https://tehnoteka.rs
Uputstvo za upotrebu (EN)
DELL računar Vostro 3030 MT i3-14100 3yr ProSupport
Tehnoteka je online destinacija za upoređivanje cena i karakteristika bele tehnike,
potrošačke elektronike i IT uređaja kod trgovinskih lanaca i internet prodavnica u Srbiji.
Naša stranica vam omogućava da istražite najnovije informacije, detaljne karakteristike
i konkurentne cene proizvoda.
Posetite nas i uživajte u ekskluzivnom iskustvu pametne kupovine klikom na link:
https://tehnoteka.rs/p/dell-racunar-vostro-3030-mt-i3-14100-3yr-prosupport-akcija-cena/

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Vostro 3030 MT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dell Vostro 3030 MT

Summary of Contents for Dell Vostro 3030 MT

  • Page 1 Uputstvo za upotrebu (EN) DELL računar Vostro 3030 MT i3-14100 3yr ProSupport Tehnoteka je online destinacija za upoređivanje cena i karakteristika bele tehnike, potrošačke elektronike i IT uređaja kod trgovinskih lanaca i internet prodavnica u Srbiji. Naša stranica vam omogućava da istražite najnovije informacije, detaljne karakteristike i konkurentne cene proizvoda.
  • Page 2 Vostro 3030 Desktop Owner's Manual Regulatory Model: D32M Regulatory Type: D32M004 December 2023 Rev. A00...
  • Page 3 A WARNING indicates a potential for property damage, personal injury, or death. © 2023 Dell Inc. or its subsidiaries. All rights reserved. Dell Technologies, Dell, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective owners.

  • Page 4: Table Of Contents

    Power ratings..................................21 Hardware security................................21 Energy Star and Trusted Platform Module (TPM)....................22 Regulatory compliance..............................22 Operating and storage environment..........................22 Dell support policies................................23 Chapter 4: Working inside your computer..................24 Safety instructions................................24 Before working inside your computer........................24 Safety precautions..............................25 Electrostatic discharge—ESD protection......................
  • Page 5 Removing the left-side cover............................31 Installing the left-side cover............................. 32 Front cover..................................33 Removing the front cover............................33 Installing the front cover............................34 Memory....................................35 Removing the memory............................... 35 Installing the memory..............................36 Solid-state drive.................................37 Removing the solid-state drive..........................37 Installing the solid-state drive..........................38 Coin-cell battery................................
  • Page 6 Updating the BIOS using the USB drive in Windows..................103 Updating the BIOS from the F12 One Time Boot menu................... 103 Chapter 9: Troubleshooting....................... 104 Locate the Service Tag or Express Service Code of your Dell computer ..........104 SupportAssist diagnostics............................. 104 System diagnostic lights..............................104 Recovering the operating system..........................105...

  • Page 7: Chapter 1: Views Of Vostro 3030 Desktop

    Views of Vostro 3030 Desktop Front Figure 1. Front view 1. Slim optical drive (optional) The optical drive reads from and writes to CDs and DVDs. 2. Power button Press to turn on the computer if it is turned off, in sleep state, or in hibernate state. Press to put the computer in sleep state if it is turned on.

  • Page 8: Back

    ● Secure Digital High Capacity (SDHC) ● Secure Digital Extended Capacity (SDXC) 4. Hard-drive activity light The activity light turns on when the computer reads from or writes to the hard drive. 5. Global headset jack Connect headphones or a headset (headphone and microphone combo). 6.

  • Page 9: Service Tag

    14. VGA port (optional) Connect an external display or a projector. Service Tag The service tag is a unique alphanumeric identifier that allows Dell service technicians to identify the hardware components in your computer and access warranty information. Views of Vostro 3030 Desktop...
  • Page 10 Figure 3. Service Tag location Views of Vostro 3030 Desktop...

