize high-precision VCA detection and real-time alarm. It is applied to perimeter protection and fire-prevention purposes in critical infrastructures such as community, villa, construction site, factory, 4S stores, and so on.
Page 17: Chapter 2 Device Activation And Accessing
Thermal Optical Bi-spectrum Network Camera User Manual Chapter 2 Device Activation and Accessing To protect the security and privacy of the user account and data, you should set a login password to activate the device when access the device via network. Note Refer to the user manual of the software client for the detailed information about the client software activation.
Page 18: Activate The Device Via Sadp
Thermal Optical Bi-spectrum Network Camera User Manual 2.1.2 Activate the Device via SADP Search and activate the online devices via SADP software. Before You Start https://www.hikmicrotech.com to get SADP software to install. Access Steps 1. Connect your computer to the same Wi-Fi network that the device is in. 2.
Page 19: Illegal Login Lock
Thermal Optical Bi-spectrum Network Camera User Manual Operating System Web Browser Operation Settings > Network Service to enable WebSocket or WebSockets for normal view if plug-in installation is not required. Display and operation of certain functions are restricted. For example, Playback and Picture are not available.
Page 20 Thermal Optical Bi-spectrum Network Camera User Manual Locking Duration The device releases the lock after the setting duration.
Page 21: Chapter 3 Network Settings
Thermal Optical Bi-spectrum Network Camera User Manual Chapter 3 Network Settings 3.1 TCP/IP TCP/IP settings must be properly configured before you operate the device over network. IPv4 and IPv6 are both supported. Both versions can be configured simultaneously without conflicting to each other. Go to Configuration >...
Page 22: Multicast Discovery
Thermal Optical Bi-spectrum Network Camera User Manual Input IPv6 Address, IPv6 Subnet, IPv6 Default Gateway. Consult the network administrator for required information. It stands for maximum transmission unit. It is the size of the largest protocol data unit that can be communicated in a single network layer transaction. The valid value range of MTU is 1280 to 1500.
Page 23: Port Mapping
Thermal Optical Bi-spectrum Network Camera User Manual It refers to the port through which the browser accesses the device with certificate. Certificate verification is required to ensure the secure access. RTSP Port It refers to the port of real-time streaming protocol. SRTP Port It refers to the port of secure real-time transport protocol.
Page 24: Set Auto Port Mapping
Thermal Optical Bi-spectrum Network Camera User Manual 3.3.1 Set Auto Port Mapping Steps 1. Check Enable UPnP™, and choose a friendly name for the camera, or you can use the default name. 2. Select the port mapping mode to Auto. 3.
Page 25: Snmp
Thermal Optical Bi-spectrum Network Camera User Manual Note Audio Port varies according to different camera models. 3.5 SNMP You can set the SNMP network management protocol to get the alarm event and exception messages in network transmission. Before You Start Before setting the SNMP, you should download the SNMP software and manage to receive the device information via SNMP port.
Page 26: Access To Device Via Pppoe Dial Up Connection
Thermal Optical Bi-spectrum Network Camera User Manual 4. Input the domain name information, and click Save. Port to check the device 5. Check the device ports and complete port mapping. Refer to Port Mapping for port mapping settings. port, and refer to 6.
Page 27: Set Isup
Thermal Optical Bi-spectrum Network Camera User Manual 3.8 Set ISUP When the device is registered on ISUP platform (formerly called Ehome), you can visit and manage the device, transmit data, and forward alarm information over public network. Steps 1. Go to Configuration > Network > Advanced Settings > Platform Access . 2.
Page 28: Set Alarm Server
Thermal Optical Bi-spectrum Network Camera User Manual 3.11 Set Alarm Server The device can send alarms to destination IP address or host name through HTTP, HTTPS, or ISUP protocol. The destination IP address or host name should support HTTP, HTTP, or ISUP data transmission.
Page 29: Set Srtp
Thermal Optical Bi-spectrum Network Camera User Manual 3. Click Save. 3.13 Set SRTP The Secure Real-time Transport Protocol (SRTP) is a Real-time Transport Protocol (RTP) internet protocol, intended to provide encryption, message authentication and integrity, and replay attack protection to the RTP data in both unicast and multicast applications. Steps 1.
