Lithium iron phosphate portable power station

Advertisement

User's manual
Customer Service
US: 1-800-645-2986
Lithium Iron Phosphate Portable Power Station
Read the instructions carefully before
use and follow the instructions
pertaining to risk of fire, electric
shock, or injury to persons. Keep
these instructions in a safe location
for future reference. For questions,
visit globalindustrial.com or contact
Customer Service at 1-800-645-2986
WARNINGS & PRECAUTIONS
Different electrical appliances have different
voltage standards. Before use, please carefully
check whether the rated voltage range of the
product is consistent with the voltage range of the
portable power station, otherwise, it may lead to
dangerous situations.
• After the battery is discharged to the cut-off
voltage, continuing to discharge is called over-
discharge. It can easily cause serious power loss in
the battery, thereby greatly shortening its service
life. Therefore, deep discharge should be avoided
as much as possible when using the battery. And
do charge in time.
• The product should be kept away from fire, high-
temperature environments, and humid and rainy
environments during use and storage, otherwise it
may lead to dangerous situations.
• This product has a built-in high-voltage power
supply, and non-professionals should not
disassemble it by themselves.
Manual del usuario
Servicio de atención al Cliente
US: 1-800-645-2986
Model:
• This product should be protected from rain,
• It cannot be used at an altitude exceeding
• The product is AC output. Please do not insert
• DO NOT drop, squeeze, or collide with the
• After use, please turn off the machine in time
1
TM
Manuel de l'utilisateur
Service à la clientèle
Canada: 888-645-2986
discard the product at the end of its
service life. Recycle the product according to
local laws and regulations.
water immersion, and violent vibration during
transportation.
2000m.
your hands or hand-held metal conductors into
the AC socket.
product, so as not to subject the product to
external pressure, which may cause a short
circuit of the internal circuit of the product and
damage to the battery.
(the no-load power consumption will continue
to consume battery power when the machine is
on.)
TM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 436986 and is the answer not in the manual?

Questions and answers

Summary of Contents for Global Industrial 436986

  • Page 1 b82045fc-0b136962-90871f19-f891407c User's manual Manual del usuario Manuel de l'utilisateur Customer Service Servicio de atención al Cliente Service à la clientèle US: 1-800-645-2986 Canada: 888-645-2986 US: 1-800-645-2986 Lithium Iron Phosphate Portable Power Station Model: Read the instructions carefully before use and follow the instructions pertaining to risk of fire, electric shock, or injury to persons.
  • Page 2 User's Manual LiFe PO4 Portable Power Station 436986 WARNINGS & PRECAUTIONS • This product and its accessories may contain • If the product accidentally falls into the water some small parts. Please keep the product and its during use, place it in a safe open area and do accessories out of the reach of children.
  • Page 3: Grounding Instructions

    User's Manual LiFe PO4 Portable Power Station 436986 IMPORTANT SAFETY INSTRUCTIONS Grounding Instructions • This product MUST be grounded. If it should WARNING malfunction or breakdown, grounding provides a path of least resistance for electric current to Improper connection of the equipment grounding reduce the risk of electric shock.
  • Page 4: Technical Parameters

    User's Manual LiFe PO4 Portable Power Station 436986 Technical Parameters Item Parameter Nominal Power 500W Peak Power Battery Parameters LiFePO4 22.4V 25AH Product Size 16.81*11.30*10.04inch (427*287*255mm) Product N.W. 30.42LBS (13.8KG) 32°F-104°F (0℃-40℃) Ambient Temperature Range Relative Humidity:≤80% Altitude≤2000M Temperature: 5°F-131°F (-15℃-55℃) Transport and Storage Relative Humidity≤93% (No Condensation)
  • Page 5 User's Manual LiFe PO4 Portable Power Station 436986 Product Use and Function Instruction Application and Function Introduction: The portable power station transforms LiFePO4 DC to AC pure sine wave by inverter. When the product is out of power or finished using, it can be charged by mains, without which this product can output AC to charge devices with corresponding power such as fridges, computers, and printers.
  • Page 6 User's Manual LiFe PO4 Portable Power Station 436986  Left Side Cooling Window Handle Cooling Window  Right Side AC Output USB/AC Output USB Output Switch AC Charging Input Socket Cooling Window Ground Post...
  • Page 7 User's Manual LiFe PO4 Portable Power Station 436986  Disaply Interface Description Power Percentage Power Bar...
  • Page 8: Operation And Usage

    User's Manual LiFe PO4 Portable Power Station 436986 Operation and Usage 1. Steps for the First Start of Portable Power Station: 1) Check whether there is any visible damage to the appearance of the station and whether the output interfaces are loose or damaged (If abnormal conditions occur, stop using) 2) Fix the grounding post to the ground.
  • Page 9: Product Maintenance

    User's Manual LiFe PO4 Portable Power Station 436986 Product Maintenance 1. Newly products should be fully charged before use. 2. Regularly remove dust and dirt from the heat dissipation window. 3. In the case of long-term storage for more than three months, not less than 50% of the power storage shall be maintained.