  • Page 11: Chapter 2: Set Up Your Vostro 3030 Desktop

    Set up your Vostro 3030 Desktop Steps 1. Connect the keyboard and mouse. Figure 4. Connect the keyboard and mouse 2. Connect to your network using a cable, or connect to a wireless network. Set up your Vostro 3030 Desktop...
  • Page 12 Figure 5. Connect to your network 3. Connect the display. Figure 6. Connect the display 4. Connect the power cable. Set up your Vostro 3030 Desktop...
  • Page 13 6. Finish the operating system setup. For Ubuntu: Follow the on-screen instructions to complete the setup. For more information about installing and configuring Ubuntu, search in the Knowledge Base Resource at www.dell.com/support. For Windows: Set up your Vostro 3030 Desktop...
  • Page 14 Follow the on-screen instructions to complete the setup. When setting up, Dell recommends that you: ● Connect to a network for Windows updates. NOTE: If connecting to a secured wireless network, enter the password for the wireless network access when prompted.

  • Page 15: Chapter 3: Specifications Of Vostro 3030 Desktop

    Specifications of Vostro 3030 Desktop Dimensions and weight The following table lists the height, width, depth, and weight of your Vostro 3030 Desktop. Table 2. Dimensions and weight  Description Values Height 324.30 mm (12.77 in.) Width 154 mm (6.06 in.) Depth 292 mm (11.50 in.) Weight...
  • Page 16 Table 3. Processor  Description Option one Option two Option three Option four Option five Option six Processor type Generation Generation Generation Generation Intel 300 Intel Core Intel Core Intel Core Intel Core Generation i3-14100 i5-14400 i5-14400F i7-14700 Intel Core i7-14700F Processor 65 W 65 W...

  • Page 17: Chipset

    Chipset The following table lists the details of the chipset that is supported for your Vostro 3030 Desktop. Table 4. Chipset  Description Values Chipset B660 Processor ● 14 Generation Intel Core i3/i5/i5F/i7/i7F ● Intel 300 DRAM bus width 64-bit Flash EPROM 32 MB PCIe bus Up to Gen 3.0...

  • Page 18: Memory Matrix

    Table 5. Memory specifications (continued) Description Values ● 64 GB: 2 x 32 GB, DDR5, 5600 MT/s, dual-channel For computers shipped with a 14th Gen Intel Core i3/i5 or Intel 300 processor: ● 8 GB: 1 x 8 GB, DDR5, 4800 MT/s, single-channel ●...

  • Page 19: Ethernet

    NOTE: To learn more about the features of different types of M.2 cards, search in the Knowledge Base Resource at www.dell.com/support. Ethernet The following table lists the wired Ethernet Local Area Network (LAN) specifications of your Vostro 3030 Desktop. Table 8. Ethernet specifications ...

  • Page 20: Storage

    Table 9. Wireless module specifications (continued) Description Option one Option two ● TKIP ● TKIP Bluetooth wireless card Bluetooth 5.3 Bluetooth 5.3 NOTE: The version of the Bluetooth wireless card may vary depending on the operating system that is installed on your computer. Storage This section lists the storage options on your Vostro 3030 Desktop.

  • Page 21: Gpu-Discrete

    GPU—Discrete The following table lists the specifications of the discrete Graphics Processing Unit (GPU) supported by your Vostro 3030 Desktop. Table 12. GPU—Discrete  Controller External display support Memory size Memory type NVIDIA RTX 3050 ● Three DisplayPort 1.4a 8 GB GDDR6 ports ●...

  • Page 22: Power Ratings

    Table 15. Audio specifications (continued) Description Values Internal audio interface High definition audio interface External audio interface ● One global headset jack ● One audio line-out port Power ratings The following table lists the power rating specifications of Vostro 3030 Desktop. Table 16.

  • Page 23: Energy Star And Trusted Platform Module (Tpm)

    Table 17. Hardware security options (continued) Hardware security options Microsoft Windows Bitlocker BIOS Data Port On/Off - Data port disablement Firmware Trusted Platform Module (TPM) 2.0 Energy Star and Trusted Platform Module (TPM) Table 18. Energy Star and TPM  Features Specifications Energy Star 8.0 Compliant configurations available Firmware-TPM (Discrete TPM disabled)

  • Page 24: Dell Support Policies

    * Measured using a random vibration spectrum that simulates user environment. † Measured using a 2 ms half-sine pulse when the hard drive is in use. Dell support policies For more information on support policy, see the knowledge base articles 000181418, 000043920, and 000181188.

