OVERVIEW
This add-in interface module permits the use of the HFC-WSW-03 and HFC-SBW-23-03 conventional sounders on an Altair intelligent loop.
COMPATIBILITY
This module is compatible only with:
- Intelligent control panels and systems based on the Argus Security Altair protocol.
- the conventional HFC-WSW-03 sounder and HFC-SBW-23-03 sounder/VAD.
For more specific information regarding compatibility refer to your fire security system supplier and the technical documentation concerning the
control panel in use.
INSTALLATION - IMPORTANT NOTES
This module must be wired according to the wiring details described in this manual.
Disconnect the intelligent loop from the control panel before wiring.
Test the HFI-SIM-01 and HFC-WSW-03 / HFC-SBW-23-03 assembly after installation.
ASSOCIATED DEVICE'S INSTALLATION INSTRUCTIONS
This manual provides installation instructions limited only to the HFI-SIM-01.
For specific installation instructions about the HFC-WSW-03 and HFC-SBW-23-03 refer to their separate manuals:
HFC-WSW-03 installation instructions
HFC-SBW-23-03 installation instructions
BEFORE ADDING IN THE MODULE
As described in the HFC-WSW-03 / HFC-SBW-23-03 manuals remember to:
1) Detach the front sounder body from the sounder back box.
2) Prepare the cable entry (or entries) on the sounder back box.
3) Fix the sounder back box to the wall.
Furthermore:
4) Assign a loop address to this module (as described below).
ADDRESS ASSIGNMENT
An address must be assigned to the device:
- The address must be unique: no other device on the intelligent loop must have the same address.
- It is possible to select an address between 1 and 240.
In order to address the module, use one of the following methods:
- Use the HFI-DPT-05 manual programmer: this must be connected to the intelligent interface module using a suitable connector; for further
information consult the manual programmer's instructions and refer to the following "CONNECTION TO THE HFI-DPT-05 MANUAL
PROGRAMMER" section.
- Perform the automatic addressing routine from the control panel once all loop devices have been wired.
This method can be used only if the control panel has been designed with this functionality; in any case, refer to your contr ol panel manual
and, above all, your system supplier, since performing this process is not possible on all types of installations.
For identification purposes, it is possible to record the loop number and device address on the module label.
Hyfire Wireless Fire Solutions Limited - Unit B12a, Holly Farm Business Park, Honiley,
Warwickshire, CV8 1NP - United Kingdom
HFI-SIM-01
ALTAIR WALL SOUNDER MODULE
code: L20-CWS1W-1400
code: L20-CWSVW-1400
*
928ah/01
**
928z/01
*
HFI-SIM-01 + HFC-WSW-03
HFI-SIM-01 + HFC-SBW-23-03
**
