  • Page 1 EN User Manual | Washing Machine LR7604HC4 aeg.com\register...
  • Page 2 Welcome to AEG! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.aeg.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................4 3. PRODUCT DESCRIPTION................6 4. TECHNICAL DATA..................7 5.
  • Page 3 the use of the appliance in a safe way and understand the hazards involved. • Children between 3 and 8 years of age and persons with very extensive and complex disabilities shall be kept away from the appliance unless continuously supervised. •...
  • Page 4 • The ventilation opening in the base must not be covered by a carpet, mat, or any floor covering. • The appliance must be connected to the water mains using the new supplied hose sets, or other new hose sets supplied by the Authorised Service Centre.
  • Page 5 2.4 Use • Always use a correctly installed shockproof socket. • Make sure that the parameters on the WARNING! rating plate are compatible with the Risk of injury, electric shock, fire, burns electrical ratings of the mains power or damage to the appliance. supply.
  • Page 6 These lamps are intended to withstand • Disconnect the appliance from the mains extreme physical conditions in household electrical and water supplies. appliances, such as temperature, • Cut off the mains electrical cable close to vibration, humidity, or are intended to the appliance and dispose of it.
  • Page 7 3.2 Appliance overview 11 12 Worktop Drain hose Detergent dispenser Inlet hose connections Control panel Mains cable Door handle Transit bolts Rating plate Hose support Drain pump filter Feet for levelling the appliance The rating plate reports: model name product number Mod.
  • Page 8 Water supply pressure Minimum 0.5 bar (0.05 MPa) Maximum 10 bar (1.0 MPa) Cold water Water supply Hot water Maximum Load Cotton 10.0 kg Spin Speed Maximum spin speed 1400 rpm Connect the water intel hoses to a water tap with a 3/4" thread. Make sure that the hot water temperature of your domestic system is not higher than 60 °C.
  • Page 9 5. Carefully put the appliance down on its rear side. 9. Remove the power supply cable and the 6. Put the front polystyrene packaging drain hose from the hose holders. element on the floor under the appliance. It is possible to see water flowing Make sure not to damage the hoses.
  • Page 10 A correct adjustment of the appliance level prevents the vibration, noise and the movement of the appliance when in operation. When the appliance is installed on a plinth or a tumble dryer is stacked on the washing machine, use the accessories described in chapter 'Accessories'.
  • Page 11 1. Connect the COLD water inlet hose to the appropriate connection (A) on the back of the appliance. 2. Connect the HOT water inlet hose to the appropriate connection (B) on the back of the appliance. Refer to the picture. To protect drinking water enclosed non- return valve must be installed between the water tap and the water supply hose.
  • Page 12 If this occurs, close the water tap and contact the authorized service centre to replace the hose. Do not use an extension hose if the inlet hoses are too short. Contact the 5.7 Water drainage authorized service centre for the replacement of the inlet hoses.
  • Page 13 • Without the plastic hose guide, to a sink The rating plate and the 'Technical Data' spigot - put the drain hose in the spigot chapter indicate the necessary electrical and tighten it with a clamp. ratings. Make sure that they are compatible •...
  • Page 14 6. CONTROL PANEL 6.1 Control panel description The options are not selectable with all washing programmes. Check the compatibility between options and washing programmes in the "Options compatibility with programmes" paragraph in the "Programmes" chapter. An option can exclude another one, in this case the appliance doesn't allow you to set the incompatible options together.
  • Page 15 6.2 Display Door locked indicator. Washing phase indicator. It flashes during pre-wash and wash phase. Rinsing phase indicator. It flashes during rinse phase. Spinning and draining phase indicator. It flashes during spin and drain phase. Steam phase indicator. Anti-crease phase indicator. Eco programme indicator: it lights on when the selected programme and options have an eco profile.
  • Page 16 The digital indicator can show: • Programme duration (e. g. The time shown when the programme is set could not correspond to effective duration and change after ProSense phase. • Maximum load. • Finish in time (e. g. • Cycle end ( ). •...
  • Page 17 7.3 Introduction 7.6 Hot & Cold If you set one of the programs beside the icon and also the indicator lights on the The options/functions are not selectable display.. The hot water connection is active. with all washing programmes. Check the The appliance fills with hot and cold from your compatibility between options/functions domestic hydraulic system.
  • Page 18 The anti-crease phase starts, the indicator is blinking, and the Start/Pauze This option can also be used to shorten remains lit. The drum performs smooth the steam programme duration. movements for about 30 minutes to keep the steam benefit. 7.10 Vlekken/Voorwas To interrupt the anti-crease phase, you can: Press this button repeatedly to activate one of •...
  • Page 19 The display shows the indicator • No Spin The drum turns regularly to reduce Set this option to deactivate all spin creasing. phases. The display shows the indicator The door stays locked. The drum turns . The appliance performs the only regularly to reduce creasing.
  • Page 20 To activate/deactivate this option, hold down text Hr for 2 seconds, 12 (thousands and hundreds) for 2 seconds and 76 (tens and the Vlekken/Voorwas button until comes units). on/goes off on the display. 4. To exit this mode, press any button or The appliance will default to this option after switch the appliance off by means of you switch it off.
  • Page 21 10. PROGRAMMES 10.1 Programme Chart The programmes are described in this chart following the order of the selector dial from the top to the bottom. The icon indicates the programs where the Hot & Cold option is available. Washing programmes Programme Programme description Low energy cycle for cottons.
  • Page 22 Programme Programme description Cotton, synthetic and mixed items. Special steam cycle without washing that can be used to prepare your dried laundry for ironing or refreshing garments Stoom worn once. This programme reduces creases, odours and relaxes the fibres. Do not use any detergent. When the programme is completed, quickly remove the laundry from the drum .