  • Page 25: Chapter 4: Working Inside Your Computer

    You should only perform troubleshooting and repairs as authorized or directed by the Dell technical assistance team. Damage due to servicing that is not authorized by Dell is not covered by your warranty. See the safety instructions that is shipped with the product or at www.dell.com/regulatory_compliance.

  • Page 26: Safety Precautions

    ESD protection is an increasing concern. Due to the increased density of semiconductors used in recent Dell products, the sensitivity to static damage is now higher than in previous Dell products. For this reason, some previously approved methods of handling parts are no longer applicable.

  • Page 27: Esd Field Service Kit

    Always place parts in your hand, on the ESD mat, in the computer, or inside an anti-static bag. ● Transporting Sensitive Components – When transporting ESD sensitive components such as replacement parts or parts to be returned to Dell, it is critical to place these parts in anti-static bags for safe transport. Working inside your computer...

  • Page 28: Transporting Sensitive Components

    It is recommended to use the traditional wired ESD grounding wrist strap and protective anti-static mat always when servicing Dell products. In addition, it is critical to keep sensitive parts separate from all insulator parts while performing service and that they use anti-static bags for transporting sensitive components.

  • Page 29: Screw List

    ● Phillips screwdriver #0 ● Phillips screwdriver #1 ● Plastic scribe Screw list NOTE: When removing screws from a component, it is recommended to note the screw type, the quantity of screws, and then place them in a screw storage box. This is to ensure that the correct number of screws and correct screw type is restored when the component is replaced.
  • Page 30 Figure 9. Major Components of your system 1. Side cover 2. Coin-cell battery 3. Optical drive 4. M.2 2280 solid state drive 5. M.2 2230 solid state drive 6. Media-card reader 7. System board 8. Power-supply unit 9. Chassis 10. Graphics card 11.
  • Page 31 NOTE: Dell provides a list of components and their part numbers for the original system configuration purchased. These parts are available according to warranty coverages purchased by the customer. Contact your Dell sales representative for purchase options. Working inside your computer...

  • Page 32: Chapter 5: Removing And Installing Customer Replaceable Units (Crus)

    Removing and installing Customer Replaceable Units (CRUs) The replaceable components in this chapter are Customer Replaceable Units (CRUs). CAUTION: Customers can replace only the Customer Replaceable Units (CRUs) following the safety precautions and replacement procedures. NOTE: The images in this document may differ from your computer depending on the configuration you ordered. Left-side cover Removing the left-side cover Prerequisites...

  • Page 33: Installing The Left-Side Cover

    Figure 10. Removing the left-side cover Steps 1. Remove the two screws (6-32) that secure the left-side cover to the chassis. 2. Holding the tab on the left-side cover firmly, slide and remove the left-side cover from the chassis. Installing the left-side cover Prerequisites If you are replacing a component, remove the existing component before performing the installation process.

  • Page 34: Front Cover

    Figure 11. Installing the left-side cover Steps 1. Holding the left-side cover firmly on both sides, slide it into the chassis towards the front of the computer. 2. Replace the two screws (6-32) that secure the left-side cover to the chassis. Next steps 1.

  • Page 35: Installing The Front Cover

    Figure 12. Removing the front cover Steps 1. Gently pry and release the tabs that secure the front-cover to the chassis. 2. Open the front cover and lift it away from the chassis. Installing the front cover Prerequisites If you are replacing a component, remove the existing component before performing the installation process. About this task The following image indicates the location of the front cover and provides a visual representation of the installation procedure.

  • Page 36: Memory

    Figure 13. Installing the front cover Steps 1. Align and insert the front-cover tabs into the slots on the right side of the chassis. 2. Rotate the front cover towards the chassis and snap the tabs into place. Next steps 1.

  • Page 37: Installing The Memory

    Figure 14. Removing the memory Steps 1. Place the computer on its side with the left side facing up. 2. Carefully spread apart the securing-clips on each end of the memory-module slot. 3. Grasp the memory module near the securing clip, and then gently ease the memory module out of the memory-module slot. CAUTION: To prevent damage to the memory module, hold the memory module by the edges.

  • Page 38: Solid-State Drive

    Figure 15. Installing the memory Steps 1. Align the notch on the memory module with the tab on the memory-module slot. 2. Insert the memory module into the memory-module slot. 3. Press down on the memory module until the memory module snaps into position and the securing clip locks in place. CAUTION: To prevent damage to the memory module, hold the memory module by the edges.

