Page 1 Triton INSTRUCTION MANUAL...
Page 2 CONTENTS Introduction ......................... 3 Where to find the Serial No & Size Labels ................3 Measurements & Useful Info ....................4 Seating System Components ..................... 5 Important Safety Advice ...................... 6 Important Safety Advice -(Accessories) ................7 Operating Brakes (Indoor Base Frames) ................7 Important - Chest Harness Adjustment ................
Page 3 Introduction The Triton is designed to provide comfort and postural support. The system is available in seven sizes across three models to accommodate children from as young as 6 months through to adult. This instruction manual contains very important information about the Triton seating system, how to use it safely and obtain the best results from it.
Page 4 Measurements & Useful Info Triton 1 Triton 2 Triton 3 Triton 0 Triton 1 Triton 2 Triton 3 Triton 4 MEASUREMENTS Long Long Long (mm) MIN MAX MIN MAX MIN MAX MIN MAX MIN MAX MIN MAX MIN MAX MIN MAX...
Page 5 Seating System Components Push Handle Headrest Shoulder Protraction Pads Lateral Supports Hip Pads Adjustable Thigh Pads Footplate Castors Multi Height & Tilt Base Tray Fixing Holes Armrest Legrest...
Page 6 (see pages 8 & 9). • When fitted to an indoor base frame the Triton should always be positioned on a level, flat floor. The Triton chair can be moved between one working area and another.
Page 7 Important Safety Advice - (Accessories) Multi Adjustable Head support Wings on the head support are ideally set at 45 degrees. Do NOT bring the wings in tight to the head. Ensure that the head support is set in such a way that the child cannot loop their head around the wings and get stuck.
Page 8 The straps at the top of the harness should be attached to the back frame of the chair. The Triton comes with a fixing point either side at the top back of the chair for attachment of straps and harnesses.
Page 9 Important - Lap Strap Safety Incorrect fitting of lap straps can put the user at serious risk. When using lap straps we recommend the following points should always be adhered to: Lap Strap Fitting adjustment strap at the buckle should be approximately 3”...
Page 10 Useful Info - Adjustment Points & Lever Use Adjustments Points Underneath Seat Split Seat Seat depth (Leg Length adjustment Discrepancy) bolts Adjustment (This is only fitted if specified at assessment) Leg rest Adjustment Sandal Adjustment Point (Handwheel) Effective Operation of Lock Levers (Where Fitted) • Continue to hold the lever out and Never remove these levers entirely as this will prevent you from being able to perform...
Page 11 Lever Use - Using Index Plungers Using the Index Plungers (Locking Variety Only) • To place the plungers in an open position - Pull out the plungers to maximum tension and turn them through a half turn anti-clockwise (B). This places them in an open position (C). TURN OPEN LOCKED...
Page 12 Mounting of Seating Unit Always ensure the base is stable and that the brakes are applied before mounting the seating unit. Please note that the handle fitted is dependent on the size of the chair. You therefore need to ensure the size label on the handle matches the size of the chair being used.
Page 13 Manual Seat Height Adjustment (Multi Height & Tilt Base) The multi height and tilt base caters for all sizes of Triton. It is controlled by a hydraulic pump mechanism. To Raise The Chair • Pump the foot pedal...
Page 14 Tilt In Space (Multi Height & Tilt Base) Always ensure the base is stable and that the brakes are applied before performing the following adjustments. • Release the locking mechanism on the handle by squeezing the small latch (A) up on the handle. • To Recline: Use one hand to squeeze handle (B) and push down the chair handle, at the same time use the...
Page 15 5 Star Base Adjustments Always ensure the base is stable and that the brakes are applied before performing the following adjustments. To Lower To Raise The Chair The Chair • Located at the back of the chair beneath the base locate the Use the handle (A) handle (A) and continuously again but this time...
Page 16 • Tighten the two allen key bolts securely. • Replace the back cushion pad. Note The picture shows the Dynamix model of the Triton chair. The Custom model has hand wheels on the back of the chair.
