TRU-CLIP

CONNECTOR

AND KEY LINK

Operator Manual

NOTE TO INSTALLERS

Always Read Instructions Before Use

Keep a copy of this manual available for reference. A QR

code linking to an electronic version of the manual is

attached to the red shipping key pin. The Operator Manual

contains information relating to the safe use of the TRU-CLIP

Connector and includes all warranty information. This docu-

ment may only be removed by the end user. Ensure that this

Operator Manual is readily available to operators at all times.

Head Rush Technologies TRU-CLIP Connector and Key Link Operator Manual

P/N 13205-01

Head Rush Technologies TRU-CLIP Connector is covered by a number of patent appli-

cations and pending patents in the USA and in other countries worldwide.

Need help?

Do you have a question about the TRUE-CLIP CONNECTOR and is the answer not in the manual?

Questions and answers

Summary of Contents for head rush technologies TRUE-CLIP CONNECTOR

Page 1 Operator Manual is readily available to operators at all times. Head Rush Technologies TRU-CLIP Connector and Key Link Operator Manual P/N 13205-01 Head Rush Technologies TRU-CLIP Connector is covered by a number of patent appli- cations and pending patents in the USA and in other countries worldwide.
Page 3 8.1.4 Install TRU-CLIP Connector to Key Link on Appropriate Connection Point 8.2 Connecting a Climber to the TRU-CLIP Connector 8.3 Disconnecting a Climber from the TRU-CLIP Connector INSPECTION AND MAINTENANCE 10.0 SPECIFICATIONS 11.0 CONTACT HEAD RUSH TECHNOLOGIES 12.0 INSPECTION AND MAINTENANCE RECORDS www.headrushtech.com | +1-720-565-6885...
Page 4 IMPORTANT SAFETY NOTICE Climbing/Descent from Height Is a Dangerous Activity Read Before Installation & Operation Failure by the operator to heed any and all instructions, warnings and cau- tions for the correct installation, operation, care and maintenance of the TRU-CLIP Connector and Key Links may result in death and/or serious injury. TRU-CLIP Connector and associated proprietary Key Links form a sequenced connector system that enhances the safety of TRUBLUE Auto Belay users.
Page 5 SAFETY INFORMATION Symbols Used in this Manual The following safety symbols are used throughout this manual to highlight po- tential dangers. One or more precautions may be associated with practices and procedures described within this manual. Failure to adhere to any precautions highlighted can result in death, serious injury, or equipment damage.
Page 6 Head Rush Technologies. Head Rush Technologies makes no warranties in respect to trade accesso- ries or component parts which are not made by Head Rush Technologies. No person, agent, or distributor is authorized to give any warranty, other than the one herein expressed, on behalf of Head Rush Technologies, or to assume for it any liability pertaining to such products.
Page 7 ƒ Normal deterioration due to use and exposure. ƒ The installer and operator must fully understand these instructions. Any questions must be submitted in writing to Head Rush Technologies. Adherence to this Operator Manual, manufacturer’s instructions, and advice given by authorized Head Rush service technicians is the responsibility of the buyer, installer, and operator.
Page 8 Notified Notified Body Controlling the Manufacture of this PPE (Module D): TÜV SÜD Product Service GmbH Daimlerstraße 11 85748 Garching Germany Notified Body Number: 0123 Manufacturer’s Information: Head Rush Technologies 1699 Cherry Street, STE C Louisville, CO 80027 www.headrushtech.com | +1-720-565-6885...
Page 9 4.0 DESCRIPTION The TRU-CLIP Connector and associated proprietary Key Links form a se- quenced connector system that enhances the safety of TRUBLUE Auto Belay users. One Key Link is attached to the climber’s harness and another to an appropriate connection point on the climbing element (e.g., a belay gate). To use the system, the climber connects the Key Link on their harness to the TRU-CLIP Connector, which detaches the Key Link from the appropriate con- nection point.
Page 10 5.0 COMPONENTS ITEM NAME MATERIAL(S) TRU-CLIP Connector Aluminum, Stainless Steel, Brass, and POM Hand Grip Nylon and UHMWPE Swivel with Webbing Length Aluminum and Stainless Steel Label Key Links (2x) Stainless Steel Key Link Positioning Straps (2x) Silicone Shipping Key Pin (red) with online manual QR code card (not shown) webbing to auto Nylon, UHMWPE, or combination...
Page 11 Major axis certification load 20kN Read instructions before use Number of Notified Body Performing 0123 Quality Assurance Major axis loading direction Model Type TRU-CLIP Connector Manufacturer Information Head Rush Technologies 1699 Cherry Street, STE C Louisville, CO 80027, USA www.headrushtech.com | +1-720-565-6885...
Page 12 Major and minor axis certification load 20kN 15kN Read instructions before use Number of Notified Body Performing 0123 Quality Assurance Model Type 13140. Model type is also Head Rush Technologies’ Part Number. Major axis loading direction Manufacturer Head Rush Technologies www.headrushtech.com | +1-720-565-6885...
