- Page 1 Translated from German to English - www.onlinedoctranslator.com EB-520G Art. No.: EB520G Ø 100 mm Ø 150 mm Ø200 mm original operating instructions earth drill EB-520G www.lumag-maschinen.de...
- Page 2 Graphics, images, texts and layouts created by LUMAG GmbH are subject to copyright and the laws protecting intellectual property. Reproduction or use of such graphics, images, texts and layouts in other electronic or printed publications is not permitted without the express consent of LUMAG GmbH.
- Page 3 air filter spark plug connector with cap transmission handle on the left protective frame exhaust vent valve Motor operating handle recoil starter throttle lock on/off switch primer pump throttle fuel mixture tank tank cap drill unit...
- Page 4 1:25 0.6 - 0.7mm...
- Page 5 TABLE OF CONTENTS TABLE OF CONTENTS scope of delivery introduction Intended Use safety instructions 4.1 General safety instructions 4.2. Operational safety 4.3 Safety when using combustion engines 4.4 Service security 4.5. Behavior in an emergency 4.6 Warning and information symbols used 4.7 Residual risks and protective measures controls transport...
- Page 6 3. INTENDED USE The EB-520G model is a handy earth drill with a 2-stroke engine for one-man operation. The earth drill has a wide range of uses in private home and hobby gardens, such as digging planting holes, making holes for fence posts or pergolas up to a maximum diameter of 250 mm in easily accessible locations.
- Page 7 SAFETY INSTRUCTIONS DANGER Failure to follow these instructions may result in serious danger to life or death. Failure to follow these instructions may result in death or serious injury. CAUTION Failure to follow these instructions may result in minor to moderate injury. A NOTICE Failure to follow these instructions may result in damage to the engine or other property.
- Page 8 SAFETY INSTRUCTIONS - Always keep the tool clean. 7. Wear appropriate clothing - Do not wear loose clothing or jewelry as they could get caught in moving parts. - Wear sturdy work gloves, leather gloves provide good protection. - Wear safety shoes with a non-slip sole and steel toe cap. - If you have long hair, wear a hair net.
- Page 9 SAFETY INSTRUCTIONS - Do not use any power tool where the switch cannot be turned on and off. 15th - The use of other drill bits, accessories and attachments that are not expressly recommended may pose a risk of injury to you. 16.
- Page 10 SAFETY INSTRUCTIONS • ALWAYSEnsure that the operator is familiar with the appropriate safety precautions, accident prevention regulations and operating procedures before using the earth auger. • ALWAYS-if necessary - wear personal protective equipment (PPE). - Hearing protection to reduce the risk of hearing loss. - Respiratory protection to reduce the risk of inhaling hazardous dust.
- Page 11 SAFETY INSTRUCTIONS • Fill the fuel tankALWAYSin a well-ventilated area. • Refuel the machineNOTnear an open flame. • Do you smokeNOTwhen refueling. • Spill when refuelingNONEFuel. • Make sure that after refueling youALWAYSPut the tank cap on and close it tightly. 4.4 Service security Improper maintenance or failure to observe or resolve a problem can become a source of danger during operation.
- Page 12 SYMBOLS USED SAFETY INSTRUCTIONS 4.6 Warning and information symbols used Attention DANGER! * The engine exhaust contains poisonous carbon monoxide. Do not run the engine in an enclosed area. * Before use, read and observe the operating instructions and safety information.
- Page 13 SAFETY INSTRUCTIONS 4.7 Residual risks and protective measures Mechanical residual hazards capture, winding The auger can catch and pull in items of clothing, cords or wires. → Wear tight-fitting clothing, wear safety shoes with non-slip soles and steel toe caps, and wear a hair net if you have long hair.
- Page 14 CONTROLS → Only use the power tool outdoors and take regular breaks. fire, explosion The machine's fuel mixture is flammable. → Smoking and open fires are prohibited during work and refueling. Danger from vibration whole-body vibration Prolonged work with the earth drill can lead to physical impairments due to vibrations. →...
- Page 15 CONTROLS spark plug on/off switch locking pin throttle throttle lock operating handle vent valve / transmission oil filler opening or drain plug handle air filter choke lever recoil starter exhaust fuel mixture tank primer pump tank cap * Recoil starter (12) The engine is started by pulling the cable.
- Page 16 TRANSPORT / STORAGE / ASSEMBLY 6. TRANSPORT Before transporting the machine or storing it indoors, switch off the engine and allow it to cool down to avoid burns and to eliminate the risk of fire. If you move the machine, even for a short distance, during work, you must switch off the engine.
- Page 17 FUEL 9. REFUELLING When handling petrol/oil, extra caution is required. Smoking and open flames are not permitted (risk of explosion!). fuel mixture The earth drill's engine is a two-stroke engine. It is powered by a fuel mixture of 1:25 two-stroke engine oil and fuel.