Page 17 Adjusting Seat Depth • Loosen (do not remove) the allen key bolts (A) on both sides of the seat. • Slide the seat in or out to change the length. • Fix the position by tightening the allen key bolts securely. When mounting the seating system to a base for the first time, or when an...
Page 18 Fitting a Tray • Line up the arms of the • Slide the arms of • Secure the tray in place tray with the holes on the tray through the with the hand wheel the arms of the chair (A) holes until the desired at the side of the chair position is reached.
Page 19 Hip Pad Adjustment Hip Pad Width Hip Pad Angle (Where Fitted) • Whilst holding plunger (A) up adjust the • Push down button (C). hip pad along the hip pad bar (B). • Manually adjust the pad to the desired • Relocate the plunger into one of the angle.
Page 20 Headrest Adjustment Adjusting the Wing Angle This adjustment point allows you to move the wing position to offer more side support to the head. This adjustment point allows you to alter the angle of the headrest to support the head and neck. • Unzip the headrest cover at the back and loosen the allen key bolts (A).
Page 21 Lateral Support Adjustment Height & Width of Supports • Loosen both bolts (A) using the allen key provided. • Slide the pads up or down along the slot in the seat back (B) to adjust the height. • Slide the pads horizontally along the slot (C) to adjust the width.
Page 22 Adjusting Arm Angle The arms fitted to your Triton chair can be altered to sit throughout an angle range, enabling the user to level their tray no matter what tilt the chair is secured at.
Page 23 Footrest, Footplate & Sandal Adjustment Footrest Angle Adjustment • Relocate the plunger into one of the positioning holes (D) at the back of the • Pull out and hold plunger (C). footplate. • Manually tilt footplate to desired angle. The plungers (C and E) should pull out freely, if resistance is felt ensure no weight is being put through the footrest.
Page 24 Follow the maintenance schedule, if the shock system shows any malfunctions such as losing oil, making unusual sounds or any part is bent or broken, cease use of the seating system immediately and contact JCM for assistance. Never try to open or disassemble the shock system. Opening the shock system could cause serious injury.
Page 25 Besides this you will not be able to reassemble the shock any more. Opening the shock will void its warranty. If there is a problem with your rear shock, cease use of your chair immediately and contact JCM Seating Solutions.
Page 26 In addition to the specific functional adjustment warnings specified in this manual, it should be ensured that a thorough inspection of the following should be completed at no greater than 6 month intervals: (Points listed here are generic across the JCM range and do not apply to all products).
Page 27 Who should carry out the service? It is stressed that only a JCM approved repairer or a person with competent training of a Class 1 medical device should carry out this work. Any modifications must not be carried out without prior agreement of JCM Seating Solutions Ltd.
Page 28 It should be completed each time an inspection, service or any other significant manipulation has taken place. JCM Seating Solutions Ltd. will require proof of service for any warranty claims or orders.
Page 29 JCM. IMPORTANT JCM Seating Solutions Ltd. will not be held responsible for any damage or injury caused by incorrect use of this product. For any information or guidance on the use of this product please call our office who will put you through to your local representative or send you any additional information you may require.
Page 30 • Electrical and Electronic Equipment Decomissioning If your product is set up with an electrical function you should always contact JCM or your authorised representative for de-comissioning information. • Appropriateness of Equipment Check that the equipment supplied is appropriate for the needs of the user taking age, weight, ability, diagnosis, and any other important factors into account.
Page 31 inflated as appropriate. • Accessories Check all accessories carefully for damage and potential shortcomings which may pose a risk to the user. • Function Ensure that all the functions of the chair are working correctly e.g. tilt in space, height adjustment, back recline, folding etc.
Page 32 ® design For living 15 -18 Maxwell Road, Woodston Industrial Estate, Peterborough, Cambridgeshire PE2 7HU Tel: 01733 405830 Fax: 01733 405838 Email: enquiries@jcmseating.co.uk © 2008 JCM Seating all rights reserved. Q.A.34 (Aug 2010)
Page 33 Triton - Model 0 INSTRUCTION MANUAL...
