WilTec 64639 Assembly Instructions Manual

Foldable gazebo 2.5x2.5 m

Advertisement

Quick Links

64639–64641 – Foldable Gazebo 2.5 × 2.5 m
Scope of delivery
A – Frame – 1×
C – Bag – 1×
E – Guy rope – 4×
Assembly
Stand opposite each other with a second person. Grasp one cross strut of the frame (A) from above
and the other cross strut from below (see fig.). Lift the frame slightly, move backwards, and press the
TIPS: Raise the frame by 5–8 cm, especially in the case of high grass or sand. Do not touch the cross
struts at the connection points to avoid crushing. Open the frame to 80–90 %.
© by WilTec Wildanger Technik GmbH
http://www.wiltec.de
ASSEMBLY INSTRUCTIONS
Step 1 – OPENING THE FRAME
rods together.
Item 64639–64641
B – Canopy – 1×
D – Tent peg – 8×
F – Hex wrench (only for maintenance) – 1×
80 % open
80 % open
Page 1
11 2024-1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 64639 and is the answer not in the manual?

Questions and answers

Summary of Contents for WilTec 64639

  • Page 1 ASSEMBLY INSTRUCTIONS 64639–64641 – Foldable Gazebo 2.5 × 2.5 m Scope of delivery A – Frame – 1× B – Canopy – 1× C – Bag – 1× D – Tent peg – 8× E – Guy rope – 4×...
  • Page 2: Step 2 - Attaching The Canopy

    TIPS: Lift the frame slightly while pushing the roof connector upwards. Press the connection point upwards with both hands. © by WilTec Wildanger Technik GmbH Item 64639–64641 Page 2 http://www.wiltec.de...
  • Page 3: Step 4 - Adjust The Height

    TIPS: Do not stand on the gazebo base when pulling out the leg. The tension resulting can otherwise lead to damage. Do not adjust the height of the legs until the frame has locked into place. © by WilTec Wildanger Technik GmbH Item 64639–64641 Page 3 http://www.wiltec.de...
  • Page 4 Pull all pegs out of the ground. Press the locking buttons on the legs to push them together. Step 2 – UNLOCKING THE LOCKED CONNECTION POINT Pull the centre roof joint downwards until the frame begins to collapse. © by WilTec Wildanger Technik GmbH Item 64639–64641 Page 4 http://www.wiltec.de...
  • Page 5 When the cloth of the tent is wet: Before storing away, wait for the cloth to have dried completely. • Cleaning: Clean with a mild detergent and water. • Storage: Disassemble the tent and store it inside the bag. © by WilTec Wildanger Technik GmbH Item 64639–64641 Page 5 http://www.wiltec.de 11 2024-1...
  • Page 6 ASSEMBLY INSTRUCTIONS List of components Letter Part Figure Upper roof connection point Lower roof connection point Connection point for legs Sliding connector Gazebo leg Roof strut Crossbars © by WilTec Wildanger Technik GmbH Item 64639–64641 Page 6 http://www.wiltec.de 11 2024-1...
  • Page 7 Bolt set M4 Foot Roof canopy (white/blue/grey) Important note: Reproduction and any commercial use (of parts) of this operating manual, requires a written permission of WilTec Wildanger Technik GmbH. © by WilTec Wildanger Technik GmbH Item 64639–64641 Page 7 http://www.wiltec.de 11 2024-1...
