- Page 1 Rev.11 02/2024 USE AND MAINTENANCE MANUAL PARALLEL BARS 2 METRES PARALLEL BARS 2 MT MODELS Description Code 2 mt painted steel handrails 1311120...
- Page 2 Table of contents INTRODUCTION p. 3 SAFETY – WARRANTY – UNPACKING – DISPOSAL p. 4 PRODUCT LABEL AND SYMBOLS p. 5 TECHNICAL SPECIFICATIONS AND MODELS p. 6 HOW TO USE THE PARALLEL BARS p. 7 ASSEMBLY INSTRUCTIONS p. 8-14 FORBIDDEN ACTIONS p.
- Page 3 90 % - temperature -10°C ÷ +50°C – Clean place. WARNING! Thoroughly read the manual before use. FISIOTECH SRL refuses any responsibility and is not liable in case any damage to people and/or goods caused by the improper use of the parallel bars, by negligent or not-qualified staff or by non compliance with these instructions occurs.
- Page 4 WARNING! Do not use the the parallel bars: On unstable floors or near inclined floors, steps, etc. If they have been tampered with or modified. If you have not adjusted and tightened Knobs/ratchet handles of the handrails WARNING! Do not adjust the handrails when the patient is using the parallel bars. The sliding and moving mechanical parts may harm the user.
- Page 5 Manufacturer Product Code Serial Number Date of manufacture Max working load Warning Temperature limit Humidity limitation Keep away from sunlight and heat sources Keep away from rain Read the instructions Differentiated collection 5 of 17...
- Page 6 D. Zinc-plated steel tube diameter 42 mm sliding tubes. E. Chipboard platform, width 59 cm. With nonslip covering. F. Anatomic handrails, dimensions 53x43. Wooden or steel handrails, depending on the model. Product code 1311120 Length 200 cm Handrailds width from 40 to 80 cm...
- Page 7 In order to adjust the height of the handrails unscrew the knobs/ratchet handles (3), lift or lower the zinc-plated sliding bars (2) moving the spring (4). Warning! The handrails must have the same height. Warning! When the height has been adjusted, fasten the knobs/ratchet handles (3) before use.
- Page 8 A. Unpack all the parts of the parallel bar (see Unpacking page 4). B. Equip yourself with the tools listed on page 9. Place the base (1) on the floor as indicated in the image (the 2 m parallel bars have a single base).
- Page 9 9 of 17...
- Page 10 Place the base on the floor as shown in the picture and fix the ramp with screws (L), washers (A), and nuts (M). 10 of 17...
- Page 11 Put the base on one side and insert two uprights in their position. Block them with washers (E) and screws (D). Pay attention to the position of the the knobs/ratchet handles (F) as per image below. 11 of 17...
- Page 12 Repeat step 2 with the other two uprights, fixing them with washers (E) and screws (D). Pay attention to the position of the knobs/ratchet handles (F) as per image below. 12 of 17...
- Page 13 Turn the base and place the elements as per image. 13 of 17...
- Page 14 WARNING! DO NOT screw in Fix the handrails with the washers (G) and nuts (H). completely, as the handrail translation will stops. 14 of 17...
- Page 15 15 of 17...
- Page 16 WARNING! The professional should never leave the patient unattended to prevent falls. The manufacturer is not liable for any damage to people and/or goods caused by negligent and/or not-qualified personnel. Maintenance must be carried out by a specialist, an electrician or someone who is familiar with the content of this manual.
- Page 17 INSPECTION RECORD SHEET DEVICE MODEL / CODE: INSTALLATION DATE SERIAL No. ……………………………………… ……………………… ……………………. Inspection Maintenance Name of the inspector Signature Date 17 of 17...