Page 30: Operate Via Mobile Client
Thermal Optical Bi-spectrum Network Camera User Manual 3.15 Operate via Mobile Client Hik-Connect is an application for mobile devices. Using the App, you can view live image, receive alarm notification and so on. Note Hik-Connect service should be supported by the camera. 3.15.1 Enable Hik-Connect Service on Camera Hik-Connect service should be enabled on your camera before using the service.
Page 31: Set Up Hik-Connect
Thermal Optical Bi-spectrum Network Camera User Manual 3. Check Enable Hik-Connect. 4. Create a verification code or change the old verification code. Note The verification code is required when you add the camera to Hik-Connect service. 5. Click and read "Terms of Service" and "Privacy Policy". 6.
Page 32 Thermal Optical Bi-spectrum Network Camera User Manual Note The router should be the same one which your mobile phone has connected to. 8. Tap Add in the next interface to finish adding. For detailed information, refer to the user manual of the Hik-Connect app.
Page 33: Chapter 4 Live View
Thermal Optical Bi-spectrum Network Camera User Manual Chapter 4 Live View It introduces the live view parameters, function icons and transmission parameters settings. 4.1 Live View Parameters The supported functions vary depending on the model. Note For multichannel devices, select the desired channel first before live view settings. 4.1.1 Window Division refers to 1 ×...
Page 34: View Previous/Next Page
Thermal Optical Bi-spectrum Network Camera User Manual 2. In live view image, drag the mouse to select the desired region. 3. Click in the live view image to back to the original image. 4.1.5 View Previous/Next Page When the number of channels surpasses that of live view window division, this function can switch live view among multiple channels.
Page 35: Lens Parameters Adjustment
Thermal Optical Bi-spectrum Network Camera User Manual Steps 1. Click to show quick setup page. 2. Set PTZ, display settings, OSD, video/audio and VCA resource parameters. Lens Parameters Adjustment . - For PTZ settings, see Display Settings . - For display settings, see OSD .
Page 36 Thermal Optical Bi-spectrum Network Camera User Manual Protocol TCP ensures complete delivery of streaming data and better video quality, yet the real-time transmission will be affected. It is suitable for the stable network environment. UDP is suitable for the unstable network environment that does not demand high video fluency.
Page 37: Chapter 5 Video And Image Settings
Thermal Optical Bi-spectrum Network Camera User Manual Chapter 5 Video and Image Settings This part introduces the configuration of video/audio and image related parameters. 5.1 Video Settings This part introduces the settings of video parameters, such as, stream type, video encoding, and resolution.
Page 38: Resolution
Thermal Optical Bi-spectrum Network Camera User Manual 5.1.3 Resolution Select video resolution according to actual needs. Higher resolution requires higher bandwidth and storage. 5.1.4 Bitrate Type and Max. Bitrate Constant Bitrate It means that the stream is compressed and transmitted at a comparatively fixed bitrate.
Page 39: I-Frame Interval
Thermal Optical Bi-spectrum Network Camera User Manual H.265 H.265, also known as High Efficiency Video Coding (HEVC) and MPEG-H Part 2, is a compression standard. In comparison to H.264, it offers better video compression at the same resolution, frame rate and image quality. MJPEG Motion JPEG (M-JPEG or MJPEG) is a video compression format in which intraframe coding technology is used.
Page 40: Smoothing
Thermal Optical Bi-spectrum Network Camera User Manual 5.1.8 Smoothing It refers to the smoothness of the stream. The higher value of the smoothing is, the better fluency of the stream will be, though, the video quality may not be so satisfactory. The lower value of the smoothing is, the higher quality of the stream will be, though it may appear not fluent.
Page 41: Two-Way Audio
Thermal Optical Bi-spectrum Network Camera User Manual LineIn Set Audio Input to LineIn when the device connects to the audio input device with the high output power, such as MP3, synthesizer or active pickup. MicIn Set Audio Input to MicIn when the device connects to the audio input device with the low output power, such as microphone or passive pickup.
Page 42: Metadata
Thermal Optical Bi-spectrum Network Camera User Manual Steps 1. Go to Configuration > Video/Audio > ROI . 2. Check Enable. 3. Select the channel No. according to your need. 4. Select Stream Type. 5. Select Region No. in Fixed Region to draw ROI region. 1)Click Draw Area.