Page 34 CONTENTS Introduction Where to find the Serial No & Size Labels Measurements & Useful Info Seating System Components Important Safety Advice Important Safety Advice -(Accessories) Important - Chest Harness Adjustment Important - Lap Strap Safety Lever Use - Using Index Plungers Operation of Locking Levers Adjusting Seat Depth Mounting of Seating Unit Removal of Seating Unit From Base Operating Brakes Adjusting The 5 Star Base Adjusting The Multi Height & Tilt Base Back Angle Adjustment Back Height Adjustment Adjusting Shoulder Protraction Pads Fitting a Tray Arm Rest and Tray Angle Adjustment Hip Pad Adjustment Lateral Support Adjustment Headrest Adjustment Sacral Pad Adjustment Footplate & Leg Rest Adjustment Footrest, Footplate & Sandal Adjustment Cleaning & Care General Maintenance Servicing via Approved Repairer Service Record Log Warranty Inspecting & Reissuing of Equipment...
Page 35 Introduction The Triton 0 is designed to provide comfort and postural support for very young children. This instruction manual contains very important information about the Triton 0 seating system, how to use it safely and obtain the best results from it. Please read all the information contained in this manual before using the chair and retain for future reference. Ensure everyone using the equipment is aware of the contents of this manual and understands how to use the equipment safely. These instructions provide guidance on the adjustments for professionals, but they also give information on how the equipment should be safely used, maintained, checked, and correctly assembled by anyone who uses the seating system. In every case the equipment should be supplied via qualified professionals who will have adjusted the equipment, checked its compliance and tested it appropriately. The seating system should only ever be adjusted by qualified professionals and persons that are suitably trained. For further information please do not hesitate to contact us - all contact details are on the back cover of the manual. Thank you for purchasing our product, we hope you enjoy your new seating system. Where to find the Serial No & Size Labels Serial Number Handle Size...
Page 36 Measurements & Useful Info TRITON 0 MEASUREMENTS (mm) A Seat Depth B Seat to Top of Back C Chest Breadth D Seat to Footplate E Seat Width (Between Hip Pads) F Floor to Seat 00mm Castors: Min 355 Max 85 / 75mm Castors: Min 35 Max 785 G Tilt in Space / Prone Prone 7° Tilt 5° H Back Angle 5° Recline 5° Forward I Base Footprint 740 x 570 J User Weight Maximum 00 kgs Triton 0 4 kgs Chair Weight Please Note All measurements given for indication only. JCM can tailor the chair to your exact requirements. Our representatives will assess your child to ensure the chair is fit for purpose both...
Page 37 Seating System Components A Push Handle Headrest C Shoulder Protraction Pads D Lateral Supports E Hip Pads Long Sitting Pad Footplate H Castors Multi Height & Tilt Base J Clear Tray Armrest Other accessories are available (not shown)
Page 38 Important Safety Advice We at JCM are committed to producing products of the highest standard. All of our products fulfil the essential safety and environmental requirements as defined in the European Directives. However, improper use of the products will potentially put the users at risk and therefore JCM strongly suggest that the following information is strictly adhered to at all times.
Page 39 Important Safety Advice - (Accessories) Multi Adjustable Head support Wings on the head support are ideally set at 45 degrees. Do NOT bring the wings in tight to the head. Ensure that the head support is set in such a way that the child cannot loop their head around the wings and get stuck. Flexi-Supports and Lateral Supports Ensure the straps do not infringe on any feeding tubes the child may have. Pommel The pommel is designed to abduct the users knees to help keep the hips in a good position. Do NOT use the pommel as a way of holding the user in the seat. Remove the pommel when transferring the user in and out of the seat. Foot Sandals and Straps Should only be fixed when the user is wearing shoes or boots. Tray Do NOT use the tray as a way of securing children in a chair always ensure that the lap strap and any other straps supplied are used. Ensure that the tray clips are secure on both sides of the tray. If the tray is damaged, ensure that this will not be a hazard to the user. Never leave hot items on the tray while children are unattended.
