MAYTONI TRA Series Operating Manual

1. Overview and Purpose of the Device
The power supply unit is designed for connecting magnetic track lighting systems to an AC
network with a nominal voltage of 85-264V and a frequency of 47-63Hz, converting it to a safe,
extra-low voltage of 48V. Operation of these track systems without power sources is not permitted.
The device is intended for indoor use only, in environments without aggressive substances or
airborne particles, within a temperature range of -40 to +80°C and relative humidity of up to 85%.
The power supply's design allows it to be mounted in the track housing and secured using clips.
For enhanced aesthetics, a decorative molding can be used to cover the track with the power
supply.
2. Technical Specifications
Input Voltage and
Model
Frequency
TRA004DR-100S
TRA004DR-150S
TRA004DR-200S
TRA004DR-320S
TRA034DR-100W-DD-B-DE
TRA034DR-100W-DD-W-DE
TRA034DR-200W-DD-B-DE
TRA034DR-200W-DD-W-DE
3. Contents
• Power Supply Unit (Driver)
• Operating Manual
4. Safety Precautions
• All installation and connection work must be performed by qualified personnel with
appropriate credentials. If necessary, contact a qualified electrician.
• Perform all installation and removal work only when the network is de-energized.
• Operating the power supply without a protective ground wire is prohibited.
• When configuring a track system, do not exceed the total current load of 1.25/2.08A per power
supply (depending on the model).
• It is recommended to use a power supply with a 20% capacity buffer above the total power
requirement of connected luminaires.
• Do not operate the device with a damaged housing or insulation on the power cable.
• This product is for indoor use only.
• Do not use in high-humidity environments or areas with excessive dust or airborne particles.
5. Installation and Operation Instructions
• Remove the power supply from the packaging and perform a visual inspection: the unit should
be free of visible defects and damage.
Power Supply Unit (Driver) of the TRA, TRX Series
Operating Manual
Electric
Output
Shock
Voltage
Protection
Class
85-264V
47-63Hz
I
88-264V
DC 48V
47-63 Hz
180-265V
47-63Hz
II
180-265V
47-63 Hz
Max.
Max. Power
IP
Current
Consumption
Rating
Load
2,3А 100W
3,3А 150W
4,2А 200W
6,7А 320W
IP20
100W
2,3А
4,2А 200W
Operating
Housing
Temperatu Color
Material
re
Gray
Metal
Silver
-30 ... +70°C
Black
White
Aluminum
Black
White
Dimensions
(mm)
30х97х129
30х97х159
30х115х215
22х45х305
22x45x330
