Global Industrial 812541 User Manual

Portable power station

Advertisement

Quick Links

User's manual
Customer Service
US: 1-800-645-2986
Read the instructions carefully before
use and follow the instructions
pertaining to risk of fire, electric
shock, or injury to persons. Keep
these instructions in a safe location
for future reference. For questions,
visit globalindustrial.com or contact
Customer Service at 1-800-645-2982
WARNINGS & PRECAUTIONS
• Failure to follow installation instructions will void
warranty.
To reduce the risk of injury, close supervision is necessary when
the product is used near children.
DO NOT put fingers or hands into the product.
DO NOT use a battery pack or appliance that is damaged or
modified. Damaged or modified batteries may exhibit
unpredictable behavior resulting in fire, explosion or risk of
injury.
DO NOT operate the power pack with a damaged cord or plug,
or a damaged output cable.
DO NOT disassemble the power pack, take it to a qualified
service person when service or repair is required. Incorrect
reassembly may result in a risk of fire or electric shock.
DO NOT expose a power pack to fire or excessive temperature.
Exposure to fire or temperature above 130°C may cause
explosion. The temperature of 130°C can be replaced by the
temperature of 265°F.
Use of an attachment not recommended or sold by power pack
manufacturer may result in a risk of fire, electric shock, or injury
to persons.
To reduce risk of damage to the electric plug and cord, pull the
plug rather than the cord when disconnecting the power pack.
To reduce the risk of electric shock, unplug the power pack form
the outlet before attempting any instructed servicing.
When charging the internal battery, work in a well ventilated
area and do not restrict ventilation in any way.
Manual del usuario
Servicio de atención al Cliente
US: 1-800-645-2986
Portable Power Station
Model: 812541
TM
RISK OF EXPLOSIVE GASES To reduce risk of battery explosion,
follow these instructions and those published by battery
manufacturer and manufacturer of any equipment you intend
to use in vicinity of the battery. Review cautionary marking on
these products and on engine.
RISK OF ELETRICAL SHOCK Never use power pack to supply
power tools to cut or access to live parts or live wirings, or
materials that may contain live parts or live wirings inside, such
as building walls, etc.
Under abusive conditions, liquid may be ejected from the
battery; avoid contact. If contact accidentally occurs, flush with
water. If liquid contacts eyes, additionally seek medical
help.Liquid ejected from the battery may cause irritation or
burns.
Have servicing performed by a qualified repair person using
only identical replacement parts. This will ensure that the safety
of the product is maintained.
Be extra cautious to reduce risk of dropping a metal tool onto
battery. It might spark or short-circuit battery or other electrical
part that may cause explosion.
Remove personal metal items such as rings, bracelets,
necklaces, and watches when working with a lead-acid battery.
A lead-acid battery can produce a short circuit current high
enough to weld a ring or the like to metal, causing a severe
burn.
NEVER smoke or allow a spark or flame in vicinity of battery or
engine.
1
Manuel de l'utilisateur
Service à la clientèle
Canada: 888-645-2986
TM
101323

Advertisement

loading
Need help?

Need help?

Do you have a question about the 812541 and is the answer not in the manual?

