- Page 1 D19 MasterSync Sync Generator/Distributor MasterSync D19 SERIES REFERENCE SAMPLING RATE POWER WARN FAIL 48 K INTERN DROP AES / EBU INTERN 48 K 44.1 K EXTERN VIDEO WCLK 44.1 K 32 K Operating Instructions...
- Page 2 Studer Pro fes sio nal Audio GmbH Printed in Switzerland Order no. 10.27.4501 (Ed. 0106) Technical Docu men ta ti on Althard stras se 30 CH-8105 Regensdorf - Switzerland Subject to change Studer is a registered trade mark of Studer Professional Audio GmbH, Regensdorf...
- Page 3 Safety Information Safety Information CAUTION To reduce the risk of electric shock, do not remove covers. No user-ser- RISK OF ELECTRIC SHOCK DO NOT OPEN viceable parts inside. Refer servicing to qualifi ed service personnel (i.e., ATTENTION persons having appropriate technical training and experience necessary RISQUE DE CHOC ELECTRIQUE NE PAS OUVRIR to be aware of hazards to which they are exposed in performing a repair...
- Page 4 Installation General Installation Instructions Please consider besides these general instructions also any product-specifi c instructions in the “Installation” chapter of this manual. Unpacking Check the equipment for any transport damage. If the unit is mechanically damaged, if liquids have been spilled or if objects have fallen into the unit, it must not be connected to the AC power outlet, or it must be immediately disconnected by unplugging the power cable.
- Page 5 Installation / EMC Class I Equipment (Mains Operation) Should the equipment be delivered without a matching mains cable, the latter has to be prepared by a trained person using the attached female plug (IEC 320 / C13 or IEC 320 / C19) with respect to the applicable regulations in your country.
- Page 6 EMC / Maintenance / ESD • Use a system grounding concept that satisfi es the safety requirements (class I equipment must be connected with a protective ground conduc- tor) and that also takes into consideration the EMC require ments. When deciding between radial, surface, or combined grounding, the advantages and disadvantages should be carefully evaluated in each case.
- Page 7 ESD / Repair • When performing a repair by replacing complete assemblies, the removed assembly must be sent back to the supplier in the same packing material in which the replacement assembly was shipped. If this should not be the case, any claim for a possible refund will be null and void.
- Page 8 Repair / Disposal SMD Components Studer has no commercially available SMD components in stock for ser- vice purposes. For repair, the corresponding devices have to be purchased locally. The specifi cations of special components can be found in the service manual.
- Page 9 Also refer to relevant information in this manual. CE Declaration of Conformity Studer Professional Audio GmbH, CH-8105 Regensdorf, declare under our sole responsibility that the products D19 MultiFeed, Sync/AES3 Signal Distributor, (from serial no.
- Page 10 Beyond these specifi cations, possible problems are described below. Ambient Temperature Units and systems by Studer are generally designed for an ambient tempera- ture range (i.e. temperature of the incoming air) of +5 °C to +40 °C. When rack mounting the units, the intended air fl ow and herewith adequate cooling must be provided.
- Page 11 Appendix evaporation (sublimation) may be expected; otherwise the system must be heated and dried while switched off. A system without visible internal formation of ice or condensation should be heated up with its own heat dissipation, as homogeneously (and subsequently as slow) as possible;...
- Page 12 Appendix Appendix 2: Mains Connector Strain Relief For anchoring connectors without a mechanical lock (e.g. IEC mains connec- tors), we recommend the following arrangement: Procedure: The cable clamp shipped with your unit is auto-adhesive. For mounting please follow the rules below: •...
- Page 13 The following Terms and Conditions grant the right to use all programs of Studer that are part of the System and/or its options at the time of its delivery to the Customer, as well as the installation software on the original data disk and the accompanying documentation (“License Material”).
- Page 14 Reverse engineering is only permitted with the express consent of Studer. The consent of Studer can be obtained but is not limited to the case in which the interface software can not be provided by Studer. In any case Studer has to be informed immediately upon complete or partial reverse engineering.
- Page 15 D19 MasterSync CONTENTS 1 Come In!..................1/1 Basic Information..............1/1 General ..................1/2 1.2.1 Scope of Delivery ..............1/2 1.2.2 Options .................. 1/2 1.2.3 Block Diagrams ..............1/3 Safety and Connections.............1/5 1.3.1 Utilization for the Purpose Intended ........1/5 1.3.2 Mains Connection ..............1/5 1.3.3 Connector Field..............
- Page 16 D19 MasterSync COME IN! We are happy to welcome you in the circle of the Studer D19 Master Sync’s users, and we felicitate you on your selection. Thanks to Studer’s experience collected during more than 40 years of business in the professional audio products Þ...
- Page 17 D19 MasterSync Redundancy: Two D19 MasterSync units may be connected with a cable (order no. 1.680.025.81). Both units then must be fed with the same sync signal and must have identical settings. In case of a malfunction, the supply as well as the AES/EBU and word clock signals are taken from the second unit.
