Tre Modular - Alisa VCF DIY Assembly Guide v1.3 Thank you for choosing Tre Modular. In this guide, we will walk you through the process of assembling your very own Tre Modular - Alisa VCF module.
Page 2
Always adhere to proper soldering techniques, work in a well-ventilated space, and handle electronic components with care to ensure the longevity and optimal performance of your Alisa VCF. Ensure you have all the necessary components listed in the Bill of Materials.
Page 5
Assembly Guide: Step 1: Identify and Sort Components Organize the components into groups based on their types: resistors, capacitors, diodes, transistors, potentiometers, connectors, switches and jack sockets. Step 2: Diodes (Front) Insert and solder diodes according to the legend. 1N4148 Insert and solder diodes according to the legend.
Page 6
Step 6: Diodes (Back) Insert and solder 1N5819 diodes according to the legend. Ensure correct orientation, referring to the diode's polarity. Step 7: 10uf Capacitors (Back) Solder 10uf capacitors onto the designated positions on the PCB according to legend. Ensure correct orientation of capacitors, referring to the capacitors polarity. Step 8: Power Connector Solder the IDC connector (Power connector) into its designated spot.
Page 7
If the module is working as it should. Insert the module into an available slot in your rack and secure it in place. Enjoy! Additional Information: For any additional questions or support, please contact Tre Modular at support@tremodular.com Happy building!