Page 40 • The sternum strap on the chest harness should always be adjusted prior to use to ensure that it is no higher than the middle of the users chest. • A lap strap should always be fitted if a harness is being used to ensure the child cannot slide down onto the sternum strap. • Always ensure that the belts offer your child both comfort and support. If the childs clothing has been adjusted (i.e. a jumper removed) the straps should be re- adjusted accordingly. Fixing Onto Chair The straps at the top of the harness should be attached to the back frame of the chair. The Triton comes with a fixing point either side at the top back of the chair for attachment of straps and harnesses. The straps at the bottom of the harness should be located to the back of the seat frame. Fastening of Belts • Feed the fabric belt through the buckle on the strap. • The belts should be pulled through enough to suitably support your child whilst still being comfortable. • When this has been achieved the buckle should be snapped closed to secure the strap in place. The same precautions highlighted here should be adhered to when using any form of trunk supports or flexi supports with straps. If there is any possible chance of the child getting the straps caught around...
Page 41 Important - Lap Strap Safety Incorrect fitting of lap straps can put the user at serious risk. When using lap straps we recommend the following points should always be adhered to: Lap Strap Fitting adjustment strap at the buckle should be approximately 3” (76mm) long. Education of the care giver is essential The angle that the hip belt is attached to the seating for correct hip belt positioning. system has a direct effect on the angle of pull on the pelvis. Sizing Considerations: Measure hip width to determine the belt size required.
Page 42 Lever Use - Using Index Plungers Using the Index Plungers (Locking Variety Only) • To place the plungers in an open position - Pull out the plungers to maximum tension and turn them through a half turn anti-clockwise (B). This places them in an open position (C). TURN OPEN LOCKED • To close - Turn the plungers a half turn clockwise and they should snap back into a locked position (A). Operation of Locking Levers Effective Operation of Lock Levers (Where Fitted) Never remove these levers entirely as this • Continue to hold the lever out and will prevent you from being able to perform reposition the lever handle in a suitable adjustments in the future. position past the obstruction. • To use: Turn the lever handle clockwise • Release the handle to re-engage the to tighten or anti clockwise to loosen. lever function (B) and continue to tighten or loosen in the normal way. • To use the lever when an obstruction is met: Pull the handle of the lever •...
Page 43 Adjusting Seat Depth view of under- side of seat Step 1- Seat Depth Increase pull the seat forwards. (50-5mm of depth) • Re-tighten the allen key bolts (A) to secure the seat in place. • Untighten screws (A) by a half turn, using the long allen key provided. • You can gain an additional 75mm seat depth forwards from 5-300mm by • Using one hand to steady the base, making another adjustment shown in grasp the top of the leg rest firmly and step below. Step 2 - Seat Depth Increase (75mm extra depth 5-300mm) • Push the seat back (reversing the process in step leaving the allen key bolts (A) untightened.
Page 44 Mounting of Seating Unit Always ensure the base is stable and that the brakes are applied before mounting the seating unit. • There are cut outs on the top of the interface plate (A) which are for locating lugs (B) on the seating unit to fit into. • Position the seating unit above outs on the interface plate (A). the interface plate, lining up the • Push the seating unit inwards locating lugs (B) with the cut outs towards the back of the chair until (A) on the interface plate. the locating lugs ‘click’ into place. • Carefully lower the seat onto • Ensure the seat is securely the interface plate ensuring the located on the base before using.
Page 45 Removal of Seating Unit From Base • Release index plunger (C) which is underneath the interface plate and slide seat forward to remove it from the base. Operating Brakes Applying Brakes Releasing Brakes Depress lever (B) with your foot. To To release the brakes you should flick secure the chair in place you should the levers up using the top of your foot. suppress all the brakes fitted to the When all brakes are released the chair wheels on the base. will be free to travel in any direction. Always apply the brakes while the chair is stationary.
