- Page 1 BoSS 1000 Low Level Work Platform Instruction Manual Tested and certified to BS 8620:2016...
- Page 2 BoSS QuickPod Instruction Manual...
- Page 3 Contents Safety First Introduction Safety Checklist Equipment Care, Maintenance, Storage and Transport 6-Point Inspection Procedure Before Using the BoSS QuickPod When Using the BoSS QuickPod Identification BoSS QuickPod Parts Setup and Use Setting Up Stabiliser Positioning Fitting the Toe Boards...
- Page 4 Safety First Introduction IMPORTANT: Never use the BoSS QuickPod (Low-level Work Platform) until you have fully read and understood this instruction manual. The user should be adequately trained and competent. Any person using the BoSS QuickPod must have a copy of this instruction manual.
- Page 5 Before using the BoSS QuickPod every time, carry out the 6-point inspection detailed in the following section. • Never use the BoSS QuickPod if any part is damaged or shows signs of excessive wear. • Store the BoSS QuickPod somewhere clean, dry and safe.
- Page 6 Check there is free movement of all hinge points, particularly checking that the gate moves freely. Refer to the BoSS Pod Inspection Guidance for detailed inspection and maintenance advice, the guidance is available to download at: www.bossaccesstowers.com.
- Page 7 • ALWAYS check the BoSS QuickPod 6-point inspection procedure and follow the instructions in this instruction manual and the labels on the BoSS QuickPod. There is a serious risk of injury if you do not follow all the instructions. •...
- Page 8 Never more than one person to use the BoSS QuickPod. • Never move when a person is standing on the working platform. • Never use the BoSS QuickPod as a means of access to another place. • Never stand on the access ladder to work. •...
- Page 9 & Ladder Assembly Side Toe Board Claw Detachable Stabiliser Leg Claw Front Stabiliser Boot Foot Castor The BoSS QuickPod 1000 (product code: 32051000) weighs 28kg excluding toe boards. List of Separate Component Description Quantity Main Frame Platform/Ladder Assembly Stabiliser Assembly bossaccesstowers.com...
- Page 10 Setup and Use Setting Up Move and position Move the BoSS QuickPod into the required location. Ensure the castors are locked. Release retaining strap. Unfold sides of the frame Unlock the castors. Pull the two vertical members on the folding frame side apart as shown Ensure the folding frame is locked.
- Page 11 Deploying the climbing side stabilisers Rotate the left hand stabiliser frame into position as shown. Rotate the right hand stabiliser frame into position as shown. Ensure the sides of the BoSS QuickPod are parallel and square with the folding frame. bossaccesstowers.com...
- Page 12 Fit the platform in position shown by locating the claws over the cross members on each side of the BoSS QuickPod. Ensure the claws on the bottom of the ladder are positioned against the location stubs on the stabiliser frames as shown.
- Page 13 Fitting detachable stabiliser legs Fit the stabilisers on the front upright tubes of left hand and right hand side of the BoSS QuickPod. Ensure both stabiliser feet are in firm contact with the ground, and the stabilisers are correctly positioned as per guidance on page 12.
- Page 14 Setup and Use Stabiliser Positioning The BoSS QuickPod should only be used with the stabilisers deployed in the positions shown below. Ensure that you use the deployed position appropriate to the working direction. Deployed position: working direction front WORKING DIRECTION...
- Page 15 Ensure the front toe board is in contact with the surface of the platform. Note: The toe board fits on the inside of the BoSS QuickPod frame. Slide the first side toe board into the slot of the front toe board.
- Page 16 Push the clip on to the rear vertical tube as shown. Ensure the side toe board is in contact with the surface of the platform. Note: The toe board fits on the inside of the BoSS QuickPod frame. BoSS QuickPod Instruction Manual...
- Page 17 Setup and Use Accessing the Platform The BoSS QuickPod is designed for use by one person only. Always work with both feet firmly on the platform. Note: The gates are always to be closed when working to provide a fully guardrailed working platform.
- Page 18 Setup and Use Closing the BoSS QuickPod To close the BoSS QuickPod reverse the steps in the setting up section of this instruction manual. A summary is provided below. Remove the toe boards. Remove the detachable stabiliser legs and carefully store to avoid damage or loss.
- Page 19 bossaccesstowers.com...
- Page 20 For further information and support for the BoSS QuickPod or any other products, design advice and services, please contact: Werner UK Sales & Distribution Ltd. Blackwater Trading Estate, The Causeway, Maldon, Essex, CM9 4LJ, United Kingdom WernerCo Hungary Kft. 6000 Kecskemét, Szt.