Questions and answers

Summary of Contents for Global Industrial 812541

  • Page 1 Service à la clientèle US: 1-800-645-2986 Canada: 888-645-2986 US: 1-800-645-2986 Portable Power Station Model: 812541 Read the instructions carefully before use and follow the instructions pertaining to risk of fire, electric shock, or injury to persons. Keep these instructions in a safe location for future reference.
  • Page 2 User's Manual Portable Power Station 812541 WARNINGS & PRECAUTIONS • This product and its accessories may contain some small parts. GROUNDING INSTRUCTIONS This product must be • Please keep the product and its accessories out of the reach of grounded.
  • Page 3 User's Manual Portable Power Station 812541 Technical Parameters Parameter Item Nominal Power Peak Power 10KW Battery Parameters LiFePo4 51.2V 100AH Battery Expansion Supports parallel expansion of up to 6 battery packs Grid Connection Product Size 33.07 x 29.52 x 34.33 inch Product Weight 305.34 lbs...
  • Page 4 User's Manual Portable Power Station 812541 Package Contents: • Portable power station*1 • Product manual*1 • Diagonal 3mm hex wrench*1 • AC power supply charging cable*1 • TT-30P Plug*1 • Photovoltaic charging connector*1 • L5-30 Plug*1 • 17mm fork wrench*1 •...
  • Page 5 User's Manual Portable Power Station 812541 Product Main Structure Composition The portable power station is mainly composed of a metal protection frame, metal shell, PV reverse control machine, touch screen, USB/DC panel, LiFePO4 battery, and other main accessories. Panel Function Description ...
  • Page 6 User's Manual Portable Power Station 812541 Panel Function Description  Left Door Storage Bag  Right Door AC Output, PV Input Circuit Breaker...
  • Page 7 User's Manual Portable Power Station 812541 Display Interface Description Parameter Setting Total Battery Level and  Home Page Button Expandable Battery Information Back Home Charging Input Status and Parameters Page Remaining Button Charging Time Load Output and Parameters Remaining Time...
  • Page 8 User's Manual Portable Power Station 812541 Display Interface Description  Charging Input Page PV Input Parameter Display Mains Input Parameter Display  Load Output Page USB/DC Load Output Parameters AC Load Output Parameters...
  • Page 9 User's Manual Portable Power Station 812541 Display Interface Description  Set Up Page Return to Previous Page Button Charging Language Setting History Screen Brightness Set the Screen Fault Touch Sound Code  Language Setting Page The product supports three language settings: English, French, Spanish (the...
  • Page 10 User's Manual Portable Power Station 812541 Display Interface Description  Screen Sleep Time Page There are four settings for the off time: 30 seconds, 1 minute, 5 minutes, and never (the default setting is 5 minutes.)  Charging History Page...
  • Page 11 User's Manual Portable Power Station 812541 Display Interface Description The Fault Icon Instructions  Fault icons are divided into three types, high temperature, short circuit and overload. If the product is in abnormal state, the corresponding fault icon and troubleshooting prompt will appear on the screen.
  • Page 12 User's Manual Portable Power Station 812541 Display Interface Description Output Overload Icon Fault Code Display  The fault code can display four fault numbers at the same time, increasing from left to right. See Chapter 5 (Failure Code Description Table) for details about the meaning of the code.
  • Page 13 User's Manual Portable Power Station 812541 Display Interface Description Fault History  The red record indicates the current most recent fault  Fault Code Query and Troubleshooting...
  • Page 14 User's Manual Portable Power Station 812541 Operation and Usage 1. Steps for the First Start of Portable Power Station - Turn on all circuit breaker switches at the side door. - Check whether there is any visible damage to the appearance of the station, and...
  • Page 15 User's Manual Portable Power Station 812541 Operation and Usage 3. AC Output On-load Usage AC on load: Before use, please check that the power range and voltage range of the on-load electrical equipment should match the output parameters of the station. Press and turn on the RESET button on the GFCI5-20R socket;Check whether the breakers at the side doors...
  • Page 16 User's Manual Portable Power Station 812541 Fault Code Comparison Table Fault Meaning Description Troubleshooting Methods Codes BatVoltLow Battery under-voltage alarm Stop Using and Charge Immediately Battery discharge average current BatOverCurrSw Reduce the Loaded Power overcurrent software protection BatOpen Battery not connected alarm...
  • Page 17 User's Manual Portable Power Station 812541 Fault Code Comparison Table Turn off, Stop Using and Charge BatCapacityLow2 Battery capacity rate below 5% alarm Immediately Turn off, Stop Using and Charge BatCapacityLowStop Battery low capacity shutdown Immediately BMSComErr BMS communication failure...