Page 46 Adjusting The 5 Star Base To Raise The Chair • Located at the back of the chair base push the red lever (A) downwards to raise the chair. To Lower The Chair • Whilst pushing the red lever (A) downwards, apply weight to the seat cushion and push down. Adjusting The Tilt In Space on the 5 Star Base • Lift up the safety latch (A) fully so that the grooves either side at the back of the latch clear the bar (C). • Pull down the main latch (B) fully so that the grooves Shows the either side at the back of the latch clear the bar (C). grooves • Tilt the chair to the required position (supporting the on both chair as you adjust). of the Groove on latch latches. locked on to bar. •...
Page 47 We recommend practicing this operation on first use You therefore need to ensure the before placing the client in the chair. size label on the handle matches the size of the chair being used. Seat Height Adjustment The multi height and tilt base caters for all sizes of Triton. It is controlled by a hydraulic pump mechanism. To Raise The Chair • Pump the foot pedal several times until the desired height is reached. (The chair will raise with each pump.)
Page 48 Back Angle Adjustment • Pull out the left one of the plungers (A) and rotate to 90 degrees to place in an open position. • Whilst holding out the right hand plunger (A), rotate the back of the chair into the desired position. • Re-locate both plungers into another of the holes as shown at point (B). Lock the plungers into place by releasing the right hand plunger and twisting the left hand plunger in an anti- clockwise direction so that it slots closed. Fig (C) shows both plungers locked into place. Always ensure that both plungers (A) are fully locked into place as in fig (C) and are fully engaged onto one of the holes (B) before allowing the chair to be used.
Page 49 Adjusting Shoulder Protraction Pads Pad Width • The pad adjusts by friction alone. Pull or push the pad firmly in or out to adjust the pad width. Pad Angle -Towards User • Manually position the pad by pushing towards the front of the chair to give the correct amount of shoulder protraction - (the pad automatically locks itself into place). • To increase the life of the ratchet mechanism, it is advisable to press the button to re-position the pad close to where it is required, using the ratchet lock to complete only fine adjustment. To Flip Away From User • Depress button (A) and hold down to flip the pad away from the user. • Release button (A) to secure in place.
Page 50 Fitting a Tray • Line up the arms of the • Slide the arms of • Secure the tray in place tray with the holes on the tray through the with the hand wheel the arms of the chair (A) holes until the desired at the side of the chair position is reached. arm. Always ensure that the arms are fixed in position and the tray is secure before leaving the user unattended. Never leave anything hot on the tray while the client is unattended.
Page 51 Hip Pad Adjustment Hip Pad Width • Whilst holding plunger (A) up adjust the hip pad along the hip pad bar (B). • Relocate the plunger into one of the relevant positioning holes on the hip pad bar (B). Hip Pad Angle • Push down button (C). • Manually adjust the pad to the desired angle. • Release the button (C) to secure. Lateral Support Adjustment Height & Width of Supports • Un-tighten allen key bolts (A) and manually move the lateral supports up and down or left and right within the slots to adjust. • Re-tighten the allen key bolts securely to lock the supports in place. Check that the supports are not too high under the arms of the user or tight around chest area by running your fingers around the inside of the supports.
Page 52 Headrest Adjustment Adjusting the Wing Angle This adjustment point allows you to move the wing position to offer more side support to the head. This adjustment point allows you to alter the angle of the headrest to support the head and neck. • Unzip the headrest cover at the back and loosen the allen key bolts (A). • Adjust the sides of the headrest into the desired position. • After desired position has been reached tighten the bolts to secure in place. Perform this for either side wing of the headrest. Adjusting the Headrest Angle • Levers (B) should be operated together to achieve the desired head positioning of the user. Loosen the levers by turning anti-clockwise. • Once loose, the head support angle can be manually adjusted to suit the user. • Tighten the levers to secure in place. Adjusting the Headrest Height • Loosen the hand wheel (C) • Slide the headrest up or down inside the bracket on the back of the chair. • Re tighten the hand wheel to secure in place.
