- Page 1 KNOB LOCK SMART SECURITY SERIES #Simplesmartsecure...
- Page 3 Smart Spaces. Thank you for trusting us with your space & choosing Hogar Knob Door Lock. This manual is designed to help you install your Hogar Knob Door Lock in an easy and hassle-free manner. Please follow all the steps given below and experience the safety...
- Page 4 KNOB DOOR LOCK SMART SECURITY SERIES TABLE OF CONTENTS USAGE NOTICE 1.1. Warnings and Considerations 1.2. Precautions PRODUCT DETAILS 2.1. Description 2.2. Features 2.3. Technical Specifications 2.4. App Registration / Login 2.5. Configuration Process WARRANTY...
- Page 5 3.5. Install Lock Body 3.6. Choose the Parts 3.7. Install the Lock - Front Panel 3.8. Install the Lock - Back Panel 3.9. Install Buckle Plate 3.10. Commissioning USING THE LOCK 4.1. Add Administrator 4.2. Add the User 4.3. Delete the User 4.4.
- Page 6 USAGE NOTICE 1.1. WARNINGS AND CONSIDERATIONS Caution symbols highlighted across the manual represent the following: Indicates the highlighted precautions to be followed to prevent any high level of severity. Indicates the instructions to be followed during installation. Indicates suggestions and tips Please follow the notices to ensure your safety as well as to prevent property loss.
- Page 7 Using this product in any manner other than how it is referred to in this document voids your warranty. Further, Hogar Controls is NOT liable for any damage incurred with the misuse of the product.
- Page 8 1.2. PRECAUTIONS Ensure the below DOs & DON'Ts are adhered to enjoy a seamless product experience: - Clean your fingers before using the product. - Replace the batteries when you receive warning signs. - Keep the emergency keys with you or in a safe outdoor place from where you can retrieve it easily.
- Page 9 - Except for the administrator, other users are not allowed to unlock the door in Secure Lock Mode. - A variety of unlocking methods are supported with this Hogar Knob Door Lock, such as mobile APP unlocking, fingerprint unlocking, password unlocking, mechanical key unlocking, and RF card unlocking.
- Page 10 2.3. TECHNICAL SPECIFICATIONS Product Number XXXXX Brand Name Hogar Fingerprint, Passcode, Modes of unlocking RF ID, Mechanical Key, Hogar SE App Door Thickness 35mm-55mm Fingerprint type Semiconductor Embedded Fingerprint App Support Android & Ios Work Temperature -20~65⁰ C Power Supply...
- Page 11 2.4. APP REGISTRATION / LOGIN - Download the “Hogar SE” application at App Store or Google Playstore. - Enter the Register/Login interface - Tap “Register” to create an account. - Select Country. - Enter your email ID. - Check ‘I agree to User Agreement & Privacy Policy’ (Please review the terms and conditions).
- Page 12 3.2. INSTALLATION OVERVIEW...
- Page 13 3.3. CONFIRM THE DIRECTION OF THE DOOR This Atrio is suitable for 4 kinds of opening directions – - LEFT OUT - LEFT IN - RIGHT OUT - RIGHT IN...
- Page 14 3.4. HANDLE DIRECTION CHANGE - Check if the door and the door lock handle are in the same direction. If not, please change the handle direction. - Front Handle Direction Change - Disassemble the direction changing screw, twist the handle CLOCKWISE 180 degrees carefully and slowly, then fix the direction changing screw.
- Page 15 3.5. INSTALL LOCK BODY - Choose installation direction of the latch bolt of the lock body by the door opening direction. - Change the direction of the lock body. - Push the reversing block to the other side. - Push the latch bolt into the lock and turn 180 degree.
- Page 16 3.6. CHOOSE THE PARTS CONNECTION CONNECTION DOOR SQUARE COLUMN COLUMN THICKNESS STEEL LENGTH LENGTH SCREW LENGTH 35 - 52mm 80mm 35mm 30mm + 50mm 53 - 62mm 80mm 35mm 50mm + 70mm 63 - 80mm 100mm 55mm 50mm + 70mm >80mm 120mm 55mm...