Page 13 TRU-CLIP webbing assemblies are ONLY available for and compatible with TRUBLUE Auto Belays. They are not compatible with any other devices from Head Rush Technologies or devices from any other manufacturer. The TRU- CLIP Connector is integrated into webbing assemblies for the following TRUBLUE Auto Belays and is available as a replacement webbing assembly.
Page 14 WARNING The anchorage and connectors used in the fall arrest system must con- form to all applicable requirements specified in the Auto Belay manual, be suitable for use in a fall arrest system, compatible in size and material characteristics, and have a minimum load capacity of 10 kN (2200 lbs) in expected directions of application.
Page 15 The TRU-CLIP Connector and Key Link must be used together to form a proper connection. Neither can be used independently or with compo- nents not manufactured by Head Rush Technologies. WARNING Users should always connect/disconnect the system at a safe location where there is no risk of falling from height.
Page 16 TRUBLUE Auto Belays when the webbing assembly is retired or replaced. The TRU-CLIP Connector and Key Links do not require periodic examination by Head Rush Technologies or an authorized service center. Inspections and maintenance shall be completed in accordance with this manual by a compe- tent individual.
Page 17 8.1.1 INSTALL TRU-CLIP WEBBING ASSEMBLY INTO THE TRUBLUE AUTO BELAY New TRUBLUE Auto Belay devices equipped with TRU-CLIP Connectors can Step 8.1.2. proceed to Webbing installation and replacement on TRUBLUE Auto Belays is the same for TRU-CLIP webbings as for all webbing connector variants. Instructions can be found in the TRUBLUE Operator Manual and at the webbing resources web- page: https://headrushtech.com/product-resources/webbing-inspection/...
Page 18 4. Thread the small Key Link Pin Set Screw into its hole on the side of the Key Link Bow. Hand-tighten the Key Link Pin Set Screw using a 2mm hex key tool. 5. Visually check to ensure the Key Link Pin Set Screw is not pro- truding from its threaded hole in the Key Link Bow.
Page 19 When annual recertification is performed on the Auto Belay by Head Rush Technologies or an autho- rized service center, the TRU-CLIP Connector sent with the device will also be inspected.
Page 20 Connecting a Climber to the TRU-CLIP Connector The TRU-CLIP Connector from the TRUBLUE Auto Belay is attached to a Key Link on an appropriate connection point. 1. The climber should be wearing a harness with Key Link installed. Pull the TRUBLUE Auto Belay webbing down to ensure proper retraction function of the TRUBLUE Auto Belay device.
Page 21 Disconnecting a Climber from the TRU-CLIP Connector When the climber arrives back at the base of the climb and needs to discon- nect from the TRU-CLIP Connector: 1. Squeeze TRU-CLIP Connector Release Buttons. 2. Insert the Key Link on the ap- propriate connection point into the empty slot on the TRU-CLIP Connector.
Page 22 The TRU-CLIP Connector and Key Link do not require additional periodic examination by Head Rush Technologies or an authorized service center. Retirement criteria are based solely on inspection for wear and function of the overall webbing assembly in accor- dance with this manual.
Page 23 DANGER A TRU-CLIP Connector, Key Link, and/or other components of the fall arrest system must be withdrawn from use if any doubt arises about its condition for safe use. This includes if components were exposed to an overload event such as a fall arrest outside the specified conditions for use (e.g.
Page 24 FREQUENCY SYSTEM FUNCTION MAINTENANCE DESCRIPTION Daily Visual, Physical ƒ Cracks or extreme wear* on the housing or swivel. Check carefully Inspection for wear around the Key Pin slots. ƒ Tightness of Rivets – no rotation of the rivets or movement be- tween housings is acceptable.
Page 25 10.0 SPECIFICATIONS TRU-CLIP Connector Height 135.2 mm 5.3 in TRU-CLIP Connector Width 68.7 mm 2.7 in TRU-CLIP Connector Depth 33.3 mm 1.3 in TRU-CLIP Gate Opening Height 8.8 mm 0.35 in TRU-CLIP Gate Opening Width 17.5 mm 0.7 in TRU-CLIP Key Link Height 66.5 mm 2.6 in TRU-CLIP Key Link Width...
Page 26 11.0 CONTACT HEAD RUSH TECHNOLOGIES Head Rush Technologies US 1699 Cherry St, Suite C Louisville, CO 80027 +1-720-565-6885 info@headrushtech.com Head Rush Technologies EU Annecy, France +33 6 29 37 10 14 info@headrushtech.eu Head Rush Technologies UK 67 Sorby St Sheffield, S4 7LA...
Page 27 12.0 INSPECTION AND MAINTENANCE RECORDS TRUBLUE Serial Number with TRU-CLIP Connector TRU-CLIP Connector Date of Manufacture Webbing Date of Manufacture Date of Purchase Date of Installation/First Use WEEKLY INSPECTIONS Check the Key Link Pin for: wear and tightness with Key Link Bow MAR APR MAY JUN OCT NOV DEC...
Page 28 NOTES www.headrushtech.com | +1-720-565-6885...
Page 30 +1-720-565-6885 www.headrushtech.com info@headrushtech.com Jan 2025...