Page 53 Sacral Pad Adjustment Un-tighten both hand wheels (A) located either side of the sacral pad, this allows all of the adjustments below to be made. Lateral Rotation • Twist the pad left and right as desired. Fore and Aft • Slide the pad forwards and backwards within the slot (B). Posterior and Anterior Rotation • Rotate the pad about its axis. Pad Height • Un-tighten both allen key bots (C) and adjust up and down along the slots. Always ensure that both hand wheels (A) either side are tightened to secure the pad in place.
Page 54 Footplate & Leg Rest Adjustment Footplate and Leg Rest Height • Slide the footplate up or down the bracket (D) as required and re-locate • Push button (A) located on the bar (B) by pushing the groove on the underside of the footplate in. end onto one of the teeth on bracket (D). Ensure that bar (B) is securely located • Pull bar (B) located on the underside of onto one of the teeth and pushed on as the footplate out away from the chair. far as it will go before resuming use of the chair. • The footplate can now either be flipped and held up as in fig (C) or it can be adjusted in height. Removal of Leg Rest and Footplate for Standing Transfer • Pull out the plunger on the left and rotate by 90 degrees to put into an open position (E). • Hold out the plunger on the other side whilst you push the bracket (F) upwards and towards the chair. Unhinge off the hooks at the top. • Reverse the whole process above to put the leg rest back on, ensuring the plungers are secured into place.
Page 55 Footrest, Footplate & Sandal Adjustment Removal of the Foot Pad Cushion for Sandal Use • For sandal use the foot pad cushion can be easily removed simply by un-clipping the 4 press studs which attach the pad to the plasic base as shown in fig (D). Sandal Rotation • Underneath the footplate loosen the central allen key bolts by turning anti-clockwise. • Rotate the sandal to the desired position along slot (G). • Fix in place by tightening the allen key bolts beneath the footplate. Foot Straps Foot straps or ankle huggers can be attached through the slots in the footplate to secure feet. Feed the strap through the buckle and close the buckle shut to secure. Do not use foot straps unless the client is wearing shoes.
Page 56 Refer to JCMs fabric cleaning guide which can be found on their website www.jcmseating.co.uk Do not use bleach, acidic, solvent, abrasive, biological or phenolic based cleaners. Metal Framework • If all upholstery is removed the metal framework can be cleaned with hot soapy water and detergent or it can be steam cleaned. (Labelling may need to be replaced following steam cleaning). • Ensure that the framework is thoroughly dried after cleaning. • Always ensure that any moving or adjustable parts are re-lubricated. General Maintenance General maintenance should be carried out by a competent, professional person who is well informed on how to use the equipment (see warranty - page 9) if there is no such person available or a more thorough check is needed, a service via an approved repairer (see opposite) should be booked. The person who carries out the maintenance check or service should always fill out the service history log record (page 8) in order to ensure the warranty remains valid. As documented opposite, the degree of maintenance required is dependant on various factors relating to the use of the product. In addition to the specific functional adjustment warnings specified in this manual, it should be ensured that a thorough inspection of the following should be completed at no greater than 6 month intervals: (Points listed here are generic across the JCM range and do not apply to all products). Castors • Lift base and check each wheel to ensure it is not damaged, loose or worn. • Removing any grease or dirt that has built up on the wheels, check that the brakes Brakes stop the wheels rotating. • Check they are securely fixed in place & that there are no signs of damage or wear & tear. • Ensure handles are functioning correctly. Pushing • Check there are no signs of damage or wear and tear. Handles • Ensure push handle grips are secure.