  • Page 39: Installing The Solid-State Drive

    About this task NOTE: Depending on the configuration ordered, your computer may have a M.2 2230 or 2280 solid-state drive that is installed in the M.2 solid-state drive slot on the system board. The following image indicates the location of the solid-state drive and provides a visual representation of the removal procedure. Figure 16.
  • Page 40 About this task NOTE: You may install either a M.2 2230 or 2280 solid-state drive into the M.2 solid-state drive slot on the system board. The following image indicates the location of the solid-state drive and provides a visual representation of the installation procedure.

  • Page 41: Coin-Cell Battery

    Coin-cell battery Removing the coin-cell battery Prerequisites 1. Follow the procedure in Before working inside your computer. 2. Remove the left-side cover. About this task The following image indicates the location of the coin-cell battery and provides a visual representation of the removal procedure. Figure 18.

  • Page 42: Wireless Card

    Figure 19. Installing the coin-cell battery Steps 1. Insert the coin-cell battery into the socket with the positive side (+) label facing up and snap the battery in the socket. 2. Place the computer in an upright position. Next steps 1.

  • Page 43: Installing The Wireless Card

    Figure 20. Removing the wireless card Steps 1. Place the computer on its side with the left side facing up. 2. Remove the screw (M2x4) that secures the wireless card to the system board. 3. Slide and lift the wireless-card bracket off the wireless card. 4.
  • Page 44 Figure 21. Installing the wireless card Steps 1. Connect the antenna cables to the wireless card. Table 22. Antenna-cable color scheme  Connectors on the Antenna-cable color Silkscreen marking wireless card △ (white triangle) Main White MAIN Auxiliary Black ▲ (black triangle) 2.

  • Page 45: Graphics Card

    2. Follow the procedure in After working inside your computer. Graphics card Removing the graphics card Prerequisites 1. Follow the procedure in Before working inside your computer. 2. Remove the left-side cover. About this task NOTE: Depending on the configuration ordered, your computer may not have a discrete graphics card installed. The following image indicates the location of the graphics card and provides a visual representation of the removal procedure.

  • Page 46: Installing The Graphics Card

    Figure 22. Removing the graphics card Steps 1. Place the computer on its side with the left side facing up. 2. Lift the tab to open the card-retention bracket. 3. Disconnect the graphics-card power cable from the graphics card. 4. Push the securing tab on the PCIe x16 slot away from the graphics card. 5.
  • Page 47 About this task The following image indicates the location of the graphics card and provides a visual representation of the installation procedure. Figure 23. Installing the graphics card Steps 1. Align the graphics card with the PCIe x16 slot on the system board. 2.

  • Page 48: Hard Drive

    2. Follow the procedure in After working inside your computer. Hard drive Removing the hard drive Prerequisites 1. Follow the procedure in Before working inside your computer. 2. Remove the left-side cover. 3. Remove the front cover. About this task The following image indicates the location of the hard drive and provides a visual representation of the removal procedure.

  • Page 49: Installing The Hard Drive

    2. Holding the hard drive in place, remove the four screws (6-32) that secure the hard drive to the chassis. 3. Disconnect the data and power cables from the hard drive. 4. Lift the hard drive off the chassis. Installing the hard drive Prerequisites If you are replacing a component, remove the existing component before performing the installation process.

  • Page 50: Power Button

    Next steps 1. Install the front cover. 2. Install the left-side cover. 3. Follow the procedure in After working inside your computer. Power button Removing the power button Prerequisites 1. Follow the procedure in Before working inside your computer. 2. Remove the left-side cover.

  • Page 51: Installing The Power Button

    Installing the power button Prerequisites If you are replacing a component, remove the existing component before performing the installation process. About this task The following image indicates the location of the power button and provides a visual representation of the installation procedure.

  • Page 52: Optical Drive

    Optical drive Removing the optical drive Prerequisites 1. Follow the procedure in Before working inside your computer. 2. Remove the left-side cover. 3. Remove the front cover. About this task NOTE: Depending on the configuration ordered, your computer may not have an optical drive installed. The following image indicates the location of the optical drive and provides a visual representation of the removal procedure.