- Page 18 COMMISSIONING 10. COMMISSIONING DANGER!Make sure that the device is completely and correctly assembled. Always observe the safety instructions when working on it. 10.1 Preparation for use Check before use: – the level of the transmission oil via the oil sight glass –...
- Page 19 COMMISSIONING 10.2 Filling the device (Fig. 2) Refuel in a well-ventilated area with the engine stopped. If the engine has been running immediately before, allow it to cool down first. Never refuel the engine inside a building where gasoline vapors can reach flames or sparks. DANGER Gasoline is extremely flammable and explosive.
- Page 20 COMMISSIONING 10.4 Starting with a cold engine (Fig. 3, 4, 5 and 6) 1. When cold, set the choke lever (11) to “OFF” (= cold start position). (Fig. 3) 2. Operate the primer pump (15) until the fuel is visible flowing through the transparent return line.
- Page 21 COMMISSIONING 10.7 Working with the earth drill Hold the handles of the drill at a maximum height of chest height, otherwise you could lose control of the device and seriously injure yourself. DANGER! Always keep the transmission cooling vent valve open (ON). Only close the valve when the engine is not running (OFF).
- Page 22 MAINTENANCE 11. MAINTENANCE DANGER Before all cleaning, maintenance and repair work • Turn off the engine • Wait for the tool to stop • Disconnect the spark plug connector from the spark plug. Wear protective gloves to avoid injury. Do not carry out maintenance work near open flames. Fire hazard! Any cleaning, maintenance and repair work other than that described in this chapter may only be carried out by an authorized specialist workshop.
- Page 23 MAINTENANCE 11.1 Maintenance plan Please follow this machine and engine maintenance table! Daily if necessary/ Every Task before 25 BTS 50 BTS season damage Operation after each use cleaning the machine Check that the fastening screws are tight Check fuel tank: - fill level - tightness - lines...
- Page 24 MAINTENANCE The idle speed must be corrected in the following cases: – Drill continues to run idle > speed is too high – if running irregularly or acceleration is lacking > idle speed too low Every 50 hours of operation, have the carburetor pan, the main jet and the idle setting checked and cleaned or corrected if necessary.
- Page 25 MAINTENANCE wipe off. 3. Carefully remove the filter element and check for damage. Replace if necessary. 4. Wash the filter element in lukewarm soapy water. Rinse thoroughly with clean water, allow to dry well and reinsert. 5. Replace the air filter cover and screw it tight. NEVER use gasoline or low flash point cleaning solvents to clean the air cleaner element.
- Page 26 MAINTENANCE Check transmission oil level through sight glass The oil level can be read at a glance from the sight glass on the gearbox. 1. Switch off the engine. 2. Stand the machine upright with the gearbox in a horizontal position. 3.
- Page 27 TROUBLESHOOTING NOTE ON ENVIRONMENTAL PROTECTION 12. TROUBLESHOOTING Caused remedy Disturbance Check the ignition cable, spark plug Spark plug or spark plug cap defective and spark plug connection Engine won't start. Check tank contents, fuel line for fuel supply kinks or damage Mechanical error Contact a specialist workshop carburetor setting incorrect...
- Page 28 TECHNICAL DATA 14. TECHNICAL DATA Model: EB-520G drive motor: 2-stroke engine displacement: Rated power: 1.75 at 7,500 rpm Idle speed: 3,000 ± 200 1/min Rated speed, drill: 0-300 1/min Fuel: unleaded regular gasoline tank capacity: Mixing ratio: 2-stroke engine oil / fuel...
- Page 29 LUMAG guarantees flawless quality and, without prejudice to the statutory warranty, provides a guarantee in the event of material or manufacturing defects. The guarantee for LUMAG products is 24 months for exclusively private use, and 12 months from the delivery date for commercial or professional use or rental.
- Page 30 CUSTOMER SERVICE Warranty work is carried out exclusively by our LUMAG service workshop. Defects that occur within the warranty period due to material or manufacturing defects must be remedied by repair if they have occurred despite proper use and care of the device. We reserve the right to make two repairs if the same defect occurs.
- Page 31 17. EC DECLARATION OF CONFORMITY In accordance with the provisions of the EC directives - Electromagnetic Compatibility 2004/108 EC - Machinery Directive 2006/42/EC the company explains: LUMAG GmbH Robert-Bosch-Ring 3 D-84375 Kirchdorf/Inn Phone: 0049 / (0)8571 / 92 556-0 Fax:...
- Page 32 COMPONENTS OF THE MACHINE 18. COMPONENTS OF THE MACHINE...
- Page 33 COMPONENTS OF THE MACHINE...
- Page 36 LUMAG GmbH Robert-Bosch-Ring 3 D-84375 Kirchdorf am Inn Tel.: +49 (0)8571 92556-0 Fax: +49 (0)8571 92556-19 www.lumag- maschinen.de Status 01/2016 - EB520Gv3...
