- Page 1 Translated from German to English - www.onlinedoctranslator.com EB-400PRO Art. No.: EB400PRO original operating instructions petrol earth drill EB-400PRO www.lumag-maschinen.de...
- Page 2 OVERVIEW OVERVIEW 1. PREFACE 2. INFORMATION ON THE OPERATING INSTRUCTIONS 3. INTENDED USE 4. TECHNICAL DESCRIPTION 5. OPERATING TIME LIMITATION 6. ENVIRONMENT 7. SAFETY INSTRUCTIONS 7.1 General safety instructions 7.2 Personal protective equipment 7.4 Safe handling of operating materials / refueling 7.4.
- Page 3 PREFACE PREFACE DANGER! Read and follow the safety instructions and warnings before use. Use this manual to familiarize yourself with the machine, its correct use and the safety instructions. Keep this manual in a safe place so that you can refer to this information at any time.
- Page 4 INFORMATION ON THE OPERATING INSTRUCTIONS INTENDED USE reservations Information on technical data, dimensions and illustrations of the machine as well as changes to safety standards are subject to further development and are therefore not binding for delivery in every case. Subject to printing and typesetting errors.
- Page 5 TECHNICAL DESCRIPTION The machine is only suitable to a limited extent for use on stony, hard and heavily rooted soils. ■ The machine must not be used in public areas, parks, sports facilities or on roads or in agriculture and forestry. ■...
- Page 6 OPERATING HOURS RESTRICTION ENVIRONMENT OPERATING HOURS RESTRICTION Earth drilling machines may not be operated in residential and small settlement areas or on the premises of hospitals and nursing homes all day on Sundays and public holidays, or on working days from 8 p.m. to 7 a.m. Please also observe the regional regulations regarding noise protection.
- Page 7 SAFETY INSTRUCTIONS A NOTICE Failure to follow these instructions may result in damage to the engine or other property. In addition, the operating instructions contain other important text passages marked with the word DANGERare marked. 7.1 General safety instructions To ensure safe handling, the operator must read this manual to familiarize himself with the handling of the machine.
- Page 8 SAFETY INSTRUCTIONS Please note, however, that personal predisposition to poor circulation and/or large gripping forces when working will reduce the duration of use. Keep other people, especially children, away from the work area. Do not operate the machine in damp or wet environments or expose it to rain Do not use the machine in easily flammable vegetation or where there is a risk of fire or explosion.
- Page 9 SAFETY INSTRUCTIONS Always observe the warnings and additional safety instructions in this manual. Failure to observe these instructions may result in serious injury or death. Do not refuel, start or run the engine indoors, in a garage or in a closed space. The engine's exhaust fumes contain poisonous carbon monoxide.
- Page 10 SAFETY INSTRUCTIONS 7.4 Service Security Improper maintenance or failure to observe or rectify a problem can become a source of danger during operation. Only operate machines that have been regularly and correctly maintained. This is the only way you can be sure that you will operate your machine safely, economically and without problems.
- Page 11 Maintenance and repair work may only be carried out as described in this manual. All other work must be carried out by a specialist workshop or LUMAG service workshop. Only use original spare parts and accessories. The use of other spare parts and accessories increases the risk of accidents.
- Page 12 SAFETY INSTRUCTIONS neglect of ergonomic principles Negligent use of personal protective equipment (PPE) Careless use or omission of personal protective equipment can result in serious injury. → Wear prescribed protective equipment. Human behavior, misconduct → Always be fully concentrated on all work. residual risk - Can never be ruled out.
- Page 13 SYMBOLS USED Other hazards Thrown objects or liquids During drilling, people and animals can be injured by stones, pieces of wood and the like being thrown out. → Make sure that no persons or animals are in the danger area and wear appropriate protective clothing as well as eye and hearing protection.