  • Page 53: Installing The Optical Drive

    2. Disconnect the power and data cables from the optical drive. 3. Remove the two screws (M2x2) that secure the optical drive to the optical-drive cage. 4. Pull to slide out the optical drive through the front of the computer. Installing the optical drive Prerequisites If you are replacing a component, remove the existing component before performing the installation process.

  • Page 54: Optical-Drive Bezel

    Next steps 1. Install the front cover. 2. Install the left-side cover. 3. Follow the procedure in After working inside your computer. Optical-drive bezel Removing the optical-drive bezel Prerequisites 1. Follow the procedure in Before working inside your computer. 2. Remove the left-side cover.

  • Page 55: Installing The Optical-Drive Bezel

    Figure 30. Removing the optical-drive bezel Steps 1. Insert an unfolded paperclip into the emergency eject pinhole of the optical drive to open the drive tray. 2. Using a plastic scribe press down the tab that secures the optical-drive bezel to the optical drive. 3.

  • Page 56: Fan Shroud

    Figure 31. Installing the optical-drive bezel Steps 1. Align the tabs on the optical-drive bezel with the slots on the optical drive and snap it in place. 2. Slide the optical-drive tray into the optical drive and close it. Next steps 1.

  • Page 57: Installing The Fan Shroud

    Figure 32. Removing the fan shroud Steps 1. Place the computer on its side with the left side facing up. 2. Press the securing clips to release the fan shroud from the fan and heat-sink assembly. 3. Lift the fan shroud off the fan and heat-sink assembly. Installing the fan shroud Prerequisites If you are replacing a component, remove the existing component before performing the installation process.

  • Page 58: Media-Card Reader

    Figure 33. Installing the fan shroud Steps 1. Place the fan shroud on the fan and heat-sink assembly. 2. Press the fan shroud against the fan and heat sink assembly to snap the fan shroud in place. 3. Place the computer in an upright position. Next steps 1.

  • Page 59: Installing The Media-Card Reader

    2. Remove the left-side cover. 3. Remove the front cover. 4. Remove the hard drive. About this task The following image indicates the location of the media-card reader and provides a visual representation of the removal procedure. Figure 34. Removing the media-card reader Steps 1.
  • Page 60 About this task The following image indicates the location of the media-card reader and provides a visual representation of the installation procedure. Figure 35. Installing the media-card reader Steps 1. Place and slide the media-card reader onto its slot on the system board. 2.

  • Page 61: Power-Supply Unit

    Power-supply unit Removing the power-supply unit Prerequisites 1. Follow the procedure in Before working inside your computer. 2. Remove the left-side cover. About this task The following image indicates the location of the power-supply unit and provides a visual representation of the removal procedure.

  • Page 62: Installing The Power-Supply Unit

    Steps 1. Place the computer on its side with the left side facing up. 2. Disconnect the graphics-card power cable from the graphics card. 3. Press the securing clip and disconnect the processor-power cable from the system board. 4. Press the securing clip and disconnect the system-board power cable from the system board. 5.
  • Page 63 Figure 37. Installing the power-supply unit Steps 1. Place and slide the tabs on the power-supply unit into the latches on the chassis. 2. Align the screw holes on the power-supply unit to the screw holes on the chassis. 3. Replace the three screws (#6-32) that secure the power-supply unit to the chassis. 4.
  • Page 64 Next steps 1. Install the left-side cover. 2. Follow the procedure in After working inside your computer. Removing and installing Customer Replaceable Units (CRUs)

  • Page 65: Chapter 6: Removing And Installing Field Replaceable Units (Frus)

    To avoid any potential damage to the component or loss of data, ensure that an authorized service technician replaces the Field Replaceable Units (FRUs). CAUTION: Dell Technologies recommends that this set of repairs, if needed, to be conducted by trained technical repair specialists. CAUTION: As a reminder, your warranty does not cover damages that may occur during the courses of FRU repairs that are not authorized by Dell Technologies.

