  • Page 1 HOTO Air Pump Pro...

  • Page 3: Safety Instructions

    01. Safety Instructions Warning! Please carefully read all safet y warnings, instructions, illustrations, and prescriptions in the manual. This product generates noise above 80 dB(A) (1m distance from when working. Please exercise caution. the product) When working continuously for an extended period, the product body and air tube may generate high temperatures.

  • Page 4: Product Introduction

    02. Product Introduction Please read this guide carefully before using the product and keep it for future reference. Thank you for choosing HOTO Air Pump Pro. The product image is for illustrative purposes only. Please refer to the actual product for details.

  • Page 5: List Of Accessories

    List of accessories American air valve French valve adapter ×1 Air tube American air tube × 1 Conversion air valve Inflation needle ×1 ×1 Quick-connection Type-C charger cable Storage bag valve adapter ×1 ×1 ×1...

  • Page 6: Battery Indicator

    03. Instructions for Use Battery indicator 75%≤battery level ： 50%≤battery level＜75% ： 25%≤battery level＜50% ： Charging battery level ＜25%： is required Charging Before using the product for the first time, please ensure that it is fully charged. To charge the air pump, connect the charger to the Type C charging cable.

  • Page 7: Power On/Off

    Power on/off To turn on the product, press and hold the "Power/Mode" button for 1.5 seconds while it is in power-off mode. To turn off the product, press and hold the "Power/Mode" button for 1.5 seconds while it is in power-on mode.
  • Page 8 Quick-connection air valve Mountain bikes, e-bikes, motorbikes, Valve type Inflatable port electric scooters, and automobiles will be equipped with American valves. To inflate, connect the American valve to American valve port high-pressure air tube. Connect the quick-connection valve adapter to the American valve and press the spanner in the direction shown in the illustration to lock it to inflate.
  • Page 9 Inflation needle An inflation needle is required to Valve type Inflatable port inflate balls such as basketballs and footballs. Inflate: Insert the inflation needle into the ball inflation hole after tightening the needle and the American valve port. Deflate: Insert the inflation needle directly into the ball inflation hole.
  • Page 10 Air pressure detection When the air compressor is on and the high-pressure air tube is connected to the object of inflation pressure detection, the number on the display of the air compressor is the current pressure. Inflation pressure check To ensure safety, please check the required inflation pressure by reading the manual of the product to be inflated before inflation to avoid bodily injury and property loss due to explosion caused by excessive inflation.
  • Page 11 Recommended inflation pressure gage of common products Recommended Product Product type pressure surface category 12-inch, 14-inch and 16-inch bicycle 30-50psi tyres 20-inch, 22-inch and 24-inch bicycle 40-50psi Bicycle tyres 26-inch, 27.5-inch and 29-inch 45-65psi mountain bike tyres 700c road bike clincher tyres 100-130psi Motorbike and Motorbike...
  • Page 12 Preset inflation pressure of tyres Mode switching Press the "Power/Mode" button to switch the following five inflation modes on the display. Free mode (without any mode light-up): 35psi by default Range of adjustment: 3-120psi Motor car mode: 2.5bar by default Range of adjustment: 1.8-3.5bar Bike mode light-up: 45psi by default Range of adjustment: 30-65psi...

  • Page 13: Unit Switch

    Fine adjustment of preset After selecting the profile, rotate the "control push knob" clockwise to "+" and anti-clockwise to "-" to adjust the preset pressure value. When adjusting the preset pressure value, the flashing number indicates the adjustment status of target pressure.
  • Page 14 Unscrew the air valve The temperature of the air valve and tube upon inflation is high, so be careful of scald when removing the valve. There will be a slight air leak when removing. Please remove quickly to minimize the amount of leaving air.
  • Page 15 04. Precautions 1. This product is not a toy, and children are forbidden to use it. The minimum recommended age for users is 16 years old. During the inflation, please keep children at a safe distance from the air compressor. 2.

  • Page 16: General Power Tool Safety Warnings

    General Power Tool Safety Warnings Warning: Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. “ ” mains-operated (corded) power tool or battery-operated (cordless) power tools.

  • Page 17: Personal Safety

    Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock. When operating a power tool outdoors, use an extension cord suitable for outdoor use.
  • Page 18 Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations. Dress properly. Do not wear loose clothing or jewellery. Keep your hair and clothing away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
  • Page 19 tool's operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control. Use the power tool, accessories and tool bits etc.
  • Page 20 Do not expose a battery pack or tool to fire or excessive temperature. Exposure to fire or temperature above 130 °C may cause explosion. “ C ° “ “ ° “ F Follow all charging instructions and do not charge the battery pack or tool outside the temperature range specified in the instructions.

  • Page 21: Battery Safety

    Battery safety Only use the battery approved by the manufacturer. Replacing with a battery of wrong type may result in failure of safety protection, causing an explosion or fire. Do not place the battery in an environment with an extremely high temperature, such as in direct sunlight, fire, microwave oven, or oven.

  • Page 22: Troubleshooting

    06. Troubleshooting Solutions Faults 1.Whether the power is sufficient 2. Check whether the Slow inflation air tube is leaking 3. Check whether the connecting parts at both ends of the air tube are screwed tight 4. Check whether the inflated object is leaking Failure to Turn on the machine after it is fully charged.

  • Page 23: Basic Parameters

    07. Basic Parameters Name: HOTO Air Pump Pro Model: QWCQB003 Size: About 192.45×128.35×55.5mm Weight: About 850g Charging temperature: 5°C-40°C Operating temperature: -10°C-45°C Storage temperature: -10°C-45°C Length of air tube: 700mm (including the American air valve port, excluding the thread) Battery type:Lithium-ion battery Battery capacity:2500mAh 27Wh (rated value 2400mAh 25.9Wh)
  • Page 24 Information: The declared vibration total value and the declared noise emission value have been measured in accordance with a standard test method and may be used for comparing one tool with another; The declared vibration total value and the declared noise emission value may also be used in a preliminary assessment of exposure.

  • Page 25: Regulatory Compliance Information

    08 Regulatory Compliance Information Europe — EU declaration of conformity We, Shanghai HOTO Technology Co., Ltd., hereby, declare that this equipment is in compliance with the applicable Directives and European Norms, and amendments. Disposal and recycling information All products bearing this symbol are waste electrical and electronic equipment (WEEE as in directive 2012/19/EU) which should not be mixed with unsorted household waste.
  • Page 26 This supplier’ s declaration of conformity is hereby for Product: OTO Air Compressed Machine. Model Number(s): QWCQB003 Brand/Trade: HOTO We declare that the above mentioned device has been tested and found in compliance with CFR 47 Part 15 Regulation. This device complies with part 15 of the FCC Rules. Operation is...
  • Page 27 ·Consult the dealer or an experienced radio/TV technician for help. Representative of Responsible Party for SDoC Company: HOTO (US) TECHNOLOGY CO LTD Address: 919 North Market Street, Suite 950, Wilmington DE 19801 Country: U.S.A.
  • Page 28 DECLAR ATION OF CONFORMITY EU Declaration of Conformity We Shanghai HOTO Technology Co., Ltd. Declare that the product: HOTO Air Pump Pro/QWCQB003 Complies with the essential health and safety requirements of the following directives: 2014/30/EU Electromagnetic Compatibility directive References to the...
  • Page 29 Disposal and recycling information All products bearing this symbol are waste electrical and electronic equipment (WEEE as in directive 2012/19/EU) which should not be mixed with unsorted household waste. Instead, you should protect human health and the environment by handing over your waste equipment to a designated collection point for the recycling of waste electrical and electronic equipment, appointed by the government or local authorities.