  • Page 23 Programme Default tempera‐ Reference spin speed Maximum load ture Spin speed range Temperature range 1200 rpm 60 °C 1200 rpm - 400 rpm Machine Clean 30 °C 800 rpm 2.0 kg 40 °C - Cold 1200 rpm - 400 rpm Fijne was 30 °C 1200 rpm...
  • Page 24 programmes - if they are available - for • Use the fragrance with different purposes delicate fabrics like cashmere and wool. than those here described. When treating smaller load reduce the • Use the fragrance on new garments. New fragrance dosage and the cycle duration: in garments may contain residual finishing only fifteen minutes, your clothes will regain compounds which are not compatible with...
  • Page 25 ■ ■ ■ Vlekken ■ ■ Voorwas ■ ■ ■ ■ Tijd besparen Extra spoelen ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ Plus Steam Klaar over ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■...
  • Page 26 11. DAILY USE CAUTION! WARNING! Washing heavily oiled, greasy stains Refer to Safety chapters. could cause damage rubber parts of the appliance. 11.1 Activating the appliance 1. Connect the mains plug to the mains 11.3 Filling the detergent and socket. additives 2.
  • Page 27 11.4 Check the position of the flap 1. Pull out the detergent dispenser until it With the flap in the position DOWN: stops. • Do not use gelatinous or thick 2. Press the lever down to remove the liquid detergents. dispenser.
  • Page 28 11.6 Starting a programme 1. The appliance detects the load in the first 30 seconds: the indicator flashes, the Touch the Start/Pauze button to start the bars under the icon move back programme. and forth and the drum rotates shortly. The related indicator stops flashing and stays 2.
  • Page 29 Now, you can set a new washing programme. The ProSense is not available with some programmes, such as Wol, programmes If the ProSense phase is already carried with short cycles and without washing out and the water filling is already phase.
  • Page 30 The indicator of the Start/Pauze button • If you have set , the appliance goes off. drains the water and spins. • If you have set , the appliance only The door unlocks and the indicator goes drains the water. off.
  • Page 31 • Follow the washing instructions on the laundry care labels. • Do not wash white and coloured items together. • Some coloured items can discolour with the first wash. We recommend that you wash them separately for the first couple of times.
  • Page 32 • The choice and quantity of detergent will • Normally soiled laundry may be washed depend on: type of fabric (delicates, without prewash in order to save woollens, cottons, etc), the colour of detergent, water and time (the clothes, size of the load, degree of soiling, environment is protected too!).
  • Page 33 The regular detergents already contain water softening agents, but we recommend to run a Clean drain pump filter Twice a year cycle with empty drum and a descaling Clean the inlet hose and Twice a year product occasionally. the valve filter The following paragraphs explain how you Always follow the instructions that you should clean each part.
  • Page 34 13.7 Cleaning the drum Regularly examine the drum to prevent unwanted deposits. Rust deposits in the drum may occur due to rusting foreign body in the washing or tap water containing iron Clean the drum with special products for stainless steel. Always follow the instructions that you 2.
  • Page 35 2. Place a suitable bowl below the drain 13.9 Cleaning the drain pump pump access to collect the water that flows out. 3. Open the chute downwards. Always keep WARNING! a rag nearby to dry up any water spillages Disconnect the mains plug from the when removing the filter.
  • Page 36 7. Turn the filter anti-clockwise to remove it. 12. Close the pump cover. 8. If it is necessary, remove fluff and objects from the filter recess. 9. Make sure that the impeller of the pump can rotate. If it does not rotate, contact the Authorised Service Centre.
  • Page 37 14. TROUBLESHOOTING WARNING! Refer to Safety chapters. 14.1 Alarm Codes and Possible failures The appliance does not start or it stops during operation. First try to find a solution to the problem (refer to the tables). WARNING! Deactivate the appliance before carrying out any check. With some problems, the display shows an alarm code and the Start/ Pauze button may flash continuously:...
  • Page 38 • Make sure that the sink spigot is not clogged. • Make sure that the drain hose has no kinks or bends. The appliance does not • Make sure that the drain filter is not clogged. Clean the filter, if necessary. Re‐ drain the water.
  • Page 39 Problem Possible solution • Make sure that a washing programme that ends with water in tub, has not been selected. • Make sure that the washing programme is finished. • Set the drain or the spin programme if there is water in the drum. You cannot open the appli‐...
  • Page 40 Make sure that the water level inside the drum is not too high. If necessary, proceed with an emergency drain (refer to «Emergency drain» in «Care and cleaning» chapter). To open the door, proceed as follows: 1. Press the Aan/Uit button to switch the appliance off.
  • Page 41 Values and programme duration may differ depending on different conditions (e.g. room temperature, water temperature and pressure, load size and type of laundry, supply voltage) and also if you change the default setting of a programme. 15.3 According to Commission Regulation Eu 2019/2023 Eco 40-60 pro‐...
  • Page 42 Programme rpm 1) Litres hh:mm °C 0.300 70.0 01:15 30.00 30.0 1200 30°C Maximum spin speed. Suitable for washing heavily soiled textiles. Suitable for washing lightly soiled cottons, synthetic and mixed fabrics. It also performs as quick washing cycle for lightly soiled laundry. 16.
  • Page 43 Programmes Load Product description Cotton and synthetic items. This programme ensures a good washing performance in a short time. The standard program duration has been developed on a laun‐ 8.0 kg dry load of 5 kg. If you wash a smaller or a bigger load, the MixLoad 69min washing time automatically decreases or increases ensuring perfect results.