Page 43: Image Adjustment
Thermal Optical Bi-spectrum Network Camera User Manual 5.2.1 Image Adjustment By adjusting the Brightness, Saturation, Hue, Sharpness and Contrast, the image can be best displayed. Figure 5-1 Saturation 5.2.2 Image Adjustment (Thermal Channel) You can optimize the image display effect of thermal channel by manual correction. Manual Correction Click DPC (Defective Pixel Correction) to optimize the image once.
Page 44: Exposure Settings
Thermal Optical Bi-spectrum Network Camera User Manual 5.2.3 Exposure Settings Exposure is controlled by the combination of iris, shutter, and photo sensibility. You can adjust image effect by setting exposure parameters. In manual mode, you need to set Exposure Time, Gain and Slow Shutter. 5.2.4 Day/Night Switch Day/Night Switch function can provide color images in the day mode and turn on fill light in the night mode.
Page 45: Blc
Thermal Optical Bi-spectrum Network Camera User Manual Adjust the upper limit of supplement light power. Light Brightness Control Control supplement light brightness automatically or manually. Auto The brightness adjusts according to the actual environment automatically. Manual You can drag the slider or set value to adjust the brightness. Note The function varies according to device models.
Page 46: White Balance
Thermal Optical Bi-spectrum Network Camera User Manual Figure 5-2 WDR 5.2.8 White Balance White balance is the white rendition function of the camera. It is used to adjust the color temperature according to the environment. Figure 5-3 White Balance 5.2.9 DNR Digital Noise Reduction is used to reduce the image noise and improve the image quality.
Page 47: Defog
Thermal Optical Bi-spectrum Network Camera User Manual Figure 5-4 DNR 5.2.10 Defog You can enable the defog function when the environment is foggy and the image is misty. It enhances the subtle details so that the image appears clearer. Figure 5-5 Defog 5.2.11 Gray Scale This section intrduces the gray scale function in optical channel.
Page 48: Set Target Enhancement
Thermal Optical Bi-spectrum Network Camera User Manual Steps 1. Go to Configuration > Image > Display Settings . 2. Select the thermal channel. 3. Select a palette mode in Image Enhancement according to your need. Result The live view displays the image with palette. 5.2.13 Set Target Enhancement You can set the color of the targets in different temperature ranges to identify the target quickly.
Page 49: Brightness Sudden Change
Thermal Optical Bi-spectrum Network Camera User Manual Set the DDE level to control the details of the image. The higher the level is, the more details shows, but the higher the noise is. 5.2.15 Brightness Sudden Change When the brightness of target and the background is hugely different (the temperature difference of target and background is huge), the system reduces the difference for viewing.
Page 50: Scene Mode
Thermal Optical Bi-spectrum Network Camera User Manual 5.2.20 Scene Mode There are several sets of image parameters predefined for different installation environments. Select a scene according to the actual installation environment to speed up the display settings. 5.2.21 Local Output Enter a short description of your concept here (optional).
Page 51: Set Privacy Mask
Thermal Optical Bi-spectrum Network Camera User Manual 5.5 Set Privacy Mask The function blocks certain areas in the live view to protect privacy. No matter how the device moves, the blocked scene will never be seen. Steps 1. Go to privacy mask setting page: Configuration > Image > Privacy Mask . 2.
Page 52: Set Picture In Picture
Thermal Optical Bi-spectrum Network Camera User Manual 3. Select manual mode. 4. Click the defective pixel on the image, then a cursor shows on the live view. 5. Click Up, Down, Left, Right to adjust the cursor position to the defective pixel position. 6.
Page 53 Thermal Optical Bi-spectrum Network Camera User Manual Note Not all models support this function. Please take the actual product for reference.
Page 54: Chapter 6 Video Recording And Picture Capture
Thermal Optical Bi-spectrum Network Camera User Manual Chapter 6 Video Recording and Picture Capture This part introduces the operations of capturing video clips and snapshots, playback, and downloading captured files. 6.1 Storage Settings This part introduces the configuration of several common storage paths. 6.1.1 Set Memory Card If you choose to store the files to memory card, make sure you insert and format the memory card in advance.