- Page 18 D19 MasterSync 1.2.3 Block Diagrams Redundancy Distributor: Port AES IN 1 AES OUT 1...4 AES IN 2 AES OUT 5...8 AES IN 3 AES OUT 9...12 AES IN 4 AES OUT 13...16 AES/EBU from Generator Distr. mode: 1 to 16 2 to 8 4 to 4 IINT...
- Page 19 D19 MasterSync Redundancy Input Option: AES OUT AES IN TRANS SYNC IN SYNC on/off SYNC IN (jumpers) AES IN (redundant) TRANS ERROR MADI Word Clock Extractor Option: TAXI MADI IN MADI OUT CTRL TRANS WCLK 1-4 Intro Date printed: 24.01.06...
- Page 20 Power Cable: The supplied mains socket has to be Þ tted with a mating power cable incl. plug by an electrician, if your local Studer agency or your dealer should not have added a Þ tting power cable. ☛ Please consult the Safety section at the very beginning of this manual! Intro 1-5 Date printed: 24.01.06...
- Page 21 D19 MasterSync 1.3.3 Connector Field [11] [10] Mains ~ 100 – 240 V AES OUT 1-4 AES OUT 5-8 AES IN 1-4 ALARM REDUNDANCY LINK AES IN AUX 1-4 AES OUT 9-12 AES OUT 13-16 DISTR MODE WCLK OUT WCLK IN VIDEO [12] [1] Mains ~ 100 –...
- Page 22 D19 MasterSync Technical SpeciÞ cations (preliminary, subject to change without notice) 1.4.1 General Inputs: AES/EBU: Impedance 110 Ω typ. Sensitivity min. 0.2 V Sampling rate 28...55 kHz ac cording to AES3 1992 Word clock: Impedance: hi-Z or 75 Ω, selectable with internal jumper; TTL level Outputs: AES/EBU: Impedance 110 Ω...
- Page 23 D19 MasterSync 1.4.6 Mechanical Data Weight: approx. 5 kg Dimensions [mm]: 44.2 approx. 8 (Rubber Feet) 482.4 1-8 Intro Date printed: 24.01.06...
- Page 24 D19 MasterSync OPERATION Operating Elements MasterSync D19 SERIES REFERENCE SAMPLING RATE POWER WARN FAIL 48 K INTERN DROP AES / EBU INTERN 48 K 44.1 K EXTERN 32 K VIDEO WCLK 44.1 K [1 ] [2] [3 ] [1] POWER Recessed pushbutton for switching the unit on or off;...
- Page 25 D19 MasterSync Connectors, Pin Assignments 2.2.1 AES/EBU SYNC IN (XLR-3f) Signal Screen Input + Input – Chassis 2.2.2 AES/EBU OUT (XLR-3m) Signal Screen Input + Input – Chassis 2.2.3 4 AES/EBU IN (15-pin D-type, f) Signal AES 1 + AES 1 – Screen Screen AES 2 +...
- Page 26 D19 MasterSync 2.2.5 ALARM (9-pin D-type, f) Signal +24 V WARN relay contact output. Active if an internal supply has a malfunction, provided that either two units are linked together or a second redundancy power supply is installed. If active, depending on the internal jumper setting, the relay either connects pins 3 and 6 (position P25-P26), or it interrupts this connection (position P26-P27;...
- Page 27 D19 MasterSync 2.2.7 REDUNDANCY LINK (15-pin D-type, f) to Pin # Signal on 2nd Unit n.c. n.c. n.c. ISYN EX WCL RE MAST n.c. (10) n.c. (10) +24 V RE (12) n.c. (12) AES RE IWARN EX IMAST Matching Cable Order no.
- Page 28 D19 MasterSync DIP SWITCH AND JUMPERS DIP Switch Settings The DIP switch is located at the rear of the unit and is accessed through a hole in the rear panel. The switches are numbered 1...8 from the left to the right. Switch Signal Description spare...
- Page 29 D19 MasterSync Internal Jumpers Caution: All internal adjustments as well as repair work on this product must be per- formed by a trained technician – no user-serviceable parts inside! Factory Settings: In all drawings below, the default jumper settings are marked in black. [3] [4] Impedance setting for the VIDEO input (BNC socket, not used).
- Page 30 D19 MasterSync This pin array is used for installing the Redundancy option. If no Redundancy option is installed, the following pins must be connected with jumpers: P43-P47, P42-P45, P48-P50, and P49-P51 (default setting). AES 1 P43 AES 1 P42 AES 1 P48 AES 1 P49 This jumper is used if the MADI word clock extractor option is installed;...
- Page 31 D19 MasterSync APPLICATIONS OnAir 2000 In many installations with the OnAir 2000 digital broadcast console (or other digital consoles), the need arises to generate a sync signal and distribute it to some peripheral devices, such as recording machines or players. OnAir 2000 SYNC MasterSync...
- Page 32 D19 MasterSync MADI Sync Extractor (Optional) With more and more signals being transported on optical Þ bre links for improved immunity against hum, many systems have inputs and outputs located remotely. These inputs and outputs must be synchronized to the main digital system.
