User & Installation
All spares available from
Copyright Notice: All rights reserved. No parts of this manual may be reproduced in any form without
express written permission of Maidaid-Halcyon (A trading name of Buttress Group Ltd)
AMIKA
40XL
Guide
13.12.2012
The Engine Shed
Top Station Road
Brackley
NN13 7UG
Tel: 0845 1308060
Fax: 01280 845345
Web: www.caterparts.com
Advertisement
Related Manuals for Maidaid Halcyon AMIKA 40XL
Summary of Contents for Maidaid Halcyon AMIKA 40XL
- Page 1 AMIKA 40XL User & Installation Guide 13.12.2012 All spares available from The Engine Shed Top Station Road Brackley NN13 7UG Tel: 0845 1308060 Fax: 01280 845345 Web: www.caterparts.com Copyright Notice: All rights reserved. No parts of this manual may be reproduced in any form without express written permission of Maidaid-Halcyon (A trading name of Buttress Group Ltd)
- Page 2 INSTRUCTION MANUAL FOR DISHWASHERS CONTENTS CHAP 1 PREFACE ........................2 CHAP 2 INSTALLATION ......................2 ........................2 NPACKING ........................2 OSITIONING ....................3 LECTRICAL CONNECTION ...................... 3 LUMBING CONNECTION ..................4 ONNECTION TO THE DRAIN LINE CHAP 3 RISKS AND IMPORTANT WARNINGS ............... 4 CHAP 4 USING YOUR APPLIANCE ..................
- Page 3 INSTRUCTION MANUAL FOR DISHWASHERS Chap 1 PREFACE Failure to follow the instructions provided in the attached documentation may jeopardize safety of the appliance and immediately cancel the warranty. The warnings contained in this manual provide important information regarding safety during the various installation, operation and maintenance stages. Carefully store all documentation near the appliance;...
- Page 4 INSTRUCTION MANUAL FOR DISHWASHERS 2.3 Electrical connection • There must be an omnipolar type of main switch that disconnects all contacts, including the neutral, with a distance of at least 3 mm between the open contacts and with safety circuit breaker tripping or connected with fuses, to be sized or calibrated in conformity with the power indicated on the machine’s data plate.
- Page 5 INSTRUCTION MANUAL FOR DISHWASHERS 2.5 Connection to the drain line • The drain line must be made up of a free water trap of a size proportionate to the delivery of the drain pipe supplied with the machine. The pipe must be able to reach the water trap without being pulled, squeezed, bent, crushed, pressed or forced by anything.
- Page 6 INSTRUCTION MANUAL FOR DISHWASHERS Chap 4 USING YOUR APPLIANCE 4.1 Symbols used Push the button corresponding Push button to one of the symbols shown. corresponding to one of the related warning light symbols shown. illuminates. warning light warning light corresponding to one of the corresponding to one of the symbols shown lights up.
- Page 7 INSTRUCTION MANUAL FOR DISHWASHERS For versions with rotating basket: • If possible, run the cycle only with the basket full, evenly distributing the dishes. • Place the lightest dishes near the middle of the rack, and the heaviest ones near the outside. •...
- Page 8 INSTRUCTION MANUAL FOR DISHWASHERS 4.6 Discharging the Appliance 4.6.1 Models without discharging pump 1. Turn off the appliance as described in the “Turning off the Appliance” paragraph, above. 2. Remove the overflow cap: wait until the tank is completely empty. 4.6.2 Models with discharging pump 1.
- Page 9 INSTRUCTION MANUAL FOR DISHWASHERS • Make sure the overflow cap has been removed. • Open the salt dispenser inside the tank. • Pour approx. 250g of regenerating salt (cooking salt with no additives and grains of 1-2 mm in diameter). •...
- Page 10 INSTRUCTION MANUAL FOR DISHWASHERS • To clean the steel tank, do not use abrasive detergents or objects; instead, use a lightly soaped damp cloth. • Do not use pressurised water jets as these may damage the electrical system. 5.3 Weekly Maintenance •...
- Page 11 INSTRUCTION MANUAL FOR DISHWASHERS 5.4 Annual Maintenance Have your appliance carefully inspected by an authorised technician, and in particular: • Remove residues from the bottom of the tank. • Remove and deep clean wash arms and diffusers. • Thoroughly clean the weir inserted in the lower wash arm shaft and the water exit area. •...
- Page 12 INSTRUCTION MANUAL FOR DISHWASHERS insufficient amount of rinse agent. • To obtain optimum results, use only rinse agents with a manufacturer’s suggested dosage of less than 1.5 gr. /litre. • 7.9 cm of pipe = 1 ml. of product (= 1 gr. of product with a density of 1 kg/dm ).
- Page 13 INSTRUCTION MANUAL FOR DISHWASHERS Chap 7 DEINSTALLATION Only qualified and authorised technical personnel can perform deinstallation. • Turn off the power to the machine with the external main switch. • Shut off the external water supply tap. • Completely disconnect the machine from the electric and water supply networks. •...
