Alemlube AA402-240V Owner Technical Manual

Description
The AA402-240V 4.0t electro-hydraulic 2-Post Hoist offers high quality & reliable performance at an affordable
price. The AA402-240V 2-Post Hoist is supplied standard with convenient 240V power making ideal for the DIY
home mechanic, car enthusiast and even domestic workshops— combining unbeatable value with quick and easy
installation. Dual hydraulic chain drive cylinders manufactured to a high standard make for very smooth lifting.
Large diameter lifting pads comfortably accommodate both large and small vehicles together with a maximum lifting
height of 2,000mm and minimum lowered height of 110mm. Quality components throughout, compliant with Australian
standards and manufactured to European CE Standards.
Product Specifications, Features and Benefits
•
Standard height clearance of 3,950mm with overall height of 4,140mm
•
High lifting capacity of 4,000kg
•
Fast lifting time of 60 seconds
•
Fast lowering time between
18 to 40 seconds
•
Asymmetric lift arm design incorporating
2 and 3 stage arms with automatic
engaging safety arm locks
•
Large diameter screw adjustable
lifting pads comfortably accommodate
large & small vehicles
•
100 mm 4WD Pad Extension included
•
Maximum lifting height of 2,000mm
•
Minimum lowered height of 110mm
•
Dual hydraulic chain drive cylinders
•
Standard economical 240 volt power pack
•
Single point manual lock release
•
Top limit switch with safety bar prevents
damaging a vehicle by raising it too high
•
Distance between columns: 2,880mm
•
Aluminium motor for improved cooling
capacity during high work demands
•
Motor size 2,850rpm/min, 2.2 kw,
pressure is 19-20 mpa
•
Quality components throughout
•
Compliant with Australian Standards
•
Manufactured to stringent European
CE Standards
•
Total weight 690kg
•
Noise Level. ≤70dB
NSW/ACT QLD/PNG
TEL: (02) 9677 1555 TEL: (07) 3204 9166
FAX: (02) 9675 1155 FAX: (07) 3204 1224
OWNER'S TECHNICAL MANUAL
Electro-Hydraulic Two-Post Lift
VIC/TAS
TEL: (03) 8787 8288
FAX: (03) 8787 8266
Visit our website at www.alemlube.com.au
WA SA/NT
TEL: (08) 9302 4199 TEL: (08) 8241 7111
FAX: (08) 9303 2095 FAX: (08) 8241 7011
or www.alemlube.co.nz
AA402
240V
October 2019
NZ
TEL: (09) 447 1007
FAX: (09) 447 1008
1
