- Page 1 AWC150, AWC300 & AWC600 Wine Coolers Installation, use and maintenance www.amica-international.co.uk...
-
Page 2: Table Of Contents
Contents: Important Before first use Notes on use Use and controls Locking and unlocking the control panel Switching the power on and off Changing the temperature Changing the temperature reading (°C/°F) Optimal temperatures for different wines Using the internal lighting 9 - 11 Temperature display (set and real) Quiet mode... -
Page 3: Important
Important Amica cannot be held responsible for injuries or losses caused by incorrect use or installation of this product. Please note that Amica reserve the right to invalidate the guarantee supplied with this product following incorrect installation or misuse of the appliance or use in a commercial environment. - Page 4 Appliance information: Please enter the details on the appliance rating plate below for reference, to assist Amica Customer Care in the event of a fault with your appliance and to register your appliance for guarantee purposes. Appliance Model Serial Number...
-
Page 5: Before First Use
Before first use You must allow the appliance to settle for at least twenty four hours prior to switching the power on. It is recommended that you remove all internal and external packaging and clean the interior of the appliance prior to first use. We recommend that you use a solution of bicarbonate of soda and warm water and then thoroughly dry the interior. - Page 6 • Only store wine in sealed containers. • Do not overload the cabinet. • Only open the door when necessary. • Do not cover the shelves with aluminium foil or anything else that will prevent air from circulating around the cabinet. •...
-
Page 7: Use And Controls
Use and controls AWC150 Key: 1 – Power button 2 – Light button 3 – "+" button 4 – "-" button AWC300 Key: 1 – Power button 2 – Light button 3 – "+" button 4 – "-" button AWC600 Key: 1 –... - Page 8 To change the temperature - all models • Unlock the control panel, if necessary. • Press the buttons until the required temperature is shown on the display. • The display flashes when temperature adjustment is active or a different temperature is being set. •...
-
Page 9: Temperature Display (Set And Real)
Optimal temperature selection Below is a table showing the recommended storage temperatures for different types of wine. These are also the ideal drinking temperatures for most types. Wine Type Red Wine 15 - 18ºC (59ºF-64ºF) Dry ⁄ White Wine 9 - 14ºC (48ºF-57ºF) Rosé... - Page 10 • A decimal point '.' next to the temperature signifies that the wine cooler is working to achieve the set temperature. When the decimal point disappears, or if it is not present, the cooler's sensor has detected that the set temperature has been reached. The decimal point may reappear periodically when the cooling system kicks in to maintain the temperature.
-
Page 11: Quiet Mode
• Use the button to switch between '02' and '01'. '02' is the Set temperature display mode and '01' is the Real temperature display mode. Once the mode you desire is shown on the display, touch nothing for approximately 5 seconds. The appliance should beep and switch to the new display mode. -
Page 12: Removing The Shelves
Removing the shelves (AWC300 & AWC600) • To remove a shelf from the AWC300 or 600, first remove all bottles from the shelf, then pull the shelf forwards until the groove on either side of the shelf is level with the plastic peg on either side of the cabinet (as shown in Fig 2). -
Page 13: Temperature Alarm
6 hours of the alarm tripping. The warnings will continue however. Troubleshooting If you have any problems with your appliance, you should check the troubleshooting guide prior to calling Amica Customer Care. If the appliance is not working, check • There is power to the appliance •... - Page 14 The appliance is working, but not very well, check • The appliance is not overloaded. • The thermostat is set to an appropriate temperature. • The door is closing properly. • The door gasket is sealing properly • There is enough ventilation at the side and rear walls. •...
-
Page 15: Installing The Wine Cooler
• The shelves are positioned correctly. The display shows “LL” or “HH” • The temperature sensor has failed. Please contact Amica Customer Care. Installing the wine cooler This appliance is intended to be installed in a space between two units. If it is to be freestanding in an open space, ensure that it can not cause harm nor damage. - Page 16 These products should not be installed: 1. In direct sunlight. 2. Adjacent to a heat source (oven or radiator). 3. Below a hob unit. 4. In a damp or wet environment Where a continuous plinth is to be used, it is necessary to cut a section out so that the ventilation slots at the front of the appliance are not obstructed in any way as per Fig 3.
-
Page 17: Reversing The Door
1. Peel back the door seal from the glass side to expose the screw holes, as per Fig. 4. Place a screwdriver against the screw and hold it in position. 2. Carefully locate the handle over the fixing screw. 3. Using a screwdriver, tighten the securing screw to fix the handle. Repeat with the remaining handle fixing screw. - Page 18 1. With the help of another, open the door and support it. Loosen and remove the two screws from the Door pivot plate of the lower right hinge, as per Fig. 6. 2. Move the door away from the wine cooler slightly and remove the pivot plate from the bottom of the Pivot plate...
- Page 19 the door as per Fig. 12. 7. Guide the door onto the upper hinge pivot and manoeuvre the lower part of the door and pivot Upper Left Hinge plate onto the lower hinge. Align Bottom Left Hinge the pivot plate holes with the hinge plate holes.
-
Page 20: Fitting The Plinth
Fitting the plinth The plinth/grille for this appliance comes packaged inside and can be fitted if desired. Follow these steps to do so: 1. Locate the plinth (packaged inside the appliance) 2. Remove the four screws from (two on each side of) the plinth section, but take care to support both sections to prevent the adjustable section from falling away. - Page 21 Fig. 14 Fig. 15 Fig. 16...
-
Page 22: Adjusting The Plinth
8. Adjust the wine cooler feet so that you achieve the desired height for the cooler. If needed, re-attach the extendable plinth section with the four screws that were removed in step 2. Stand the wine cooler up steadily - if the extendable section will foul the floor or similar, remove it. -
Page 23: Electrical Information
Electrical information Warning! This appliance must be earthed. Green and yellow to Earth Brown to Live 13 Amp fuse Cord clamp Blue to Neutral Fig. 14 The mains lead of this appliance has been fitted with a BS 1363A 13 amp fused plug. - Page 24 How to connect an alternative plug If the fitted plug is not suitable for your socket outlet, then it should be cut off and disposed of safely to avoid possible shock hazard. A suitable alternative plug of at least 13 Amp rating to BS 1363 should be used.
- Page 25 NOTES:...
- Page 26 NOTES:...
-
Page 27: Energy Efficiency Information
18 [lowest temperature] °C and 38 [highest temperature] °C Airborne Acoustic dB(A) Noise Emissions Installation Type Built-under Built-under E & O E. All instructions, dimensions and illustrations are provided for guidance only. Amica reserve the right to change specifications without prior notice. - Page 28 For more information please contact: The Sales Department on 01949 862 010 Customer Care Department: Amica CCD, The CDA Group Building, Harby Road, Langar, Nottinghamshire, NG13 9HY T: 01949 862012 F: 01949 862003 E: customercare@amica-international.co.uk www.amica-international.co.uk...