- Page 14 SYMBOLS USED Wear protective gloves. Warning of hot surfaces. Danger of burns! Do not touch hot engine parts. These remain hot for a short time even after the machine has been switched off. Warning of rotating parts. Warning! Danger of objects being thrown when the engine is running. Keep bystanders and pets away from rotating machine parts.
- Page 15 SCOPE OF DELIVERY SCOPE OF DELIVERY After unpacking, check the contents of the box/transport box for ■ Completeness ■ possible transport damage Report any complaints to the dealer or manufacturer immediately. Complaints made later will not be accepted. Drive unit (drill attachment optional) Bow handle (2 pieces) connecting shaft torsion spring...
- Page 16 CONTROLS AND FUNCTIONS 10. CONTROLS AND FUNCTIONS drive unit The drive unit consists of a petrol engine, clutch, fuel system, ignition system, recoil starter and maintenance-free special gearbox. recoil starter The engine is started by pulling the cable. fuel pump (primer) To make starting easier after the machine has been idle for a long time.
- Page 17 CONTROLS AND FUNCTIONS engine switch (ignition switch) The engine switch activates and deactivates the ignition system. Turn the switch to the "ON" position to start the engine. Turn the switch to the "OFF" position to turn the engine off. choke lever The choke lever closes and opens the choke flap in the carburettor.
- Page 18 TRANSPORT / STORAGE 11. TRANSPORT Before transporting the machine or storing it indoors, allow the engine to cool down to avoid burns and the risk of fire. If you move the machine, even for a short distance, during work, you must switch off the engine.
- Page 19 ASSEMBLY 13. ASSEMBLY Place the drive unit on a stable surface and carry out the following steps for assembly and testing. 13.1 Assembly of handle, throttle lever & connecting shaft Mount the handle to the frame of the drive unit as shown in the illustration. 1.
- Page 20 ASSEMBLY 1. Insert the connecting shaft onto the drive shaft and the other end between the torsion spring. 2. Now secure the connecting shaft to the drive shaft and to the torsion springs using screws, washers and nuts. 13.2 Mounting drill (optional accessory) Mount the drill bit onto the drive unit shaft as shown in the illustration.
- Page 21 COMMISSIONING 14. COMMISSIONING ATTENTION! Read the safety instructions carefully (see section “Safety instructions”). 14.1 Special safety for earth drilling machines Do not work alone; someone must be nearby in case of emergencies. Make sure that there are no children or other people in the working area of the machine. Watch out for animals.
- Page 22 COMMISSIONING Do not place or lay the hot machine on dry grass or on flammable objects –Fire hazard! When carrying out any work on the machine, always switch off the engine, pull the spark plug connector and wear protective gloves. The earth drill may only be started after it has been completely assembled and tested.
- Page 23 COMMISSIONING Always secure drill holes, otherwise there is a risk of injury! Use the earth drill only to drill holes in the ground. Other uses are not permitted. 14.3 Operating materials / refueling You may only carry out the work described in this chapter after you have read and understood the safety instructions.
- Page 24 COMMISSIONING dipstick MAX oil level MIN oil level oil drain plug engine oil dipstick Engine oil capacity: approx. 0.55 liters Do not overfill! Using SAE 30 oil below 10°C will result in harder starting and possible damage to the engine bore due to insufficient lubrication.
- Page 25 COMMISSIONING Refuel in a well-ventilated area with the engine stopped. If the engine has been running immediately before, allow it to cool down first. Never refuel the engine inside a building where gasoline vapors can reach flames or sparks. Gasoline is extremely flammable and explosive. You can suffer burns or other serious injuries when handling fuel.
- Page 26 COMMISSIONING 14.4 Starting the engine Stay at least 3 meters away from the refueling area! Place the machine safely on the ground: • Left foot on the handle • Left hand on the handle • Drill bit must not touch the ground Open the fuel tap.
- Page 27 Set the engine switch (ignition switch) to the “OFF” position. If the engine does not stop, close the choke to stop the engine. Have the engine switch checked or repaired by the LUMAG service workshop or an authorized specialist workshop before using the machine again.