Page 55: Set Ftp
Thermal Optical Bi-spectrum Network Camera User Manual Steps 1. Go to NAS setting page: Configuration > Storage > Storage Management > Net HDD . 2. Click HDD No.. Enter the server address and file path for the disk. Server Address The IP address of the network disk.
Page 56: Set Cloud Storage
Thermal Optical Bi-spectrum Network Camera User Manual 3. Click Upload Picture or Upload Video to enable uploading snapshots or videos to the FTP server. 4. Click Test to verify the FTP server. 5. Click Save. 6.1.4 Set Cloud Storage It helps to upload the captured pictures and data to the cloud. The platform requests picture directly from the cloud for picture and analysis.
Page 57: Record Automatically
Thermal Optical Bi-spectrum Network Camera User Manual 6.2.1 Record Automatically This function can record video automatically during configured time periods. Before You Start Select Trigger Recording in event settings for each record type except Continuous. See Event and Alarm for details. Steps Note The function varies according to different models.
Page 58: Record Manually
Thermal Optical Bi-spectrum Network Camera User Manual Enable Overwrite to overwrite the video records when the storage space is full. Otherwise the camera cannot record new videos. Pre-record The time period you set to record before the scheduled time. Post-record The time period you set to stop recording after the scheduled time.
Page 59: Capture Configuration
Thermal Optical Bi-spectrum Network Camera User Manual Note Go to Configuration > Local , click Save clips to to change the saving path of clipped video files. 5. Click on the playback interface to download files. 1)Set search condition and click Search. 2)Select the video files and then click Download.
Page 60: View And Download Picture
Thermal Optical Bi-spectrum Network Camera User Manual JPEG The picture size of this format is comparatively small, which is better for network transmission. The picture is compressed with good quality. 3. Click Save. 4. Click near the live view or play back window to capture a picture manually. 6.3.3 View and Download Picture You can search, view and download the pictures stored in the local storage or network storage.
Page 61: Chapter 7 Vca Resource
Thermal Optical Bi-spectrum Network Camera User Manual Chapter 7 VCA Resource VCA resource is a collection of smart functions supported by the device. 7.1 Temperature Measurement When you enable this function, the device measures the actual temperature of the scene. It alarms when temperature exceeds the temperature threshold value.
Page 62 Thermal Optical Bi-spectrum Network Camera User Manual Figure 7-1 Thermography Configuration Flow Chart...
Page 63: Automatic Thermography
Thermal Optical Bi-spectrum Network Camera User Manual Note Quick Start Guide for detailed information of Installation part in the flow Please refer to the chart. 7.1.3 Automatic Thermography Configure the temperature measurement parameters and temperature measurement rules. The device can measure the actual temperature and output alarms when temperature exceeds the alarm threshold value.
Page 64 Thermal Optical Bi-spectrum Network Camera User Manual Check to add data on alarm triggered capture of thermal channel. Picture Quality Set picture quality as high, medium, or low. Add Original Data on Stream Add and save original raw data to stream. The function requires higher network bandwidth.
Page 65 Thermal Optical Bi-spectrum Network Camera User Manual Alarm Interval Set the alarm interval between two alarms. Reflect Light Filter Enable these functions if there is strong reflected light from sun, or it may cause false alarm. The filter sensitivity can be adjusted. Check Display Filtering Status, and an OSD will be displayed when the function is enabled.
Page 66 Thermal Optical Bi-spectrum Network Camera User Manual When the temperature of target exceeds the Pre-Alarm Threshold and this status lasts not shorter than the Filtering Time, the pre-alarm is triggered. Alarm Threshold and Filtering Time When the temperature of target exceeds the Alarm Threshold, and this status lasts not shorter than the Filtering Time, the alarm is triggered.
Page 67 Thermal Optical Bi-spectrum Network Camera User Manual 7. Click Save. The maximum and minimum temperature will be displayed on the live view. Note Go to Image > VCA Rules Display to adjust the fonts size and the temperature colour of normal, alarm and pre-alarm.
Page 68 Thermal Optical Bi-spectrum Network Camera User Manual Set the emissivity of the target. The emissivity of the surface of a material is its effectiveness in emitting energy as thermal radiation. Different objects have different Common Material Emissivity Reference to search for the target emissivity.
