Page 2
DAMAGES OF ANY CHARACTER (E.G. DAMAGES FOR LOSS OF PROFIT, SOFTWARE RESTORATION, WORK STOPPAGE, LOSS OF SAVED DATA OR ANY OTHER COMMERCIAL DAMAGES OR LOSSES) RESULTING FROM THE APPLICATION OR IMPROPER USE OF THE CLAVISTER PRODUCT OR FAILURE OF THE PRODUCT, EVEN CLAVISTER INFORMED...
Page 4
List of Figures 1.1. An Unpacked Clavister SG3100 Series Appliance ..........6 1.2. Front view of the Clavister SG3100 Series............8 2.1. SG3200 Rear View ..................12 2.2. Rear view of the Clavister SG3100 Series............12 3.1. A Typical SG3100 Series Installation Setup ............16 6.1.
Page 5
Preface Target Audience The target audience for this guide is the user who has taken delivery of a packaged Clavister SG3100 Series appliance. The guide takes the user from unpacking and installation of the device through to power-up and initial network connection.
Page 6
• Keypad, Ports and Connectors, page 8 1.1. Unpacking the Product This section details the unpacking of the SG3100 Series appliance. Open the packaging box used for shipping and carefully unpack the contents. The box should contain the following: The Clavister SG3100 Series Appliance.
Page 7
1.1. Unpacking the Product Chapter 1. Product Overview Note If any items are missing from your package, please contact your reseller or distributor. All PDF documentation can be freely downloaded from the Clavister website.
Page 8
Each Ethernet port has equal operational capacity and corresponds to a logical interface in the CorePlus software configuration. The default logical interface names are if1 to if6. SG3100 Series ports are capable of link speed auto-negotiation and can operate with 10Base-T or 100Base-Tx.
Page 9
Port Status LEDs Chapter 1. Product Overview...
Page 10
The rubber feet supplied with the SG3100 Series unit should be attached to the underside of the device for operation on a flat surface. This protects both the surface and the device from external damage as well as allowing air to circulate underneath the device during operation.
Page 11
Rack Installation Chapter 2. Installation • A rack or cabinet used for mounting should be adequately secured to prevent it from becoming unstable and/or falling over. • Devices installed in a rack or cabinet should be mounted as low as possible, with the heaviest devices at the bottom and progressively lighter devices installed above.
Page 12
2.2. Connecting Power Figure 2.1. SG3200 Rear View An SG3100 Series appliance is delivered in a form able to support AC or DC power, but not both. The device should be ordered in either an AC or DC compatible hardware version.
Page 13
• Fasten the black (negative) cable lug to the "-" distribution panel • Connect the SG3100 Series DC power connector to the DC terminal port on the power supply. Note The DC power connector that comes with the SG3100 Series is 0.90 meters in length and provides a terminal connector block and 2 cables.
Page 14
Connecting DC Power Chapter 2. Installation unit from a third party is considered to ensure that the hardware is protected from damage by electrical power surges. Surge protection is particularly important in locations subject to lightning strikes. A surge protection unit should be installed exactly according to the manufacturer's instructions as correct installation of such units is vital for their effectiveness.
Page 15
Connecting DC Power Chapter 2. Installation...
Page 16
3.1.2. Connecting the Console Port The serial console port is an RS-232 port that enables a connection to a PC or terminal for monitoring and initial configuration of the SG3100 Series device. To use the console port, you need the following equipment: •...
Page 17
Chapter 3. Initial Setup Flow Control. • An RS-232 cable with appropriate connectors. The SG3100 Series package includes an RS-232 null-modem cable. To connect a terminal to the console port, follow these steps: Set the terminal protocol as described previously.
Page 18
3.2. Local RS232 Console Setup Make sure that a terminal (or a computer running terminal emulation software such as Hyper-Terminal) is connected to the console port on the Clavister SG3100 Series hardware as described above in Section 3.1.2, “Connecting the Console Port”.
Page 19
3.2. Local RS232 Console Setup Chapter 3. Initial Setup When entering IP addresses, use the "." (period) key to move the console cursor from one part of the IP address input field to the next. The Default Gateway does not need to be specified if the management workstation is local. If, however, the management workstation is at least one router hop away from the appliance then the Default Gateway needs to be specified so that the appropriate entry is placed in the CorePlus routing table which is otherwise empty.
Page 20
3.3. Setup with Display and Keypad The SG3100 Series appliance is equipped with a keypad and display on the front panel. These can be used to setup the base configuration. Alternatively a local console can be used as described in Section 3.2, “Local RS232 Console Setup”.
Page 21
3.4. Finalizing the Configuration After intial setup, the user should refer to the companion publications found in PDF format on the accompanying CD for information on how to begin to configure the SG3100 Series device: Clavister CorePlus This describes the general operation and control of the...
Page 22
3.4. Finalizing the Configuration Chapter 3. Initial Setup...
Page 23
Start Date (as defined below). The warranty will only apply to failure of the product if Clavister is informed of the failure not later than two (2) years from the "Start Date" or thirty (30) days after that the failure was or ought to have been noticed by the customer. The warranty will not...
Page 24
Clavister's entire liability according to this warranty shall be, at Clavister's option, either return of the price paid, or repair or replacement of the Hardware that does not meet Clavister's limited warranty and which is returned to Clavister with a copy of your receipt.
Page 25
Chapter 5. Safety Safety Information Clavister SG3100 Series devices are safety class I products and have protective ground terminals. There must be an uninterrupted safety earth ground from the main power source to the product’s input wiring terminals, power cord, or supplied power cord set. Whenever it is likely that the protection has been impaired, disconnect the power cord until the ground has been restored.
Page 26
Hinweise zur Sicherheit Chapter 5. Safety dépannage, réglage, entretien ou réparation devra être confié exclusivement à un personnel qualifié. Hinweise zur Sicherheit Dies ist ein Gerät der Sicherheitsklasse I und verfügt über einen schützenden Erdungsterminal. Der Betrieb des Geräts erfordert eine ununterbrochene Sicherheitserdung von der Hauptstromquelle zu den Geräteingabeterminals, den Netzkabeln oder dem mit Strom belieferten Netzkabelsatz voraus.
Page 27
Consideraciones sobre seguridad Chapter 5. Safety momentáneos que entrañen peligro (rayos o alteraciones en la red de energía eléctrica). Manejar con precaución los componentes de metal de la LAN que estén al descubierto. Este aparato no contiene pieza alguna susceptible de reparación por parte del usuario. Todas las reparaciones, ajustes o servicio de mantenimiento debe realizarlos solamente el técnico.
Page 28
Chapter 6. Hardware Specifications Below are the key hardware specifications for Clavister SG3100 Series installation. Figure 6.1. SG3100 Series Dimensions and Weight Height x Width x Depth (mm) 44 x 440 x 270 Device weight 4.4 kg Device form Factor Rack Mountable 19"...