  • Page 66: Installing The Antenna Modules

    Figure 38. Removing the antenna modules Steps 1. Loosen the two captive screws (M3) that secure the antenna modules to the chassis. 2. Remove the antenna cables through the routing guide on the chassis and unroute the antenna cables through the slot on the chassis.
  • Page 67 About this task The following image indicates the location of the antenna modules and provides a visual representation of the installation procedure. Figure 39. Installing the antenna modules Steps 1. Place the antenna modules on the chassis. 2. Align the captive screws on the antenna modules with the screw holes on the chassis. 3.

  • Page 68: Processor Fan And Heat-Sink Assembly

    Processor fan and heat-sink assembly Removing the processor fan and heat-sink assembly CAUTION: The information in this section is intended for authorized service technicians only. Prerequisites 1. Follow the procedure in Before working inside your computer. 2. Remove the left-side cover.

  • Page 69: Installing The Processor Fan And Heat-Sink Assembly

    2. In a reverse sequential order (4>3>2>1) loosen the four captive screws (M3) that secure the processor fan and heat-sink assembly to the system board. 3. Lift the processor fan and heat-sink assembly from the system board. Installing the processor fan and heat-sink assembly CAUTION: The information in this section is intended for authorized service technicians only.

  • Page 70: Processor

    Next steps 1. Install the shroud. 2. Install the left-side cover. 3. Follow the procedure in After working inside your computer. Processor Removing the processor CAUTION: The information in this section is intended for authorized service technicians only. Prerequisites 1. Follow the procedure in Before working inside your computer.

  • Page 71: Installing The Processor

    Installing the processor CAUTION: The information in this section is intended for authorized service technicians only. Prerequisites If you are replacing a component, remove the existing component before performing the installation process. About this task The following image indicates the location of the processor and provides a visual representation of the installation procedure. Figure 43.

  • Page 72: Optional Input/Output Modules

    Optional Input/Output modules Serial module Removing the optional serial module CAUTION: The information in this section is intended for authorized service technicians only. Prerequisites 1. Follow the procedure in Before working inside your computer. 2. Remove the side cover. 3. Remove the shroud.

  • Page 73: Vga Module

    About this task The following image indicates the location of the serial module and provides a visual representation of the installation procedure. Figure 45. Installing the serial module Steps 1. Using a screwdriver, remove the serial module cover from the chassis. NOTE: This step is applicable only when the serial module is being installed for the first time.

  • Page 74: Installing Optional Vga Module

    Prerequisites 1. Follow the procedure in before working inside your computer. 2. Remove the side cover. 3. Remove the shroud. About this task The following image indicates the location of the optional VGA module and provides a visual representation of the removal procedure.

  • Page 75: System Board

    Figure 47. Installing optional VGA module Steps 1. To remove the dummy metal bracket, insert a star-head screwdriver in the hole of the bracket, push the bracket to release the bracket, and then lift the bracket out from the computer. NOTE: Applies if you are upgrading the computer that did not have these optional modules.
  • Page 76 Prerequisites 1. Follow the procedure in Before working inside your computer. 2. Remove the left-side cover. 3. Remove the front cover. 4. Remove the memory. 5. Remove the solid-state drive. 6. Remove the hard drive. 7. Remove the graphics card. 8.
  • Page 77 Figure 48. System board callout 1. Serial port connector 2. VGA port connector 3. processor-power cable connector 4. Processor socket 5. processor-fan cable connector 6. memory-module slots 7. system-board power cable connector 8. coin-cell battery socket 9. power-button cable connector 10.
  • Page 78 15. Hard drive data cable connector (SATA 0, boot drive) 16. M.2 2230/2280 solid state drive slot 17. PCIe x16 slot (SLOT 3) 18. Two PCIe x1 slots (SLOT 2) The following images indicate the location of the system board and provide a visual representation of the removal procedure. Figure 49.