- Page 17 INSTALL THE LOCK 3.7. INSTALL THE FRONT PANEL - Install 2 connection columns on the front panel. - Adjust the dot direction on the square steel sleeve with reference to the sticker on the rubber mat. *LEFT OPEN – Keep the dot in the left or in the right. *RIGHT OPEN –...
- Page 18 3.8. INSTALL THE BACK PANEL - Press the front panel and connect the connection wire with the corresponding interface of the back panel, then insert the access wire into the door hole. - Align the square steel with the square steel hole of the back panel and compress the back panel.
- Page 19 When installing the back lock, please view from the screw hole ensure that connection wire does block the connection column hole to AVOID damaging the connection wire when installing the screw. 3.9. INSTALL BUCKLE PLATE AND BUCKLE BOX...
- Page 20 3.10. COMMISSIONING - Always keep the door in half open status when commissioning. - Check if the following functions can be achieved or not - PRESS DOWN front handle, latch bolt/ dead bolt remains in locking status. - PRESS DOWN front handle, latch bolt/dead bolt retracts in unlocking status. - PRESS DOWN back handle, latch bolt/dead bolt retracts in any status.
- Page 21 - Once you hear "Add successfully" on the Voice Prompt, you can continue to add more. NOTE: a. Different position fingerprints can be added to improve identification. “*” - back, sign out button "#" - confirm button 4.2. ADD THE USER - Remove the battery cover.
- Page 22 4.3. DELETE THE USER - Remove the battery cover. short press ”Set” (back panel) or long press “*”, then the voice prompts: ‘please verify the administrator’. - Verify the administrator. - Short press “Set” (Back panel) or long press "*" again.
- Page 23 4.6. APP INSTALLATION & NETWORK CONFIGURATION Zigbee - Download, install and open Hogar SE app. Register and login using mobile number. - Connect the zigbee gateway with the router via network cable. The light will be ON when its plugged in.
- Page 24 - If the LED light show “X” and the voice prompts ‘’Add Failure’’, please try again Zwave - Download, install and open Hogar Pro App. Register and login using mobile number. Include the device from Z-Wave network - Go to App -> Settings -> Setup Devices -> Select the HC -> Click on Z-Wave ->...
- Page 25 - Go to Door lock, press no “3” from the keypad and click “#” to confirm Configuration mode. - Verify the administrator using the admin password. - Wait until ‘’Device got removed from the network’’. Note: The app only supports 2.4 GHz Wi-Fi network, the Wi-Fi connected to the app and the mobile phone should be the same.
- Page 26 ADD ATRIO TO HOGAR SE APP WITH ZIGBEE...
- Page 27 EDIT DEVICE NAME & ASSIGN ROOM Atrio - Door Lock...
- Page 28 APP SCREEN WITH DOORLOCK CONTROL Atrio - Door Lock...
- Page 29 4.7. SELF LOCKING - If the WRONG password is entered 5 times continuously the system will be locked for 180 seconds. Fingerprint or card unlock can remove self-locking. - If the WRONG fingerprint is entered 5 times continuously the system will be locked for 180 seconds.
- Page 30 Warranty Hogar offers an Exclusive 18-Month Warranty on any product that covers defects in materials and quality under normal use of the Product. The Terms and Conditions of this 1.5 YEARS LIMITED WARRANTY can be viewed on www.hogarcontrols.com or scan the QR code:...
- Page 31 CONGRATULATIONS! You've successfully installed your Atrio. Now you can experience seamless control of your Atrio with your Hogar Pro & Hogar SE App. Add more to your home from our range of smart home automation solutions and live the smart life.
- Page 32 Hogar Controls Inc, 46040 Center Oak Plaza, Suite 125, Sterling, Virginia 20166 Phone : +1 703 844 1160 INDIA Hogar Controls India Pvt. Ltd., Plot No. 3, I.D.A-Uppal, support@hogarcontrols.com Hyderabad, Telangana, India Phone : +91 844 844 0789 www.hogarcontrols.com...
