Featuring the Color-Keyed
System
®
TBM45BB COMFORT CRIMP
COMPRESSION TOOL WITH SHURE STAKE
For Installing Blackburn
Lugs, Splices, and C-Taps 8-2 AWG Cu, 10-6 AWG Al
IMPORTANT:
information in this manual before operating or servicing this tool.
WARNING
KEEP ALL BODY PARTS AWAY FROM DIE NEST
DURING GAGING OR CRIMPING PROCEDURE.
In the event the SHURE STAKE
1.0
1.1
For Use With Blackburn
1.
Open handles fully.
2. Depress wheel release button and rotate
wheel to proper die nest. Allow wheel to
lock into position by releasing button.
3. Insert terminal into the nest as shown in
Figure 2.
4. Close the handles slightly to secure the
terminal. Do not deform the terminal.
5. Insert stripped wire.
6. Close handles until the SHURE STAKE
mechanism cycle has been completed.
7. Perform two equally spaced crimps on the
terminal barrel.
TA04652 C Page 1 of 2
®
Read and understand all of the instructions and safety
DO NOT CRIMP ON HOT ENERGIZED WIRES.
mechanism must be released, please see Figure 4.
®
INSTRUCTIONS FOR USE
®
®
Copper and Aluminum
WARNING
HANDLES ARE NON-INSULATING.
Lugs, Splices, and C-Taps
®
®
MECHANISM
Figure 1
Figure 2
Advertisement
Related Manuals for blackburn COMFORT CRIMP TBM45BB
Summary of Contents for blackburn COMFORT CRIMP TBM45BB
- Page 1 Figure 1 In the event the SHURE STAKE mechanism must be released, please see Figure 4. ® INSTRUCTIONS FOR USE For Use With Blackburn Lugs, Splices, and C-Taps ® Open handles fully. 2. Depress wheel release button and rotate wheel to proper die nest. Allow wheel to lock into position by releasing button.
- Page 2 CRIMP ASSIST Foot ® For larger wire and terminal combinations that require more force to complete the crimp, it may be useful to press the tool against a flat work surface (i.e. worktable, floor, etc.) to gain more leverage. The patent pending Crimp Assist™...