Page 69 Thermal Optical Bi-spectrum Network Camera User Manual Note The function varies according to different camera models. 1)Click 2)Check Enable Offsite. 3)Set the offsite pre-alarm/alarm and follow step 4~5 to adjust the pre-alarm/alarm temperature and arming schedule during working hours. Note The same parameters and linkage method apply to the two kinds of pre-alarm/alarm, only the threshold temperature and arming schedule vary.
Page 70 Thermal Optical Bi-spectrum Network Camera User Manual Line Thermography Configure the temperature measurement rule and monitor the maximum temperature of the line. Steps 1. Click and drag the mouse to draw a line in the live view interface. 2. Click and move the line to adjust the position. 3.
Page 71: Manual Thermography
Thermal Optical Bi-spectrum Network Camera User Manual 7.1.4 Manual Thermography After enable the manual thermography function of the device, you can click any position on the live view to show the real temperature. Steps 1. Go to Configuration > Local and select Display Temperature Info. as Yes. 2.
Page 72 Thermal Optical Bi-spectrum Network Camera User Manual Before You Start Go to Configuration > System > Maintenance > VCA Resource Type , select Temperature Measurement + Fire and Smoke Detection. Steps 1. Go to Configuration > Event > Smart Event , select Fire and Smoke Detection. 2.
Page 73 Thermal Optical Bi-spectrum Network Camera User Manual Detection Function Parameter Description Set the alarm interval between two alarms. The smaller the value is, the higher the detection frequency is. Picture Quality Set quality of the alarm capture. The better the quality is, the sharper the image is, and the larger the file size is.
Page 74: Set Dynamic Fire Source Detection
Thermal Optical Bi-spectrum Network Camera User Manual Note Smoke Detection is not supported when Day/Night Switch mode is Night or when the device identifies the environment as night. 5. Optional: Go to Smart Event > Smoke Detection Shield . You can shield certain areas Set Detection Shield Region .
Page 75: Set Detection Shield Region
Thermal Optical Bi-spectrum Network Camera User Manual Resource Type is selected as Temperature Measurement + Fire and Smoke Detection, Dynamic Fire is also supported in Fire Source Detection. 6. Check Display Fire Source Frame on Stream to display a red frame around the fire source on stream when fire occurs.
Page 76 Thermal Optical Bi-spectrum Network Camera User Manual 3. Optional: Check Enable Fusion to view optical and thermal image. 4. Set perimeter protection rules. 1)Click to add a new rule. 2)Enter the rule name, and click the drop down menu to select Rule Type. Line Crossing If any target moves across the setting line, the alarm will be triggered.
Page 77 Thermal Optical Bi-spectrum Network Camera User Manual Rule Type How to Draw and What Parameters to Set Note The recommended drawing is optional for some camera models, refer to the pop-up operation guide after you checked Intelligent Analysis. b. Set Duration. When a target intrudes into the set area and stays in the area for more than the set duration, the device triggers an intrusion alarm.
Page 78: Set Perimeter Protection Shield Region
Thermal Optical Bi-spectrum Network Camera User Manual Check to enable Filter by Pixel. Draw max. size and min. size rectangles to filter the target among human, vehicle, animal, and others. Only the target whose size is between the Max. Size and Min. Size value will trigger the alarm. Note The filter configuration is optional for some camera models, refer to the pop-up ●...
Page 79: Calibration
Thermal Optical Bi-spectrum Network Camera User Manual Select to display target info and rule on stream, the information will be added to the video stream, and the overlay will be displayed if you get live view or play back by the VS Player.
Page 80 Thermal Optical Bi-spectrum Network Camera User Manual Caution The auto calibration starts when the person is totally seen in live view, and ends when ● the person is in the endpoint. The endpoint-to-camera distance (m) equals 4 times the lens focal length (mm). E.g, ●...
Page 81: Set Advanced Configuration Parameters
Thermal Optical Bi-spectrum Network Camera User Manual Caution Separate 4 vertical lines in the optical-axis direction at the close site, middle and far ● site respectively. Separate 4 vertical lines at the left, middle and right of the image respectively. ●...
