Summary of Contents for Rovin TCA542
- Page 1 TCA542 Portable Gas BBQ INSTRUCTION MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Information ................... 3 Part List ......................... 6 Installation & Assembly ................. 7 Positioning the Barbecue ................8 Using the Barbecue ..................10 Portable Gas Cylinders ..................11 Leak Test ......................12 Care Instructions ....................13 Maintenance ...................... 14 Troubleshooting ....................15 Warranty Information ..................16... -
Page 3: Safety Information
SAFETY INFORMATION This barbecue has been tested and certified in accordance with Australian Standards AS 4557 (Amendment 2) and is approved for use in Australia. WARNING: This barbecue must not be used indoors. Read this instruction manual carefully before assembling and using the barbecue. - Page 4 If there is a leak: Turn the gas cylinder off Disperse gas be encouraging maximum ventilation and spraying with a fine water spray. Check all connections. If the leak persists, keep the cylinder upright and keep outside. Keep skin away from any gas or liquid escaping from the cylinder. Keep the cylinder at least 20 metres away from any spark or ignition source, including electrical equipment, camera flashes, and engines.
- Page 5 DO’S • Do have LPG cylinders filled by an authorised LPG supplier. • Do check all gas line connections for leaks with a soapy solution prior to lighting, and tighten until bubbles disappear. • Do turn off the gas off if the barbecue doesn’t ignite straight away. Try again after 1 minute.
-
Page 6: Part List
PART LIST HANDLE OF LID FLAME TAMER COOKING GRID BODY GREASE BOX REGULATOR (LPG) 10. IGNITION CONTROL ASSEMBLY KNOB... -
Page 7: Installation & Assembly
INSTALLATION & ASSEMBLY It is important to read these instructions thoroughly. • The appliance must be installed in accordance with these instructions and installation requirements of your local Gas Authority. • Before installing the barbecue, consider the location of the gas supply and routing of the gas line. -
Page 8: Positioning The Barbecue
POSITIONING THE BARBECUE This barbecue should only be used in an above ground open air situation with natural ventilation, without stagnant areas where gas leakage and products of combustion are rapidly dispersed by wind and natural convection. Any enclosure in which the barbecue is used shall comply with one of the following: •... - Page 9 The following figures are diagrammatical representations of outdoor areas described. Rectangular areas have been used in these figures - the same principle applies to any other shaped area.
-
Page 10: Using The Barbecue
USING THE BARBECUE Lighting Instructions: Using the spark ignition: • Turn on the gas cylinder. • With the barbecue hood open, press and turn the control knob in an anti-clockwise direction to the HIGH position and press the red ignition button 3 successive times. -
Page 11: Portable Gas Cylinders
Portable appliances often have a short length of hose which connects the gas bottle to the appliance. TCA542 DO NOT REMOVE ® AUSTRALIA AND NEW ZEALAND... -
Page 12: Leak Test
LEAK TEST Before lighting your barbecue it is important to carry out this simple test to check there are no gas leaks. All gas connections must be tested before each use by using soapy water solution. Turn on the gas cylinder but make sure all the barbecue controls are turned OFF. -
Page 13: Care Instructions
CARE INSTRUCTIONS Stainless Steel Wash in hot soapy water, rinse and dry immediately. To remove streaks or heat stains from stainless steel, rub with soda water. Never use abrasives, such as general household cleaning products, heavy duty cleaners, bleach, steel wool or salt. Dampness can lead to rust. Steel The steel in this product may experience rusting deterioration over a prolonged period of time if left outside unprotected. -
Page 14: Maintenance
MAINTENANCE After cooking, turn the control knob to the HI setting for 5 minutes to burn off excess grease deposits. Then turn off the gas at the gas cylinder and then the barbecue. Let the barbecue cool down before removing any parts for cleaning, or moving the barbecue. -
Page 15: Troubleshooting
TROUBLESHOOTING BBQ will not light properly: • Check LPG supply is turned on • Ensure all gas connections are secure. • Check that the end of the burner is positioned properly over the gas valve. • Check that there are no spider webs or debris clogging the burner. •... -
Page 16: Warranty Information
WARRANTY INFORMATION Our product is guaranteed to be free from manufacturing defects for a period of 12 Months. If your product becomes defective during this period, Electus Distribution will repair, replace, or refund where a product is faulty; or not fit for intended purpose.
