USER'S MANUAL

Battery Management System

BM100

BP100-12VT

BP100-2VT

The Battery Remote Management System allows a battery system to

be managed, monitored, and configured.

SAVE THESE INSTRUCTIONS

Please read this manual and follow the instructions for installation and use.

K01-E000024-02

Need help?

Do you have a question about the BM100 and is the answer not in the manual?

Questions and answers

Summary of Contents for CyberPower BM100

Page 1 USER’S MANUAL Battery Management System BM100 BP100-12VT BP100-2VT The Battery Remote Management System allows a battery system to be managed, monitored, and configured. SAVE THESE INSTRUCTIONS Please read this manual and follow the instructions for installation and use. Copyright © 2023 Cyber Power Systems, Inc. All rights reserved.
Page 2 Save and Restore Configuration Settings ..............28 Troubleshooting ........................29 Conformance Approvals..................... 30 Appendix 1: IP Address Settings for CyberPower Battery Manager ....31 Appendix 2: How to Configure a Battery Manager User Account in Authentication Servers .................32 Appendix 3: Software Support ..................32...
Page 3 Safety Instructions Read these instructions carefully and be familiar with the equipment before trying to install, operate, move, maintain or repair it. Owing to the possibility of potential hazards, always use extreme caution when working with batteries. The following safety information should be observed before any works are performed on the system.
Page 4 • Inspect whether there is any mistakenly connected polarity between batteries before powering on the system. • To avoid short circuits or suffering from electrical shock, do not touch or replace any cables connected to the battery before having disconnected the system from the batteries.
Page 5 Introduction Overview The CyberPower Battery Management System (BMS) provides a proactive approach to manage and monitor a battery system attached to a network, eliminating the risk of downtime by ensuring the batteries are optimally charged and ready for use (e.g. UPS system).
Page 6 Unpacking Inspect the package upon receipt. The package should contain the following: Battery Manager • CyberPower Battery Manager • Quick Start Guide • Dry Contact Interface Power Cable (244cm; L4) • 4 Battery Probe Communication Cables (90cm; L1) •...
Page 7 Battery Probe • CyberPower Battery Probe • Quick Start Guide • Battery Connecting Cable (250 terminal; 30cm; L3) • Battery Probe Communication Cable (30cm; L2) • 4 Ring Washers (M8 Ring*2, M10 Ring*2; L5) Battery Manager • Front Panel DC POWER...
Page 8 • LCD Panel System Select Battery Status String Status Battery Balance Enter BM100 Name Description/Condition Green (steady): The Battery Manager is supplied with power and works normally. System Red (steady): The communication or conditions of battery probes are abnormal. Green (steady): The communication of the environmental sensor is normal.
Page 9 Name Description/Condition Communication Test Button LED1 (Red) Steady: The battery is abnormal. Steady: Power is provided, the communication is normal, and datagram is receiving or transmitting. LED2 (Green) Flashing: The power of the battery probe is on and the communication is under testing. Installation Guide Please read safety instructions carefully before installation.
Page 10 Connect the battery connecting cable (L3) to M8 or M10 ring washers (L5). Besides, make sure that the M8 or M10 washers (L5) are installed above the battery series connection wire. Note: Please see below illustration for correct installation of the two black cables. Besides, connect the red cable to the battery pole (+).
Page 11 Note: These instructions are for Windows OS. For other OS please refer to Appendix 4. Method 1: Using the Power Device Network Utility 2 Install the Power Device Network Utility 2 available for download at www.CyberPower. com. 2. After installation completes, run the “Power Device Network Utility 2”.
Page 12 5. You will need to enter a User Name and Password for the Battery Manager in the authentication window, as shown in Figure 2. - Default Account: admin - Default Password: admin Figure 2. Authentication window 6. You can modify the IP Address, Subnet Mask, and Gateway address for the Device MAC Address listed in the Device Network Settings window, as shown in Figure 3.
Page 13 Method 2: Using a command prompt Obtain the MAC address from the label on the Battery Manager. Each Manager has a unique MAC address. Note: The MAC address is labelled on the Manager. 2. Use the ARP command to set the IP address. Example: To assign the IP Address 192.168.20.177 for the Battery Manager, which has a MAC address of 00-0C-15-00-00-21 you will type in the following in the command prompt...
Page 14 Item Definition System Data Name The name given to the Battery Manager. Location Location description given to the Battery Manager. Contact The person to contact about this Battery Manager. Uptime. Length of time the system has been working continuously Envir Status Graph of the current temperature reading of the environmental Temperature sensor.
Page 15 [Battery->Status] Display the basic information about the current battery status. Items displayed are auto refreshed. Item Definition Data # (index) Index of the battery within its string. Volt. Current battery voltage reading. Temp. Current battery temperature reading. Res. Current battery resistance reading. Current battery equalization power in percentage.
Page 16 Item Definition Temperature Setup battery temperature range. Battery probe gives alarm when Range battery temperature is out of range. Setup battery resistance range. Battery probe gives alarm when battery resistance is out of range. Note: If the battery is fully charged and battery resistance is out of Resistance Range high threshold, it may be caused by a faulty or aged battery and should be checked to eliminate the risk of downtime.
Page 17 [Current->Status] Configure the parameters of the system. Item Definition Configuration # (index) Index of the current probe. Current Probe The name of the current probe. Name Current Probe The location of the current probe Location Channel Channel index of the current probe. Measure Name The name used to identify the measurement.