Page 82: Open Platform
Thermal Optical Bi-spectrum Network Camera User Manual Note The settings vary according to different models. 7.4 Open Platform Open platform allows you to install the application for the third-party to develop and run its function and service. Note Only certain device models support the function. 7.4.1 Set Open Platform You can install the application for the third-party to develop and run its function and service.
Page 83 Thermal Optical Bi-spectrum Network Camera User Manual Click Download Logs Export log. Click Update Browse a local path and import an application package to update the application. Figure 7-2 Set VCA Resource...
Page 84: Chapter 8 Event And Alarm
Thermal Optical Bi-spectrum Network Camera User Manual Chapter 8 Event and Alarm This part introduces the configuration of events. The device takes certain response to triggered alarm. Certain events may not be supported by certain device models. 8.1 Set Motion Detection It helps to detect the moving objects in the detection region and trigger the linkage actions.
Page 85: Expert Mode
Thermal Optical Bi-spectrum Network Camera User Manual 8.1.2 Expert Mode You can configure the motion detection parameters of day/night switch according to the actual needs. Steps 1. Select expert mode in Configuration. 2. Set parameters of expert mode. Day/Night Switch OFF: Day/Night switch is disabled.
Page 86: Set Alarm Input
Thermal Optical Bi-spectrum Network Camera User Manual Clear All Delete all the drawn areas. Figure 8-1 Set Video Tampering Area Set Arming Schedule for setting scheduled time. Refer to Linkage Method 6. Refer to Settings for setting linkage method. 7. Click Save. 8.3 Set Alarm Input Alarm signal from the external device triggers the corresponding actions of the current device.
Page 87: Set Exception Alarm
Thermal Optical Bi-spectrum Network Camera User Manual 6. Click Save. 8.4 Set Exception Alarm Exception such as network disconnection can trigger the device to take corresponding action. Steps 1. Go to Configuration > Event > Basic Event > Exception . 2.
Page 88: Detect Scene Change
Thermal Optical Bi-spectrum Network Camera User Manual Note The lower the sensitivity is, the more significant the change should be to trigger the ● detection. The sound intensity threshold refers to the sound intensity reference for the ● detection. It is recommended to set as the average sound intensity in the environment.
Page 89: Chapter 9 Arming Schedule And Alarm Linkage
Thermal Optical Bi-spectrum Network Camera User Manual Chapter 9 Arming Schedule and Alarm Linkage Arming schedule is a customized time period in which the device performs certain tasks. Alarm linkage is the response to the detected certain incident or target during the scheduled time.
Page 90: Manual Alarm
Thermal Optical Bi-spectrum Network Camera User Manual Manual Alarm You can trigger an alarm output manually. Steps 1. Set the manual alarm parameters. Alarm Output No. Select the alarm output No. according to the alarm interface connected to the external alarm device. Alarm Name Custom a name for the alarm output.
Page 91: Ftp/Nas/Memory Card Uploading
Thermal Optical Bi-spectrum Network Camera User Manual Steps 1. Check Enable Auto Trigger. 2. Set Trigger Time, and the device will trigger an alarm output to the alarm server automatically in the set time. 3. Set Auto Trigger Delay. It refers to the time duration that the alarm output remains in effect after the auto trigger.
Page 92: Notify Surveillance Center
Thermal Optical Bi-spectrum Network Camera User Manual When you select SSL or TLS, and disable STARTTLS, emails are sent after encrypted ● by SSL or TLS. The SMTP port should be set as 465. When you select SSL or TLS and Enable STARTTLS, emails are sent after encrypted ●...
Page 93: Set Audible Alarm Output
Thermal Optical Bi-spectrum Network Camera User Manual For device with more than one camera channels, you can set one or more channels to take recordings if needed. Video Recording and Picture Capture . For recording settings, refer to 9.2.6 Set Audible Alarm Output When the device detects targets in the detection area, audible alarm can be triggered as a warning.
Page 94 Thermal Optical Bi-spectrum Network Camera User Manual Note Only certain camera models support the function.
Page 95: Chapter 10 System And Security
Thermal Optical Bi-spectrum Network Camera User Manual Chapter 10 System and Security It introduces system maintenance, system settings and security management, and explains how to configure relevant parameters. 10.1 View Device Information You can view device information, such as Device No., Model, Serial No. and Firmware Version.
