- Page 1 Electric scooter Model G16 Quick basic User guide FEB-2024 Please read this manual before use. easybike israel -ultra light mobility www.easybike.co.il Golan 62, Nirit,44805 , ISRAEL 054-6648155...
- Page 2 Thank you. We thank and congratulate you on purchasing the new Scooter from EasyBike. We have worked hard to ensure excellent value for your money. G16 is built for longevity with proper maintenance. It is not intended for competitions or jumps.
- Page 3 Golan 62 Nirit israel www.easybike .co.il 6648155 OPERATE YOUR SCOOTER Before use please fully charge. turned on the main power switch (1 = on , 0 = off) located on the battery down left side. Switching on : use the remote key. Double-click the spark button Switching off: one click on button sign with the lock key open .
- Page 4 Golan 62 Nirit israel www.easybike .co.il 6648155 The scooter Equipped with double disk brake 140mm disk. each wheel has one. Right lever brake the front wheel. left lever brake the rear wheel. Before you ride always check the brake efficiency. Feel it. never ride if the brake not work perfect.
- Page 5 Golan 62 Nirit israel www.easybike .co.il 6648155 48V battery with a capacity of 10 amps will be fully charged within 5 hours. The charger has a charging capacity of 2 amps per hour . Charger: when you charge the bulb become red light.
- Page 6 Guidance on the subject can be obtained from us . Folding the G16 scooter The G16 structure build in a way to avoid any failre of broken steering or shaking. Please check the video how to fold . page...
- Page 7 In most cases the repair is done by replacing the entire inner tube. Almost every bike shop knows how to perform. In the case of the G16, repairing a flat is simple. It is easy to pull out a rear wheel (the motor cable must be disconnected) the front wheel can remove out easy thanks to the quick release system.
- Page 8 Golan 62 Nirit israel www.easybike .co.il 6648155 How to check? Hold the handlebars with both hands. Press the two brakes lever, pushing the handlebars back and forth. If even the slightest freedom is felt, the cause must be checked immediately and treated. The source of freedom must be located and corrected accordingly.
- Page 9 Golan 62 Nirit israel www.easybike .co.il 6648155 Specification 22.5 kg Weight (include battery 48V-13.5A) size & weight Frame type Aluminum tubing 6061 T6 wheel base 1100 mm outer size 1500*1200*590 mm board size 240*400 mm (969cm^2) handlebar length 590mm Tire size rear : 12.5 x 3”...
- Page 10 Golan 62 Nirit israel www.easybike .co.il 6648155 Error code (display EN06) Code(Decimal) Description 0 Normal 1 Reserved 2 Brake Error 3 Reserved 4 6KM/H Error 5 Cruise control error 6 Battery low voltage protection 7 Motor Error 8 Throttle Error...
