Xprinter DT108B Series Quick Manual

3.Replace print head
(1)Steps are as follows：
①.Turn off the printer power and open the upper cover
②.With the groove down the print head assembly buckle on the direction of the arrow shown in the left buckle
according to gently remove the print head.
③.Remove print head assembly
(2)The installation of the printhead is as follows：
①A new print head assembly, the print head assembly on the slide on the slide cover alignment printer, printer
to the surface of the upper cover is pushed into the print head assembly
②..Hear a slight "pop" sound after the confirmation of the print head assembly fully installed in place (the print
head assembly front and upper cover front, Qi Ping) under the pressure of the upper cover of the printer
③.Turn on the power supply and test the printer
Precautions for use
● Before the start of operation of this system in you, please read the following notes, in order to avoid people's negligence
causing damage and even the safety of human body system。
● Before use, please check the parts of the product is normal, and whether there is any damage to the power cord, or the
connection is not correct. If there is any damage, please contact your authorized dealer as soon as possible to replace the good
line。
● The location of the machine should be kept away from too much dust, too high temperature, direct sunlight。
● Keep the machine in a dry environment, rain, moisture, liquids and other minerals will corrode the electronic circuit。
● When using the machine, be sure to keep the surrounding heat dissipation space, in order to facilitate heat dissipation。
● Before use, please check whether the interface device has been connected to boot。
● Do not put any objects into the machine parts, to avoid mechanical damage or short circuit。
● Please turn off the power when installing or removing the peripheral products。
● If damage occurs, do not repair it yourself, please hand it to the authorized dealer。
● When you don't use the machine for a while, take a vacation or a typhoon day, unplug the power cord after you turn off the
power.
Warning user:
This is the information product, in a domestic environment, may cause radio
In this case, the user will be required to take appropriate countermeasures.
Note: do not replace the non print
head to do the above, so as not to cause
unnecessary damage to the print head
Warning: safety instructions
Barcode printer
Quickly guide
Please keep quickly user manual for reference