Page 96: Export Diagnose Information
Thermal Optical Bi-spectrum Network Camera User Manual Note You can import the exported Device Common Parameters to devices of the same series. 4)Click Browse to select the saved configuration file. 5)Input the encryption password you have set when exporting the configuration file. 6)Click Import.
Page 97: Upgrade
Thermal Optical Bi-spectrum Network Camera User Manual 2. Click Restore or Default according to your needs. Restore Reset device parameters, except user information, IP parameters and video format to the default settings. Default Reset all the parameters to the factory default. Note Be careful when using this function.
Page 98: Set Ntp Server
Thermal Optical Bi-spectrum Network Camera User Manual 2. Select Time Zone. 3. Click Manual Time Sync.. 4. Choose one time synchronization method. - Select Set Time, and manually input or select date and time from the pop-up calendar. - Check Sync. with computer time to synchronize the time of the device with that of the local PC.
Page 99: Set Rs-485
Thermal Optical Bi-spectrum Network Camera User Manual Before You Start Connect the device to computer or terminal with RS-232 cable. Steps 1. Go to Configuration > System > System Settings > RS-232 . 2. Set RS-232 parameters to match the device with computer or terminal. 3.
Page 100: Security
Thermal Optical Bi-spectrum Network Camera User Manual 10.14 Security You can improve system security by setting security parameters. 10.14.1 Authentication You can improve network access security by setting RTSP and WEB authentication. Go to Configuration > System > Security > Authentication to choose authentication protocol and method according to your needs.
Page 101: Set Ip Address Filter
Thermal Optical Bi-spectrum Network Camera User Manual Security audit logs can be saved on device internal storage. The log will be saved every half hour after device booting. Due to limited storage space, you can also save the logs on a log server.
Page 102: Set Mac Address Filter
Thermal Optical Bi-spectrum Network Camera User Manual 10.14.4 Set MAC Address Filter MAC address filter is a tool for access control. You can enable the MAC address filter to allow or forbid the visits from the certain MAC addresses. Steps Note MAC Address Filter is mutually exclusive with IP Address Filter.
Page 103: Create Certificate Request
Thermal Optical Bi-spectrum Network Camera User Manual 4. Optional: Click Export to export the certificate, or click Delete to delete the certificate to recreate a certificate, or click Certificate Properties to view the certificate details. Create Certificate Request Before You Start Select a self-signed certificate.
Page 104: Control Timeout Settings
Thermal Optical Bi-spectrum Network Camera User Manual Install CA Certificate Steps 1. Click Import. 2. Enter the Certificate ID. 3. Click Browser to select the desired server/client certificate. 4. Select the desired import method and enter the required information. 5. Click OK. Note Up to 16 certificates are allowed.
Page 105: Set Https
Thermal Optical Bi-spectrum Network Camera User Manual Steps 1. Go to Configuration > System > Security > Security Service . 2. Check Enable SSH. 3. Click Save. 10.14.8 Set HTTPS HTTPS is a network protocol that enables encrypted transmission and identity authentication, which improves the security of remote access.
Page 106: Set Ieee 802.1X
Thermal Optical Bi-spectrum Network Camera User Manual 10.14.10 Set IEEE 802.1X You can authenticate user permission of the connected device by setting IEEE 802.1X. Go to Configuration > Network > Advanced Settings > 802.1X , and enable the function. Select protocol and version according to router information. User name and password of server are required.
Page 107: Online Users
Thermal Optical Bi-spectrum Network Camera User Manual 3. Click General to set the allowed number of multi-user simultaneous login. Note Only the administrator has the authority to the operation. 4. Click OK. 10.15.2 Online Users The information of users logging into the device is shown. Go to Configuration >...
Page 108: Chapter 11 Appendix
Thermal Optical Bi-spectrum Network Camera User Manual Chapter 11 Appendix 11.1 Common Material Emissivity Reference Material Emissivity Human Skin 0.98 Printed Curcuit Board 0.91 Concrete 0.95 Ceramic 0.92 Rubber 0.95 Paint 0.93 Wood 0.85 Pitch 0.96 Brick 0.95 Sand 0.90 Soil 0.92 Cloth...