Page 18 Item Definition Temperature Current Value The current environmental temperature. Maximum The highest temperature and time detected by the environmental sensor. Minimum The lowest temperature and time detected by the environmental sensor. Humidity Current Value The current environmental humidity. Maximum The highest humidity and time detected by the environmental sensor. Minimum The lowest humidity and time detected by the environmental sensor.
Page 19 [Logs->Status Records] This page is used to view the logs of the system status and environment status. • Date: The time of the specific status records. • String Voltage (V): The voltage of the particular battery string. • String Current (A): The current of the particular battery string. •...
Page 20 [Logs->Syslog] Allow users to set syslog server and send test message. Item Definition Syslog Enable or disable Syslog function. Facility Code Select Syslog facility. Server IP The IP address of Syslog server. Server Port The UDP port used by the Syslog server. Send Test Send test message to Syslog server.
Page 21 [System->General->Time] Display the system date and time and allow users to set it manually or by using the NTP (Network Time Protocol) server. Item Definition Displays the current date and time on the manager status and time Current Settings until the next Network Time Protocol (NTP) update. System Time Configuration Time Zone Choose the Battery Manager time zone in GMT (Greenwich Mean Time).
Page 22 [System->Security->Local Account] This page is used to configure the login account. Item Definition Administrator Administrator has full access to read/write configuration settings. Viewer Viewer has restricted access to read only. This setting determines what IP address is allowed to access the device using either Admin or Viewer accounts.
Page 23 [System->Security->LDAP Configuration] After setting the proper LDAP server, the Battery Manager can use user name and password that set on the LDAP server to login. Item Definition LDAP Server The IP address of LDAP server. LDAP SSL Enable to communicate with LDAP server by LDAPS. Port The TCP port used by the LDAP(S) server.
Page 24 [System->Network Service->TCP/IPv6] Display and configure the current IPv6 settings. Item Definition IPv6 Interface Displays the current IPv6 address. IPv6 Gateway Displays the current IPv6 gateway. IPv6 Configuration Access Set the IPv6 service to either Enable or Disable. Address Mode The IPv6 address is assigned through one of the following methods Router Control as configured in the router settings: Stateless Address Auto- configuration, Stateless DHCPv6 or Stateful DHCPv6.
Page 25 [System->Network Service->SNMPv3 Service] Allow users to use a NMS and configure the appropriate SNMPv3 settings. Item Definition SNMPv3 Service Allow Access Set the SNMPv3 service to either Enable or Disable. SNMPv3 Access Control The name to identify SNMPv3 user. The field must be 1 to 31 User Name characters in length.
Page 26 Item Definition Click the following links: • Valid Certificate (or Invalid Certificate): Certificate detail information. Certificate Status • Upload Certificate: Upload a certificate and replace the current one. Note: The format of uploading certificate must in a standard PEM (Privacy Enhanced Mail). [System->Network Service->FTP Service] Allow users to Enable/Disable the FTP server service and configure the TCP/IP port of the FTP server (21 by default).
Page 27 Item Definition Username Username used for Authentication. Password Password used for Authentication. Secure connection Enable TLS or SSL security. Service port The port number used to communicate with the SMTP server. [System->Notifications->E-mail Recipients] Set up to five email recipients to receive notifications when configured Events occur.
Page 28 E-mail The expressions will be replaced by the relevant content before the (SMTP) message is sent by the SMS provider. For example: Address sample@cyberpower.com Subject TestSubject Content E_PHONE_NUMBER&text=E_MESSAGE [System->Notifications->SMS Recipients] Users can set up to 10 mobile phone numbers as SMS recipients.
Page 29 - A. cpsbmethafw_XXX.bin - B. cpsbmethadata_XXX.bin Note: To ensure keeping the Ethernet firmware up to date, please visit CyberPower website every 3 months to see if there is any updated firmware version available. Note: Please do not turn the Battery Manager off when processing the Firmware upgrade.
Page 30 Use the following steps to upgrade the firmware: Download the latest firmware 2. Extract the downloaded files to “C:\” 3. Open a command prompt window 4. Login to the CyberPower Battery Manager with FTP command, in the command prompt type: (1) ftp (2) ftp> open (3) To [current IP address of Battery Manager] [port];...
Page 31 2. Ensure the PC being used is on the same local network subnet method 2 as the CyberPower device you are trying to communicate with. 3. Ensure the Jumper on the Reset Pin is correctly installed. 1. Use method 1 and/or method 2 to get/set a correct IP address for the Battery Manager.
Page 32 Problem Solution Get the alarm of Check the battery charging system first, retest battery resistance battery resistance after the battery is fully charged to confirm whether it’s a battery and the battery is aging or charger problem. not fully charged 1.
Page 33 All devices on a computer network need to have an IP address. Each device’s IP address is unique. The same address cannot be used twice. In order to assign an IP address to the CyberPower Battery Manager, you must determine the range of the available IP addresses, and then choose an unused IP address to assign to the Battery Manager.
Page 34 Battery Management System (BMS) Software is used to collect and configure multiple Battery Managers’ data. Battery Management System (BMS) Software is available on CyberPower Systems official website. Please visit www.CyberPower.com and go to the software section for free download. Communicate with BMS software The Battery Manager requires authentication with BMS software via a shared secret phrase, as shown in Figure 10.
Page 35 Figure 10. Battery Management System > Authentication web UI. Appendix 4: Mounting Bracket Installation Guide Method 1: Horizontal Installation Method 2: Upright Installation Note: Please set up the Battery Manager on a level surface.
Page 36 Cyber Power Systems, Inc. www.cyberpower.com For USA and Canada: 4241 12th Ave East, Suite 400 Shakopee, MN 55379 Toll-free: (877) 297-6937 For all other regions: Please visit our website for local contact information. Copyright © 2023 Cyber Power Systems, Inc. All rights reserved.
