Installation Instructions
RF5910
®
RF5910: EXTERNAL ANTENNA
*
Faceplate options accommodate
various keeper and latchbolt
actions. For more detail, contact
HES tech support
at 800-626-7590
HID is a registered trademark of HID Corporation.
Product
Description
Dimensions
Orientation
Compatibility
Access Control Systems
Proximity Cards
Frequency
Indicators
Supervision
Applications
Frames
Trim Enhancer
Locks
Latchbolts Released*
Environment
Temperature
Humidity
Electrical
Reader Module
Operating Voltage
Operating Current
Electric Strike Module
Operating Voltage
Operating Current
Cable detail
Reader Module
Distance to Host
Recommended Type
Electric Strike Module
Distance to Power
Recommended Type
Certifications
Compliance
Security
Warranty
HES, Inc.
22630 N. 17th Ave.
Phoenix, AZ 85027
800-626-7590
Electric Strike and Proximity Card Reader with
Antenna Module Mounted Separately in Frame
See pages 5-7
Non handed
Open Architecture
Interfaces with Wiegand Protocol Systems
Supports HID 26 39 Bit Formats
Supports HID 125 kHz Credentials
Red/Green LED and Buzzer
Door Position Switch and Latchbolt Monitor
Steel, Aluminum, Wood
Included
Cylindrical
Accomodates 1/2"-5/8" latchbolts
(5/8" with 1/8" door gap)
Suitable for Exterior Doors
-32˚ F to 150˚ F (-35˚ C to 65˚ C)
5 - 95%, Non-condensing
12VDC +/- 20%
125 mA Max. @ 12VDC
12VDC +/- 10%
240 mA max. @ 12VDC
500 ft. Max.
18 22 AWG (Dependent on Distance)
See Page 4
See Page 4
FCC Part 15/IC Class B
ANSI/BHMA 156.31, Grade 1
Lifetime Waranty against defects
in materials and workmanship
1
Stranded and Shielded

Advertisement

loading
Need help?

Need help?

Do you have a question about the HES RF5910 and is the answer not in the manual?

Questions and answers

Summary of Contents for Assa Abloy HES RF5910

  • Page 1 Installation Instructions HES, Inc. 22630 N. 17th Ave. RF5910 ® Phoenix, AZ 85027 800-626-7590 RF5910: EXTERNAL ANTENNA Product Description Electric Strike and Proximity Card Reader with Antenna Module Mounted Separately in Frame Dimensions See pages 5-7 Orientation Non handed Compatibility Open Architecture Access Control Systems Interfaces with Wiegand Protocol Systems...
  • Page 2 Product Components RF5910: EXTERNAL ANTENNA Hybrid Electric Strike Dielectric Grease (for humid applications) Door Position Switch, Press-Fit Magnet 24” Cable (connecting reader/antenna and strike) and 10” Connector Cable (2 Pin) Reader/Antenna Body Pigtail Connectors (8 pin and two 2 pin) #6-32 Reader/Antenna Screws Faceplate (sold separately) Reader/Antenna Cover...
  • Page 3 Installation Directions RF5910 EXTERNAL ANTENNA CAUTION! Before connecting any device at the installation site, verify that there is 12VDC input voltage using a multimeter. Many power supplies and low voltage transformers operate at higher levels than listed. Any input voltage outside the electrical specifications outlined on page 1 may cause severe damage to the unit and will void the warranty.
  • Page 4 Preparation RF5910: EXTERNAL ANTENNA FACEPLATE INSTALLATION VERTICAL ALIGNMENT VERTICAL ADJUSTABILITY Centerline Wire Gauge Diagram WIRE GAUGE DIAGRAM 12VDC @ 240 mA 12VDC @ 240 mA Max. One-way Distance Voltage Drop/100’ Recommended AWG Max. One-way Distance Voltage Drop/100’ Recommended AWG 800’ 0.15 12 Gauge 800’...
  • Page 5 Cutout Templates RF5910: EXTERNAL ANTENNA RF5910 with 591 Faceplate 1-1/4” x 4-7/8” Square Corner Faceplate ANSI Metal Jamb Installations Remove additional material as 1-1/4" [32] needed to provide clearance for hybrid electric strike and wires 4-7/8" [124] 1-5/16” [33] 4-1/8" [105] 5/8”...
  • Page 6 Cutout Templates RF5910: EXTERNAL ANTENNA RF5910 with 592 Faceplate 1-7/16” x 7-15/16” Radius Corner Faceplate Aluminum and Wood Jamb Installations Remove additional material as 1-7/16" [36.5] needed to provide clearance for hybrid electric strike and wires 1 - 5/16" [33] 5/8”...
  • Page 7 Cutout Templates RF5910: EXTERNAL ANTENNA RF5910 with 595 Faceplate 1-3/8” x 9” Radius Corner Faceplate Aluminum or Wood Jamb Installations Remove additional material as needed to provide clearance for 1-3/8" [35] hybrid electric strike and wires 9" [228.4] 1 - 5/16” [33] 5/8”...
  • Page 8 Fail Safe Conversion RF5910: EXTERNAL ANTENNA Fail Safe Remove Reader Module Finish a. In order to change the mode of operation from fail secure e. Replace the reader module and tighten the two (standard) to fail safe, first detach the reader module by screws to hold it in place.
