ATRIO W+
SMART SECURITY SERIES
#Simplesmartsecure

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ATRIO W+ SMART SECURITY Series and is the answer not in the manual?

Questions and answers

Related Manuals for hogar ATRIO W+ SMART SECURITY Series

Summary of Contents for hogar ATRIO W+ SMART SECURITY Series

  • Page 1 ATRIO W+ SMART SECURITY SERIES #Simplesmartsecure...
  • Page 3 WELCOME TO HOGAR IOT WORLD Welcome to Hogar Controls © – Smart IoT Solutions for Smart Spaces. Thank you for trusting us with your space & choosing Atrio W+ smart door lock. This manual is designed to help you install your Atrio W+ in an easy and hassle-free manner.

  • Page 4: Table Of Contents

    ATRIO W+ SMART SECURITY SERIES TABLE OF CONTENTS USAGE NOTICE 1.1. Warnings and Considerations 1.2. Precautions PRODUCT DETAILS 2.1. Description 2.2. Features 2.3. Contents in the Box 2.4. Technical Specifications PRE-INSTALLATION INSTALLATION APP SETUP CONFIGURATION Management Settings Mode Management Settings Menu...
  • Page 5 Add User Add Administrator Delete User System Management In Common Mode Mechanical Key Battery Level Detection 6.10 Anti Peek Hole Detection 6.11 Net Pairing RESET WARRANTY...

  • Page 6: Usage Notice

    USAGE NOTICE 1.1. WARNINGS AND CONSIDERATIONS Caution symbols highlighted across the manual represent the following: Indicates the highlighted precautions to be followed to prevent any high level of severity. Indicates the instructions to be followed during installation. Indicates suggestions and tips Please follow the notices to ensure your safety as well as to prevent property loss.
  • Page 7 Using this product in any manner other than how it is referred to in this document voids your warranty. Further, Hogar Controls is NOT liable for any damage incurred with the misuse of the product.

  • Page 8: Precautions

    1.2. PRECAUTIONS Ensure the below DOs & DON'Ts are adhered to enjoy a seamless product experience: - Clean your fingers before using the product. - Replace the batteries when you receive warning signs. - Keep the emergency keys with you or in a safe outdoor place from where you can retrieve it easily.

  • Page 9: Product Details

    2. PRODUCT DETAILS 2.1. DESCRIPTION The Atrio W+ smart door lock is an innovative and advanced smart door lock designed to revolutionize how you secure your home. With its futuristic technology and user-friendly unlocking features, this state-of-the-art lock ensures maximum convenience and protection for you and your loved ones.

  • Page 10: Technical Specifications

    6 to 12 digits Navigation Full Voice Prompt Navigation 100 cards in capacity, with Proximity Card 2 proximity cards included 2 pcs Mechanical Key Mobile App Hogar SE Power Supply 4 AA batteries Features Anti-Pry Alarm, trial, and error alarm, low battery alarm...

  • Page 11: Pre-Installation

    3. PRE-INSTALLATION - Prior to installation, the lock MUST be properly chosen based on the direction that the door will open. - The door MUST remain partially open during installation till commissioning is finished. - To prevent injuring the connection wire when installing the screw, please ALITE from the screw hole when mounting the rear panel and make sure that the connection wire does not obstruct the connection column hole.

  • Page 12: Installation

    4. INSTALLATION...

  • Page 13: App Setup

    5. APP SETUP - Download the “Hogar SE '' application at App Store or Google Play Store. - Enter the Register/Login interface. - Tap “Register” to create an account. - Select Country. - Enter your email ID. - Check “I agree to User Agreement & Privacy Policy” (Please review the terms and conditions).

  • Page 14: Management Settings Menu

    - To register, please follow the fingerprint, password, or proximity card registration process. If the administrator has already been registered, the system will prompt "Please authorize." Note: In case of unsuccessful administrator identification, the system will play a voice prompt saying "input error." Upon successful recognition, it will seamlessly transition into the main menu.

  • Page 15: Add User

    Note: All operations are voice operated. 6.3. ADD USER: Enter to add an administrator, the voice will play “Please enter fingerprint, password, card”, according to the user press the finger, enter the password or swipe the card to determine whether to add a fingerprint, password or proximity card. 6.4.

  • Page 16: System Management

    b. Verify to delete press 2, user could be deleted by pressing finger, enter password or card to delete. c. If the fingerprint, password and proximity card are not registered, the voice plays “No user, no card” to skip to the previous step. 6.6.

  • Page 17: In Common Mode

    6.7. IN COMMON MODE: 6.7.1 PASSWORD UNLOCK Enter the added password, press# to confirm, password verification success voice prompt “press the handle to open the door”. Press down the handle to unlock. Note: You can add any dummy password before or after the user password, and the length including the dummy password should not exceed 30 digits, which comletely eliminates the risk of password leakage.

  • Page 18: Mechanical Key

    6.7.3 SWIPE TO UNLOCK Put the added proximity card close to or paste it on the keypad area, and the proximity card verification is successful and the voice prompt” please press the handle to open the door”. Press down the handle to unlock. 6.8.
  • Page 19 6.8.2 USB EMERGENCY POWER SUPPLY When the battery is exhausted and there is no key, you can connect an external power bank or 5V1A power supply for emergency, and open the door according to the normal operation steps. Please replace the battery in time after the emergency unlock.
  • Page 20 6.8.4 INSIDE LOCK: Unlock the inner body anti-peep hole by pressing the designated button. 6.8.5 DOOR INSIDE THE SAFETY KNOB Rotate the button to activate or deactivate the function, ensuring the prevention of accidental unlocking by children or pets. In this state, the door cannot be opened conventionally from the outside and requires unlocking from the inside.

  • Page 21: Battery Level Detection

    6.9 BATTERY LEVEL DETECTION: When the battery voltage ranges between 4.5V and 4.8V, it is recognized normally, accompanied by a voice prompt before each unlocking attempt stating "Low Battery, Please Replace." If the battery drops below 4.5V, the touch keypad, when awakened, will produce 5 beeps, and the door will remain locked without unlocking.

  • Page 22: Net Pairing

    6 to enter network pairing. Press 1 for smart configuration and press 3 for version upgrade. Open the Hogar SE app, choose "device," and enter the WiFi name and password. Press "Next" to initiate the pairing process. Confirm when the indicator is rapidly blinking and press "Next."...

  • Page 23: Warranty

    Warranty Hogar offers an Exclusive 18-Month Warranty on any product that covers defects in materials and quality under normal use of the Product. The Terms and Conditions of this 1.5 YEARS LIMITED WARRANTY can be viewed on www.hogarcontrols.com or scan the QR code: IMPORTANT NOTICE: All information, including but not limited to product features, functionality, and/or other specifications, is subject to change without...
  • Page 24 CONGRATULATIONS! You've successfully installed your Atrio W+. Now you can experience seamless control of your Atrio W+ with your Hogar SE App. Add more to your home from our range of smart home automation solutions and live the smart life.
  • Page 25 Hogar Controls Inc 21000 Atlantic Blvd, #300 Sterling, Virginia, USA -20166 INDIA Sandhya Techno-1, Khajaguda X Road, support@hogarcontrols.com Radhe Nagar, Rai Durg, Hyderabad Telangana 500081 | Phone : +91 844 844 0789 www.hogarcontrols.com...