  • Page 79: Installing The System Board

    Figure 50. Removing the system board Steps 1. Remove the two screws (6-32) that secure the front I/O-bracket to the chassis. 2. Remove and lift the front I/O-bracket from the chassis. 3. Disconnect all the cables that are connected to the system board. ●...
  • Page 80 Figure 51. System board callout 1. Serial port connector 2. VGA port connector 3. processor-power cable connector 4. Processor socket 5. processor-fan cable connector 6. memory-module slots 7. system-board power cable connector 8. coin-cell battery socket 9. power-button cable connector 10.
  • Page 81 15. Hard drive data cable connector (SATA 0, boot drive) 16. M.2 2230/2280 solid state drive slot 17. PCIe x16 slot (SLOT 3) 18. Two PCIe x1 slots (SLOT 2) The following images indicate the location of the system board and provide a visual representation of the installation procedure. Figure 52.
  • Page 82 Figure 53. Installing the system board Steps 1. Slide the front I/O-ports on the system board into the front I/O-slots on the chassis. 2. Align the screw holes on the system board with the screw holes on the chassis. 3. Replace the eight screws (6-32) that secure the system board to the chassis. 4.
  • Page 83 5. Install the shroud. 6. Install the media-card reader. 7. Install the coin-cell battery. 8. Install the wireless card. 9. Install the graphics card. 10. Install the hard drive. 11. Install the solid-state drive. 12. Install the memory. 13. Install the front cover.

  • Page 84: Chapter 7: Software

    ● Windows 11 Home National Education ● Windows 11 Pro National Education ● Ubuntu 22.04 LTS Drivers and downloads When troubleshooting, downloading, or installing drivers, it is recommended that you read the Dell Knowledge Base article, Drivers and Downloads FAQs 000123347. Software...

  • Page 85: Chapter 8: Bios Setup

    Boot sequence allows you to bypass the System Setup–defined boot device order and boot directly to a specific device (for example: optical drive or hard drive). During the Power-on Self Test (POST), when the Dell logo appears, you can: BIOS Setup...

  • Page 86: F12 One Time Boot Menu

    ● Access System Setup by pressing F2 key ● Bring up the one-time boot menu by pressing F12 key The one-time boot menu displays the devices that you can boot from including the diagnostic option. The boot menu options are: ●...
  • Page 87 Table 24. System setup options—System information menu (continued) Overview Current Clock Speed Displays the current processor clock speed. Core Count Displays the number of cores on the processor. Processor ID Displays the processor identification code. Processor L2 Cache Displays the Processor L2 Cache size. Processor L3 Cache Displays the Processor L2 Cache size.
  • Page 88 Table 25. System setup options—Boot Configuration menu (continued) Boot Configuration Secure Boot Enable Secure Boot Enables secure boot using only validated boot software. Default: OFF Secure Boot Mode Modifies the behavior of Secure Boot to allow evaluation or enforcement of UEFI driver signatures. Deployed Mode should be selected for normal operation of Secure Boot.
  • Page 89 Table 26. System setup options—Integrated Devices menu (continued) Integrated Devices By default, Enable USB Boot Support is selected. Front USB Configuration Enables or disables individual USB ports. By default, Front Port 1 (Bottom Left)* is selected. By default, Front Port 2 (Bottom Right)* is selected. By default, Front Port 3 (Top Left) is selected.
  • Page 90 Table 28. System setup options—Display menu (continued) Display Video Primary Display Set or change the primary video controller when multi controllers are available in the system. By default, Auto is selected. Brightness on battery power Sets the screen brightness when the computer is running on battery power. Default: 50 Full Screen Logo Full Screen Logo...
  • Page 91 TPM On Allows you to enable or disable TPM. By default, the TPM On option is enabled. For additional security, Dell Technologies recommends keeping TPM On enabled to allow these security technologies to fully function. Physical Presence Interface (PPI) Bypass...
  • Page 92 BIOS. This option returns to the disabled state when the computer restarts. By default, the Clear option is disabled. Dell Technologies recommends enabling the Clear option only when TPM data is required to be cleared. TPM State Enables or disables the Trusted Platform Module (TPM).
  • Page 93 PTT fTPM after exiting the computer's BIOS. This option returns to the disabled state when the computer restarts. By default, the Clear option is disabled. Dell Technologies recommends enabling the Clear option only when PTT fTPM data needs to be cleared. Chassis intrusion...
  • Page 94 By default, the Start Data Wipe option is disabled. Absolute Absolute Software provides various cyber security solutions, some requiring software preloaded on Dell computers and integrated into the BIOS. To use these features, you must enable the Absolute BIOS setting and contact Absolute for configuration and activation.
  • Page 95 Password prompt. ● The computer password is not prompted when the computer resumes from standby mode. Dell Technologies recommends using the computer password in situations where it is likely that a computer may be lost or stolen. Hard Drive Password The Hard Drive Password can be set to prevent unauthorized access of the data stored on the hard drive.
  • Page 96 BIOS passwords. You can modify the minimum and maximum length of the passwords and require passwords to contain certain character classes (upper case, lower case, digit, special character). Dell Technologies recommends setting the minimum password length to at least eight characters. Password Bypass The Password Bypass option allows the computer to reboot from the operating system without entering the computer or hard drive password.
  • Page 97 The Recovery Password can be used when a system owner forgets the administrator, system, or hard drive password. You can get an unlock code from Dell Support over the phone after verifying ownership details. The unlock code overrides and removes the existing password.
  • Page 98 Allows you to control the automatic boot flow for SupportAssist System Resolution Console and for Dell operating system Recovery Tool. By default, the Dell Auto OS Recovery Threshold value is set to 2. Table 34. System setup options—System Management menu ...
  • Page 99 Table 35. System setup options—Keyboard menu (continued) Keyboard Keyboard Backlight Timeout on Battery Sets the timeout value for the keyboard backlight when the computer is running only on the battery power. The keyboard backlight timeout value is only effective when the backlight is enabled. By default, the 10 seconds option is selected.
  • Page 100 Table 37. System setup options—Virtualization menu (continued) Virtualization Support For additional security, Dell Technologies recommends keeping the Intel Trusted Execution Technology (TXT) option enabled. DMA Protection Enable Pre-Boot DMA Support Allows you to control the Pre-Boot DMA protection for both internal and external ports.