- Page 28 COMMISSIONING 14.6 Operation Before starting the engine, check: • the fuel level – the tank should be at least half full • the condition of the fuel lines • the external screw connections are tight • the place of operation ATTENTION! When starting, make sure that the drill can rotate freely.
- Page 29 COMMISSIONING 14.7 Working with shaft extension (optional accessory) Do not mount the shaft extension until the drill is 2/3 of the way into the hole. To change the drill bits or install the shaft extension, switch off the engine and remove the spark plug connector –Risk of injury! 1.
- Page 30 MAINTENANCE 15. MAINTENANCE Maintain the machine regularly. Only carry out maintenance work and repairs that are described in the operating instructions. Have all other work carried out by an authorized specialist workshop. DANGER During all work on the machine – Turn off the engine –...
- Page 31 MAINTENANCE A NOTICE If you return a machine for repair, please note that for safety reasons it must be sent to the service center free of oil and petrol. 15.2 Air filter Cleaning the air filter frequently prevents carburetor malfunctions. Clean the air filter approximately every 10 - 20 hours of operation.
- Page 32 MAINTENANCE Variant with foam filter insert:Clean the filter element in warm soapy water, rinse thoroughly and allow to dry. Dip the filter element in clean engine oil and then squeeze out excess oil. If too much oil remains in the element, the engine will smoke when starting. 5.
- Page 33 MAINTENANCE replacing the spark plug • every 100 hours or once a year • if the insulator is damaged • with large electrode gap • if the electrodes are heavily soiled or oily. Use the following spark plug: F6RTC or F7RTC or other equivalent spark plug. 15.4 Spark protection If the engine has been running, the muffler is hot–Danger of burns! Allow the muffler to cool before servicing the spark arrester.
- Page 34 MAINTENANCE 15.5 Draining operating fluids Change the engine oil while the engine is still warm. Warm oil drains quickly and completely. ATTENTION! Environmental damage. Operating materials and parts contaminated with operating materials must not be allowed into the drinking water supply. Dispose of the operating materials as hazardous waste, even if only small quantities are involved.
- Page 35 TROUBLESHOOTING • Make sure that the ventilation slots for engine cooling are clear -Danger of overheating! • Keep the cylinder cooling fins free from dust and dirt. 16. TROUBLESHOOTING DANGER During all work on the machine – Turn off the engine –...
- Page 36 TROUBLESHOOTING Caused remedy Disturbance • Incorrect carburetor setting • contact an authorized service Engine starts and (idle speed) workshop immediately dies Engine does not reach • Wrong fuel • Use fresh fuel RON 91 or maximum speed higher and/or gives •...
- Page 37 The permissible workplace values can also vary from country to country. However, this information is intended to enable the user to make a better assessment of hazard and risk. 18th ACCESSORIES for petrol earth drill EB-400PRO Article Dimensions Weight 5EB400150 drill Ø...
- Page 38 LUMAG guarantees impeccable quality and, without prejudice to the statutory warranty, provides a guarantee in the event of material or manufacturing defects. The guarantee for LUMAG products is 24 months for exclusively private use, and 12 months for commercial or professional use or rental, from the date of delivery.
- Page 39 0049 / (0)8571 / 92 556-19 that the product Device type: Gasoline earth drill Device type: EB-400PRO meets the essential protection requirements of the above-mentioned EC directives. Authorized representative for the compilation of the technical documentation: Gabriele Denk The declaration of conformity refers only to the machinery in the condition in which it was placed on the market;...
- Page 40 COMPONENTS OF THE MACHINE 21st COMPONENTS OF THE MACHINE...
- Page 41 NOTE...
- Page 44 LUMAG GmbH Robert-Bosch-Ring 3 D-84375 Kirchdorf am Inn Phone: + 49 (0)85 71 / 92 556 - 0 Fax: + 49 (0)85 71 / 92 556 - 19 www.lumag-maschinen.de Status: 08/2015 - EB400PRO_v1...