Page 57 What should be completed during a service? A service is a comprehensive combination of inspection, maintenance and repair or replacement of worn, faulty or missing components. The growth and any changes of the occupants needs since the original assessment is taken into account when performing the service. This is in contrast to general maintenance (opposite), where only straightforward checks, inspections and adjustments take place and primary services are planned. What happens if a fault is found? If any faults are found that could prove to be a risk to either the user or the operator then all use of the equipment should be ceased immediately until the product has been repaired. Who should carry out the service? It is stressed that only a JCM approved repairer or a person with competent training of a Class medical device should carry out this work. Any modifications must not be carried out without prior agreement of JCM Seating Solutions Ltd. It must be understood that unauthorised modifications may pose a risk to users and attendants. Unauthorised modifications will also invalidate the warranty. Any new parts required should be genuine JCM Seating Solutions Ltd. approved parts, fitted to JCM specifications. Frequency of Service JCM recommend that a service of this product is completed once every 6 months as a minimum. However, the frequency of inspection and service must be altered depending upon the severity of use. If the system is used in any of the following ways then the use could be said to be fairly heavy and constant. Therefore we would recommend the service interval be reduced to once every three months;...
Page 58 Service Record Log This log is an important record of usage and care of the product. It is a primary tool in predicting the need for further service and maintenance. It should be completed each time an inspection, service or any other significant manipulation has taken place. JCM Seating Solutions Ltd. will require proof of service for any warranty claims or orders. Seating system serial number ___________________ Date delivered ______/______/______ Battery use by date ______/______/______ Date Service Performed Organisation Print Name & Sign...
Page 59 3 year warranty. YEAR What it Covers The warranty covers all aspects of product failure due to faulty workmanship or manufacturing. Period of Cover The period of the warranty runs for 3 years from the date that the product is dispatched. The Work JCM is Obliged to Complete JCM’s obligation under this warranty is to replace or repair any defective goods within the period of the warranty free of charge. What the Warranty Does Not Cover • Items that are damaged or fail due to natural wear and tear, extreme usage, neglect or misuse.
Page 60 Inspecting & Reissuing of Equipment Most JCM Seating Solutions Ltd. products are individually assessed for a client prior to issue. They are handed over in a controlled way to ensure optimum fit and specification, checks are completed and any additional individual verbal instructions given. We therefore recommend the following points are adhered to prior to any re-issue of equipment: • Cleaning Follow a rigorous process of cleaning in order to decontaminate the product and eliminate the chance of cross infection. • Assessment of Fabrics / Foams Carefully assess the condition of fabrics and foams in the seating product, and have these replaced partially or even completely if need be. In severe cases if the chassis is worn and the seating in poor condition it may be necessary to have the product re- furbished by the manufacturer. In very severe cases if the chassis is badly worn and the seating in very poor condition then the product should be decommissioned and disposed of. • Electrical and Electronic Equipment Decomissioning If your product is set up with an electrical function you should always contact JCM or your authorised representative for de-comissioning information. • Appropriateness of Equipment Check that the equipment supplied is appropriate for the needs of the user taking age, weight, ability, diagnosis, and any other important factors into account. For instance, JCM Seating Solutions Ltd. products may not be suitable for persons with severe...
Page 61 inflated as appropriate. • Accessories Check all accessories carefully for damage and potential shortcomings which may pose a risk to the user. • Function Ensure that all the functions of the chair are working correctly e.g. tilt in space, height adjustment, back recline, folding etc. • Fixings Check that any knobs, hand wheels, nuts, bolts, levers and fixings are in good condition and fitted in place securely. • Modifications Any special modifications, adaptations, alterations or other such procedures including added accessories may require review. If they are found inappropriate, remedial action (if considered safe and practical) should be taken to reverse them if possible. • Labelling Any labelling specific to the previous user should be removed and replaced with labelling specific to the new user. • Adjustment Adjustment of the equipment to the new user must be carried out by suitably qualified and experienced professionals. These adjustments along with the other appropriate checks and tests should be completed with the owners knowledge and agreement. • Hand Over Competent handing over of the equipment to the new user or attendant must include proper training and advice in safe use, particularly regarding transportation issues. • Packaging Always ensure that the chair is packaged correctly before delivery. • Handle Fitting Please note that the handle fitted is dependent on the size of the chair. You therefore need to ensure the size label on the handle matches the size of the chair being used.