  • Page 101: System And Setup Password

    Table 38. System setup options—Performance menu (continued) Performance Enable Intel Hyper-Threading Technology Enables the Intel Hyper-Threading mode of the processor. When enabled, the Intel Hyper-Threading increases the efficiency of the processor resources when multiple threads run on each core. By default, the Intel Hyper-Threading Technology option is enabled. Dynamic Tuning: Machine Learning Enable Dynamic Tuning: Machine Learning Enables or disables operating system capability to enhance power tuning...

  • Page 102: Deleting Or Changing An Existing System Setup Password

    Depending on how the computer is configured, you may see LED indications during the period the power button is held and after it is released. Once the reset is complete, the computer restarts and the Dell logo appears indicates reset success.

  • Page 103: Clearing Bios (System Setup) And System Passwords

    ● Password clear The Master System Password is used to clear the admin and computer password. To clear the system or BIOS passwords, contact Dell technical support as described at www.dell.com/contactdell. NOTE: For information on how to reset Windows or application passwords, refer to the documentation accompanying Windows or your application.

  • Page 104: Updating The Bios Using The Usb Drive In Windows

    Time Boot menu on the computer. Most of the Dell computers built after 2012 have this capability, and you can confirm by booting your computer to the F12 One Time Boot Menu to see if BIOS FLASH UPDATE is listed as a boot option for your computer. If the option is listed, then the BIOS supports this BIOS update option.

  • Page 105: Chapter 9: Troubleshooting

    Locate the Service Tag or Express Service Code of your Dell computer Your Dell computer is uniquely identified with a Service Tag or Express Service Code. To view relevant support resources for your Dell computer, we recommend entering the Service Tag or Express Service Code at www.dell.com/support.

  • Page 106: Recovering The Operating System

    It enables you to diagnose hardware issues, repair your computer, back up your files, or restore your computer to its factory state. You can also download it from the Dell Support website to troubleshoot and fix your computer when it fails to boot into their primary operating system due to software or hardware failures.

  • Page 107: Drain Residual Flea Power (Perform Hard Reset)

    3. Press and hold the power button for 20 seconds to drain the flea power. 4. Connect the power adapter to your computer. 5. Turn on your computer. NOTE: For more information about performing a hard reset, see the knowledge base article 000130881 www.dell.com/support. Troubleshooting...

  • Page 108: Chapter 10: Getting Help And Contacting Dell

    Getting help and contacting Dell Self-help resources You can get information and help on Dell products and services using these self-help resources: Table 42. Self-help resources  Self-help resources Resource location Information about Dell products and services www.dell.com My Dell app Figure 54.
